2ADYL-JPD500Fpulse oximeter

Pulse Oximeter JPD-500F FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference. (2) this device must accept any interference receiv ed,including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 o f the FCC Rules. These limits are designed to provide reasonable protection again st harmful interference in a residential installation. This equipment generat es, uses and can radiate radio frequency energy and, if not installed and us ed in accordance with the instructions, may cause harmful interferen ce to radio communications. However, there is no guarantee that interference wi ll not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by tu rning the equipment off and on, the ser is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ●Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ●Consult the dealer or an experienced radio/TV tech nician for help. Warning: Changes or modifications to this unit not express ly approved by the party responsible for compliance could void the use r’s authority to operate the equipment. Precautions
Do not attempt to maintain the Oximeter unless you are professional engineers. Only professionals with maintenance qual ification are allowed to perform interior maintenance as necessary.
Periodically change the contact position between t he Oximeter probe and the finger for a measurement that lasts a long time. Adjust the position of the probe before the measurement lasts two hours, and check the integrity of skin, the blood circulation condit ion of the finger as well as the position of the finger.
This product is not applicable to the examination of newborn babies.
Seek for medical care in time if the measured valu e goes beyond the normal range while you are sure that the instrument does not malfunction.
Do not directly expose your eyes to light-emitting components of the Oximeter, as that could cause harm to your eyes.
For details about clinical limitations and contrai ndications, please carefully consult relevant medical literatures. The following factors may cause disturbance to or a ffect the accuracy of examination: ◆ This product is used in an environment involving h igh-frequency devices, such as high-frequency electric knives and CT appar atuses. ◆ The probe of the Oximeter is placed on the same bo dy part or limb as with blood pressure cuff arterial duct or intraveno us injection. ◆ The user suffers from hypotension, severe vascular atrophy, severe anemia, or low oxygen. ◆ The user is in sudden cardiac arrest or shock stat e. ◆ The finger with nail polish or a fake fingernail m ay cause wrong readings of pulse oxygen saturation. Warnings Warning: Do not use the Oximeter in an environment with any inflammable gases, inflammable anesthetic, or other inflammable substa nces. Warning: Do not attempt to charge any common dry battery, a s that could cause leakage, fire disaster, or even explosion. Dispose of exhausted batteries in accordance with environment protection regulations. Warning: Do not use the Oximeter in an MRI or CT environmen t. Warning: Do not operate the Oximeter when it is damp with ov erflow or water vapor condensation. Avoid moving the Oximeter from an excessively-cold environment to a high-temperature moist environment . Symbol Conventions Symbol Description BF-type application part Caution: Please see this manual. %SpO2 Symbol of oxygen saturation bpmPR Symbol of pulse rate Bluetooth symbol When end users abandon this product, they must send the product to the collection place for recycling. Overview Oxygen saturation is the percentage of oxyhemoglobi n (HbO2) that is combined with oxygen against all combinable hemoglobin (Hb). It is an important physiological parameter involved in respiration and circulation. The oxygen saturation of arterial blood in a normal human body is 98%. Oxygen saturat ion is an important indicator of the oxygen condition in the human body. In gener al, the normal values of oxygen saturation shall not be lower than 94%. If the meas ured value of oxygen saturation is lower than 94%, an insufficient supply of oxygen is considered. The pulse rate is the number of pulse beats per min ute. Normally, the pulse rate is consistent with the heart rate. In general, the pul se rate of every people is 60 to 90 beats per minute. The Perfusion Index (PI) usually reflects the limb perfusion status of an examined patient, and shows the detection precision of the i nstrument as well; that is, examination can still be performed even in the low or weak perfusion condition.The PI of a normal human body is 3% or greater. Working Principles, Expected Usage, and Applicable Scope Based on full digital technology, the Finger Pulse Oximeter non-invasively measures the actual content (oxygen saturation) of oxyhemogl obin (HbO2) in arterial blood using the optical transmittance method. The Finger Pulse Oximeter measures the blood oxygen saturation and pulse rate of a human body via finger artery. It is applicable to a wide range of fields, such as families, hospitals (including operation rooms of t he departments of internal medicine and surgery, the department of anesthesiol ogy, the department of paediatrics, and intensive care rooms), oxygen bars , social medical care institutions, and sports & health. Use this instrument for measure ment before or after sports. You are not advised to use this instrument during s ports activities. It is applicable to patients 15 to 60 years old. Do not use it for cont…

Text truncated - open the document above for the full version.

ZX_BLE_A3block diagram: Frequency:2402MHz~2480MHz Bluetooth Chip :CC2540 2.4GPCB antenna Crystal 32MHz External power supply +3.3V Crystal 32.768K

J2 OLED Display Screen J3 Bluetooth Module POWER 2.5-3.0V 8M OSC U2 STM32F103C8T6 CPU Receiving tube Luminesce nt tube

FCC ID:2ADYL-JPD500F This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) this device may not cause harmful interference, and (2) this device must accept any interference received,including interference that may cause undesired operation. 23mm 16mm

500F circuit function specification serial number function description 1 Bluetooth Module CC2540 Transmit data. Connect CPU via serial port 2 luminescence driver chip Red LED and infrared LED drive. 3 CPU part Calculation and save the data. Using 8 MHZ internal clock. 4 power supply chip Input 3 V and step up to 3.5 V. 5 power supply chip Input 3.5V and output 3.3V 6 power supply chip Input 3.5V and output 3.3V 7 interface Power input interface 8 button Switch menu 9 buzzer The main chip output PWM voice drive 10 display screen OLED-9.6’’ 11 receiving tube receiving tube 12 Bluetooth Version 4.0 Smart(BLE) 13 Operating Frequency 2.4GHz ISM band 14 Antenna Type Integrate 15 Antenna Gain 3 dBi 16 Operating clock frequency 32MHz 17 Power supply + 3.0V ~ + 3.3VDC, 50mA How the device is operating about the Bluetooth function The Bluetooth function is automatically turned on while the pulse oximeter is power on. Then turn on the Bluetooth of cell phone, set up the wireless communication after successfully pairing. Cell phone receive real-time oximetry data, realize the wireless transmission function.

CC2540F128, CC2540F256 www.ti.comSWRS084F– OCTOBER2010– REVISEDJUNE2013 2.4-GHzBluetooth ® lowenergySystem-on-Chip CheckforSamples:CC2540F128, CC2540F256 1 FEATURES A •TPS62730Compatible 23456 •TrueSingle-ChipBLESolution:CC2540Can LowPowerinActiveMode RunBothApplicationandBLEProtocolStack, IncludesPeripheralstoInterfaceWithWide –RXDownto15.8mA(3V Supply) RangeofSensors,Etc. –TX(-6dBm):18.6mA(3V Supply) •6-mm× 6-mmPackage A •RF •Microcontroller –Bluetoothlowenergytechnology –High-PerformanceandLow-Power8051 Compatible MicrocontrollerCore –ExcellentLinkBudget(upto97dB), –In-System-ProgrammableFlash,128KBor EnablingLong-RangeApplicationsWithout 256KB ExternalFrontEnd –8-KBSRAM –AccurateDigitalReceivedSignal-Strength A Indicator(RSSI) •Peripherals –SuitableforSystemsTargetingCompliance –12-BitADCwithEightChannelsand WithWorldwideRadioFrequency ConfigurableResolution Regulations:ETSIEN300328andEN300 –IntegratedHigh-PerformanceOp-Ampand 440Class2 (Europe),FCCCFR47Part15 Ultralow-PowerComparator (US),andARIBSTD-T66(Japan) –General-PurposeTimers(One16-Bit,Two •Layout 8-Bit) –FewExternalComponents –21General-PurposeI/OPins(19× 4 mA,2× –ReferenceDesignProvided 20mA) –6-mm× 6-mmQFN40Package –32-kHzSleepTimerWithCapture •LowPower –TwoPowerfulUSARTsWithSupportfor –ActiveModeRXDownto19.6mA SeveralSerialProtocols –ActiveModeTX(–6 dBm):24mA –Full-SpeedUSBInterface –PowerMode1 (3-μs Wake-Up):235μA –IRGenerationCircuitry –PowerMode2 (SleepTimerOn):0.9μA –PowerfulFive-ChannelDMA –PowerMode3 (ExternalInterrupts):0.4μA –AESSecurityCoprocessor –WideSupplyVoltageRange(2V–3.6V) –BatteryMonitorandTemperatureSensor –FullRAMandRegisterRetentioninAll –EachCC2540Containsa Unique48-bit PowerModes IEEEAddress 1 Pleasebeawarethatanimportantnoticeconcerningavailability,standardwarranty,andusein criticalapplicationsof TexasInstrumentssemiconductorproductsanddisclaimerstheretoappearsattheendofthisdatasheet. 2SmartRFis a trademarkofTexasInstruments. 3Bluetoothis a registeredtrademarkofBluetoothSIG,Inc. 4SupportedbyIAREmbeddedWorkbenchis a trademarkofIARSystemsAB. 5ZigBeeis a registeredtrademarkofZigBeeAlliance. 6Allothertrademarksarethepropertyoftheirrespectiveowners. PRODUCTIONDATAinformationis currentasofpublicationdate. Copyright© 2010–2013,TexasInstrumentsIncorporated ProductsconformtospecificationsperthetermsoftheTexas Instrumentsstandardwarranty.Productionprocessingdoesnot necessarilyincludetestingofallparameters. CC2540F128, CC2540F256 SWRS084F– OCTOBER2010– REVISEDJUNE2013www.ti.com SOFTWAREFEATURESAPPLICATIONS •Bluetoothv4.0CompliantProtocolStackfor•2.4-GHzBluetoothlowenergySystems Single-ModeBLESolution •MobilePhoneAccessories –CompletePower-OptimizedStack, •SportsandLeisureEquipment IncludingControllerandHost •ConsumerElectronics –GAP– Central,Peripheral,Observer,or •HumanInterfaceDevices(Keyboard,Mouse, Broadcaster(IncludingCombination RemoteControl) Roles) •USBDongles –ATT/ GATT– ClientandServer •HealthCareandMedical –SMP– AES-128Encryptionand Decryption CC2540WITHTPS62730 –L2CAP •TPS62730isa 2 MHzStepDownConverter –SampleApplicationsandProfiles withBypassMode –GenericApplicationsforGAPCentral •ExtendsBatteryLifetimebyupto20% andPeripheralRoles •ReducedCurrentinTXandRX –Proximity,Accelerometer,SimpleKeys, •30nABypassModeCurrenttoSupportLow andBatteryGATTServices PowerModes –MultipleConfigurationoptions •RFPerformanceUnchanged –Single-ChipConfiguration,Allowing •SmallPackageAllowsforSmallSolutionSize ApplicationtoRunonCC2540 •CC2540Controllable –NetworkProcessorInterfacefor ApplicationsRunningonanExternal Microcontroller –BTool– WindowsPCApplicationfor Evaluation,Development,andTest •DevelopmentTools –CC2540MiniDevelopmentKit –SmartRF™Software –SupportedbyIAREmbeddedWorkbench™ Softwarefor8051 DESCRIPTION TheCC2540is a cost-effective,low-power,truesystem-on-chip(SoC)forBluetoothlowenergyapplications.It enablesrobustBLEmasterorslavenodestobebuiltwithverylowtotalbill-of-materialcosts.TheCC2540 combinesanexcellentRFtransceiverwithanindustry-standardenhanced8051MCU,in-systemprogrammable flashmemory,8-KBRAM,andmanyotherpowerfulsupportingfeaturesandperipherals.TheCC2540is suitable forsystemswhereverylowpowerconsumptionisrequired.Verylow-powersleepmodesareavailable.Short transitiontimesbetweenoperatingmodesfurtherenablelowpowerconsumption. TheCC2540comesintwodifferentversions:CC2540F128/F256,with128and256KBofflashmemory, respectively. CombinedwiththeBluetoothlowenergyprotocolstackfromTexasInstruments,theCC2540F128/F256forms themarket’s mostflexibleandcost-effectivesingle-modeBluetoothlowenergysolution. 2SubmitDocumentationFeedbackCopyright© 2010–2013,TexasInstrumentsIncorporated ProductFolderLinks:CC2540F128CC2540F256 RESET WATCHDOG TIMER IRQ CTRL FLASH CTRL DEBUG INTERFACE CLOCK MUX and CALIBRATION DMA 8051 CPU CORE 32-MHz CRYSTAL OSC OP-AMP 32.768-kHz CRYSTAL OSC HIGH- SPEED RC-OSC POWER MANAGEMENT CONTROLLER USART 0 USB USART 1 TIMER 1 (16-Bit) TIMER 3 (8-Bit) TIMER 4 (8-Bit) TIMER 2 (BLE LL TIMER) FLASH FIFOCTRL 1 KB SRAM ON-CHIP VOLTAGE REGULATOR POWER-ON RESET BROWN OUT VDD (2 V–3.6 V) DCOUPL RESET_N XOSC_Q2 XOSC_Q1 P2_4 P1_7 P0_7 P2_3 P1_6 P0_6 P2_2 P1_5 P0_5 P1_2 P0_2 P2_1 P1_4 P0_4 P1_1 P0_1 P2_0 P1_3 P0_3 P1_0 P0_0 MODULATOR DEMODULATOR RECEIVE TRANSMIT FREQUENCY SYNTHESIZER SYNTH RF_P RF_N B0301-05 RADIO REGISTERS SFR Bus SFR Bus DS ADC AUDIO/DC AES ENCRYPTION AND DECRYPTION MEMORY ARBITRATOR FLASH UNIFIED SFR IRAM XRAM PDATA SLEEP TIMER 32-kHz RC-OSC I/O CONTROLLER DIGITAL ANALOG MIXED ANALOG COMPARATOR USB_N USB_P Radio Arbiter Link Layer Engine CC2540F128, CC2540F256 www.ti.comSWRS084F– OCTOBER2010– REVISEDJUNE2013 Copyright© 2010–2013,TexasInstrumentsIncorporatedSubmitDocumentationFeedback3 ProductFolderLinks:CC2540F128CC2540F256 CC2540F128, CC2540F256 SWRS084F– OCTOBER2010– REVISEDJUNE2013www.ti.com ThisintegratedcircuitcanbedamagedbyESD.TexasInstrumentsrecommendsthatallintegratedcircuitsbehandledwith appropriateprecautions.Failuretoobserveproperhandlingandinstallationprocedurescancausedamage. ESDdamage…

Text truncated - open the document above for the full version.

Intertek Testing Services Shenzhen Ltd. Guangzhou Branch Job No.: 141212001GZU Page: 1 of 1 FCC ID: 2ADYL-JPD500F RF Exposure Compliance Requirement The product belongs to standalone portable device base the FCC rule part 2.1091&2.1093. The transmission frequencies of the device are between 100 MHz and 6 GHz. The worst case test separation distance is 5mm. The Max Conducted Output Power and SAR Test Exclusion Threshold (mW) are listed below: Transmit frequency (GHz) Max Conducted Output Power (mW) SAR Test Exclusion Threshold (mW) 2.402 0.891 9.7 2.440 0.995 9.6 2.480 0.703 9.5 The SAR Test Exclusion Threshold is calculated from: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR
f(GHz) is the RF channel transmit frequency in GHz
Power and distance are rounded to the nearest mW and mm before calculation17
The result is rounded to one decimal place for comparison According to SAR Exclusion Threshold in KDB 447498 (D01) General RF Exposure Guidance v05, the SAR report is not required.

1 1 2 2 3 3 4 4 DD CC BB AA Title NumberRevisionSize A4 Date:2014-08-02Sheet of File:E:\BlueTooth\..\TI_BLE_Module_V1.03.SchDocDrawn By: DVDD 10 AVDD_DREG 39 DGND_USB 1 USB_P 2 USB_M 3 DVDD_USB 4 P2_0 36 P2_1 35 P2_2 34 P1_0 11 P1_1 9 P1_2 8 P1_3 7 P1_4 6 P1_5 5 P1_6 38 P1_7 37 P0_0 19 P0_1 18 P0_2 17 P0_3 16 P0_4 15 P0_5 14 P0_6 13 P0_7 12 RESET_N 20 GND 41 RBIAS 30 DCOUPL 40 XOSC32M_Q1 22 XOSC32M_Q2 23 P2_4 32 P2_3 33 RF_N 26 RF_P 25 AVDD_GUARD 31 AVDD5 21 AVDD3 24 AVDD2 27 AVDD1 28 AVDD4 29 U1 CC2540 GND P2.0 P2.1 P2.2 P1.0 P1.1 P1.2 P1.3 P1.4 P1.5 P1.6 P1.7 P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7 RST_N C3 1uF C4 100nF C5 100nF C6 100nF NCC9 100nF C8 220p C2 2.2uF L1 L_BEAD_102 VCC GND GNDGNDGNDGNDGNDGNDGND C11 C_18P C13 C_18P L4 L_2N0_0402 L5 L_2N0_0402 L2 L_1N0_0402 L3 L_3N0_0402 C14 C_1P0 C10 C_1P0 C12 C_1P0 GND GND GND C15 1uF GND 1 2 3 4 X2 3225 C19 12pF C20 12pF GND X1 32.768K C16 10pF C17 10pF GNDGND TI BLE Module V1.03 CAIBO, 2014-07-26 GND C1 10pF C18 1nF GND DP DM GND RST_N P0.0 P0.1 P0.2 P0.3 P0.4 P0.5 P0.6 P0.7 P1.0 P1.1 P1.2P1.3 P1.4 P1.5 P1.6 P1.7 P2.0 P2.1 P2.2 GND P2.1 P2.2 RST_N R3 56K 1 A1 ANT VCC DP DM 1 2 3 4 5 P3 Header 5 VCC R2 10K 1 2 3 4 5 6 7 8 9 10 11 12 P1 Header 12 1 2 3 4 5 6 7 8 9 10 11 12 P2 Header 12

12345678 A B C D 87654321 D C B A Title NumberRevisionSize A3 Date:3-Mar-2015 Sheet of File:I:\worknow\FM2008\fm产品\stm32指甲\蓝牙4.0数字板\蓝牙4.0数字板\蓝牙4.0数字板.DDBDrawn By: AGND FB2100 IR_CS RED_CS GND AVCC R3110K R3010K E1 47U/10V VBATT E4 10U/10V VDD Vin 1 Gnd 2 EN 3 Vout 5 RSN 4 U12 SGM2019 GND R8 10R GND R5 100K R11 100K V-DET CS V D D _ 3 4 8 V S S _ 3 4 7 PB9_TIM4-4 46 PB8_TIM4-3 45 BOOT0 44 PB7_TIM4-2 43 PB6_TIM4-1 42 PB5 41 PB4 40 PB3 39 PA15 38 PA14 37 V D D _ 2 3 6 V S S _ 2 3 5 PA13 34 PA12 33 PA11_TIM1-4 32 PA10_RXD1_TIM1-3 31 PA9_TXD1_TIM1-2 30 PA8_TIM1-1 29 PB15_SPI2-MOSI 28 PB14_SPI2-MISO 27 PB13_SPI2-SCK 26 PB12_SPI2-NSS 25 V D D _ 1 2 4 V S S _ 1 2 3 PB11_I2C2-SDA_RXD3 22 PB10_I2C2-SCL_TXD3 21 PB2_BOOT1 20 PB1_ADC9_TIM3-4 19 PB0_ADC8_TIM3-3 18 PA7_AD7_SPI1-MOSI_TIM3-2 17 PA6_AD6_SPI1-MISO_TIM3-1 16 PA5_AD5_SPI1-SCK 15 PA4_AD4_SPI1-NSS 14 PA3_AD3_RXD2_TIM2-4 13 PA2_AD2_TXD2_TIM2-3 12 PA1_AD1_TIM2-2 11 PA0_WKUP_AD0_TIM2-1 10 V D D A 9 V S S A 8 nRST 7 PD1_OSC_OUT 6 PD0_OSC_IN 5 PC15_OSC32_OUT 4 PC14_OSC32_IN 3 PC13_TAMPER_RTC 2 V B A T 1 U2 STM32F103C8_LQFP48 R17 100K R19 100K X1 X2 /RST R1210K VBATT RXA0 TXA0 D0 D1 D/C RES V-DET VBATTVBATT R14 100K R2 10K R15 1M VBATT IR_CS RED_CS OUT C4 0.1U C9 0.1U C18 0.1U VBATT E11 10UF/10V C30.1U C2 0.1U 1 2 3 U4 TSL235R-LF OUT R1100R E9 4.7uF/10V VDD V_ALLR RED- RED_CS AVCC V_ALLR RED+ IR_CS AVCC GND AGND 1 1 2 2 3 3 4 4 5 5 6 6 7 7 8 8 9 9 10 10 U9 SGM3005 VCC 1 GND 2 RXA0 3 TXA0 4 J1 RS232 VBATT GND RXA0 TXA0 1 1 2 2 JP2 CON2 VBATT VDD VDD VDD V34 VSS 1 C2P 2 C2N 3 C1P 4 VBATT 6 VSS 8 VDD 9 BS0 10 BS1 11 BS2 12 CS 13 RES 14 DC 15 RW 16 RD 17 D0 18 D1 19 D2 20 D3 21 D4 22 D5 23 D6 24 D7 25 IREF 26 VCOMH 27 VCC 28 VLSS 29 VSS 30 VBREF 7 C1N 5 J2 UG-2864HMBEG01 R7390K D1 D0 D/C RES CS AVCC E2 10U/10V R9 100K1% R6 604K1% E3 22U/10V L110uH V34 * * VBATT SW 1 VBAT 6 EN 3 G N D 2 FB 4 VOUT 5 U3 SGM6600 /ON /ON ON E13 4.7uF LDOEN1 LY LDOEN1 R4 1M GND 1 2 9 11 5 VBATT U31 BUZZER 1 2 3 Q37 8550 R20 1K SPEAK R27 10K R22 15R SPEAK LIS_SCL LIS_SDA GND VBATT RED- RED+ 1 2 3 4 JP4 p4x1 C140.047u R E D + R E D - TXA0 RXA0 Vin 1 Gnd 2 EN 3 Vout 5 RSN 4 U8 SGM2019 GNDC7 0.1U E10 10U/10V GC02_EN R26 1M V34 V35 R23 0 R24 NC V35 GC02_EN 1 2 3 4 S1 SW-P VDD V34 C5 4.7uF C1 4.7uF FB1100 VDD E7 1UF E5 1UF E12 1UF ON X2-1 X2-2 E6 4.7uF E8 1uF 1234567891 0 1 1 1 2 1 3 1 4 1 5 1 6 1 7 1 8 1 9 2 0 2 1 2 2 2 3 2 4 J3 CON24 LY 1 T5 CON1 1 T2 CON1 1 T6 CON1 1 T4 CON1 1 T1 CON1 1 T3 CON1 LY2 LY2 C 6 RST 7 VCC 8 NC 4 GND 1 NC 2 IO 3 NC 5 U1 HXK103 C6 0.1U GNDVDD R13 10K R10 10K R16 0R VDD R18 0R PA3 PA2 PA3 D1 1N4148 PA2 PA7 PB15 PB15 PA7 C8 10pf GND 4 3 10 6 7 8

Report No.: 141212001GZU-001 Issued: 11 March 2015 FCC ID: 2ADYL-JPD500F Page 2 of 42 CONTENT TEST REPORT ........................................................................................................................................................... 1 CONTENT ................................................................................................................................................................... 2 1.0 Summary of Test............................................................................................................................................ 3 2.0 General Description ....................................................................................................................................... 4 2.1 Product Description ........................................................................................................................ 4 2.2 Related Submittal(s) Grants ........................................................................................................... 5 2.3 Test Methodology .......................................................................................................................... 5 2.4 Test Facility .................................................................................................................................... 5 3.0 System Test Configuration ............................................................................................................................ 6 3.1 Justification .................................................................................................................................... 6 3.2 Measurement Uncertainty .............................................................................................................. 7 3.3 Equipment Modification ................................................................................................................. 7 3.4 Support Equipment List and Description ....................................................................................... 7 4.0 Measurement Results ..................................................................................................................................... 8 4.1 Antenna Requirement: .................................................................................................................... 8 4.2 6 dB Bandwidth: ............................................................................................................................. 9 4.3 Maximum Peak Conducted Output Power ................................................................................... 12 4.4 Peak Power Spectral Density ....................................................................................................... 16 4.5 Out of Band Conducted Emissions .............................................................................................. 20 4.6 Out of Band Radiated Emissions .................................................................................................. 26 4.7 Radiated Emissions in Restricted Bands ...................................................................................... 27 4.8 Band Edges Requirement ............................................................................................................. 39 5.0 Test Equipment List ..................................................................................................................................... 42 Report No.: 141212001GZU-001 Issued: 11 March 2015 FCC ID: 2ADYL-JPD500F Page 3 of 42 1.0 Summary of Test TEST TEST REQUIREMENT TEST METHOD RESULT Antenna Requirement FCC PART 15 C section 15.247 (c) and Section 15.203 FCC PART 15 C section 15.247 (c) and Section 15.203 PASS 6 dB Bandwidth FCC PART 15 C section 15.247 (a)(2) ANSI C63.10: Clause 6.9.1 PASS Maximum Peak Conducted Output Power FCC PART 15 C section 15.247(b)(3) ANSI C63.10: Clause 6.10.2.1 PASS Peak Power Spectral Density FCC PART 15 C section 15.247(e) ANSI C63.10: Clause 6.11.2.3 PASS Out of Band Conducted Emissions FCC PART 15 C section 15.209 &15.247(d) ANSI C63.10: Clause 6.7 PASS Out of Band Radiated Emission FCC PART 15 C section 15.209 &15.247(d) ANSI C63.10: Clause 6.4, 6.5 and 6.6 N/A Radiated Emissions in Restricted Bands FCC PART 15 C section 15.209 &15.247(d) ANSI C63.10: Clause 6.4, 6.5 and 6.6 PASS Band Edges Measurement FCC PART 15 C section 15.247 (d) &15.205 ANSI C63.10: Clause 6.9.2 PASS Conducted Emissions at Mains Terminals FCC PART 15 C section 15.207 ANSI C63.10: Clause 6.2 N/A Remark: N/A: not applicable. Refer to the relative section for the details. EUT: In this whole report EUT means Equipment Under Test. Tx: In this whole report Tx (or tx) means Transmitter. Rx: In this whole report Rx (or rx) means Receiver. RF: In this whole report RF means Radio Frequency. ANSI C63.10: the detail version is ANSI C63.10:2009 in the whole report. Report No.: 141212001GZU-001 Issued: 11 March 2015 FCC ID: 2ADYL-JPD500F Page 4 of 42 2.0 General Description 2.1 Product Description Operating Frequency 2402 MHz to 2480 MHz Type of Modulation: GFSK Number of Channels 40 Channels Channel Separation: 2 MHz Antenna Type Integral Antenna gain: 3 dBi Speciality: Bluetooth 4.0 with BLE (Bluetooth Low Energy) Function: pulse oximeter with BT function to transmit signal Power Supply: DC 3V EUT modulation and data packet during test: The EUT has been tested on the Modulation of GFSK with 1 Mbps data rate. EUT channels and frequencies list: Test frequencies are lowest channel 0: 2402 MHz, middle channel 19: 2440 MHz and highest channel 39: 2480 MHz. Channel Frequency (MHz) Channel Frequency (MHz) Channel Frequency (MHz) 0 2402 14 2430 28 2458 1 2404 15 2432 29 2460 2 2406 16 2434 30 2462 3 2408 17 2436 31 2464 4 2410 18 2438 32 2466 5 2412 19 2440 33 2468 6 2414 20 2442 34 2470 7 2416 21 2444 35 2472 8 2418 22 2446 36 2474 9 2420 23 2448 37 2476 10 2422 24 2450 38 2478 11 2424 25 2452 39 2480 12 …
