2ADTG-F750THINKWARE DASH CAM

THINKWARE CORPORATION

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Feb 04, 2015
Application Purpose: Original Equipment
Date of Application: Feb 04, 2015
Equipment Note: THINKWARE DASH CAM
Frequency Range: 2412.00000000 - 2462.00000000
Company: THINKWARE CORPORATION
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

U s e r M a n u a l F750 This Dashboard Camera (dash cam) is a specialized onboard device that continuously records video while the vehicle is in use. Some features may not be available depending on installation, driving conditions, and vehicle type. The video quality might vary for each device as a result of installed firmware. The device DOES NOT guarantee video recording of all accidents as built-in impact sensor may not be activated due to combina- tion of user settings and the level of impact during the collision. ACMA-021DAM101 C o n t e n t s Before Using THINKWARE DASH CAM TM F750 2 FCC Statement 2 Caution 3 Getting Started 1-1. In the Package 5 1-2. Optional Accessories 5 1-3. Product Overview 5 1-4. Inserting a Memory Card 7 1-5. Vehicle Installation 8 Basics 2-1. Turning the Device Power On/Off 10 2-2. Road Safety Warning System 11 2-3. Lane Departure Warning System (LDWS) 12 2-4. Forward Collision Warning System (FCWS) 12 2-5. Recorded Files 13 2-6. Recording Videos While Driving 14 2-7. Recording Videos While Parked (Optional Accessory) 16 2-8. Manual Recording 17 2-9. Audio Recording 18 2-10. Formatting MicroSD Card 18 2-11. Initializing Device Settings 19 2-12. Upgrading Firmware 19 Mobile Application 3-1. Thinkware Dash Cam Mobile Viewer 20 PC Viewer Software 4-1. Thinkware Dash Cam PC Viewer 29 Device Information 5-1. Specifications 34 01 02 03 04 05 2 Before Using THINKWARE DASH CAM TM F750 ⶺ Under the copyright laws, this manual may not be copied, in whole or in part, without the written consent of THINKWARE. ⶺ Every effort has been made to ensure this Guide's accuracy. However, we cannot guarantee the accuracy of the contents in this document as there may be technical errors, omissions, and/or future changes. ⶺ THINKWARE reserves the right to change or modify the product and the content of this manual at any time without prior notice for product improvements. ⶺ Images contained in this user guide are illustrations for instructional purposes only and may differ from the actual product. ⶺ Users do not reserve the right to use the product for purposes other than as specified in this user guide. According to the Personal Information Protection Act and other related regulations, the user/owner may be held liable if the video and/or conversation recorded by the device are distributed without their con- sent. Thus, special attention should be paid in using this product. ⷅ The MicroSD memory card should be tested for errors on a regular basis and as the memory card is a consumable item, it will need to be replaced periodically. ⷅ THINKWARE is NOT responsible for any problems and/or damages that may occur from the use of disin- genuous, modified, or unauthorized parts and accessories. ⷅ The device and the recorded videos are intended for personal use and the recorded videos should be used for reference only. ⷅ The device does NOT guarantee video recording of all accidents as built-in impact sensor may not be activated due to combination of user settings and the level of impact during the collision. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful inter- ference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ⶺReorient or relocate the receiving antenna. ⶺIncrease the separation between the equipment and receiver. ⶺConnect the equipment into an outlet on a circuit different from that to which the receiver is connected. ⶺConsult the dealer or an experienced radio/TV technician for help. FCC CAUTION: Any changes or modifications to the equipment not expressly approved by the party responsi- ble for compliance could void your authority to operate the equipment. FCC ID: 2ADTG-F750 3 Getting Started 01 Information to user : Please be cautioned the changes or modifications not expressly approved by the party responsible for compli- ance could void the user’s authority to operate the equipment. 5IJTEFWJDFDPNQMJFTXJUI*OEVTUSZ$BOBEBhTMJDFODFFYFNQU344T0QFSBUJPOJTTVCKFDUUPUIFGPMMPXJOHUXP DPOEJUJPOT 5IJTEFWJDFNBZOPUDBVTFJOUFSGFSFODFBOE 5IJTEFWJDFNVTUBDDFQUBOZJOUFSGFSFODF JODMVEJOHJOUFSGFSFODFUIBUNBZDBVTFVOEFTJSFEPQFSBUJPOPG UIFEFWJDF This Class B digital apparatus complies with Canadian ICES-003. IC: 12594A-F750 4 Caution Depending on the make and model of your car, the power may be constantly supplied to the dash cam even with the ignition turned off. This may result in vehicle battery discharge. This device is designed to record video while the vehicle is in operation. The quality of the video might be affected by weather conditions and the road environment such as day or night, presence of street lighting, entering/exiting tunnels, and the surrounding temperature. THINKWARE is NOT responsible for the loss of any recorded video during operation. Although designed to withstand high impact of car collision, THINKWARE does NOT guarantee re- cording of accidents where the impact may cause the device to be damaged. Keep the windshield clean for optimal video qual- ity. If a foreign substance (e.g. fing…

Text truncated - open the document above for the full version.

Cover Letter(s)

THINKWARE SYSTEMS CORPORATION 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel. +82-2-589-9356 / Fax. +82-2-589-9600 Date: January 08, 2015 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, Samsung Electronics Co., Ltd., hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project : - Product: THINKWARE DASH CAM - Model name: F750 - FCC ID: 2ADTG-F750 I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). This authorization is valid until further written notice from the applicant. Sincerely Yours, ______________________________________ / Chan U k Heo / Assistant / THINKWARE SYSTEMS CORPORATION /[email protected] /Telecom: +82-02-589-9356 /Fax: +82 -02-589-9600

Cover Letter(s)

THINKWARE SYSTEMS CORPORATION 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel. +82-2-589-9356 / Fax. +82-2-589-9600 FCC Confidentiality Request Letter Date: January 08, 2015 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia MD 21046 Subject: Permanent Confidentiality Request for FCC ID: 2ADTG-F750 We hereby request confidential treatment of information accompanying this application as outlined below: • Block diagram • Schematics • Operation Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely Yours, ______________________________________ / Chan U k Heo / Assistant / THINKWARE SYSTEMS CORPORATION /[email protected] /Telecom: +82-02-589-9356 /Fax: +82-02-589-9600

Cover Letter(s)

THINKWARE SYSTEMS CORPORATION 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel. +82-2-589-9356 / Fax. +82-2-589-9600 Company Letter head Date: January 08, 2015 To: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD FCC ID: 2ADTG-F750 To Whom It May Concern: This letter is to ascertain that THINKWARE SYSTEMS CORPORATION Product F750, 2ADTG- F750, has been the units used for conducting FCC compliance testing, the DoC part will be tested by FCC recognized test lab. If you have any question or concerns, please. contact us. Sincerely Yours, ______________________________________ / Chan U k Heo / Assistant / THINKWARE SYSTEMS CORPORATION /[email protected] /Telecom: +82-02-589-9356 /Fax: +82-02-589-9600

External Photos

http://www.emc2000.co.kr External photos of EUT EMC compliance Ltd. Page: 1 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr EMC compliance Ltd. Page: 2 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr EMC compliance Ltd. Page: 3 of 3 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

ID Label/Location Info

http://www.emc2000.co.kr FCC TEST REPORT -Basic Model EMC compliance Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 44 3-390, Kor ea 82-31 -336-9919 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced, except in full, Without the written approval.

Internal Photos

http://www.emc2000.co.kr Internal photos of EUT EMC compliance Ltd. Page: 1 of 4 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr EMC compliance Ltd. Page: 2 of 4 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr EMC compliance Ltd. Page: 3 of 4 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr Antenna EMC compliance Ltd. Page: 4 of 4 65, Sinwon-ro, Yeongtong-gu, Suwon- si , Gyeonggi-do, 443-390, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

RF Exposure Info

http://www.emc2000.co.kr * RF Exposure 1. Regulation According to §15.247(i), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission's guidelines. See § 1.1307(b)(1) of this Chapter. Limits for Maximum Permissive Exposure: RF exposure is calculated. Frequency Range Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Averaging Time [minute] Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *(100) 30 1.34 ~ 30 824/f 2.19/f *(180/f 2 ) 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 15 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01 () SPGRRPGS ππ4 4 2 =⇒= S = power density [㎽ /㎠] P = Power input to antenna [㎽] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [㎝] EUT: Maximum peak output power = 63.10 [㎽] (18.00 ㏈m) Antenna gain = 1.10 [㎽] (0.41 ㏈i) 100 ㎽, at 20 cm from an antenna 6 [㏈i] S = PG/4πR² = 100 × 3.98 / (4 × π × 400) = 0.079 18 [㎽/㎠] < 1.0 [㎽/㎠] 63.10 ㎽, at 20 cm from an antenna 0.41 [㏈i] S = PG/4πR² = 0.013 80 [㎽/㎠] < 1.0 [㎽/㎠] Target power table Mode Target power [㏈m] Allowed tolerant [㏈] Max tune up power [㏈m] Measured Average power [㏈m] 802.11b 16 ±2.0 18 16.16 802.11g 14 ±2.0 16 14.02 802.11n HT20 13 ±2.0 15 13.21 802.11n HT40 13 ±1.5 14.5 12.99 EMC compliance Ltd. Page: 1 of 2 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82-70-5008-1021(Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr 2. RF Exposure Compliance Issue The information should be included in the user’s manual: This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. A minimum separation distance of 20 cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. 3. Calculation Result of RF Exposure * 802.11b Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 412 1.10 17.95 62.37 0.013 64 Middle 2 437 1.10 18.06 63.97 0.013 99 Highest 2 462 1.10 18.86 76.91 0.016 82 * 802.11g Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 412 1.10 22.86 193.20 0.042 24 Middle 2 437 1.10 23.87 243.78 0.053 30 Highest 2 462 1.10 23.87 243.78 0.053 30 * 802.11n HT20 Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 412 1.10 21.36 136.77 0.029 90 Middle 2 437 1.10 22.26 168.27 0.036 79 Highest 2 462 1.10 23.07 202.77 0.044 33 * 802.11n HT40 Channel Frequency Ant Gain power power Power Density at 20 ㎝ [㎒] [㏈m] [㎽] [㎽/㎠] Lowest 2 422 1.10 23.37 217.27 0.047 50 Middle 2 437 1.10 23.97 249.46 0.054 54 Highest 2 452 1.10 24.47 279.90 0.061 20 EMC compliance Ltd. Page: 2 of 2 480-5 Shin-dong, Yeongtong-gu, Suwon-city, Gyunggi-do, 443-390, Korea 82-70-5008-1021(Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

Test Report

http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0204 [ Contents ] 1. Client information ............................................................................................................................................. 3 2. Laboratory information .................................................................................................................................... 4 3. Description of E.U.T. ......................................................................................................................................... 5 3.1 Basic description ........................................................................................................................................... 5 3.2 General description ....................................................................................................................................... 5 3.3 Test frequency ............................................................................................................................................... 6 3.4 Test Voltage................................................................................................................................................... 6 4. Summary of test results ..................................................................................................................................... 7 4.1 Standards & results ....................................................................................................................................... 7 5. Test results .......................................................................................................................................................... 8 5.1 Antenna Requirement ................................................................................................................................... 8 5.2 Maximum Peak Output Power ...................................................................................................................... 9 5.3 Peak Power Spectral Density ...................................................................................................................... 11 5.4 6 dB Bandwidth(DTS Channel Bandwidth) ............................................................................................... 19 5.5 Spurious Emission, Band Edge and Restricted bands ................................................................................. 33 6. Test equipment used for test ........................................................................................................................... 60 EMC compliance Ltd. Page: 2 of 60 80-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0204 1. Client information Applicant: THINKWARE SYSTEMS CORPORATION Address: 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Telephone number: +82-02-589-9356 Facsimile number: +82-02-589-9600 Contact person: Heo Chan Wook / [email protected] Manufacturer: THINKWARE SYSTEMS CORPORATION Address: 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea EMC compliance Ltd. Page: 3 of 60 80-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0204 2. Laboratory information Address EMC compliance Ltd. 80-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea Telephone Number: 82-70-5008-1021 Facsimile Number: 82-505-299-8311 Certificate KOLAS No.: 231 FCC Site Designation No.: KR0040 FCC Site Registration No.: 687132 VCCI Site Registration No.: R-3327, G-198, C-3706, T-1849 IC Site Registration No.:8035A-2 SITE MAP EMC Compliance Ltd. Suwon city EMC compliance Ltd. Page: 4 of 60 80-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0204 3. Description of E.U.T. 3.1 Basic description Applicant: THINKWARE SYSTEMS CORPORATION Address of Applicant 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Manufacturer THINKWARE SYSTEMS CORPORATION Address of Manufacturer 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Type of equipment THINKWARE DASH CAM Basic Model F750 Serial number N/A 3.2 General description Frequency Range 2 412 ㎒ ~ 2 462 ㎒ (802.11b/g/n_HT20) 2 422 ㎒ ~ 2 452 ㎒ (802.11n_HT40) Type of Modulation IEEE 802.11b/g/n_HT20, HT40 Number of Channels 79 channels Type of Antenna Chip Antenna Antenna Gain 0.41 ㏈i Transmit Power 24.47 ㏈m Power supply DC 12 ~ 24 V* Product SW/HW version H/W: 3.0 S/W: 0.00.13 Radio SW/HW version H/W: 1.2 Ver S/W: Driver 4.1.8 Test SW Version Using the lisence open SW ‘Tera Term’ and adjusting with ‘Command’. RF power setting in TEST SW Entering ‘Target Power’ respectively. * Declared by the applicant. EMC compliance Ltd. Page: 5 of 60 80-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval. http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0204 3.3 Test frequency For all test items, the low, middle and high channels of the modes were tested with above worst case data rate. 802.11b/g/n_HT20 Frequency Low frequency 2 412 ㎒ Middle frequency 2 437 ㎒ High frequency 2 462 ㎒ 802.11n_HT40 Frequency Low frequency 2 422 ㎒ Middle frequency 2 437 ㎒ High frequency 2 452 ㎒ 3.4 Test Voltage Mode Vo l t a g e Norminal voltage …

Text truncated - open the document above for the full version.

Test Setup Photos

http://www.emc2000.co.kr FCC TEST REPORT Report No.: EMC-FCC-R0000 Te s t setup photos * 9 ㎑ ~ 30 ㎒ * 30 ㎒ ~ 1 ㎓ EMC compliance Ltd. Page: 1 of 1 80-5, Sin-dong, Yeongtong-gu, Suwon-si, Gyeonggi-do, Korea 82-70-5008-1021 (Main) 82-505-299-8311 (Fax) This test report shall not be reproduced except in full, Without the written approval.

Contact Information

Applicant

Mu Sung Kim(Manager)

[email protected]82-2-589-9425Fax: 82-2-589-9600

Test Firm

EMC Compliance Ltdchangmin kim

[email protected]82313369919Fax: 82313364767

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	280.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is the maximum conducted output power. Device contains 20 and 40 MHz signal bandwidth. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
