2AEP6XM-JPV1-1Raindrop Camera

FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a re sidential installation. This equipment generates, uses and ca n radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, th ere is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception , which can be determined by turning the equipment off and on, the user is encourag ed to try to correct the interference by one or more of the following measures: -Reorient or relocate th e receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. To assure continued compliance, any changes or modifications not expressly approved by the party. Responsible for compliance could void the user’s authority to operate this equipment. (Example- use only shielded interface cab les when connecting to computer or peripheral devices). This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, incl uding interference that may cause undesired operation. RF warning statement: The device has been evaluated to meet general RF exposure requir ement. The device can be used in portable exposure condition wi thout restriction.

Model Declaration Letter For FCC ID: 2AEP6XM-JPV1-1 We, the undersigning company Company Name: HangZhou XiongMai Technology CO., LTD Address: 9th Floor, Building 9, Yinhu Innovation Center, No.9 FuXian Road, YinHu Street, Hangzhou, China Hereby confirm that the following products: Product description: Raindrop Camera Type designation: XM-JPV1-1, XM-JPV1-1F, XM-JPV1-1R Trade name or Brand(s): XM That All models are identical in the same PCB layout, interior structure and electrical circuits, The only difference is model name for commercial purpose. City and Country: Date: Name: Function: Signature: HangZhou 07/24/2015 Ping Yao Manager

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 5.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (current) 4.0 5.0 Sept 16 2014 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 5.0 HangZhou XiongMai Technology CO., LTD 2015-07-24 To: SIEMIC, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, _____ HangZhou XiongMai Technology CO., LTD ____hereby authorize SIEMIC, Inc. to act as a Certification Body for certifying for the following project(s): (Raindrop Camera, XM-JPV1-1, XM-JPV1-1F, XM-JPV1-1R) FCC ID: 2AEP6XM-JPV1-1 Sincerely, Client’s signature Client’s name / title Ping Yao / Manager Contact information / address 9th Floor, Building 9, Yinhu Innovation Center, No.9 FuXian Road, YinHu Street, Hangzhou, China

HangZhou XiongMai Technology CO., LTD SCS-F19: Confidentiality Request Letter Page 1 of 2 Rev 4.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (current) 3.0 4.0 March-26-2015 HangZhou XiongMai Technology CO., LTD SCS-F19: Confidentiality Request Letter Page 2 of 2 Rev 4.0 2015-07-24 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AEP6XM-JPV1-1 We hereby request confidential treatment of information accompanying this application as outlined below: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 & 0.459 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature : Ping Yao Client’s name & title : Manager Contact information / address: 9th Floor, Building 9, Yinhu Innovation Center, No.9 FuXian Road, YinHu Street, Hangzhou, China

To whom We hav e 13 opera Please c h Compan y Address : Name / Tit Signature Phone : 0 0 Email : laif Date : 201 H m it may conc e declared be ating capabilit heck Produc t Produc t Howeve Produc t And me Pls exp Others Pls ex p Name: HangZh 9th Floor, Build tle : Ping Yao / M : 086-755-265093 fang@xiongmai 15-07-24 angZho WIF cern : elow featured ty for FCC ID t hardware does t hardware has er , these 2 cha t hardware has eeting KDB 594 plain detail here plain detail here hou XiongMai Te ding 9, Yinhu In Mana ger 301 itech.com u Xiong I Channel for FCC equ D : 2AEP6XM-J s not have the c the capability to annels will be dis the capability to 280 D01 requir . . echnology CO., novation Cente gMai Tec 12 & 13 De uipment autho JPV1-1 capability to ope o operate on ch sabled via softw o operate on ch ement. , LTD er, No.9 FuXian chnolog eclaration orization in re erate on channe hannel 12 & 13. ware and user w hannel 12 & 13. Road, YinHu S gy CO., L Letter egard to 802. el 12 & 13 will not able to e Street, Hangzho LTD .11b/g/n chan enable these 2 c u, China nnel 12 & channels

Report No.: TB-FCC144820 Page: 3 of 11 TB-RF-075-1.0 Appendix III EUT External Photographs Photo 1 Appearance of EUT Photo 2 Appearance of EUT Report No.: TB-FCC144820 Page: 4 of 11 TB-RF-075-1.0 Photo 3 Appearance of EUT Photo 4 Appearance of EUT Report No.: TB-FCC144820 Page: 5 of 11 TB-RF-075-1.0 Photo 5 Appearance of EUT Photo 6 Appearance of EUT

Report No.: TB-FCC144820 Page: 2 of 11 TB-RF-075-1.0 Appendix II ID Label Location ID LOCATION

Report No.: TB-FCC144820 Page: 1 of 11 TB-RF-074-1.0 Appendix IFCC ID Label FCC ID: 2AEP6XM-JPV1-1 Raindrop Camera HangZhou XiongMai Technology CO., LTD This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Model: XM-JPV1-1

Report No.: TB-FCC144820 Page: 6 of 11 TB-RF-075-1.0 Appendix IV EUT Internal Photographs Photo 7 Internal of EUT Photo 8 Internal of EUT Report No.: TB-FCC144820 Page: 7 of 11 TB-RF-075-1.0 Photo 9 Internal of EUT Photo 10 Appearance of PCB 2.4G PCB Antenna Report No.: TB-FCC144820 Page: 8 of 11 TB-RF-075-1.0 Photo 11 Appearance of PCB Photo 12 Appearance of PCB Report No.: TB-FCC144820 Page: 9 of 11 TB-RF-075-1.0 Photo 13 Appearance of PCB Photo 14 Appearance of PCB

Shenzhen Toby Technology Co., Ltd. Report No.: TB-MPE144821 Page: 1 of 3 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 RF Exposure Evaluation FCC ID: 2AEP6XM-JPV1-1 1. Client Information Applicant : HangZhou XiongMai Technology CO., LTD. Address : 9th Floor, Building 9, Yinhu Innovation Center, No.9 FuXian Road, YinHu Street, Hangzhou, China Manufacturer : HangZhou XiongMai Technology CO., LTD. Address : 9th Floor, Building 9, Yinhu Innovation Center, No.9 FuXian Road, YinHu Street, Hangzhou, China 2. General Description of EUT EUT Name : Raindrop Camera Models No. : XM-JPV1-1, XM-JPV1-1F, XM-JPV1-1R Model difference : All models are identical in the same PCB layout, interior structure and electrical circuits, the only difference is model name for commercial purpose. Product Description : Operation Frequency: 802.11b/g/n(HT20): 2412MHz~2462MHz 802.11n(HT40): 2422MHz~2452MHz Number of Channel: 802.11b/g/n(HT20):11channels 802.11n(HT40): 7 channels Max Peak Output Power: 802.11b: 8.65 dBm 802.11g: 8.39 dBm 802.11n (HT20): 8.64 dBm 802.11n (HT40): 8.24 dBm Antenna Gain: 2 dBi PCB Antenna Modulation Type: 802.11b: CCK, DQPSK, DBPSK 802.11g: 64-QAM,QPSK,BPSK 802.11n: 64-QAM,16-QAM,QPSK,BPSK Power Supply : DC Voltage supplied from AC/DC adapter Power Rating : AC/DC Adapter: Input: AC 100~240V, 50/60 Hz, 150mA Output: DC 5V 1000mA Connecting I/O Port(S) : Please refer to the User's Manual Note: More test information about the EUT please refer the RF Test Report. Report No.: TB-MPE144821 Page: 2 of 3 TB-RF-074-1.0 SAR Test Exclusion Calculations 1. FCC: According to KDB 447498 D01 Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies v05r02. (1) Clause 4.3: General SAR test reduction and exclusion guidance Sub clause 4.31: Standalone SAR test exclusion considerations 1) The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6GHz at test separation distance≤5 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤3.0 for 1-g SAR [(max. power of channel, including tune-up tolerance, mW)/(min. test separation, mm)]*[√f (GHz) ] ≤7.5.0 for 10-g SAR Report No.: TB-MPE144821 Page: 3 of 3 TB-RF-074-1.0 2. Calculation: Test separation: 5mm 802.11b Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.412 8.53 ±0.5 7.998 2.484 3.0 2.437 8.39 ±0.5 7.745 2.418 3.0 2.462 8.65 ±0.5 8.222 2.580 3.0 802.11g Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.412 8.39 ±0.5 7.745 2.406 3.0 2.437 7.82 ±0.5 6.792 2.121 3.0 2.462 8.24 ±0.5 7.482 2.348 3.0 802.11n(HT20) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.412 8.64 ±0.5 8.204 2.548 3.0 2.437 8.11 ±0.5 7.261 2.267 3.0 2.462 8.07 ±0.5 7.194 2.258 3.0 802.11n(HT40) Frequency (GHz) Conducted Power (dBm) Turn-up Power Tolerance (dB) Max power of tune up tolerance (mw) Calculation Value Threshold Value 2.422 8.24 ±0.5 7.482 2.329 3.0 2.437 7.83 ±0.5 6.808 2.125 3.0 2.452 7.67 ±0.5 6.561 2.055 3.0 So standalone SAR measurements are not required.

Shenzhen Toby Technology Co., Ltd. Report No.: TB-FCC144820 Page: 1 of 89 TB-RF-074-1.0 1A/F., Bldg.6, Yusheng Industrial Zone, The National Road No.107 Xixiang Section 467, Xixiang, Bao’an, Shenzhen, China Tel: +86 75526509301 Fax: +86 75526509195 FCC Radio Test Report FCC ID: 2AEP6XM-JPV1-1 Original Grant Report No. : TB-FCC144820 Applicant : HangZhou XiongMai Technology CO., LTD Equipment Under Test (EUT) EUT Name : Raindrop Camera Model No. : XM-JPV1-1 Series No. : XM-JPV1-1F, XM-JPV1-1R Brand Name : XM Receipt Date : 2015-07-16 Test Date : 2015-07-16 to 2015-07-23 Issue Date : 2015-07-24 Standards : FCC Part 15, Subpart C (15.247:2014) Test Method : ANSI C63.10: 2013 Conclusions : PASS In the configuration tested, the EUT complied with the standards specified above, The EUT technically complies with the FCC and IC requirements Test/Witness Engineer : Approved& Authorized : This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other samples of the same product. The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in the report. Report No.: TB-FCC144820 Page: 2 of 89 TB-RF-074-1.0 Contents CONTENTS ............................................................................................................................................. 2 1. GENERAL INFORMATION ABOUT EUT ............................................................................. 4 1.1 Client Information ................................................................................................................. 4 1.2 General Description of EUT (Equipment Under Test) ................................................... 4 1.3 Block Diagram Showing the Configuration of System Tested ...................................... 5 1.4 Description of Support Units .............................................................................................. 5 1.5 Description of Test Mode .................................................................................................... 6 1.6 Description of Test Software Setting ................................................................................ 6 1.7 Measurement Uncertainty .................................................................................................. 7 1.7 Test Facility ........................................................................................................................... 8 2. TEST SUMMARY ....................................................................................................................... 9 3. TEST EQUIPMENT .................................................................................................................. 10 4. CONDUCTED EMISSION TEST ........................................................................................... 11 4.1 Test Standard and Limit .................................................................................................... 11 4.2 Test Setup ........................................................................................................................... 11 4.3 Test Procedure ................................................................................................................... 11 4.4 EUT Operating Mode ........................................................................................................ 12 4.5 Test Data ............................................................................................................................. 12 5. RADIATED EMISSION TEST ................................................................................................ 17 5.1 Test Standard and Limit .................................................................................................... 17 5.2 Test Setup ........................................................................................................................... 18 5.3 Test Procedure ................................................................................................................... 19 5.4 EUT Operating Condition ................................................................................................. 20 5.5 Test Data ............................................................................................................................. 20 6. RESTRICTED BANDS REQUIREMENT ............................................................................. 47 6.1 Test Standard and Limit .................................................................................................... 47 6.2 Test Setup ........................................................................................................................... 47 6.3 Test Procedure ................................................................................................................... 47 6.4 EUT Operating Condition ................................................................................................. 48 6.5 Test Data ............................................................................................................................. 48 7. BANDWIDTH TEST ................................................................................................................. 69 7.1 Test Standard and Limit .................................................................................................... 69 7.2 Test Setup ........................................................................................................................... 69 7.3 Test Procedure ................................................................................................................... 69 7.4 EUT Operating Condition ................................................................................................. 69 7.5 Test Data ..........................................................................................…
