2ADYL-JPDHA200CElectronic Blood Pressure Monitor

Version:V1.0 RevisionDate:2025.6 ElectronicBloodPressureMonitor JPD-HA200CUserManual -1- ProductComposition TheproductiscomprisedofthehostmachineandtheUpper-arm-typecuffof ElectronicBloodPressureMonitor(measuredarmcircumference22-36cmor 22-42cm). Intendeduse&IntendedUser&Intendedpatientpopulation TheElectronicBloodPressureMonitorisintendedtomeasurethesystolicand diastolicbloodpressureaswellasthepulserateofadultpersonvianon-invasive oscillometrictechniqueatmedicalfacilitiesorathome.Theintendeduseris professionalorlayuser.Thedeviceisintendedtobeusedbyadultsover12years old. WorkingPrinciple ThisproductisdesignedbasedontheprincipleofOscillographicmethodto measurethebloodpressureofpatients.Inflatablecuffisusedtoblockarterial bloodflowduringtheoscilloscopemeasurement.Becauseofthehemodynamic actionoftheheartbeat,thepulsewavesynchronizedwiththeheartbeatis overlappedonthesleevepressure.Thepulsewavedisappearedwhentheair sleevepressurewasmuchhigherthanthesystolicpressure.Asthesleeve pressuredrops,thepulsebeginstoappear.Whenthecuffpressureishigherthan thecontractionpressuredowntothesystolicpressure,thepulsewavesuddenly increasesandreachesthemaximumvaluewhentheaveragepressureisreached. Thenthepulsewaveattenuateswiththedecreaseofcuffpressure.Thenblood pressureiscalculatedaccordingtotherelationshipbetweenpulsewaveamplitude andthecorrespondingtimesleevepressure. -2- SafetyPrecautions ThewarningsandillustrationsshownintheUserManualenableyouto usetheproductsafelyandcorrectly,thuspreventingyouandothers frombeinginjured,specificallyasfollows: Legend,markandmeaning Warningmessage Anti-electricshockdegreeisTypeBFoftheapplication part Whentheproductlifeexpiresandtheendusersdiscard theproducts,sendthemtothedesignatedcollectingand separatingplacefordisposalaccordingtothe requirementsfromthelocalenvironmentalprotection authority. Consulttheinstructionsforuse. ThisproductcomplieswiththeMDR2017/745 requirements. IP21 Degreeofprotectionagainsttheingressofwater. Informationofmanufacturer Dateofmanufacture AuthorizedEuropeanRepresentative -3- QuickStartGuide Avoidsmoking,eating,drinkingcaffeinateddrinksorexercisingfor30 minutesbeforetakingmeasurement. 1.Situprightinachairwithbothfeetonthefloor. 2.Removetightfittingclothingfromyourupper armalongwithanythickclothing. 3.Pullontheendofthecuffuntilitwraps securelyaroundyourupperarm.Placeyourarm onatablesothatthecuffwillbeatthesamelevel asyourheart. 4.Thecuffwillautomaticallyinflateandthe measurementwillstart,uponpressingthe “”button. 5.Whenthemeasurementiscomplete,the cuffwillautomaticallydeflateandyour systolicanddiastolicpressurevaluesand pulseratewillbedisplayed. MedicalDevice InformationofImporter -4- 1.Overview 1.1Monitor 1.2Features UniversalCuff Autopoweroff Averageoflast3readings IrregularHeartbeatDetector  AtrialFibrillationDetection(AFib)  199Readings*2Users(withguestmode) Operatedby4AAAbatteries(USB5Voptional) Backlight(Optional) -5- 1.3Display 1.4PackingList No.NameQuantit6y 1ElectronicBloodPressureMonitor1 2Cuff1 3DryBattery(AAA)4 4UserManual1 5Easy-to-carryStorageBag1 -6- 2.Preparation 2.1BatteryInstallation a)Openthebatterycoverasshown inthepicture. b)Place4AAAdrybatteries.Pay attentiontothebatteryelectrodeindication. 2.2Batterypowerindicationandreplacement Aftertheproductisturnedon,iflowpowersymbolappearsonthe screen,themeasurementcannotbeperformed,andthebatterymustbe replaced. Donotuseanyexpiredbattery; Iftheproductisnotusedforover3months,pleasetakeoutthe batteries. 2.3USBPowerSupply USBlinecanbeconnectedforpowersupplyoftheproductwithout battery. IfneedconnectSeparatepowersupply,pleasenotethefollowing: 1)Output:DC5V;0.5A. 2)Ratedinputvoltageshallnotexceed500V. -7- 3)Classificationofprotectionagainstelectricshock:ClassII Note:PleaseselecttheUSBpowersupplythatissuppliedbythe manufacturerorthatcomplieswiththerelevantsafetystandards(e.g. IEC62368andIEC60601-1). 2.4Cuff Theapplicablearmcircumferencerangeofthecuffis22-36cmor 22-42cm. Connection:Inserttheairplugofcuffairtubeintoairjackofthe ElectronicBloodPressureMonitor.Figureshownasabove: 8 3.FunctionSettingMode 3.1UserMode  Intheshutdownstate,pressthe"User"buttontoswitchtothe otheruser.(defaultuser:User1) (Note:Intheshutdownstate,press“User”buttontoviewthe currenttimeandthecurrentuser) 3.2Year/Month/Date/TimeSetting 1)YearSetting:  Intheshutdownstate,longpressthe"User"buttontoenterthe yearsettingmode.Thescreenshow"20XX"andblink. Pressthe"Memory"buttontoadjustyearsvalues. Pressthe"User"buttontoconfirmandentertotheMonth setting. Note:Thedevicemayautomaticallyentertheyearsettingmodeafter batteryreplacementandpower-on. 2)MonthSetting:  Thescreenshows"XX-XX"andmonthvaluesblink. 9 Press"Memory"toadjustmonthvaluesbetween1to12. Pressthe"User"buttontoconfirmandentertotheDate setting. 3)DateSetting: Thescreenshows"XX-XX"anddatevaluesblink.  Press"Memory"toadjustdatevaluesbetween01and31. Pressthe"User"buttontoconfirmandentertotheTime setting. 4)TimeSetting: Thescreenshows"XX:XX"(Timevalueflashing).  Press"Memory"toadjusthoursvaluesbetween01and23, thenadjustminutesvaluesbetween00and59. Pressthe"User"buttontoconfirmandentertotheTalking functionsetting. Note:Whensettingtimevalues,holdthe"Memory"buttonto quicklyadjustvalues.Whenthemaximumvalueisreached,thesetting willresettotheminimumvalue. 10 3.3Talkingfunctionsetting(voiceversiononly)  AfterenteringtheTalkingfunctionsettingmode,thescreenshows “”attheSYSarea,withthecurrentvoicestatus“”/“ ” and voiceicon(notdisplayed,whentalkingfunctionmodeisoff)attheDIA area.  Pressthe“Memory”buttontoswitchthevoicestatus,and pressthe“User”buttonforconfirmationandentertheunit displaysetting. 3.4Unitsetting Afterenteringtheunitsettingmode,thescreenshows“”atthe SYSareaandunitareawilldisplaymmHg,itmeanstheunitmmHgis selected(systemdefaultunit:mmHg), Pressofthe“Memory”buttontoswitchtheunitandpressthe “User”buttontoconfirmationandsavetheunitsetting. 11 4.1Howtousethecuff (1)Placethecuffflatonthetable,leavethehook&loopdownwards, andpasstheendofcuffthroughthemetalringtoform…
