2AFP2LC06Fast Wireless Charger

90*65mm 1:1 无线充电器说明书 LC06 / 128g哑粉纸 双面四色印刷 2020.10.23 3-608LC060602A0001 中性 DC5V 3A, DC9V 2.22A, DC12V 1.67A Φ63×10.5mm 57 DC5V 3A, DC9V 2.22A, DC12V 1.67A Φ63×10.5mm 57 注：20W适配器需另外购买，请根据适配器接口选择是否使用转接头。 充电板通电后白灯闪烁三次然后熄灭进入待机模式。 将带有磁吸无线充电功能的手机放置在充电板上，充电板会自动吸附 对位，指示灯白灯长亮30秒后熄灭，当有金属等异物放置在充电板上，指示 灯呈白灯闪烁。 本产品同时支持对不带磁吸功能的无线充电设备进行充电。 USB转接头 USB output port *20W PD wall charger need to buy separately, please use the connector adapter accordding to your wall charger USB output port. 快速无线充电器 The white LED light of charger will flash 3times when power on, then enter to standby mode. Put the magnetic wireless charging phone one the charger, they will align automaticly, white LED light will turn off after 30 seconds. The white LED light will flashing when FOD detected. The device also support wireless charging to other nonmagnatic wireless charging function device. FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. To maintain compliance with FCC’s RF Exposure guidelines, This equipment should be installed and operated with minimum distance between 20cm the radiator your body: Use only the supplied antenna. 警告语 此设备符合FCC规则的第15部分。 操作必须符合以下两个条件：（1）此设备 不会造成有害干扰，并且（2）此设备必须接受收到的任何干扰，包括可能导 致意外操作的干扰。 未经负责合规方明确批准的任何更改或修改，都可能使用户丧失操作设备的 权限。 注意：根据FCC规则第15部分的规定，本设备已经过测试，符合B类数字设备 的限制。 这些限制旨在为住宅安装中的有害干扰提供合理的保护。 本设备会 产生，使用并辐射射频能量，如果未按照说明进行安装和使用，可能会对无 线电通信造成有害干扰。 但是，不能保证在特定安装中不会发生干扰。 如果此设备确实对广播或电视接收造成有害干扰， 可以通过打开和关闭设备来确定，建议用户尝试以下一种或多种措施来纠正 干扰： - 重新调整或摆放接收天线。 - 增加设备和接收器之间的距离。 -将设备连接到与接收器不同电路的插座上。 -向经销商或有经验的无线电/电视技术人员咨询以获得帮助。 为了保持符合FCC的RF暴露准则，应在距您的身体辐射器20厘米的最小距离 内安装和操作此设备：仅使用提供的天线。 Fast Wireless Charger

Shenzhen Powerqi Technology Co., Ltd. Model difference statement Product Name: Fast Wireless Charger Model N o.: LC06, PS102, 9915101100113, 9915101100112 We (Shenzhen Powerqi Technology Co., Ltd., 2nd Floor, A4 Building, Block A, Fangxing Science & Tech. Park, Longgang District, Shenzhen, China) hereby state that all the models are the same circuit and RF module, except the model No.. Signature: Name / title: Tina Qu / Sales Manager Tel: 075584522599 Email: [email protected] Date: 4.28.2021

C5266091_X8_Ed.1 1/1 Letter of Authorization Shenzhen Powerqi Technology Co., Ltd. Company: Shenzhen Powerqi Technology Co., Ltd. Address: 2nd Floor, A4 Building, Block A, Fangxing Science & Tech. Park, Longgang District, Shenzhen, China Product Name: Fast Wireless Charger Model Number: LC06, PS102, 9915101100113, 9915101100112 FCC Identifier: 2AFP2LC06 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Tina Qu Date: 4/28/2021 Title: Sales Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 Shenzhen Powerqi Technology Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 5/7/2021 Subject: Request for Confidentiality FCC ID: 2AFP2LC06 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Tina Qu Date: 5/7/2021 Title: Sales Manager

1 - Page 1 of 3 - Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] APPENDIX 1- EUT PHOTO Photo 1 (For model LC06) Photo 2 1 - Page 2 of 3 - Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 3 Photo 4 1 - Page 3 of 3 - Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 5 Photo 6

面壳 LC06 / / 1:1 中性 1.1 丝印颜色：白色 内容居中 箭头指向 F C C I D ： 2 A F P 2 L C 0 6

1 - Page 1 of 3 - Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] APPENDIX 1- EUT PHOTO Photo 1 (For model LC06) Photo 2 Wireless charge ANT 1 - Page 2 of 3 - Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 3 Photo 4 1 - Page 3 of 3 - Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Photo 5 Photo 6

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] RF EXPOSURE Test Report Report No.: MTi210315006-01E2 Date of issue: Apr. 26, 2021 Applicant: Shenzhen Powerqi Technology Co., Ltd. Product name: Fast Wireless Charger Model(s): LC06, PS102, 9915101100113, 9915101100112 FCC ID: 2AFP2LC06 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 10 - Report No.: MTi210315006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 10 - Report No.: MTi210315006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] TEST RESULT CERTIFICATION Applicant’s name .................... : Shenzhen Powerqi Technology Co., Ltd. Address .................................. : 2nd Floor, A4 Building, Block A, Fangxing Science & Tech. Park, Longgang District, Shenzhen, China Manufacturer's Name ............. : Shenzhen Powerqi Technology Co., Ltd. Address .................................. : 2nd Floor, A4 Building, Block A, Fangxing Science & Tech. Park, Longgang District, Shenzhen, China Product description Product name ........................... : Fast Wireless Charger Trademark ............................. : N/A Model Name .......................... : LC06 Serial Model ............................ PS102, 9915101100113, 9915101100112 Standards ............................... : FCC CFR 47 PART 1 , 1.1310 Test procedure ....................... : KDB 680106 D01 RF Exposure Wireless Charging Apps v03r01 Date of Test Date (s) of performance of tests ............. : Mar. 25, 2021 ~ Apr. 15, 2021 Test Result .............................................. : Pass This device described above has been tested by Shenzhen Microtest Co., Ltd. and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. Testing Engineer : (Cindy Qin) Technical Manager : (Leo Su) Authorized Signatory : (Tom Xue) - Page 4 of 10 - Report No.: MTi210315006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Table of Contents 1 GENERAL INFORMATION ...................................................................................................................................... 5 1.1 DESCRIPTION OF EUT ................................................................................................................................................... 5 1.2 ANCILLARY EQUIPMENT LIST ........................................................................................................................................... 5 1.3 MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 2 TESTING SITE ........................................................................................................................................................ 6 3 LIST OF TEST EQUIPMENT ..................................................................................................................................... 7 4 TEST RESULTS ....................................................................................................................................................... 8 4.4 MAXIMUM PERMISSIBLE EXPOSURE.................................................................................................................................. 8 4.4.1 Limit .................................................................................................................................................................... 8 4.4.2 Test Procedures ................................................................................................................................................... 8 4.4.3 Test Setup ........................................................................................................................................................... 9 4.4.4 Test Result ........................................................................................................................................................... 9 4.4.5 MPE Setup photo .............................................................................................................................................. 10 - Page 5 of 10 - Report No.: MTi210315006-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Tel: (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] 1 General Information 1.1 Description of EUT Product name: Fast Wireless Charger Brand name: N/A Model name: LC06 Series model: PS102, 9915101100113, 9915101100112 Deference in serial model: All the models are the same circuit and RF module, except th…

Text truncated - open the document above for the full version.

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi210315006-01E1 Date of issue: Apr. 26, 2021 Applicant: Shenzhen Powerqi Technology Co., Ltd. Product name: Fast Wireless Charger Model(s): LC06, PS102, 9915101100113, 9915101100112 FCC ID: 2AFP2LC06 Shenzhen Microtest Co., Ltd. http://www.mtitest.com - Page 2 of 24 - Report No.: MTi210315006-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Instructions 1. The report shall not be partially reproduced without the written consent of the laboratory; 2. The test results of this report are only responsible for the samples submitted; 3. This report is invalid without the seal and signature of the laboratory; 4. This report is invalid if transferred, altered or tampered with in any form without authorization; 5. Any objection to this report shall be submitted to the laboratory within 15 days from the date of receipt of the report. - Page 3 of 24 - Report No.: MTi210315006-01E1 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’ an District, Shenzhen, Guangdong, China. Te l : (86-755)88850135 Fax: (86-755) 88850136 Web:www.mtitest.com E-mail: [email protected] Table of Contents 1 GENERAL INFORMATION ................................................................................................................................. 5 1.1 FEATURE OF EQUIPMENT UNDER TEST (EUT) ................................................................................................................... 5 1.2 TEST MODE .............................................................................................................................................................. 5 1.3 EUT TEST SETUP ....................................................................................................................................................... 5 1.4 ANCILLARY EQUIPMENT .............................................................................................................................................. 5 2 SUMMARY OF TEST RESULT ............................................................................................................................. 6 2.1 OPERATION CHANNEL LIST ........................................................................................................................................... 6 2.2 TEST CHANNEL .......................................................................................................................................................... 6 3 TEST FACILITIES AND ACCREDITATIONS ............................................................................................................ 7 3.1 TEST LABORATORY ..................................................................................................................................................... 7 3.2 ENVIRONMENTAL CONDITIONS ..................................................................................................................................... 7 3.3 MEASUREMENT UNCERTAINTY ...................................................................................................................................... 7 4 LIST OF TEST EQUIPMENT ................................................................................................................................ 8 5 TEST RESULTS .................................................................................................................................................. 9 5.1 ANTENNA REQUIREMENT ............................................................................................................................................ 9 5.1.1 Standard requirement ................................................................................................................................. 9 5.1.2 EUT Antenna ............................................................................................................................................... 9 5.2 CONDUCTED EMISSION ............................................................................................................................................. 10 5.2.1 Limits ......................................................................................................................................................... 10 5.2.2 Test Procedures ......................................................................................................................................... 10 5.2.3 Te s t S e t u p .................................................................................................................................................. 10 5.2.4 Test Result ................................................................................................................................................. 10 5.3 RADIATED EMISSION ................................................................................................................................................. 15 5.3.1 Limits ......................................................................................................................................................... 15 5.3.2 Test Procedures ......................................................................................................................................... 16 5.3.3 Te s t S e t u p .................................................................................................................................................. 17 5.3.4 Test Result ............................................................................................…

Text truncated - open the document above for the full version.

Model: LC06 Radiated emission Conducted emission
