Brydge 11.0 Pro+ User Manual Mode d’emploi Connected Settings On 11.0 Pro+ IMPORTANT Remove non-Brydge screen protectors before attaching your Brydge keyboard. This will ensure a perfect fit and eliminate unnecessary pressure to your screen when inserted into the hinges. TO INSERT: Place your Brydge on a flat surface and set the hinges upright to 90 degrees. Insert your iPad into the hinges with the home button on the right, one side at a time. If your iPad is loose, remove it and gently squeeze the hinges. Repeat this process until your iPad is held firmly. TO REMOVE: Ensure your Brydge is on a flat surface. Place your hand towards the back of the keyboard and pull up, one side at a time. TO TURN ON: Press the power key for one second until the LED flashes green. TO TURN OFF: Press and hold the power key for three seconds until the LED flashes red. NOTE: To conserve battery, your Brydge will enter sleep mode after 20 minutes of non-use. Press any key to turn back on. Your Brydge will enter sleep mode when both devices are closed like a laptop. TO PAIR: Press and hold the Bluetooth key for three seconds until the LED flashes blue. On your iPad, under Settings > Bluetooth select Brydge 11.0 Pro+. When successfully paired, the blue LED will turn off. TO CHECK BATTERY LIFE: In Today View, go to the BATTERIES section to check battery life. If not available, swipe left on your Home Screen to show Today View, scroll to the bottom and click edit. Scroll down to Batteries, and click the green ‘+’ icon to add. NOTE: If battery life is below 15%, backlit key functionality will be disabled to conserve battery. TO CHARGE: Insert the charging cable into the keyboard and plug the other end into a power source. A solid red LED indicates the Brydge is charging. When the keyboard is fully charged, the red LED will turn off. A full charge can take up to three hours. Thank you for purchasing a Brydge product. This product comes with a 1-year limited hardware warranty on the terms and conditions set out in this document and at www.brydge.com/warranty. All Brydge warranties are non-transferrable and are only available to the original end-user of the product. Warranties do not apply to products purchased from online vendors unauthorized to sell Brydge-branded product. If a defect arises during the warranty period, cease using the product and contact Brydge. To obtain warranty service, visit www.brydge.com/support or call +1 (435) 604-0481. Brydge, at its sole discretion and option, will (1) repair the product at no charge using new parts or parts that are equivalent to new in performance and reliability, or (2) replace or exchange the product with a product of equivalent functionality and value. Brydge offers free return shipping on any approved warranty claims. A shipping label will be provided to you if you are within the United States. If you are outside the United States, Brydge will reimburse your return shipping to a maximum of US$15.00 after providing a copy of the shipping receipt. Australia Only: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure. Brydge Technologies LLC | 1912 Sidewinder Dr., Suite 104, Park City, UT 84060 USA HAVE A QUESTION? Visit www.brydge.com/support INSERT/REMOVE POWER PAIR CHARGE KEYBOARD SHORTCUTS WARRANTY Copy Command + C Paste Command + V Cut Command + X Underline Command + U Italic Command + I Home Screen Command + H Switch App Command + Tab Show Dock Command + Option + D Search Command + Space Undo Command + Z Switch Language Ctrl + Shift + Spacebar (Spacebar allows you to toggle through available languages) ENABLE TOUCH GO TO: Settings > Accessibility > Touch > AssistiveTouch and toggle it on. CONFIGURE SETTINGS GO TO: Settings > Accessibility > Touch > AssistiveTouch > Devices (Pointer Devices) > Brydge 11.0 Pro+ (Connected Devices) and adjust the Button shortcuts to the recommmended settings below: SETTING UP THE TRACKPAD Magnetic cover is located in the bottom of the packaging. MAGNETIC COVER For up-to-date settings and video instructions, visit: www.brydge.com/pro-plus-instructions POUR ALLUMER : maintenez la touche marche/arrêt enfoncée pendant une seconde jusqu’à ce que la DEL clignote verte. POUR ÉTEINDRE : maintenez la touche marche/arrêt enfoncée pendant trois secondes jusqu’à ce que la DEL clignote rouge. REMARQUE : pour préserver la charge de la batterie, votre pavé tactile sans fil Brydge entrera en mode veille après 20 minutes d’inactivité. Votre pavé tactile sans fil Brydge entrera en mode veille lorsque les deux appareils sont fermés, comme un ordinateur portable. ALIMENTATION Connected Settings On 11.0 Pro+ POUR JUMELER : maintenez la touche Bluetooth enfoncée pendant 3 secondes jusqu’à ce que la DEL bleue clignote. Sur votre iPad, sous Paramètres > Bluetooth, sélectionnez Brydge 11.0 Pro+. Une fois jumelé avec succès, la DEL s’éteindra. JUMELER ACTIVER L’INTERACTION TACTILE ACCÉDER À : Réglages > Accessibilité > Toucher > AssistiveTouch et activer-le. CONFIGURE SETTINGS ACCÉDER À : Réglages > Accessibilité > Toucher > AssistiveTouch > Appareils > Brydge 11.0 Pro+ (Appareils Connectés) et régler les raccourcis de Bouton aux paramètres recommandés ci-dessous : INSTALLATION DU PAVÉ TACTILE Pour les paramètres et les instructions vidéo à jour, visiter : www.brydge.com/proplustrackpad IMPORTANT Supprimez les protecteurs d’écran non-Brydge avant de connecter votre clavier Brydge. Cela garantira un ajustement parfait et éliminera toute pression inutile sur votre écran lors de son insertion dans les charnières. Placez votre clavier sans fil Brydge sur une surface plane et faites pivoter les charnières à 90°. Insérez votre iPad dans les …
