2AE77DGU-6E14-N3MGN AVN

MODEL NAME User Manual Thank you for purchasing this multimedia system. This user manual explains how to use the multimedia system. Before using the product, read the contents of this user manual carefully. Please use this product safely. Before using the product, read the contents of this user manual carefully. Please use this product safely. ※The design and specification of this product may change without prior notification for the purpose of product improvement. Notations used in this User Manual WARNING Failure to observe the safety instructions within this category could result in serious injury or death. CAUTION Failure to observe the safety instructions within this category could result in accident related injuries or damage to the vehicle. Information Information and tips that provides additional user convenience in using the product i Read the following safety cautions for your safety. Note Information on specific features that facilitate proper product use and functional understanding. Information on terminology used within this manual. Table of Contents General Warnings and Cautions Trademark Key Product Features Warnings and Cautions Trademark Key Product Features Component Names and Functions Starting the System for the First Time General Warnings and Cautions Even when receiving route guidance from the Navigation system, please abide by actual traffic and road regulations. Following only the Navigation route guidance may lead to violations of actual traffic and road regulations and lead to traffic accidents. When checking the current vehicle speed, first check the speedometer rather than the speed displayed within the Navigation. Do not stare at the screen while driving. Staring at the screen for prolonged periods of time could lead to traffic accidents. Do not operate the Navigation system while driving, such as entering POIs or conducting route searches. Such acts could lead to accidents.Park the vehicle before operating the device. Do not disassemble, assemble, or modify the AVN system. Such acts could result in accidents, fire, or electric shock. Using phone features while driving may distract drivers from paying attention to traffic conditions and result in traffic accidents. Use phone features only after the vehicle has been parked. Heed caution not to spill water or introduce foreign objects into the device. Such acts could lead to smoke, fire, or product malfunction. Please refrain from use if the screen is blank or no sound can be heard as these signs may indicate product malfunction. Continued use in such conditions could lead to accidents (fires, electric shock) or product malfunctions. Do not touch the antenna during thunder or lightening as such acts may lead to lightning induced electric shock. Do not stop or park in parking-restricted areas to operate the product. Such acts could lead to traffic accidents. The video screen will not operate when the vehicle is in motion. For your safety, first park the vehicle to watch or view the screen. Some Non-video features may also not operate when the vehicle is in motion. These features will operate only when the vehicle has been parked. WARNING Warnings and Cautions CAUTION In some instances, the navigation may provide guidance through restricted areas. Operating the device while driving could lead to accidents due to a lack of attention to external surroundings. First park the vehicle before operating the device. In addition, some features may not work for your safety when the vehicle is in motion. These features will operate only when the vehicle has been parked. Adjust the volume to levels that allow the driver to hear sounds from outside of the vehicle. Driving in a state where external sounds cannot be heard may lead to accidents. Pay attention to the volume setting when turning the device on. A sudden output of extreme volume upon turning the device on could lead to hearing impairment. (Adjust the volume to a suitable levels before turning off the device.) If you want to change the position of device installation, please inquire with your place of purchase or service maintenance center. Technical expertise is required to install or disassemble the device. Turn on the car ignition before using this device. Do not operate the Audio Video Navigation system for long periods of time with the ignition turned off as such operations may lead to battery discharge. Upon using the Audio Video Navigation system for more than 10 minutes with the car engine turned off, the following warning will be displayed. After 10 minutes, the warning will be displayed for 5 seconds every 1 minute. Do not subject the device to severe shock or impact Direct pressure onto the front side of the monitor may cause damage to the LCD or touch screen. When cleaning the device, make sure to turn off the device and use a dry and smooth cloth. Never use tough materials, chemical cloths, or solvents (alcohol, benzene, thinners, etc.) as such materials may damage the device panel or cause color/quality deterioration. When experiencing product malfunctions, inquire with your place of purchase or service maintenance center. CAUTIONS for Using SD Cards Ejecting and Inserting SD Cards •Ejecting and inserting SD cards while the multimedia system is operating may result in SD Card or System errors. To eject or insert the SD card, first turn off the multimedia system and the vehicle ignition. •Eject/insert SD cards only to update the multimedia system with a new version. Use of SD Cards •SD cards are formatted to include only Map and new system update files. •SD cards cannot be used to save and play music. •Do not add, delete or format files on the SD card. Trademark iPod® is a registered trademark of Apple Inc. iPod® The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks is under license. A Bluetooth® enabled cell phone is required to use Bluetooth® wireless technology. A …

Text truncated - open the document above for the full version.

DIGEN 89, Seongseo4chacheomdan-ro, Dalseo-gu, Daegu, 704-801, Korea Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Subject: Request for Confidentiality FCC ID: 2AE77DGU-6E14-N3 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematics / Block Diagram / Operational Description / Parts List A bove mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. 2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting the commission to grant short-term confidentiality request on the following attachments until 180 days External Photos / Internal Photos / Test Setup Photos / User Manual It is our understanding that all measurement test reports, FCC ID label format and correspondence during certification review process cannot be granted as confidential documents and such information will be available for public review once the grant of equipment authorization is issued. Sincerely Yours, J ong-Sun, Park / Manager DI GEN

DIGEN 89, Seongseo4chacheomdan-ro, Dalseo-gu, Daegu, 704-801, Korea Date: Nov 4, 2015 Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 c.c. Timco Engineering, Inc. Certification Division 849 N.W. State Road 45 P.O. Box 370 Newberry, Florida 32669 USA To whom it may concern: I, the undersigned, hereby authorize Technical Manager Issac Jin of MOVON CORPORATION and hereafter referred to as MOVON CORPORATION, to act on our behalf in all manners relating to application for equipment authorization, including signing of all documents relating to these m atters. Any and all acts carried out by Technical Manager Issac Jin of MOVON CORPORATION on our behalf shall have the same effect as acts of our own. I, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). In authorizing MOVON CORPORATION as our agent, we still recognize that we are responsible to: a) comply with the relevant provisions of the certification program; b) make all necessary arrangements for the conduct of the evaluation, including provision for examining documentation and access to all areas, records (including internal audit reports) and personnel for the purposes of evaluation (e.g. testing, inspection, assessment, surveillance, reassessment) and resolution of complaints; c) make claims regarding certification only in respect of the scope for which certification has been granted; d) do not use our product certification in such a manner as to bring the Certification Division into disrepute and not make any statement regarding our product certification which the Certification Division may consider misleading or unauthorized; DIGEN 89, Seongseo4chacheomdan-ro, Dalseo-gu, Daegu, 704-801, Korea e) upon suspension or cancellation of certification, discontinue use of all advertising matter that contains any reference thereto and return any certification documents as required by the Certification Division; f) use certification only to indicate the products are certified as being in conformity with specified standards; g) endeavor to ensure that no certificate or report nor any part thereof is used in a misleading manner; h) ensure that any reference to our product certification in communication media such as documents, brochures or advertising, complies with the requirements of the Certification Division; i) keep a record of all complaints made known to the us relating to the product’s compliance with requirements of the relevant standard and to make these records available to the Certification Division when requested; j) take appropriate action with respect to such complaints and any deficiencies found in products or services that affect compliance with the requirements for certification; k) document the actions taken. This authorization is valid until further written notice from the applicant. Sincerely Yours, Jong-Sun, Park / Manager DIGEN REMARK: 1. This authorization letter will be sent along with your application when filing with the Certification Division. 2. Please follow the format and type it on company letterhead and send original to us. 3. Authorized signature must be in agreement with grantee code contact in FCC database.

Label Information Model name: DGU-6E14-N3 FCC ID: 2AE77DGU-6E14-N3 Label Location Label

Internal photos of EUT (DGU-6E14-N3) Bluetooth antenna Top view of Main PCB Bottom view of Main PCB Top view of Front PCB Bottom view of Front PCB Top view of LCD Bottom view of LCD Top view of Bluetooth PCB Bottom view of Bluetooth PCB Top view of TF Card PCB Bottom view of TF Card PCB Top view of Cd-rom Bottom view of Cd-rom

MOVON CORPORATION Report Number: MOV-15-RF-I085 FCC Part 15 Subpart C §15.247 Test Report Equipment Under Test M G N AV N Model Name DGU-6E14-N3 Variant Model Name DGU-6E14-B3 Applicant DIGEN FCC ID 2AE77DGU-6E14-N3 Manufacturer DIGEN Date of Test(s) 2015.11.04 ~ 2015.11.10 Date of Issue 2015.11.11 In the configuration tested, the EUT complied with the standards specified above. Issue to Issue by DIGEN 89, Seongseo4chacheomdan-ro, Dalseo-gu, Daegu, 704-801, Korea Te l . : +82-70-4850-3322 Fax: +82-2-532-8811Fax: +82-2-517-5574 MOVON CORPORATION 498-2, Geumeo-ro, Pogok-eup, Cheoin-gu, Yongin-si, Gyeonggi-do, Korea, 449-812 Tel.: +82-31-338-8837 Fax: +82-31-338-8847 Page : (1) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 Revision history Revision Date of issue Description Revised by -- Nov 11, 2015 Initial -- Page : (2) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 Table of contents 1. ATTESTATION OF TEST RESULT ................................................................................ 4 2. EUT DESCRIPTION ........................................................................................................ 6 3. MEASUREMENT EQUIPMENT ...................................................................................... 7 4. TRANSMITTER RADIATED SPURIOUS EMISSIONS AND CONDUCTED SPURIOUS EMISSIONS .................................................................................................................. 8 5. 6 ㏈ BANDWIDTH ....................................................................................................... 23 6. MAXIMUM OUTPUT POWER MEASUREMENT .......................................................... 26 7. POWER SPECTRAL DENSITY MEASUREMENT ....................................................... 29 8. ANTENNA REQUIREMENT ......................................................................................... 32 9. RF EXPOSURE EVALUATION .................................................................................... 33 Page : (3) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 1. Attestation of test result 1.1. Details of applicant & Manufacturer Applicant / Manufacturer : DIGEN Address : 89, Seongseo4chacheomdan-ro, Dalseo-gu, Daegu, 704-801, Korea Contact Person : Jong-Sun, Park Telephone : +82-70-7100-1706 Fax : +82-2-532-8811 Page : (4) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 2. EUT Description Kind of product MG N AVN FCC ID 2AE77DGU-6E14-N3 Model Name DGU-6E14-N3 Variant Model DGU-6E14-B3 Serial Number N/A Power supply DC 14.4 V Frequency range 2 402 ㎒ ~ 2 480㎒ Modulation technique GFSK Number of channels 40 Antenna gain 2.07㏈i (Max.) Test Site Registration Number FCC(670686) 2.1. Declarations by the manufacturer None 2.2. Details of modification None Page : (6) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 3. Measurement equipment Equipment Manufacturer Model Serial number Calibration Interval Calibration due. Test Receiver R&S ESVS30 829673/015 1 year 2016-05-12 Signal Generator R&S SMA100A 102188 1 year 2016-09-23 Spectrum Analyzer R&S FSV-40 100832 1 year 2016-03-06 Power Meter Agilent E4416A GB41290645 1 year 2016-09-23 Power Sensor Agilent 9327A US40441490 1 year 2016-03-05 Horn Antenna R&S HF906 100236 2 year 2017-07-24 Horn Antenna R&S HF906 100235 2 year 2017-04-23 Biolog Antenna A.H.System SAS-521-7 127 2 year 2017-11-02 Power Amplifier MITEQ AM-1431 1497315 1 year 2016-09-24 Power Amplifier MITEQ AFS43-01002600 1374382 1 year 2016-09-24 High Pass Filter Wainwright WHK3.0/18G-10SS 508 1 year 2016-09-23 Controller INNCO CO2000 co200/064/6961003/L N/A N/A Antenna Master INNCO MA4000 MA4000/038/6961003/L N/A N/A Loop Antenna ETS LINDGREN 6502 00118166 2 year 2017-04-20 ※ Remark; Support equipment Description Manufacturer Model Serial number Notebook computer DELL Lattitude D510 - Page : (7) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 4. Transmitter radiated spurious emissions and conducted spurious emissions 4.1. Test setup 4.1.1. Transmitter radiated spurious emissions The diagram below shows the test setup that is utilized to make the measurements for emission from 9kHz to 30MHz Emissions. The diagram below shows the test setup that is utilized to make the measurements for emission from 30 ㎒ to 1 ㎓ emissions. Page : (8) of (33) The results shown in this test report refer only to the sample(s) tested unless otherwise stated. This test report cannot be reproduced, except in full, without the written approval of MOVON CORPORATION. MOVON CORPORATION Report Number: MOV-15-RF-I085 The diagram below shows the test setup that is utilized to make the measurements for emission from 1 ㎓ to 40 ㎓ emissions. 4.2. Limit According to §15.247(d), in any 100 ㎑ bandwidth outside the frequen…

Text truncated - open the document above for the full version.

Test setup photo of EUT Photo of radiated spurious emission at below 30 ㎒ Photo of radiated spurious emission at 30 ㎒ ~ 1 000 ㎒ Photo of radiated spurious emission at above 1 000 ㎒
