NC-200 USER GUIDE National Geographic gimbal cam is a portable gimbal camera that combines ease of use and functionality. 2 Contents 1. Basic information overview 3 1.1 Included items 3 1.1.1 Standard items 3 1.1.2 Accessories (sold separately) 3 1.2 Part names 4 1.2.1 Main unit (front/back view) 4 1.2.2 Main unit (side view) 4 1.2.3 Main unit (top/bottom view) 5 1.3 Removing and inserting the memory card 5 1.4 Removing and inserting the battery 6 1.5 Charging the product 6 1.5.1 Charging the product with a cable 6 1.5.2 Charging the battery with a charger 7 1.6 Turning the product on/off 7 1.7 Checking the battery level 8 1.8 Connecting the product to the backpack mount 8 1.9 Connecting the product to the head tracker (optional) 9 1.10 Safety information for proper use 10 2. Using the product 11 2.1 Overview of the LCD 11 2.1.1 Main menu tree 11 2.1.2 Using the LCD function 12 2.1.3 Screen layout 12 2.2 Using the buttons 14 2.3 Overview of LED status and beep 15 3. Overview of National Geographic gimbal cam features 16 3.1 Using AI tracking mode 16 3.2 Face tracking mode 17 3.3 Using Face ID 18 3.4 Using dynamic motion recording mode 19 3.5 Updating the firmware 20 4. Using the National Geographic gimbal cam app 21 4.1 Connecting the National Geographic gimbal cam app 21 4.2 Using live streaming 22 5. Using recording modes 25 5.1 Using video modes 25 5.2 Using photo modes 27 5.3 Setting presets 28 5.4 Connecting the product to the computer 29 6. Viewing album 30 6.1 Overview of the Album screen 30 6.2 Deleting files in the album 30 7. Configuring the settings 31 7.1 Gimbal settings 31 7.2 Connection settings 31 7.3 Sysyem settings 32 7.3.1 Recording settings 32 7.3.2 Other settings 32 7.3.3 System information 32 8. Specifications 33 3 1. Basic information overview 1.1 Included items 1.1.1 Standard items Quick start guideStrapUSB-C cableBackpack mount Main unitBatteryPouchFerrite coreBattery charger 1.1.2 Accessories (sold separately) Mini tripod / Microphone / ND filter / LCD protective film / Hard protective case (small) / Hard protective case (large) / Head tracker Visit the THINKWARE homepage (http://thinkware.com) to buy extra included items and accessories. Basic information overview 4 1.2 Part names 1.2.1 Main unit (front/back view) Camera Pan motor Speaker Trigger M4 mount connector Strap holder LCD LED status Recording button Joystick Mode/Power button Battery cover 1.2.2 Main unit (side view) Roll motor Microphone USB port/SD card slot cover USB-C port Microphone External microphone port microSD card slot Basic information overview 5 1.2.3 Main unit (top/bottom view) Tilt motor Battery cover release button 1/4” mount connector 1.3 Removing and inserting the memory card Before removing the memory card, ensure that the product is turned off. Gently push the bottom of the memory card with your fingernail to release it, and then remove it from the product. To insert the memory card, open the USB/SD card slot cover, ensure that the memory card is in the correct direction, and insert it into the slot until you hear a click. • Ensure that the memory card is in the correct direction before inserting it into the product. The product slot or the memory card may be damaged if it is inserted incorrectly. • Format the memory card periodically to avoid memory card fragmentation and storage errors. • For more information about the recommended microSD cards, visit http://www.thinkware.com/help. • The recommended microSD cards are subject to change and SD cards from manufacturers other than THINKWARE are not guaranteed to operate properly. Basic information overview 6 1.4 Removing and inserting the battery 2 1 ➊➊ ➋➋ ➌➌ • For optimal performance, use a genuine battery. • The performance of the product may be limited and the camera performance is not guaranteed if you do not use an authentic battery. For more information on battery safety and use, refer to the Battery Information Guide. 1 Open the battery cover by pressing the battery cover release button and take out the battery by holding the grooves on both sides of the battery. 2 Check that the metal part of the new battery is facing upward and insert it in the correct direction. The product uses a removable battery. Ensure that the battery cover is tightly closed and sealed before using the product. 1.5 Charging the product 1.5.1 Charging the product with a cable 1 Connect the product to a USB adapter or computer USB port using the included USB cable. • Fully charge the battery before using the product for the first time. • Use an adapter that supports 2A or higher. The product may not charge when using certain adapters. • If you use a cable other than the included authentic cable, the product may not charge. 2 When charging begins, the product’s LED indicator will turn red, and when charging is complete, the LED indicator will turn off. • It takes 180 minutes to fully charge the battery. (You can charge two batteries at the same time by using battery charger.) • For the fastest charging of the product, use the charger. • Charging time may vary depending on the charging environment. Basic information overview 7 1.5.2 Charging the battery with a charger Check the metal parts of the battery and charger, and be sure to insert the battery in the correct direction. Operation statusLED status StandbyLED off ChargingRed light on Fully chargedGreen light on ErrorRed + Green lights flicker • If you do not know the voltage or current of the charger, use the included USB cable to charge the battery with a laptop or computer. • This product is for indoor use only and has not been designed for outdoor use or tested for charging leisure vehicles, mobile motor generators, etc. • Only charge genuine batteries designated for the product. • Use a 5V adapter and an adapter of 2A or higher. Using a smaller adapter may prevent charging or increase the charging time. 1.6 Turning the product on/off Press and hold the button on the product to turn the product on. T…

Text truncated - open the document above for the full version.

Overview of National Geographic gimbal cam features 17 Active tracking mode Use Active tracking mode to track moving or specific objects in AI tracking mode. In AI tracking mode, touch a specific target you want to record twice, then a square, yellow border will be created and active tracking mode will start. To end tracking, touch the square, yellow border. 3.2 Face tracking mode Face tracking mode recognizes and tracks a person's face. Face tracking mode 1 Swipe left on the preview screen to open the gimbal quick settings, then change the tracking mode to Face tracking mode. 2 Face recognition mode will start in Face tracking mode. When a subject's face is detected, a square, white border is created around their face. 3 If you touch the inside of the square, white border, it turns yellow and tracking starts. To end tracking, touch the yellow square border. Overview of National Geographic gimbal cam features 18 3.3 Using Face ID Once you register people's faces on Face ID, the faces will be automatically recognized and tracked based on the camera angle without requiring any actions. Face ID registration 1 Swipe left on the preview screen to open the gimbal quick settings, then touch the tracking button to activate the Face ID feature. 2 Start recording the person you want to register for Face ID. When the product recognizes a face, a white square border will be created around the face and the + button inside the box will become activated. 3 Touch the + button > Confirm to complete Face ID registration. • The product tracks who has the highest registration priority. • You can register up to five Face IDs. Overview of National Geographic gimbal cam features 19 Check/delete Face ID 1 Touch Settings() > System Settings > Recording Settings > Face ID to check the registered people by registration rank. 2 Touch the Face ID you want to delete, then press on the top right to delete the Face ID. 3.4 Using dynamic motion recording mode With the dynamic motion function, you can specify up to 4 recording points and set the path and time to record before recording. Dynamic motion recording mode 1 On the Video preview screen, touch the () button to open the motion settings. 2 Set the time to record. The video length is automatically calculated and displayed based on the video settings value (speed, interval). 3 After setting the recording time, touch the () button to return to the Motion Settings screen, and then touch the ( ) button in the upper-right corner to move to the Route Settings screen. 4 Use the joystick to move to the desired shooting points and press the + button to designate up to four shooting points (A-D). 5 Press the button on the product. The product will shoot the selected points. • The route can be set up to 4 points (A-D). • Touching the End button on the Settings screen will move you to the End Selection screen, and at the end, it will delete all location information and move to the Motion Settings screen. • While recording, all locations set as routes are displayed on the preview screen, and the route completed, the route being recorded, and the route to be recorded are displayed as images to help you recognize the route. Overview of National Geographic gimbal cam features 20 Recording in Repeat mode You can set two shooting points and take continuous and repeating shots at set time intervals. With the joystick, select two recording points by pressing the + button, press the Repeat mode ( ) button, and press the button on the product. You cannot use the repeat mode if you set more paths than two recording points. 3.5 Updating the firmware For optimal operation of the product, ensure that you keep the firmware up to date. 1 Visit www.thinkware.com/support. 2 Save the downloaded firmware file to the product's memory card. 3 Insert the memory card with the firmware to start updating the firmware. • For more information on product updates, visit www.thinkware.com/support. • If you save the firmware to the SD card and update the product at the same time, the update will proceed in the order of system firmware and gimbal firmware. 21 4. Using the National Geographic gimbal cam app You can use various functions of the product by connecting the product to the National Geographic gimbal cam app. 4.1 Connecting the National Geographic gimbal cam app 1 On your smartphone, search for the National Geographic gimbal cam app in the Google Play Store or Apple App Store, or scan the QR code below to download and install the app. 2 Open the installed National Geographic gimbal cam app. 3 On your smartphone, turn on the Bluetooth and Wi-Fi features. 4 Swipe down on the preview screen to open the settings menu, then touch Settings() > Connection Settings > National Geographic App > Use connected device switch to activate it. 5 In the National Geographic gimbal cam app, touch the Connect a camera button, find and connect to a product name that starts with NC-200. • The Wi-Fi password is 12345678. • If the product is connected to the head tracker, tap Connect via Wi-Fi to connect. Using the National Geographic gimbal cam app 22 4.2 Using live streaming You can use the live streaming feature in the National Geographic gimbal cam app to stream stable and high-definition broadcasts. Live streaming 1 Swipe down on the preview screen to open the settings menu, then touch the app connection button and follow the on-screen instructions to connect the app and product. 2 Select the desired broadcasting platform from the Live streaming menu in the app preview screen or the app home screen’s setting menu, and then go to the streaming settings. Twitch live streaming will be supported. 3 Sign in to the registered or newly registered account for each broadcasting platform, set the transmission resolution and network items, and touch the Streaming Settings Complete button. To use mobile hotspot data, first enable hotspot data in your smartphone Wi-Fi settings, and then enter the hotspot's AP information. 4 When th…
