2AEOCPC212Mobile 4W AM/FM CBRS Transceiver

Owner’s manual / Manual del usuario Manuel d’utilisation / Manual do usuário 12/24 V Un vistazo a vuestro PRESIDENT HARRISON FCCYour PRESIDENT HARRISON FCC at a glance Votre PRESIDENT HARRISON FCC en un coup d'œil Uma olhada no seu PRESIDENT HARRISON FCC 3 SOMMAIRE INSTALLATION ..........................................................................................36 UTILISATION ..............................................................................................38 FONCTIONS AVEC LA PÉDALE D’ÉMISSION PTT ....................................42 MENUS .....................................................................................................42 CARACTÉRISTIQUES TECHNIQUES ..........................................................47 GUIDE DE DÉPANNAGE ..........................................................................47 COMMENT ÉMETTRE OU RECEVOIR UN MESSAGE ..............................48 GLOSSAIRE ..............................................................................................48 CONDITIONS GÉNÉRALES DE GARANTIE ..............................................50 TABLEAUX DES FRÉQUENCES ..................................................................67 SUMARIO INSTALACIÓN .........................................................................................20 UTILIZACIÓN ...........................................................................................22 FUNCIONES CON LA PALANCA DE EMISIÓN PTT ................................26 MENÚS ....................................................................................................27 CARACTERÍSTICAS TÉCNICAS ...............................................................31 GUÍA DE PROBLEMAS ............................................................................32 COMO EMITIR O RECIBIR UN MENSAJE ...............................................32 LÉXICO ....................................................................................................32 CONDICIONES GENERALES DE GARANTÍA .........................................34 TABLAS DE FRECUENCIAS ......................................................................67 SUMMARY INSTALLATION ...........................................................................................5 HOW TO USE YOUR TRANSCEIVER ..........................................................7 FUNCTIONS WITH THE PTT SWITCH ........................................................11 MENU ......................................................................................................11 TECHNICAL CHARACTERISTICS .............................................................15 TROUBLE SHOOTING ..............................................................................16 HOW TO TRANSMIT OR RECEIVE A MESSAGE .....................................16 GLOSSARY ..............................................................................................16 GENERAL WARRANTY CONDITIONS .....................................................18 FREQUENCY TABLES ...............................................................................67 Français Español English SUMÁRIO INSTALAÇÃO ...........................................................................................52 UTILIZAÇÃO .............................................................................................54 FUNÇÕES COM A ALAVANCA DE EMISSÃO PTT ..................................58 MENUS .....................................................................................................58 CARACTERÍSTICAS TÉCNICAS ................................................................62 GUIA DE PROBLEMAS .............................................................................63 COMO TRANSMITIR OU RECEBER UMA MENSAGEM ...........................63 GLOSSÁRIO .............................................................................................63 CONDIÇÕES GERAIS DE GARANTIA .....................................................66 TABELAS DE FREQUÊNCIAS .....................................................................67 Português 4 English WARNING ! Before using, be careful never to transmit without first having connected the antenna (connection “B” situated on the back panel of the equipment) or without having set the SWR (Standing Wave Ratio)! Failure to do so may result in destruction of the power amplifier, which is not covered by the warranty. The warranty of this transceiver is valid only in the country of purchase. WARNING: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other repro- ductive harm. For more information go to www.P65Warnings.ca.gov. AVERTISSEMENT : Ce produit peut vous exposer à des agents chimiques, y compris le plomb, identifiés par l’État de Californie comme pouvant causer le cancer et des malformations congénitales ou autres effets nocifs sur la reproduction. Pour de plus amples informations, prière de consulter le site www.P65Warnings.ca.gov. 5 Welcome to the world of the new generation of CB radios. The new PRESIDENT range gives you access to top performance transceiver equipment. With the use of up-to-date technology, which guarantees unprecedented quality, your PRESIDENT HARRISON FCC is a new step in personal communication and is the surest choice for the most demanding of professional CB radio users. To ensure that you make the most of all its capacities, we advise you to read carefully this manual before installing and using your PRESIDENT HARRISON FCC. A) INSTALLATION 1) WHERE AND HOW TO MOUNT YOUR MOBILE CB RADIO a) You should choose a well ventilated place most appropriate setting from a simple and practical point of view. b) Your CB radio should not interfere with the driver or the passengers. c) Remember to provide for the passing and protection of different wires (e.g. power, antenna, accessory cabling) so that they do not in any way interfere with the driving of …

Text truncated - open the document above for the full version.

© Celltech Labs Inc – 2022 ______________________________________________________________________________________ 21-364 Lougheed Road, Kelowna, British Columbia, Canada V1X 7R8 Tel: 1-250-765-7650 Fax: 1-250-765-7645 Date: 1 December 2022 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Rd. Columbia, MD 21046 RE: New Certification Request, FCC ID: 2AEOCPC212 Dear FCC Representative This is a new certification request of FCC ID: 2AEOCPC212, Model: Harrison FCC. The Walker III FCC is a Mobile 4W, AM/FM CBRS transceiver. In accordance with FCC 47 CFR Part 2, Subpart J, this Equipment is subject to certification to FCC 47 CFR Part 95, Subpart D. In addition, this Equipment receives weather channels in the 162.400 to 162.550MHz band. In accordance with FCC 47 CFR §15.101(a)(b), both the CBRS and weather receivers are subject to certification, Equipment Class CXX.. As per FCC 47 CFR §2.1091, an RF Exposure evaluation (MPE) is required for this Equipment. This Equipment is capable of Voice Activated Transmission (VOX), a 75% transmit duty factor applies. The results of the RF Exposure evaluation appear in a separate report accompanied with this application. Should there be any questions or concerns please feel free to contact me. Thank you for your consideration. Sincerely, Art Voss, P.Eng.

Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 10 of 33 EXHIBIT 21 – PHOTOS – DUT EXTERNAL AND SAR DUT Figure E21.1 – External, Top Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 11 of 33 Figure E21.2 – External, Bottom Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 12 of 33 Figure E21.3 – External, Front Figure E21.4 – External, Back Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 13 of 33 Figure E21.5 – External, Left Figure E21.6 – External, Right

Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 7 of 33 EXHIBIT 13 – LABEL SAMPLE Figure E13.1 – Label Sample 2AEOCPC212 2AEOCPC212

Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 8 of 33 EXHIBIT 14 – LABEL LOCATION Figure E14.1 – Label Location

Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 14 of 33 EXHIBIT 22 – PHOTOS – DUT INTERNAL Figure E22.1 – Internal, Bottom Removed Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 15 of 33 Figure E22.2 – Internal, Shields Removed Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 16 of 33 Figure E22.3 – Internal, Top Removed Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 17 of 33 Figure E22.4 – Internal, Top and Bottom Covers Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 18 of 33 Figure E22.5 – Internal, Top and Bottom Covers Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 19 of 33 Figure E22.6 – Internal, Front Components Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 20 of 33 Figure E22.7 – Internal, Front Components Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 21 of 33 Figure E22.8 – Internal, Back Panel

Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 5 of 33 EXHIBIT 11 –FCC RF EXPOSURE (MPE) REPORT 180 f 2 S 20 = S L = S C = R 20 = R c = P T = P A = G N = f = (%) (dB) R C = S C = FCC ID: 2AEOCPC212RESULT: 45cm (mW/cm 2 ) Power Density of the Device at 20cm Prediction of MPE Limit 47 CFR § 2.1091 S 20 = P A G N R C = √ P A G N S C = P A G N 4 πR C 2 4 π S L 4 πR 20 2 S L = S L = Duty Cycle/Loss Adjusted Power (P A ): Transmit Frequency Transmit Duty Cycle = (dBi) Tx Frequency (f): RF Power at Antenna Input Port (P T ): Transmit Duty Cycle: Use Group = General Popuation 4000.00 75.00 27.41 0.240 (mW/cm 2 ) (mW) 44.6 (cm) (mW/cm 2 ) 0.24 (mW/cm 2 ) 75% Power Density Limit Minimum Distance to the Radiating Element to Meet Compliance Power Density of the Device at the Compliance Distance R C 20cm This device is capable of Voice Activated Transmission (VOX). S 20 at 20cm = 1.191 Power Input to Antenna Numeric Gain of the Antenna (MHz) Antenna Gain:3.00 (numeric) 3000.00(mW) Cable or Other Loss:0.00 Numeric Antenna Gain (G N ): 2.00 Adjust Power

USA Product Model Number / HVINProduct Name / PMN Harrison FCCHarrison FCC 2AEOCPC21220240-PC212 In Accordance With: 1616 Approved By: FCC ID:IC Registration Number Applicant: RSS-GEN, RSS-236 Issue 2 1007 Collier Center Wa y Naples, FL, 34110 © 2022 Celltech Labs Inc, This report shall not be reproduced in any form without the expressed written consent of Celltech Labs Inc. Citizen Band (26.960 to 27.410 MHz) FCC 47 CFR Part 95 Subpart D, Part 15 Subpart B Licensed Non-Broadcast Station Transmitter (TNB) FCC Registration: CA3874 Ben Hewson, President Celltech Labs Inc. IC Registration 3874A 21-364 Lougheed Rd. Kelowna, BC, V1X 7R8 Canada Test Lab Certificate: 2470.01 President Electronics USA Test Report Serial Number: Test Report Date: EMC Test Report - New Filing 45461772 R3.0 Project Number: 13 December 2022 Test Report S/N: 45461772 R3.0 Test Report Issue Date: 13 December 2022 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 2 of 71 Table of Contents 1.0 REVISION HISTORY ........................................................................................................................................................ 5 2.0 CLIENT AND DUT INFORMATION .................................................................................................................................. 6 3.0 SCOPE .............................................................................................................................................................................. 7 4.0 TEST RESULT SUMMARY .............................................................................................................................................. 8 5.0 NORMATIVE REFERENCES ......................................................................................................................................... 10 6.0 FACILITIES AND ACCREDITATIONS ........................................................................................................................... 11 7.0 CONDUCTED POWER ................................................................................................................................................... 12 8.0 MODULATION RESPONSE ........................................................................................................................................... 20 9.0 OCCUPIED BANDWIDTH AND EMISSION MASKS ..................................................................................................... 27 10 CONDUCTED OUT OF BAND SPURIOUS EMISSIONS ............................................................................................... 35 11.0 RADIATED SPURIOUS TX EMISSIONS ..................................................................................................................... 41 12.0 RADIATED SPURIOUS RX EMISSIONS ..................................................................................................................... 56 13.0 FREQUENCY STABILITY ............................................................................................................................................. 62 APPENDIX A – TEST SETUP DRAWINGS AND EQUIPMENT .......................................................................................... 65 APPENDIX B – EQUIPMENT LIST AND CALIBRATION ..................................................................................................... 70 APPENDIX C – MEASUREMENT INSTRUMENT UNCERTAINTY ..................................................................................... 71 END OF REPORT ................................................................................................................................................................. 71 Table of Figures Figure A.1 – Test Setup Conducted Measurements ............................................................................................................. 65 Figure A.2 – Test Setup Audio Modulation Response Measurements ................................................................................. 66 Figure A.3 – Test Setup Radiated Emissions Measurements Below 30MHz ....................................................................... 67 Figure A.4 – Test Setup Radiated Emissions Measurements 30-1000MHz ........................................................................ 68 Figure A.5 – Test Setup Radiated Emissions Measurements 30-1000MHz ........................................................................ 68 Figure A.6 – Test Setup Frequency Stability Measurements ............................................................................................... 69 Test Report S/N: 45461772 R3.0 Test Report Issue Date: 13 December 2022 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 3 of 71 Table of Plots Plot 7.1 – Conducted Output Power, Channel 1, AM ........................................................................................................... 13 Plot 7.2 – Conducted Output Power, Channel 20, AM ......................................................................................................... 14 Plot 7.3 – Conducted Output Power, Channel 40, AM ......................................................................................................... 15 Plot 7.4 – Conducted Output Power, Channel 1, FM ............................................................................................................ 16 Plot 7.5 – Conducted Output Power, Channel 20, FM .......................................................................................................... 17 Plot 7.6 – Conducted Output Power, Channel 40, FM .......................................................................................................... 18 Plot 8.1 – Audio Frequency and Low Pass Filter Response, AM ...........…

Text truncated - open the document above for the full version.

Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 22 of 33 EXHIBIT 23 – PHOTOS – EMC SETUP Figure E23.1 – Setup, Conducted Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 23 of 33 Figure E23.2 – Setup, Audio Response Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 24 of 33 Figure E23.3 – Setup, Audio Response Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 25 of 33 Figure E23.4 – Setup, Radiated with Accessories Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 26 of 33 Figure E23.5 – Setup, Radiated with Accessories Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 27 of 33 Figure E23.6 – Setup, Radiated Below 30MHz without Accessories Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 28 of 33 Figure E23.7 – Setup, Radiated Below 30MHz with Accessories Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 29 of 33 Figure E23.8 – Setup, Radiated Above 30MHz without Accessories Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 30 of 33 Figure E23.9 – Setup, Radiated Above 30MHz with Accessories Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 31 of 33 Figure E23.10 – Setup, Frequency Stability Applicant: President Electronics FCC ID: 2AEOCPC212 Test Report S/N: 45461772 R2.0 ISED ID 20240-PC212 ©2022 Celltech Labs Inc. This document is not to be reproduced in whole or in part without the expressed written permission of Celltech Labs Inc. Page 32 of 33 Figure E23.11 – Setup, Frequency Stability
