This product records videos while the vehicle is operating. Read and follow the instructions in this guide to properly use and maintain the product. User Guide F 790 Before using the product About the product This product records videos while the vehicle is operating. Use this product only for reference when investigating incidents or road accidents. This product is not guaranteed to record or process cloud data for all events. The device may not record accidents with impacts that are too minor to activate the impact sensor or accidents with massive impacts that cause the vehicle’s battery voltage to deviate. Video recording does not begin until the product is completely turned on (booted up). To ensure that all vehicle events are recorded, wait until the product is completely booted up after turning it on, and then begin operating the vehicle. THINKWARE is not responsible for any loss caused by an accident, nor is it responsible for providing any support regarding the outcome of an accident. Depending on the vehicle’s configuration or operating conditions, such as the installation of remote door lock devices, ECU settings, or TPMS settings, some product features may not be supported, and different firmware versions may influence the product’s performance or features. About the user guide The information provided in the guide may change when the manufacturer updates its service policy. This user guide is intended for THINKWARE Blade model only, and it may contain technical errors, editorial errors, or missing information. Copyrights All rights for the content and maps in this guide are reserved by THINKWARE and are protected under copyright laws. All unauthorized duplication, revision, publication, or distribution of this guide without written consent from THINKWARE is prohibited and is eligible for criminal charges. Registered trademarks THINKWARE Blade is a registered trademark of THINKWARE. Other product logos and service names in this guide are trademarks of the relevant companies. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. • This appliance and its antenna must not be co-located or operation in conjunction with any other antenna or transmitter. • A minimum separation distance of 20cm must be maintained between the antenna and the person for this appliance to satisfy the RF exposure requirements. FCC CAUTION: Any changes or modifications to the equipment not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC ID: 2ADTG-F790 Information to user : RSS-247 This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Please be cautioned the changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Notice: Operation is subject to the following two conditions : (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. This Class B digital apparatus complies with Canadian ICES-003. IC: 12594A-F790 4 Contents Safety information 5 1. Product overview 8 1.1 Included items 8 1.1.1 Standard items 8 1.1.2 Accessories (sold separately) 8 1.2 Part names 9 1.2.1 Front camera (main unit) - front view 9 1.2.2 Front camera (main unit) - rear view 10 1.2.3 Cradle 10 1.2.4 Rear camera (optional) 11 1.3 Removing and inserting the memory card 11 2. Installing the product 12 2.1 Installing the front camera (main unit) 12 2.1.1 Selecting an installation location 12 2.1.2 Securing the product 12 2.1.3 Connecting the power cable 14 2.2 Installing the rear camera (optional) 15 2.2.1 Selecting an installation location 15 2.2.2 Securing the rear camera 15 2.2.3 Connecting the rear camera cable 16 3. Using recording features 17 3.1 T urning the product on or off 17 3.2 Learning about the file storage locations 17 3.3 Using the continuous recording feature 17 3.4 Recording manually 18 3.5 Using parking mode 18 3.6 Using the Super Night V ision 20 3.7 Using the road safety features 20 4. Using the mobile viewer 21 4.1 Connect the product to a smartphone 21 4.2 Viewing the mobile viewer screen layout 21 5. Using the PC viewer 22 5.1 System requirements 22 5.2 Learning about the PC viewer 22 5.2.1 Installing the PC viewer 22 5.2.2 PC viewer screen layout (for Windows) 23 …
Text truncated - open the document above for the full version.
THINKWARE CORPORATION A, 9FL, Samhwa Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do,South Korea Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: October 23, 2020 Regarding FCC Application (FCC ID: 2ADTG-F790) We, THINKWARE CORPORATION declare that the device does not support channel 12 ~ 13 in 2.4 GHz band. The firmware setting is not accessible by end users and/or unauthorized 3rd parties. Sincerely, Kyuhwa Lee / Deputy General Manager THINKWARE CORPORATION
THINKWARE CORPORATION A, 9FL, Samhwa Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do,South Korea Date: October 23, 2020 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: 2ADTG-F790 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT Exhibit Type File Name Part List Part List_F790.pdf Schematics Diagram(s) Schematics_F790.pdf Block diagram Block diagram_F790.pdf Operation description Operation description_F790.pdf And the above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Kyuhwa Lee / Deputy General Manager THINKWARE CORPORATION
THINKWARE CORPORATION A, 9FL, Samhwa Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do,South Korea Date: October 23, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 To whom it may concern: I, the undersigned, hereby authorize Young-Jin, Lee of KES Co., Ltd. and hereafter referred to as KES Co., Ltd., to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these matters. Any and all acts carried out by Young-Jin, Lee of KES Co., Ltd. on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing KES Co., Ltd. as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; THINKWARE CORPORATION A, 9FL, Samhwa Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do,South Korea h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Kyuhwa Lee / Deputy General Manager THINKWARE CORPORATION REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.
Supplier's Declaration of Conformity Product Description: BLACK BOX Model/Brand Name: F790 Variant Model: - FCC Rule Part(s): FCC Part 15 Subpart B Class B Part 15.107(b) & Part 15.109(b) Applicant Name: THINKWARE CORPORATION Applicant Address: A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Manufacturer Name: THINKWARE CORPORATION Manufacturer Address: A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea BLACK BOX, Model F790 has been tested in accordance with the measurement procedures specified in FCC Part 15 Subpart B class B and has been shown to be complied with the electromagnetic emission limits specified in FCC Rule Part 15 Subpart B class B. A testing of the sample product has been valid for the sample tested based on the reference test report. Responsible Party – U.S. Contact Information Company Name: Thinkware Systems USA Inc. Company Address: 18021, Sky Park Circle, STE J2, Irvine, CA, 92614, USA E-mail : [email protected] Company Name: Thinkware Systems USA Inc. Date of Issue: Oct. 23, 2020 President: Heung Bok, Lee Signature: THINKWARE CORPORATION A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Tel: +82- 02-589-9439
United States Representative Letter of Attestation United States Representative Company Name : Thinkware Systems USA Inc. Address : 6N\3DUN&LUFOH67(-,UYLQH&$86$ E-mail : [email protected] This letter is to confirm that we have accepted the responsibility to act as United States Representative on behalf of THINKWARE CORPORATION as noted below. Applicant Company Name : THINKWARE CORPORATION Contact Name : Kyuhwa Lee Address : A, 9FL., Samwhan Hipex, 240, Pangyoyeok-ro, Bundang-gu, Seongnam-si, Gyeonggi-do, South Korea Telephone Number : +82-10-2320-7248 Fax Number : +82-2-589-9100 E-mail : [email protected] Product / Model name : BLACK BOX / F790 Data of issuance : Date: October 23, 2020 Signature : Signed by (printed name): Kyuhwa Lee
Model No.: F790 Page 1 of 2 External photos Model No.: F790 Page 2 of 2 External photos
The device is so small that it is not practicable to place the statement specified under 15.19 statement request, the information required by this paragraph shall be placed in a Prominent location in the User’s Manual.
Model No.: F790 Page 1 of 2 Internal photos Chip Antenna Model No.: F790 Page 2 of 2 Internal photos N/A
Model No.: F790 RF exposure According to FCC part 1.1310 : The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in § 1.1307(b) Limits for Maximum Permissible Exposure (MPE) f= frequency in Friis transmission formula: Pd = (Pout×G)/(4×pi×R 2 ) Where, Pd = power density in / Pout = output power to antenna in G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd the limit of MPE, 1 /. If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Results - Worst case WIFI (2.4G, 5.2G) Operation mode Max tune-up Average power (m) Antenna gain (i) Power density at 20 (/) Limit (/) 802.11b SISO 15.0 0.80 0.007564 1 802.11g/n_HT20 SISO 11.0 0.80 0.003011 1 802.11a/n_HT20/40, 802.11ac_VHT20/VHT40 SISO 11.0 1.95 0.003924 1 Frequency range () Electric field strength(V/m) Magnetic field strength (A/m) Power density (/) Average time (A) Limits for Occupational / Control Exposures 300 – 1 500 -- -- f/300 6 1 500 - 100000 -- -- 5 6 (B) Limits for General Population / Uncontrol Exposures 300 – 1 500 -- -- f/1500 6 1 500 – 100 000 -- -- 1 30 Model No.: F790 RF exposure According to RSS-Gen 3.2: the requirements in Radio Standards Specification RSS-102, Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands), shall be met. INDUSTRY CANADA EXEMPTION RF exposure evaluation is required if the separation distance between the user and/or bystander and the device’s radiating element is greater than 20 , except when the device operates as follows: At or above 300 and below 6 and the source-based, time-averaged maximum e.i.r.p. of the device is equal to or less than 1.31 × 10 -2 ƒ 0.6834 W (adjusted for tune-up tolerance), where ƒ is in ; Results - Worst case WIFI (2.4G, 5.8G) Band Operation mode Conducted Power (dBm) Ant Gain (dBi) EIRP Limit (dBm) (W) 802.11b SISO 15.00 0.8015.80 0.038 2.684 802.11g/n_HT20 SISO 11.00 0.8011.80 0.015 2.684 802.11a/n_HT20/40, 802.11ac_VHT20/VHT40 SISO 14.00 2.0516.05 0.040 2.684
