2AFGR-APS2530HZigbee module

昱能科技 NO.1 Yatai Road, Jiaxing, Zhejiang, China 浙江省嘉兴市南湖区亚太路1号 +86 57383986967 | APsystems.com User Manual for APS2530H The model used ZigBee PRO protocol to send RF signals for device communication. The model can be used after pairing with a dedicated device which was installed with a receiver dongle. APS2530H was used as a dongle which need to be installed in customer’s device. It offers UART to communicate with customer’s device according predefined protocol. 1:product figure(APS2530H) 2: Technical specifications RF operating frequency: 2402MHz ~ 2483MHz Reference frequency: 2.400GHz Channel spacing: 5MHz Channel wide：2MHz Modulation method: OQPSK Communication rate: 250Kbps 昱能科技 NO.1 Yatai Road, Jiaxing, Zhejiang, China 浙江省嘉兴市南湖区亚太路1号 +86 57383986967 | APsystems.com Output power: 15DBm Communication mechanism: applied ZigBee frequency hopping mechanism, passively frequency hopping. Average operating current：<20mA Operating voltage：2V-3.6V Max remitting current: 20mA Max rate：250Kbit/s Receiving sensitivity： -95dbm Receiving current：<24mA Max receiving distance：>100M Normal operating receiving distance： 100M 昱能科技 NO.1 Yatai Road, Jiaxing, Zhejiang, China 浙江省嘉兴市南湖区亚太路1号 +86 57383986967 | APsystems.com 3. Installation and usage instructions Installation Notes: users can use SMT or DIP to connect to ZIGBEE module. It must be ensured that the interface of the module(VCC,GND,RESET,UART) is accurately connected with the customer's equipment. Make sure the IPEX interface is properly connected to the antenna. Instructions for use: Users can interact with the zigbee module through the serial port. The user uses the serial port to send data to the zigbee module in the specified format, and the zigbee module will send the data to the specified slave module through the radio frequency signal. Pin Descriptions Pin name Pin type Description P0_0 Digital I/O Port0.0 P0_1 Digital I/O Port0.1 P0_2 Digital I/O Port0.2 - UART RX P0_3 Digital I/O Port0.3 - UART TX P0_4 Digital I/O Port0.4 P0_5 Digital I/O Port0.5 P0_6 Digital I/O Port0.6 昱能科技 NO.1 Yatai Road, Jiaxing, Zhejiang, China 浙江省嘉兴市南湖区亚太路1号 +86 57383986967 | APsystems.com P0_7 Digital I/O Port0.7 P1_0 Digital I/O Port1.0 – 20-mA drive capability P1_1 Digital I/O Port1.1 – 20-mA drive capability P1_2 Digital I/O Port1.2 P1_3 Digital I/O Port1.3 P1_4 Digital I/O Port1.4 P1_5 Digital I/O Port1.5 P1_6 Digital I/O Port1.6 P1_7 Digital I/O Port1.7 P2_0 Digital I/O Port2.0 P2_1 Digital I/O Port2.1 P2_2 Digital I/O Port2.2 VCC Power 2-V–3.6-V digital power-supply connection GND Ground Connect to GND RESET_N Digital input Reset, active-low Package Size 4. Warning This device complies with Part 15, Subpart C, Section 15.247 of the FCC Rules. - product should not collocate with other radio - host label should content modular FCC ID:2AFGR-APS2530H/IC :20481-APS2530H - ANT type/gain tolerance of antenna OEM should use. Use only the antenna supplied by the manufacturer when operating this device(antenna gain:2dBi). Unauthorized antennas, modifications, or attachments, could damage the device and violate FCC regulations. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. - Do not disassemble, repair, modify or replace the remote 昱能科技 NO.1 Yatai Road, Jiaxing, Zhejiang, China 浙江省嘉兴市南湖区亚太路1号 +86 57383986967 | APsystems.com control Unit or any of its components. EF Radiation Exposure and Hazard Statement: - To ensure compliance with FCC RF exposure requirement, this device must be installed in a location such that antenna of the device will b greater than 20cm away from all persons. Using higher gain antennas and types of antennas not covered under the FCC certification of this product is not allowed. Installers of the radio and end users of the product must adhere to installation instructions provided in this manual. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. - Please comply with the national and international flight safety regulations when using device during your flight trip. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. RF exposure warning This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. IC Caution: This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two…

Text truncated - open the document above for the full version.

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Revised wording (obsolete) 1.0 2.0 Sept–25-2007 Updated company template (obsolete) 2.0 3.0 Jan-31-2012 Updated letter information (obsolete) 3.0 4.0 May-23-2014 Added FCC ID field (obsolete) 4.0 5.0 Sep-16-2014 Updated company name & logo (current) 5.0 6.0 Jun-27-2018 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 6.0 ALTENERGY POWER SYSTEM INC. June 2, 2020 To: BVCPS, INC. 775 Montague Expressway, Milpitas, CA 95035 USA Dear Sir/Madam, Re: Product Certification Representative Authorization Letter We, ALTENERGY POWER SYSTEM INC.hereby authorize Bureau Veritas Consumer Product Services, Inc. to act as a Certification Body for certifying for the following project(s): FCC ID: 2AFGR- APS2530H Product Description: Zigbee module Model: APS2530H Sincerely, Client’s signature: Client’s name / title: Kevin Lu/ Certification Engineer Contact information / address: No.1, Yatai Road, Jiaxing, Zhejiang 314050,P.R. China

SCS-F19: Confidentiality Request Letter Page 1 of 3 Rev 6.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Confidentiality Request Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (obsolete) 1.0 1.0 Nov-14-2006 Adding CFR 2.459 (obsolete) 1.0 2.0 August – 11 - 2008 Updated company template & Added text box (obsolete) 2.0 3.0 Jan-31-2012 Added IC confidentiality letter form (obsolete) 3.0 4.0 March-26-2015 Corrections to STC form. Added reference to KDB (obsolete) 4.0 5.0 Nov-19-2015 Updated company logo (current) 5.0 6.0 Jun-26-2019 SCS-F19: Confidentiality Request Letter Page 2 of 3 Rev 6.0 ALTENERGY POWER SYSTEM INC. June 2, 2020 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD Subject: Permanent Confidentiality Request for FCC ID: 2AFGR- APS2530H Pursuant to sections 0.457 and 0.459 of CFR 47, we respectfully request permanent confidential treatment of the following Exhibits accompanying this application as: - Block Diagram - Schematics - Operational Description The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Sincerely, Client’s signature: Client’s name & title: Certification Engineer Contact information / address: No.1, Yatai Road, Jiaxing ，Zhejiang 314050,P.R. China SCS-F19: Confidentiality Request Letter Page 3 of 3 Rev 6.0 (ALTENERGY POWER SYSTEM INC.) June 2, 2020 To: Federal Communications Commission Office of Engineering and Technology Equipment Authorization Division 7345 Oakland Mills Road Columbia, Maryland 21046 Subject: Short Term Confidentiality Request for FCC ID: 2AFGR- APS2530H To Whom It May Concern: Pursuant to sections 0.457 and 0.459 of CFR 47, and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 45 or 180 days; or for a specified date of / / not to exceed 180 days from the Grant Date. See KDB 726920. - User Manual - Internal Photos - Test Setup photos The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Client’s signature: Client’s name & title: Certification Engineer Contact information / address: No.1, Yatai Road, Jiaxing ，Zhejiang 314050,P.R. China

SCS-F26 Modular Approval Letter Page 1 of 2 Rev 12.0 775 Montague Expressway Milpitas, CA 95035 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Modular Approval Declaration Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (Obsolete) 1.0 1.0 Dec-04-2006 Added IC Modular Letter (Obsolete) 1.0 2.0 Feb 16 2009 Add LMA and MA option (Obsolete) 2.0 3.0 April 14 2010 Revised per RSS Gen issue 3.0 (Obsolete) 3.0 4.0 Jan 12 2011 Removed Foot(2) (obsolete) 4.0 5.0 July 19 2011 Adding New note per KDB996369 D01 V01R03 (obsolete) 5.0 6.0 August 29 2011 Updated company template & Added text box (obsolete) 6.0 7.0 Jan-31-2012 Updated modular requirement (obsolete) 7.0 8.0 Sept 05 2014 Updated template to meet RSP 100 issue 10 (obsolete) 8.0 9.0 Nov 20 2014 Updated template to meet RSP 100 issue 11 (obsolete)) 9.0 10.0 March 19 2015 Revised the Modular Requirement statements (obsolete) 10.0 11.0 July 28, 2016 Updated template with BV logo (current) 11.0 12.0 June 26, 2019 SCS-F26 Modular Approval Letter Page 2 of 2 Rev 12.0 ALTENERGY POWER SYSTEM INC. (Date) June 2, 2020 (Product name) FCC ID: 2AFGR- APS2530H , is seeking FCC Authorization as a Single Modular Transmitter / Single Limited Modular Transmitter (Please check one) The EUT meets the requirements for Single Modular Approval / Single Limited Modular Approval (Please check one) as detailed in KDB 996369. Compliance to each of the requirements is described below: Item Modular requirement Yes No Please provide a detailed explanation if the answer is “No.” 1 Have its own RF shielding √ 2 Have buffered modulation/data inputs (if such inputs are provided) √ 3 The modular transmitter must have its own power supply regulation. √ 4 Meet the antenna requirements of section 15.203 √ 5 Be tested in a stand-alone configuration, i.e., the antenna, AC or DC power and data input/output lines must be connected to the module but, the module must not be inside another case during testing. √ 6 Be labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. √ 7 The modular transmitter is manufactured so that the user can not influence the operation of the transmitter that will operate outside of the scope of the regulations. √ 8 Address compliance with the Commission`s RF exposure limits in Sections 1.1310 and 2.1093. √ Note: (1) LMA may be granted when one or more of the requirements in the table above cannot be demonstrated. LMA will also be issued in those instances where applicants can demonstrate that they will retain control over the final installation of the device, such that compliance of the end product is assured. In such cases, an operating condition on the LMA for the module must state that the module is only approved for use when installed in devices produced by a specific manufacturer. When LMA is sought, the application for equipment certification must specifically state how control of the end product into which the module will be installed, and will be maintained, such that full compliance of the end product is always ensured. (2) Please provide Clear and specific instructions describing the conditions, limitations and procedures for third-parties to use and/or integrate the module into a host device. (3) For non-Software Defined Radio transmitter modules where software is used to ensure compliance of the device, technical description of how such control is implemented to ensure prevention of third party modification must be provided (see KDB 594280). Note 1: Compliance of a module in its final configuration is the responsibility of the applicant. A host device will not be considered certified if the instructions regarding antenna configuration provided in the original description, of one or more separately certified modules it contains, were not followed. Example: A separately certified low-power transceiver module using Bluetooth technology which is housed in a desktop computer, laptop or peripheral does not require the overall system to be recertified, if the desktop computer, laptop or peripheral, as a stand-alone unit, complies with all applicable technical standards. Client’s signature Client’s name / title ：Certification Engineer Contact information / address ：No.1 Yatai Road, Jiaxing 314050 Zhejiang Province, P.R. China

Page 1 of 4 External Photo Page 2 of 4 Page 3 of 4 Page 4 of 4

Model APS2530H : FCC ID 2AFGR- APS2530H : IC 20481- APS2530H : Label

Page 1 of 4 Internal Photo Page 2 of 4 Page 3 of 4 Page 4 of 4

Report No.: ZEK-ESH-P20050862B-2 Page No. 1 / 6 Report Format Verision: 6.1.1 MPE Test Report Report No.: ZEK-ESH-P20050862B-2 FCC ID: 2AFGR- APS2530H Product: Zigbee module Model: APS2530H Received Date: May.14, 2020 Test Date: May.15 to May.29, 2020 Issued Date: Jun.02, 2020 Applicant: ALTENERGY POWER SYSTEM INC. Address: No.1 Yatai Road, Jiaxing 314050 Zhejiang Province, P.R. China Manufacturer: ALTENERGY POWER SYSTEM INC. Address: No.1 Yatai Road, Jiaxing 314050 Zhejiang Province, P.R. China Issued By: BUREAU VERITAS ADT (Shanghai) Corporation Lab Address: No. 829, Xinzhuan Road, Shanghai, P.R.China (201612) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: ZEK-ESH-P20050862B-2 Page No. 2 / 6 Report Format Verision: 6.1.1 Table of Contents Release Control Record ............................................................................................................................... 3 1 Certificate of Conformity .................................................................................................................... 4 General Description of EUT ...................................................................................................................... 5 2 RF Exposure ..................................................................................................................................... 6 2.1 Limits For Maximum Permissible Exposure (MPE) ......................................................................... 6 2.2 MPE Calculation Formula ............................................................................................................... 6 2.3 MPE Calculation Formula ............................................................................................................... 6 2.4 Calculation Result of Maximum Permissible Exposure.................................................................... 6 Report No.: ZEK-ESH-P20050862B-2 Page No. 3 / 6 Report Format Verision: 6.1.1 Release Control Record Issue No. Description Date Issued ZEK-ESH-P20050862B-1 Original release Jun.02, 2020 Report No.: ZEK-ESH-P20050862B-2 Page No. 5 / 6 Report Format Verision: 6.1.1 2 General Description of EUT Product Zigbee module Brand -- Test Model APS2530H Power Rating DC 3.3V Modulation Type DSSS Modulation Technology O-QPSK Operating Frequency 2405MHz to 2480MHz Number of Channel 16 Antenna Type Wire Antenna Antenna Connector -- Antenna Gain 2.0dBi Note:1. For more details, please refer to the User’s manual of the EUT. Report No.: ZEK-ESH-P20050862B-2 Page No. 6 / 6 Report Format Verision: 6.1.1 3 RF Exposure 3.1 Limits For Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Average Time (minutes) Limits For General Population / Uncontrolled Exposure 300-1,500 - - F/1500 30 1,500-100,000 - - 1.0 30 F = Frequency in MHz 3.2 MPE Calculation Formula Power density (S) is calculated according to the formula: S = PG / (4πR²) Where S = power density in mW/cm² P = transmit power in mW G = numeric gain of transmit antenna (numeric gain=Log-1(dB antenna gain/10)) R = distance (cm) 3.3 MPE Calculation Formula The antenna of this product, under normal use condition, is at least 20cm from the body of the user. So the device is classified as Mobile Device. 3.4 Calculation Result of Maximum Permissible Exposure Frequency Band (MHz) Max. Conducted output power(dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) Zigbee 2.4GHz 2405-2480 13.34 2.0 20 0.0068069 1 Conclusion: The calculation result of MPE is less than the limit. --- END ---

Report No.: ZEK-ESH-P20050862B-1 Page No. 1 / 54 Report Format Verision: 6.1.1 FCC Test Report Report No.: ZEK-ESH-P20050862B-1 FCC ID: 2AFGR- APS2530H Product: Zigbee module Test Model: APS2530H Received Date: May.14, 2020 Test Date: May.15 to May.29, 2020 Issued Date: Jun.02, 2020 Applicant: ALTENERGY POWER SYSTEM INC. Address: No.1 Yatai Road, Jiaxing 314050 Zhejiang Province, P.R. China Issued By: BUREAU VERITAS ADT (Shanghai) Corporation Lab Address: No. 829, Xinzhuan Road, Shanghai, P.R.China (201612) This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. Unless specific mention, the uncertainty of measurement has been explicitly taken into account to declare the compliance or non-compliance to the specification. The report must not be used by the client to claim product certification, approval, or endorsement by TAF or any government agencies. Report No.: ZEK-ESH-P20050862B-1 Page No. 2 / 54 Report Format Verision: 6.1.1 Table of Contents Release Control Record .................................................................................................................................... 4 1 Certificate of Conformity ......................................................................................................................... 5 2 Summary of Test Results ........................................................................................................................ 5 2.1 Test Instruments .................................................................................................................................. 7 2.2 Measurement Uncertainty ................................................................................................................... 8 2.3 Modification Record ............................................................................................................................ 8 3 General Information ................................................................................................................................ 9 3.1 General Description of EUT ................................................................................................................ 9 3.2 Description of Test Modes ................................................................................................................. 10 3.2.1 Test Mode Applicability: ...................................................................................................................... 11 3.2.2 Test Condition: ................................................................................................................................... 12 3.3 Duty Cycle of Test Signal .................................................................................................................. 13 3.4 General Description of Applied Standards ........................................................................................ 13 4 Test Procedure and Results .................................................................................................................. 14 4.1 6dB Bandwidth Measurement ........................................................................................................... 14 4.1.1 Limit ................................................................................................................................................... 14 4.1.2 Test Setup .......................................................................................................................................... 14 4.1.3 Test Procedures ................................................................................................................................. 14 4.1.4 Deviation of Test Standard ................................................................................................................ 14 4.1.5 Test Results ....................................................................................................................................... 15 4.2 Conducted Output Power Measurement ........................................................................................... 17 4.2.1 Limit ................................................................................................................................................... 17 4.2.2 Test Setup .......................................................................................................................................... 17 4.2.3 Test Procedures ................................................................................................................................. 17 4.2.4 Deviation of Test Standard ................................................................................................................ 17 4.2.5 Test Results ....................................................................................................................................... 18 4.3 Power Spectral Density Measurement .........…

Text truncated - open the document above for the full version.

Page 1 of 3 Test Setup Photo Page 2 of 3 1. Radiated Emission Below 1GHz Above 1GHz Page 3 of 3 2. Conducted Emission
