2ADTG-U3000PROCAR DASH CAM

This product records videos while the vehicle is operating. Read and follow the instructions in this guide to properly use and maintain the product. User Guide Before using the product About the product This product records videos while the vehicle is operating. Use this product only for reference when investigating incidents or road accidents. This product is not guaranteed to record all events. The device may not record accidents with impacts that are too minor to activate the impact sensor or accidents with massive impacts that cause the vehicle’s battery voltage to deviate. Please read the user guide thoroughly before using this product. The manufacturer is not responsible for any accidents that occur due to not reading the user guide thoroughly. A PC meeting the minimum OS requirements is necessary for using all of this product's functions. Please check the "Using the mobile viewer" and "Using the PC viewer" sections later for details. Video recording does not begin until the product is completely turned on (booted up). To ensure that all vehicle events are recorded, wait until the product is completely booted up after turning it on, and then begin operating the vehicle. This product currently displays the product's status with LEDs. People who have difficulty distinguishing the colors of LEDs, such as those with color blindness or another color vision deficiency, should use it with caution. Depending on the vehicle's configuration or operating conditions, such as the installation of remote door lock devices, ECU settings, or TPMS settings, some product features may not be supported, and different firmware versions may influence the product's performance or features. About the user guide The information provided in the guide may change when the manufacturer updates its service policy. If the information provided changes, the THINKWARE website (www.thinkware.com) and its app will provide separate guidance. This user guide is intended for THINKWARE U3000PRO models only, and it may contain technical errors, editorial errors, or missing information. Copyrights All rights for the content and maps in this guide are reserved by THINKWARE and are protected under copyright laws. All unauthorized duplication, revision, publication, or distribution of this guide without written consent from THINKWARE is prohibited and is eligible for criminal charges. Registered trademarks THINKWARE U3000PRO is a registered trademark of THINKWARE. Other product logos and service names in this guide are trademarks of the relevant companies. Turning voice recording ON or OFF Some jurisdictions may prohibit recording voice in the vehicle or may require that all passengers have knowledge of the recording and provide consent before you record voice in the vehicle. It is your responsibility to know and follow all laws and restrictions for your jurisdiction. The device can record voice using the integrated microphone while recording video. Voice recording is ON by default. Please refer to the manual to turn voice recording on or off at any time. 3 Contents Safety information 4 1. Product overview 6 1.1 Included items 6 1.1.1 Standard items 6 1.1.2 Accessories (sold separately) 7 1.2 Part names 8 1.2.1 Front camera (main unit) - front view 8 1.2.2 Front camera (main unit) - rear view 9 1.2.3 Rear camera (2-channel) 10 1.3 Removing and inserting the memory card 10 2. Using the mobile viewer 11 2.1 Connect the product to a smartphone 11 3. Installing the product 12 3.1 Installing the front camera (main unit) 12 3.1.1 Selecting an installation location 12 3.1.2 Securing the product 12 3.1.3 Connecting the power cable 14 3.2 Installing the rear camera (2-channel) 17 3.2.1 Selecting an installation location 17 3.2.2 Securing the rear camera 17 3.2.3 Connecting the rear camera cable 18 3.3 Installing the interior IR camera (optional) 19 4. Using recording features 20 4.1 T urning the product on or off 20 4.2 Learning about the file storage locations 20 4.3 Using the continuous recording feature 21 4.4 Recording manually 21 4.5 Using the SOS recording feature 22 4.6 Using the in-cabin recording feature 22 4.7 Using parking mode 22 4.8 Using the Super Night V ision 24 4.9 Using the High Dynamic Range (HDR) 25 4.10 Using the road safety features 25 5. Settings 26 5.1 Managing the memory card 26 5.2 Setting the Camera 27 5.3 Setting recording features 27 5.4 Setting road safety features 28 5.5 Configuring the system settings 29 6. Using the PC viewer 30 6.1 System requirements 30 6.2 Learning about the PC viewer 30 6.2.1 Downloading the PC viewer 30 6.2.2 PC viewer screen layout 31 6.2.3 Playing recorded videos on the PC viewer 32 7. Using THINKWARE CONNECTED (optional) 33 7.1 Installing the THINKWARE CONNECTED dongle (optional) 33 7.2 Connecting the product to THINKWARE CONNECTED 34 8. Accessing the product information 35 8.1 V iewing the product information 35 8.2 Accessing and configuring the GPS 35 9. Upgrading the firmware 36 10. Troubleshooting 37 11. Specifications 38 4 Safety information Read the following safety information to properly use the product. Safety symbols in this guide "Warning" - Indicates a potential hazard which, if not avoided, may result in injury or death. "Caution" - Indicates a potential hazard which, if not avoided, may result in minor injury or property damage. "Note" - Provides useful information to help users better utilize the product’s features. Safety information for proper use Driving and product operation • Do not operate the product while driving a vehicle. Distraction while driving may cause accidents and result in injury or death. • Install the product in places where the driver’ s view is not obstructed. Obstruction of the driver’s vision may cause accidents and result in injury or death. Check with your state and municipal laws before mounting the product to the windshield. Power supply • Do not operate or handle the power cable with wet hands. Doing so may result in electrocution. • D…

Text truncated - open the document above for the full version.

Certification Attestation Statements Attn: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 12, 2025 FCC ID: 2ADTG-U3000PRO Ref: Attestation Statements Part 2.911(d)(5)(i) Filing THINKWARE CORPORATIONcertifies that the equipment for which authorization is soughtis not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Hanwha Vision Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant toDA-24-886andKDB 986446 D01 Covered Equipment Guidancesection B(2a). Device is inherently compliant based on hardware limitations or software controls. or A Software Bill of Materials (SBOM) is provided to the TCB for review, and The end-user or third parties cannot install additional software on this device. Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing THINKWARE CORPORATION(“the applicant”)certifies that, as of the date of the filing of the application, the applicantis notidentified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signature Name:Musung, Kim. Title: Manager Company:THINKWARE CORPORATION Tel # : +82-02-589-9425

Rev 1/26/2023 Attn: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: September 12, 2025 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID or Grantee Code:FCC ID : 2ADTG-U3000PRO Applicant’s FRN : 0024149957 THINKWARE CORPORATION(“the applicant”) certifies that, as of the date of the filing of the application, Thinkware Systems USA Inc.is our designated U.S. agent for service of process for the above referenced FCC ID.THINKWARE CORPORATIONaccepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Thinkware Systems USA Inc.accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name:Thinkware Systems USA Inc. FRN: 0033574567 Address: 18019 Sky Park Circle, Suite L, Irvine, CA 92614 Contact Person: Patrick Bong Email: [email protected] Sincerely, THINKWARE CORPORATIONThinkwareSystems USA Inc. Musung, Kim.Patrick Bong [InsertApplicantsignature][U.S. Agent signature]

THINKWARE CORPORATION A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-2-589-9425 / Fax: +82-2-589-9600 Date: September 11, 2025 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Regarding Application FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Reuse of test reports of FCC ID : 2AATL-8223A-SR / IC Numer : 24844-8223ASR for new Certification We,THINKWARE CORPORATION, here by declare our productModel name: U3000 PRO (FC C ID : 2ADTG-U3000PRO / IC number : 12594A-U3000PRO) will reuse test reports of productModule Model name: 8223A-SR (FCC ID : 2AATL- 8223A-SR / IC Numer : 24844-8223ASR)as difference declaration as follow; 1. Our product integrated BLE & WLAN Module (FCC ID : 2AATL-8223A-SR / IC Numer : 24844-8223ASR), And the version is identical to that specified in the module test report. So conducted test data re-used (FCC Report No. NTC1712033FV00, NTC1712035FV00, TCT171018E032 IC Report No. EC1905007RI01, EC1905007RI03, EC1905007RI04); 2. Radiation emission re-tested and reported in Report (Report Number:KES-RF250468, KES-RF250616, KES-RF250617); 3. For UNII bands, only UNII-1 is to be used in the USA, and only UNII-3 is to be used in CANADA. Sincerely Yours, Mr Mu Sung Kim / manager THINKWARE CORPORATION THINKWARE CORPORATION A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-2-589-9425 / Fax: +82-2-589-9600

THINKWARE CORPORATION A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-2-589-9425 / Fax: +82-2-589-9600 Date: September 11, 2025 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Chief, Certification and Engineering Bureau Industry Canada 1241 Clyde Avenue Ottawa, Ontario Canada K2C 1Y3 Confidentiality Request regarding application for certification of FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules and IC regulation, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit TypeFile Name Part ListPart List.pdf Schematics Diagram(s)Schematic.pdf Operation descriptionOperation description.pdf Block diagramBlock diagram.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Mr Mu Sung Kim / manager THINKWARE CORPORATION

THINKWARE CORPORATION A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-2-589-9425 / Fax: +82-2-589-9600 Date: September 11, 2025 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Chief, Certification and Engineering Bureau Industry Canada 1241 Clyde Avenue Ottawa, Ontario Canada K2C 1Y3 FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a)comply with the relevant provisions of the certification program; b)make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c)make claims regarding certification only in respect of the scope for which certification has been granted; d)do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product THINKWARE CORPORATION A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82-2-589-9425 / Fax: +82-2-589-9600 certification which the Certification Division may consider misleading or unauthorized; e)upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f)use certification only to indicate the products are certified as being in conformity with specified standards; g)endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h)ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i)keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j)take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k)document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Mr Mu Sung Kim / manager THINKWARE CORPORATION REMARK: 1.This authorization letter will be sent along with your application when filing with the Certification Division. 2.Please follow the format and type it on company letterhead and send original to us. 3.Authorized signature must be in agreement with grantee code contact in FCC database.

FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Page 1 of 2 External photos FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Page 2 of 2

FCC ID : 2ADTG-U3000PRO IC Number : 12594A-U3000PRO Page 1 of 1 Label & Label Location The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a prominent location in the User’s Manual.

FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Page 1 of 3 Internal photos FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Page 2 of 3 FCC ID : 2ADTG-U3000PRO IC number : 12594A-U3000PRO Page 3 of 3 Chip Antenna

verify No.047831522440 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0163-A Page (2) of (6) KCTL-TIR001-003/7 (220705) KP25-05226 REPORT REVISION HISTORY Date Revision Page No 2025-09-09 Originally issued - 2025-09-12 Added calculation for simultaneous transmission - This report shall not be reproduced except in full, without the written approval of Eurofins KCTL Co.,Ltd. This document may be altered or revised by Eurofins KCTL Co.,Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Eurofins KCTL Co.,Ltd. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. Note. The report No. KR25-SRF0163 is superseded by the report No. KR25-SRF0163-A. General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0163-A Page (3) of (6) KCTL-TIR001-003/7 (220705) KP25-05226 CONTENTS 1. General information ......................................................................................................4 2. Device information ........................................................................................................4 2.1. Frequency/channel operations................................................................................4 3. RF Exposure .................................................................................................................5 3.1. Test results..............................................................................................................6 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0163-A Page (4) of (6) KCTL-TIR001-003/7 (220705) KP25-05226 1. General information Applicant : THINKWARE CORPORATION. Address : A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi- do, South Korea Manufacturer : THINKWARE CORPORATION Address : A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi- do, South Korea Laboratory : Eurofins KCTL Co.,Ltd. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 CAB Identifier: KR0040, ISED Number: 8035A KOLAS No.: KT231 2. Device information Equipment under test : CAR DASH CAM Model : U3000 PRO Modulation technique : FMCW Frequency range : 59 500 ㎒ ~ 62 400 ㎒ Power source : DC 12.0 V, DC 24.0 V Antenna specification : Integrated patch Antenna Antenna gain : 4.0 ㏈i Software version : V1.0 Hardware version : V4.0 Test device serial No. : KAUDAAQ8000131A Operation temperature : -10 °C ~ 60 °C 2. 1. Frequency/channel operations This device contains the following capabilities: FMCW Ch. Frequency (㎓) 01 59.5 ~ 62.4 Table 2.1.1. FMCW Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0163-A Page (5) of (6) KCTL-TIR001-003/7 (220705) KP25-05226 3. RF Exposure Regulation This document is prepared to show compliance with the RF Exposure requirements as required in §1.1310 of the FCC rules and Regulations. The limit for Maximum Permissible Exposure (MPE), specified in FCC §1.1310, is listed in Table 1-1. According to FCC §1.1310: the criteria listed in the following table shall be used to evaluate the environmental impact of human exposure to radio-frequency (RF) radiation as specified in §1.1307(b). Table 1 – Limits for Maximum Permissible Exposure (MPE) Frequency Range (㎒) Electric Field Strength [V/m] Magnetic Field Strength [A/m] Power Density [㎽/㎠] Averaging Time [minute] (A) Limits for Occupational / Controlled Exposure 0.3 ~ 3.0 614 1.63 *100 6 3.0 ~ 30 1842/f 4.89/f *900/f 2 6 30 ~ 300 61.4 0.163 1.0 6 300 ~ 1 500 / / f/300 6 1 500 ~ 100 000 / / 5 6 (B) Limits for General Population / Uncontrolled Exposure 0.3 ~ 1.34 614 1.63 *100 30 1.34 ~ 30 824/f 2.19/f *180/f 2 30 30 ~ 300 27.5 0.073 0.2 30 300 ~ 1 500 / / f/1 500 30 1 500 ~ 100 000 / / 1.0 30 f=frequency in ㎒, *= plane-wave equivalent power density Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0163-A Page (6) of (6) KCTL-TIR001-003/7 (220705) KP25-05226 3.1. Test results MPE (Maximum Permissive Exposure) Prediction Predication of MPE limit at a given distance: Equation from page 18 of OET Bulletin 65, Edition 97-01 () SPGRRPGSππ4 4 2 =⇒= S = power density [㎽/㎠] P = Power input to antenna [㎽] G = Power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna [㎝] Calculation Result of RF exposure Frequency [㎒] Max Tune-up Power [㏈m] Max Tune-up Power [㎽] Power density at 20 ㎝ [㎽/㎠] Limit [㎽/㎠] 59 500 ~ 62 400 14.00 25.12 0.004 997 1.00 Note. 1. Maximum tune up: 14.00 ㏈m 2. The power density “Pd” at a distance of 20 ㎝ is calculated. Simultaneous transmission results of RF exposure Mode Frequency…

Text truncated - open the document above for the full version.

verify No.137572579830 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0162 Page (2) of (33) KCTL-TIR001-003/7 (220705) KP25-05226 REPORT REVISION HISTORY Date Revision Page No 2025-09-09 Originally issued - This report shall not be reproduced except in full, without the written approval of Eurofins KCTL Co.,Ltd. This document may be altered or revised by Eurofins KCTL Co.,Ltd. personnel only, and shall be noted in the revision section of the document. Any alteration of this document not carried out by Eurofins KCTL Co.,Ltd. will constitute fraud and shall nullify the document. This test report is a general report that does not use the KOLAS accreditation mark and is not related to KS Q ISO/IEC 17025 and KOLAS accreditation. General remarks for test reports Statement concerning the uncertainty of the measurement systems used for the tests (may be required by the product standard or client) Internal procedure used for type testing through which traceability of the measuring uncertainty has been established: Procedure number, issue date and title: Calculations leading to the reported values are on file with the testing laboratory that conducted the testing. Statement not required by the standard or client used for type testing Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0162 Page (3) of (33) KCTL-TIR001-003/7 (220705) KP25-05226 CONTENTS 1. General information ......................................................................................................4 2. Device information ........................................................................................................4 2.1. Frequency/channel operations................................................................................5 2.2. Far field distance ....................................................................................................5 3. Summary of tests ..........................................................................................................6 4. Measurement uncertainty .............................................................................................7 5. Test results ...................................................................................................................8 5.1. Emission bandwidth, 99% Occupied bandwidth .....................................................8 5.2. OFF Time Interval ................................................................................................. 11 5.3. Peak EIRP ............................................................................................................ 13 5.4. Spurious emissions ............................................................................................... 16 5.5. Frequency stability ................................................................................................ 31 6. Measurement equipment ............................................................................................ 33 Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0162 Page (4) of (33) KCTL-TIR001-003/7 (220705) KP25-05226 1. General information Applicant : THINKWARE CORPORATION. Address : A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi- do, South Korea Manufacturer : THINKWARE CORPORATION Address : A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi- do, South Korea Laboratory : Eurofins KCTL Co.,Ltd. Address : 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea Accreditations : FCC Site Designation No: KR0040, FCC Site Registration No: 687132 VCCI Registration No. : R-20080, G-20078, C-20059, T-20056 CAB Identifier: KR0040, ISED Number: 8035A KOLAS No.: KT231 2. Device information Equipment under test : CAR DASH CAM Model : U3000 PRO Modulation technique : FMCW Frequency range : 59 500 ㎒ ~ 62 400 ㎒ Power source : DC 12.0 V, DC 24.0 V Antenna specification : Integrated patch Antenna Antenna gain : 4.0 ㏈i Software version : V1.0 Hardware version : V4.0 Test device serial No. : VHWDAFND011051A Operation temperature : -10 °C ~ 60 °C Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0162 Page (5) of (33) KCTL-TIR001-003/7 (220705) KP25-05226 2. 1. Frequency/channel operations This device contains the following capabilities: FMCW Ch. Frequency (㎓) 01 59.5 ~ 62.4 Table 2.1.1. FMCW 2. 2. Far field distance Far field distance(R m ) Freq range [㎒] Speed of light [m/s] Freq [㎒] wavelength(λ) [m] Largest Antenna Dimension [m] Far Field Distance [m] Measurement Distance [m] Measurement Antenna EUT 40 000 – 64 000 300 64 000 0.004 7 0.058 2 0.0030 1.44 1.50 60 000 – 90 000 300 90 000 0.003 3 0.037 8 - 0.86 1.00 90 000 – 140 000 300 140 000 0.002 1 0.024 8 - 0.57 1.00 140 000 – 220 000 300 220 000 0.001 4 0.015 8 - 0.37 1.00 Note: EUT antenna dimension was provided by customer. All measurements shall be made in the far-field of the measurement antenna. The far-field boundary for mm-wave antennas is 2D 2 / λ. For fundamental or out-of-band emissions the far-field boundary distance of the EUT antenna or measurement antenna, whichever is largest, shall be used. For spurious and harmonic emissions the farfield boundary distance shall be based on the measurement antenna. Eurofins KCTL Co.,Ltd. 65, Sinwon-ro, Yeongtong-gu, Suwon-si, Gyeonggi-do, 16677, Korea TEL: 82-70-4904-0113 FAX: 82-505-299-8311 www.kctl.co.kr Report No.: KR25-SRF0162 Page (6) of (33) KCTL-TIR001-003/7 (220705) KP25-05226 3. Summary of tests FCC Part section(s) Parameter Test condition Test results 15.255 (c)(2)(iii)(…

Text truncated - open the document above for the full version.

ٛDielectric Chip Antenna Original Design Chip Antenna Data Sheet - P/N : ODBWPTR5020 - - Application Frequency Band[MHz] Bluetooth(2.4GHz WiFi) & 5GHz WiFi Bluetooth : 2400 ~ 2485 & WiFi : 5150 ~ 5825 `Dielectric Chip Antenna ■ ODBWPTR5020 Dimension B B C Chip Antenna Dimension Chip Antenna Soldering Pad Dimension PCB Soldering Land Dimension T L W A F F C EAEAAD AAAAAA D ParameterLWTABCDEF Value[mm] 5.0 ±0.1 2.0 ±0.1 1.2 ±0.1 0.60.80.41.40.70.9 Unless Specified tolerances are ± 0.05 mm `Dielectric Chip Antenna ■ Antenna Marking System ◀ BW 1 5 4 ①②③④⑤ ITEMDESCRIPTION ① Input Signal Input Signal ② Serial Bluetooth(2.4GHz WiFi) Band and 5GHz WiFi Band ③ Year Ex)1-2011,2-2012, .... , 9 - 2019, .... ④ Month 123456 JanuaryFebruaryMarchAprilMayJune 789ABC JulyAugustSeptemberOctoberNovemberDecember ⑤ Date 123456789AB 1st2nd3rd4th5th6th7th8th9th10th11th CDEFGHIJKLM 12th13th14th15th16th17th18th19th20th21th22th NOPQRSTUV 23th24th25th26th27th28th29th30th31th ■ Antenna PAD Information Via Non-Ground Region Ground Region 0.5mm feed line 1005 series 1005 series 1005 series 78 123 65 4 0.5mm feed line ◀BW154 ` Dielectric Chip Antenna ■ AutoCAD Drawing of Reference PCB Design for ODBWPTR5020 Product 1 2 3 4 5 6 7 8 `Dielectric Chip Antenna ■ FEEDING METHOD (unit : mm, tolerance : ± 0.05) Via Non-Ground Region Ground Region 0.5mm feed line 1005 series 1005 series 1005 series 78 123 65 4 0.5mm feed line <Top View> Via Non-Ground Region Ground Region <Bottom View> 12 3 4 87 6 5 < Equivalent Circuit > ◀BW154 `Dielectric Chip Antenna ■ Matching Value Band (MHz) Dual FeedingSingle Feeding Matching Valu e (Default) PCB Artwor k (Example) ■ Temperature condition 온도범위단위 사용온도 -40 ∼ +110 °C 보관온도 -40 ∼ +70 °C - 온도조건 Test 조건 항목온도범위 사용온도 저온 -75 °C 에서 24 시간 정상동작 고온 +150 °C 에서 24 시간 정상동작 보관온도 저온 -75 °C 에서 1000 hr 방치 시 정상동작 고온 +85 °C 에서 1000 hr 방치 시 정상동작 * 고온 방치 시 포장재 보관온도 문제로 85 °C이상불가함 . `Dielectric Chip Antenna - Dual Feeding 3D Passive Gain For BT&WiFi ■ Gain & VSWR Peak [dBi] Average [dBi] Efficiency [%] 2400MHz1.38-0.9680.09 2445MHz1.47-0.8482.43 2485MHz0.86-1.6069.26 5150MHz2.35-1.4072.50 5500MHz2.54-1.4172.30 5825MHz3.36-1.4671.47 ■ 3D Radiation Pa…

Text truncated - open the document above for the full version.
