2ADR3U5103G MOBILE PHONE

user manual Model name:U510 Brand name: Unnecto ™ Drone X User Manual 1 Contents Safety Precautions ............................................................................................................................. 2 Overview ........................................................................................................................................... 3 Installing and Removal of the SIM Card ............................................................................................... 3 Installing and Removal of the Micro SD Card ....................................................................................... 3 Battery Use ........................................................................................................................................ 4 Battery Charging ................................................................................................................................ 4 Starting your device for the first time ................................................................................................. 4 Dialing Calls ....................................................................................................................................... 4 SIM Management .............................................................................................................................. 4 Mobile Networks ............................................................................................................................... 4 Wireless Update................................................................................................................................. 4 Play Store .......................................................................................................................................... 4 FCC .................................................................................................................................................... 5 Specifications of Battery and Charger Battery: Li-ion 3.7 V∣1100 mA Max Charging Voltage: 4.2 V Charger: Input: 100-240 VAC∣50/60 Hz ∣150 mA Output: DC 5.0 V∣700 mA Unnecto ™ Drone X User Manual 2 Safety Precautions Read these simple guidelines. Breaking the rules may be dangerous or illegal. Further detailed information is given in this manual. ROAD SAFETY Do not use the phone while you are driving. Park the vehicle before using your phone. SWITCH OFF IN AIRCRAFT Mobile device may cause harmful interference so turn off your mobile device before boarding an airplane. SWITCH OFF IN HOSPITALS Follow any restrictions or rules. Switch off the phone near medical equipment. SWITCH OFF WHEN REFUELING Switch off the phone at a refueling point or any fuel or chemicals places. SWITCH OFF NEAR BLASTING POINT Don’t use the phone where blasting is in progress. Observe restrictions, and follow any regulations or rules. INTERFERENCE All wireless phones may be susceptible to interference, which could affect the performance. USE NORMALLY Use in the normal position explained in the product documentation. Don’t touch the antenna unnecessarily. ENHANCEMENTS AND BATTERIES Use only the approved enhancements and batteries. Do not connect incompatible products. EMERGENCY CALLS Turn on your phone and keep it in service areas, dial emergency phone numbers and then press send key to make a call. KEEP AWAY FROM CHILDREN Keep your phone and its accessories away from children. Unnecto ™ Drone X User Manual 3 1. Overview 1 - Front Screen 7 - Receiver 2 - Back Cover 8 - Touch Panel 3 - Volume Keys 9 - Capacitive Buttons 4 - Micro USB Port 10 - Back Camera 5 - Front Camera 11 - Flash Light 6 - Earphone Jack 12 - Battery Cover 13 - Power Key 2. Installing and Removal of the SIM Card  Switch off the phone and remove the battery.  Insert the SIM Card into the designated SIM 1 or SIM 2 slot.  To remove the SIM Card; turn off the phone; remove the battery; then remove the SIM Card from the SIM Card slot. 3. Installing and Removal of the Micro SD Card  Turn off phone before inserting or removing the Micro SD Card.  To insert, slide the Micro SD Card into the Micro SD Card slot (Micro SD Card facing up), located inside the back of the phone.  To remove, pull the Micro SD Card out of the slot. Unnecto ™ Drone X User Manual 4 4. Battery Use - Installation and Removal of the Battery  Turn off the phone before removing the battery.  Remove the back cover to access the battery.  Place the battery into the phone; aligning the battery pins to the phone’s pins.  To remove the battery, lift up the crease on the corner of the phone. 5. Battery Charging  Plug the provided charger into a standard wall outlet.  Plug the Micro USB charger into the USB port of the phone.  When the phone is fully charged; unplug the charger from the standard wall outlet and from the phone.  If the phone automatically powers off or the battery indictor is low; then you should immediately charge the phone. 6. Starting your device for the first time  Make sure one or two SIM cards are inserted before powering on the phone.  Make sure the battery is charged for at least 30 minutes before the phone is powered on.  Create or sign in an existing Google account for access to the Android features. 7. Dialing Calls  Press the Phone Icon on the phone.  Input the phone number; press the dial key to make the call.  Default call setting is on “Always ask”. For outgoing calls, a prompt will ask you to select SIM 1 or SIM 2. The default can be changed in the SIM Management Settings. 8. SIM Management  SIM Management is located in Settings.  You are able to manage SIM 1 and/or SIM 2 Call, Data, and Roaming preferences. 9. Mobile Networks  Mobile Networks are located in Settings-> More...-> Mobile Network  This setting allows you to select the preferred SIM Card for the 3G Data connection. 10. Wireless Update  Wireless Updates are located in settings-> About Phone ->Wireless Update.  If available, this wi…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2Rev 5.0 UNNECTO HOLDING LIMITED (Current Date) 2014.12.18 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, UNNECTO HOLDING LIMITED (client’s company name) hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Product description, model name): Product description: 3G MOBILE PHONE model name: U510 FCC ID: 2ADR3U510 Sincerely, Client’s signature : vita Li Client’s name / title: manager Applicant company：UNNECTO HOLDING LIMITED address： ROOM 1501(445),15/F., SPA CENTRE,53-55 LOCKHART ROAD,WANCHAI,HONGKONG

SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 3.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (current) 2.0 3.0 Jan-31-2012 SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 3.0 UNNECTO HOLDING LIMITED 2014.12.18 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2ADR3U510 We hereby request confidential treatment of information accompanying this application as outlined below: - e.g. Block Diagram - e.g. Schematics - e.g. Operational Description - e.g. Tune up Procedure - e.g. Part List The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : vita Li Client’s name / title : manager Applicant company：UNNECTO HOLDING LIMITED address： ROOM 1501(445),15/F., SPA CENTRE,53-55 LOCKHART ROAD,WANCHAI,HONGKONG

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6 Photo 7 Photo 8 Photo 9 Photo 10 Photo 11

Label 3G MOBILE PHONE Model name: U510 Brand name: unnecto ™ FCC ID: 2ADR3U510 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. label

BT/WIFI/GPS Antenna WCDMA/GSM Antenna 14.4CM 1.2CM 1.4C 0.86CM 3.2CM

APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Photo 1 Photo 2 BT/WIFE/GPS ANTENNA GSM/WCDMA ANTENNA Photo 3 Photo 4 Photo 5

Ref : ACR.262.1.14.SATU.A SHENZHEN STS TEST SERVICES CO., LTD. 1/F, BUILDING 2, ZHUOKE SCIENCE PARK, CHONGQING ROAD FUYONG, BAO’ AN DISTRICT, SHENZHEN,CHINA SATIMO COMOSAR DOSIMETRIC E-FIELD PROBE SERIAL NO.: SN 17/14 EP221 Calibrated at SATIMO US 2105 Barrett Park Dr. - Kennesaw, GA 30144 09/01/2014 Summary: This document presents the method and results from an accredited COMOSAR Dosimetric E-Field Probe calibration performed in SATIMO USA using the CALISAR / CALIBAIR test bench, for use with a SATIMO COMOSAR system only. All calibration results are traceable to national metrology institutions. COMOSAR E-Field Probe Calibration Report COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 2/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. Name Function Date Signature Prepared by : Jérôme LUC Product Manager 9/19/2014 Checked by : Jérôme LUC Product Manager 9/19/2014 Approved by : Kim RUTKOWSKI Quality Manager 9/19/2014 Customer Name Distribution : Shenzhen STS Test Services Co., Ltd. Issue Date Modifications A 9/19/2014 Initial release COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 3/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. TABLE OF CONTENTS 1 Device Under Test ..................................................................................................... 4 2 Product Description ................................................................................................... 4 2.1 General Information _______________________________________________________ 4 3 Measurement Method ................................................................................................ 4 3.1 Linearity ________________________________________________________________ 4 3.2 Sensitivity _______________________________________________________________ 5 3.3 Lower Detection Limit _____________________________________________________ 5 3.4 Isotropy _________________________________________________________________ 5 3.5 Boundary Effect __________________________________________________________ 5 4 Measurement Uncertainty .......................................................................................... 5 5 Calibration Measurement Results .............................................................................. 6 5.1 Sensitivity in air __________________________________________________________ 6 5.2 Linearity ________________________________________________________________ 7 5.3 Sensitivity in liquid ________________________________________________________ 7 5.4 Isotropy _________________________________________________________________ 8 6 List of Equipment ...................................................................................................... 9 COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 4/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 1 DEVICE UNDER TEST Device Under Test Device Type COMOSAR DOSIMETRIC E FIELD PROBE Manufacturer Satimo Model SSE5 Serial Number SN 17/14 EP221 Product Condition (new / used) New Frequency Range of Probe 0.4 GHz- 6 GHz Resistance of Three Dipoles at Connector Dipole 1: R1=0.179 M Dipole 2: R2=0.167 M Dipole 3: R3=0.178 M A yearly calibration interval is recommended. 2 PRODUCT DESCRIPTION 2.1 GENERAL INFORMATION Satimo’s COMOSAR E field Probes are built in accordance to the IEEE 1528, OET 65 Bulletin C and CEI/IEC 62209 standards. Figure 1 – Satimo COMOSAR Dosimetric E field Dipole Probe Length 330 mm Length of Individual Dipoles 4.5 mm Maximum external diameter 8 mm Probe Tip External Diameter 5 mm Distance between dipoles / probe extremity 2.7 mm 3 MEASUREMENT METHOD The IEEE 1528, OET 65 Bulletin C, CENELEC EN50361 and CEI/IEC 62209 standards provide recommended practices for the probe calibrations, including the performance characteristics of interest and methods by which to assess their affect. All calibrations / measurements performed meet the fore mentioned standards. 3.1 LINEARITY The evaluation of the linearity was done in free space using the waveguide, performing a power sweep to cover the SAR range 0.01W/kg to 100W/kg. COMOSAR E-FIELD PROBE CALIBRATION REPORT Ref: ACR.262.1.14.SATU.A Page: 5/9 This document shall not be reproduced, except in full or in part, without the written approval of SATIMO. The information contained herein is to be used only for the purpose for which it is submitted and is not to be released in whole or part without written approval of SATIMO. 3.2 SENSITIVITY The sensitivity factors of the three dipoles were determined using a two step calibration method (air and tissue simulating liquid) using waveguides as outlined in the standards. 3.3 LOWER DETECTION LIMIT The lower detection limit was assessed using the same measurement set up as used for the linearity measurement. The required lower detection limit is 10 mW/kg. 3.4 ISOTROPY The axial isotropy was evaluated by exposing the probe to a reference wave from a standard dipole with the dipole mounted under the flat phantom in the test configuration suggested for system validations and checks. The probe was rotated along its main axis from 0 - 360 degrees in 15 degree steps. The hemispherical isotropy is determined by inserting the probe in a thin plastic box filled with tissue-equivalent liquid,…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC SAR TEST REPORT Report No: STS1412031H01 Issued for UNNECTO HOLDING LIMITED ROOM 1501(445),15F.,SPA CENTRE,53-55LOCKHART ROAD,WANCHAI,HONGKONG Product Name: 3G MOBILE PHONE Brand Name: UNNECTO ™ Model No.: U510 Series Model: N/A FCC ID: 2ADR3U510 Test Standard: ANSI/IEEE Std. C95.1 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 Max. SAR (1g): Head:0.333 W/kg Body:0.724 W/kg S T L A B S Page 2 of 97 Report No.: STS1412031H01 Test Report Certification Applicant’s name ................. : UNNECTO HOLDING LIMITED Address ................................. : ROOM 1501(445),15F.,SPA CENTRE,53-55LOCKHARTROAD, WANCHAI,HONGKONG Manufacture's Name ............ : TEM MOBILE LIMITED Address ................................. : No 1708,Cangsong building,Tairan 6 Road,Futian Shenzhen,China Product description Product name ........................ : 3G MOBILE PHONE Trademark ............................ : UNNECTO ™ Model and/or type reference : U510 Serial Model： N/A Standards ............................. : ANSI/IEEE Std. C95.1-1992 FCC 47 CFR Part 2 ( 2.1093) IEEE 1528: 2013 The device was tested by Shenzhen STS Test Services Co., Ltd. in accordance with the measurement methods and procedures specified in KDB 865664 The test results in this report apply only to the tested sample of the stated device/equipment. Other similar device/equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Date of Test ............................................ : Date (s) of performance of tests ............. : 17 Dec.. 2014 Date of Issue ........................................... : 19 Dec.. 2014 Test Result ............................................... : Pass Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 97 Report No.: STS1412031H01 TABLE OF CONTENS 1. General Information 4 1.1 EUT Description 4 1.2 Test Environment 5 1.3 Test Facility 5 2. Test Standards And Limits 6 3. SAR Measurement System 7 3.1 Definition Of Specific Absorption Rate (SAR) 7 3.2 SAR System 7 3.2.1 Probe 8 3.2.2 Phantom 9 3.2.3 Device Holder 9 4. Tissue Simulating Liquids 10 4.1 Simulating Liquids Parameter Check 10 5. SAR System Validation 11 5.1 Validation System 11 5.2 Validation Result 11 6. SAR Evaluation Procedures 12 7. EUT Antenna Location Sketch 13 7.1 SAR TEST EXCLUSION CONSIDER TABLE 14 8. EUT Test Position 16 8.1 Define Two Imaginary Lines On The Handset 16 8.2 Hotspot mode exposure position condition 17 9. Measurement Uncertainty 18 10. Conducted Power Measurement 20 11. EUT And Test Setup Photo 24 11.1 EUT Photo 24 11.2 Setup Photo 27 12. SAR Result Summary 32 12.1 Head SAR 32 12.2 Body SAR And Hotspot 33 13. Equipment List 36 Appendix A. System Validation Plots 37 Appendix B. SAR Test Plots 49 Appendix C. Probe Calibration And Dipole Calibration Report 97 Page 4 of 97 Report No.: STS1412031H01 1. General Information 1.1 EUT Description Equipment 3G MOBILE PHONE Brand Name UNNECTO ™ Model No. U510 Serial Model N/A FCC ID 2ADR3U510 Model Difference N/A Adapter Input: AC100-240V, 150m A, 50/60 Hz Output: DC 5V, 700mA Battery Rated Voltage: 3.7V Charge Limit: 4.2V Capacity: 1100mAh Hardware Version SP7715GA_V1.0.0 Software Version fs007_qy_u510_ga_v100_20141210_101055_userdebug Frequency Range GSM 850: 824.2 ~ 848.8 MHz PCS1900: 1850.2 ~ 1909.8 MHz WCDMA II: 1852.4~1907.6 MHz WCDMA V: 826.4~846.6 MHz WLAN 802.11 b/g/n(HT20):2412-2462 MHz Bluetooth：2402~2480MHz Transmit Power(MAX): GSM 850: 30.36dBm GSM 1900: 28.12dBm WCDMA II: 21.76dBm WCDMA V: 22.89dBm 802.11b: 12.58dBm 802.11g:10.67dBm 802.11 n(HT20): 10.25dBm Bluetooth:9.448dBm Max. Reported SAR(1g): Head: GSM 850: 0.298 W/kg GSM 1900: 0.279 W/kg WCDMA II: 0.333 W/kg WCDMA V: 0.198 W/kg WIFI: 0.288W/kg Body: GSM 850: 0.724W/kg GSM 1900: 0.396 W/kg WCDMA II: 0.477 W/kg WCDMA V: 0.464 W/kg WIFI: 0.174W/kg Hotspot: GSM 850: 0.603W/kg GSM 1900: 0.280 W/kg WCDMA II: 0.477W/kg WCDMA V: 0.464 W/kg WIFI: 0.174W/kg Operating Mode: GSM: GSM Voice/GPRS/EGPRS Class 12; WCDMA: RMC/HSDPA/HSUPA Release 6; WLAN: 802.11 b/g/n; Bluetooth: V2.1 + EDR (GFSK +π/4DQPSK+8DPSK) Antenna Specification: GSM/WCDMA: PIFA Antenna BT/WIFI: PIFA Antenna SIM Card Support dual-SIM, dual standby, the multiple SIM card with two lines cannot transmitting at the same time Hotspot Mode: Support DTM Mode: Not Support Page 5 of 97 Report No.: STS1412031H01 1.2 Test Environment Ambient conditions in the SAR laboratory: Items Required Actual Temperature (°C) 18-25 22~23 Humidity (%RH) 30-70 55~65 1.3 Test Facility Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China FCC Registration No.: 842334;IC Registration No.: 12108A-1 Page 6 of 97 Report No.: STS1412031H01 2. Test Standards And Limits No. Identity Document Title 1 47 CFR Part 2 Frequency Allocations and Radio Treaty Matters; General Rules and Regulations 2 ANSI/IEEE Std. C95.1-1992 IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz 3 IEEE Std. 1528-2013 Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques 4 FCC KDB 447498 D01 v05r02 Mobile and Portable Device RF Exposure Procedures and Equipment Authorization Policies 5 FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 6 FCC KDB 865664 D01 v01r03 SAR Measurement 100 MHz to 6 GHz 7 FCC KDB 941225 D01 SAR Measureme…

Text truncated - open the document above for the full version.

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, All Test Data Presented in this report is only applicable to presented Test sample. Shenzhen STS Test Services Co., Ltd. 1/F, Building B, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] FCC TEST REPORT Product Name: 3G MOBILE PHONE Brand Name: unnecto ™ Model No.: U510 Series Model: N/A FCC ID:2ADR3U510 Test Standard: FCC Part 15.247 Report No: STS1412031F03 Issued for UNNECTO HOLDING LIMITED ROOM 1501(445),15/F.,SPA CENTRE,53-55 LOCKHART ROAD,WANCHAI,HONGKONG S T L A B S Page 2 of 67 Report No.: STS1412031F03 TEST RESULT CERTIFICATION Applicant’s name .................. : UNNECTO HOLDING LIMITED Address .................................. : ROOM 1501(445),15/F.,SPA CENTRE,53-55 LOCKHART ROAD,WANCHAI,HONGKONG Manufacture's Name ............ : TEM MOBILE LIMITED Address .................................. : No 1708,Cangsong Building,Tairan 6 Road,Futian Shenzhen,China Product description Product name ........................... : 3G MOBILE PHONE Model and/or type reference . : U510 Serial Model .............................. : N/A Standards .............................. : FCC Part15.247 Test procedure ............................... : ANSI C63.10-2009 This device described above has been tested by STS, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document may be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date (s) of performance of tests ............. : 16 Dec. 2014 ~19 Dec. 2014 Date of Issue ........................................... : 19 Dec. 2014 Test Result .............................................. : Pass Testing Engineer : (Tony Liu) Technical Manager : (Vita Li) Authorized Signatory : (Bovey Yang) Page 3 of 67 Report No.: STS1412031F03 Table of Contents Page 1. SUMMARY OF TEST RESULTS 5 1.1 TEST FACILITY 5 1.2 MEASUREMENT UNCERTAINTY 5 2. GENERAL INFORMATION 6 2.1 GENERAL DESCRIPTION OF EUT 6 2.2 DESCRIPTION OF TEST MODES 8 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TEST 9 2.4 DESCRIPTION OF SUPPORT UNITS 9 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 10 3. EMC EMISSION TEST 11 3.1 CONDUCTED EMISSION MEASUREMENT 11 3.1.1 POWER LINE CONDUCTED EMISSION LIMITS 11 3.1.2 TEST RESULTS 12 3.2 RADIATED EMISSION MEASUREMENT 14 3.2.1 RADIATED EMISSION LIMITS 14 3.2.2 TEST PROCEDURE 15 3.2.3 TEST SETUP 16 3.2.4 EUT OPERATING CONDITIONS 17 3.2.5 TEST RESULT 18 3.2.6 TEST RESULTS (BAND EDGE) 30 4. CONDUCTED SPURIOUS EMISSIONS 36 4.1 APPLIED PROCEDURES / LIMIT 36 4.2 TEST PROCEDURE 36 4.3 DEVIATION FROM STANDARD 36 4.4 TEST SETUP 36 4.5 EUT OPERATION CONDITIONS 36 4.6 TEST RESULTS 37 5. POWER SPECTRAL DENSITY TEST 49 5.1 APPLIED PROCEDURES / LIMIT 49 5.2 TEST PROCEDURE 49 5.3 DEVIATION FROM STANDARD 49 5.4 TEST SETUP 49 5.5 EUT OPERATION CONDITIONS 49 5.6 TEST RESULTS 50 Page 4 of 67 Report No.: STS1412031F03 Table of Contents Page 6. BANDWIDTH TEST 56 6.1 APPLIED PROCEDURES / LIMIT 56 6.2 TEST PROCEDURE 56 6.3 DEVIATION FROM STANDARD 56 6.4 TEST SETUP 56 6.5 EUT OPERATION CONDITIONS 56 6.6 TEST RESULTS 57 7. PEAK OUTPUT POWER TEST 63 7.1 APPLIED PROCEDURES / LIMIT 63 7.2 TEST PROCEDURE 63 7.3 DEVIATION FROM STANDARD 63 7.4 TEST SETUP 63 7.4 EUT OPERATION CONDITIONS 63 7.5 TEST RESULTS 64 8. ANTENNA REQUIREMENT 65 8.1 STANDARD REQUIREMENT 65 8.2 EUT ANTENNA 65 APPENDIX - PHOTOS OF TEST SETUP 66 Page 5 of 67 Report No.: STS1412031F03 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.247) , Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission PASS 15.247 (a)(2) 6dB Bandwidth PASS 15.247 (b) (reference KDB 558074 d05 v02. /9.1.2) Peak Output Power PASS 15.247 (c) Radiated Spurious Emission PASS 15.247 (d) Conducted Spurious Emission PASS 15.247 (e) Power Spectral Density PASS 15.205 Band Edge Emission PASS 15.203 Antenna Requirement PASS NOTE: (1)” N/A” denotes test is not applicable in this Test Report 1.1 TEST FACILITY Shenzhen STS Test Services Co., Ltd. Add. : 1/F, Building 2, Zhuoke Science Park, Chongqing Road, Fuyong, Baoan District, Shenzhen, China. FCC Registration No.: 842334; IC Registration No.: 12108A-1 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U，where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2，providing a level of confidence of approximately 95 %。 No. Item Uncertainty 1 Conducted Emission Test ±1.38dB 2 RF power,conducted ±0.16dB 3 Spurious emissions,conducted ±0.21dB 4 All emissions,radiated(<1G) ±4.68dB 5 All emissions,radiated(>1G) ±4.89dB 6 Temperature ±0.5°C 7 Humidity ±2% Page 6 of 67 Report No.: STS1412031F03 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF EUT Equipment 3G MOBILE PHONE Trade Name unnecto ™ Model Name U510 Serial Model N/A Model Difference N/A Product Description The EUT is a 3G MOBILE PHONE Operation Frequency: 802.11b/g/n 20: 2412~2462 MHz Modulation Type: CCK/OFDM/DBPSK Bit Rate of Transmitter 802.11b:11/5.5/2/1 Mbps 802.11g:54/48/36/24/18/12/9/6Mbps 802.11n(20MHz):300/150/144.44/130/ 117/115.56/104/86.67/78/52/6.5Mbps Number Of Channel 802.11b/g/n20: 11CH Antenna Designation: Please see Note 3. Antenna Gain (dBi) 0.5 dbi Channel List Please refer to the Note 2. Ratings DC 3.7V from battery Adapter Power supply and ADP（rating）： Input:100-240V AC,50/60Hz 0.15A Output:5.0V,700mA Battery Rated Voltage: 3.7V Charge Limit: 4.2V capacity :1100mAh Hardware version number SP7715GA_V1.0.0 Software versioning number fs007_qy_u510_ga_v100_20141210…

Text truncated - open the document above for the full version.

DSS&DTSSetup photo DSS&DTS conduction DSS&DTSradiation L DSS&DTSradiation H DSS&DTS RF conduction test photos DSS&DTS High and low temperature test photos
