2AFP2LC65C3-in-1 Magnetic Wireless Charging Stand

90*65mm 1:1 无线充电器说明书 LC65 / 128g哑粉纸 双面单色印刷 2023.2.3 中性 Input: DC5V,3A DC9V,3A Output(Phone): 5W/7.5W/10W/15W Output(Apple Watch): 5W Output(Airpods): 5W 80×136×108mm This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. 315g Put the smartphone/Airpods/Apple Watch properly on the transmitter. 110-148kHZ (Only for EU);115-205kHZ (Only for FCC) This product is a 3 in 1 wireless charger, support phone/Airpods/ Apple Watch charging at the same time. Power cable FCC WPT exposure statement: FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance between 20cm the radiator your body. FCC WarningFCC Warning

OasisCompliance,Inc.FCCID:2AFP2LC65C CFR47§2.911(d)(7)FCCUSAgentLetterofAttestation Date:03-28-2023 FCCID:2AFP2LC65C To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ToWhomItMayConcern, ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSAgentonbehalf ofShenzhenpowerqiTechnologyCo.,Ltd(“theapplicant”)fortheabovereferencedFCCID. Weareawareoftherequirementsandresponsibilitiesoftheapplicant’sagentforserviceof processasoutlinedintheFCCsection2.911(d)(7)andReportandOrderFCC22-84paragraph 63. U.S.AgentInformation: OasisCompliance,Inc. FRN:0033464157 JamesHe (01)2026028330 3313VerdiDr,SanJose,CA95111 Sincerelyyours, JamesHe GlobalMarketAccessManager OasisCompliance,Inc. Email:[email protected]

C5266091_X24_Ed.1 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Shenzhen Powerqi Technology Co., Ltd. Grantee code: 2AFP2 FCC ID: 2AFP2LC65C Contact Name: Tina Qu Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China. Telephone No: 0755-84522599 Fax No: 0755-84522699 Email: [email protected] i. [Shenzhen Powerqi Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Shenzhen Powerqi Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. Date: 3.27.2023 Applicant’s Name: Tina Qu Title: Sales Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

CFR47§2.911(d)(7)AgentDesignationAttestation Date:03-28-2023 FCCID:2AFP2LC65C To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ShenzhenpowerqiTechnologyCo.,Ltd (“theapplicant”)asrequiredbysection2.911(d)(7), designatesthefollowingagent,locatedintheUnitedStates,forpurposesofactingasthe applicant’sagentforserviceofprocess. Theapplicantacknowledgesthattheywillmaintainanagentfornolessthanoneyearafterthe granteehasterminatedallmarketingandimportationortheconclusionofanyCommission- relatedproceedinginvolvingtheequipment.Theapplicantfurtheracknowledgestheir responsibilitytoinformtheFCCwhenevertheagentinformationchanges. U.S.AgentInformation: JamesHe OasisCompliance,Inc. (01)2026028330 3313VerdiDr,SanJose,CA95111 [email protected] Sincerelyyours, TinaQu Manager ShenzhenpowerqiTechnologyCo.,Ltd Address:Room201,302,401ofA4Building,BlockA,FangxingScienceandTechnologyPark, No.13ofBaonanRoad,LonggangDistrict,Shenzhen,China. Email:[email protected] Phone:0755-84522599

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Shenzhen Powerqi Technology Co., Ltd. Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China. Product Name: 3-in- 1 Magnetic Wireless Charging Stand Model Number: LC65C FCC Identifier: 2AFP2LC65C We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Tina Qu Date: 3/27/2023 Title: Sales Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 Shenzhen Powerqi Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 3/27/2023 Subject: Request for Confidentiality FCC ID: 2AFP2LC65C To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Tina Qu Date: 3/27/2023 Title: Sales Manager

Page 1 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: LC65C transmitter 1(Phone) transmitter 2(Airpods) Page 2 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 4 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report----

3-in-1 Magnetic Wireless Charging Stand Input: 5V 3A 9V 3A Output(Phone): 5W/7.5W/10W/15W Output(Airpods): 5W Output(USB): 5W FCC ID:2AFP2LC65C 底壳 / 2022.12.9 100 100 1:1 LC65 中性 丝印冷灰3C 1.0

Page 1 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - EUT Photos Model: LC65C Page 2 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 3 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Page 4 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Coil 2 Page 5 of 5 Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] ----End of Report---- Coil 1

Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230104005-01E2 Date of issue: 2023-02-27 Applicant: Shenzhen powerqi Technology Co.,Ltd Product: 3-in-1 Magnetic Wireless Charging Stand Model(s): LC65C FCC ID: 2AFP2LC65C Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 13 Report No.: MTi230104005-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 13 Report No.: MTi230104005-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Contents 1 General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 5 1.3 Description of support units ................................................................................................................................ 6 2 Measurement uncertainty ............................................................................................................... 6 3 Test facilities and accreditations .................................................................................................... 7 3.1 Test laboratory .................................................................................................................................................... 7 4 List of test equipment ..................................................................................................................... 8 5 Test result ........................................................................................................................................ 9 5.2 Test setup ......................................................................................................................................................... 10 5.3 Test Procedures ................................................................................................................................................ 10 5.4 Equipment Approval Considerations item 5 b) of KDB 680106 D01 v03r01 .................................................... 11 5.5 Test results ....................................................................................................................................................... 12 Photographs of the Test Setup ............................................................................................................ 13 Photographs of the EUT....................................................................................................................... 13 Page 4 of 13 Report No.: MTi230104005-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Shenzhen powerqi Technology Co.,Ltd Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China. Manufacturer: Shenzhen powerqi Technology Co.,Ltd Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China. Product description Product name: 3-in-1 Magnetic Wireless Charging Stand Trademark: N/A Model name: LC65C Series Model: N/A Standards: FCC CFR 47 PART 1, § 1.1310 Test method: KDB 680106 v03r01 Date of Test Date of test: 2023-02-03 ~ 2023-02-27 Test result: Pass Test Engineer : (Yanice Xie) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) Page 5 of 13 Report No.: MTi230104005-01E2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1 General Description 1.1 Description of the EUT Product name: 3-in-1 Magnetic Wireless Charging Stand Model name: LC65C Series Model: N/A Model difference: N/A Electrical rating: Input: DC5V/3A, 9V/3A Output: USB-A+USB-C: 5W Wireless Output: Transmitter 1(Phone): 5W/7.5W/10W/15W Transmitter 2(Airpods): 5W Accessories: Cable: USB-A to USB-C cable (1.5m) Hardware version: V10 Software version: V10 RF specification: Operation frequency: Transmitter 1(Phone): 115 kHz – 205 kHz Transmitter 2(Airpods):115 kHz – 205 kHz Modulation type: ASK Antenna type: Coil Antenna 1.2 Description of test modes All the test modes were carried out with the EUT in normal operation, the final test mode of the EUT was the worst test mode for emission test, which was shown in this report and defined as: No. Emission test mode…

Text truncated - open the document above for the full version.

Page 1 of 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address: 东莞市石碣镇西沙路 2 号 Tel ： 86-076986018114Fax ： 86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 东莞市金赞智能科技有限公司 产品规格书 PRODUCTSPECIFICATION 拟制 PREPAREDBY 跟单员 MERCHANDISER 工程审核 ENGINEER CHECKEDBY 制程审核 PRODUCTION CHECKDEDBY 批准 APPROVEDBY 王云帆 客户：深圳市倍力奇科技有限公司 CUSTOMER:____________________________________________________________________ 客户料号：3-122DX01010AA-063 CUSTP/N:____________________________________________________________________ 金赞料号： KCP/N:____________________________________________________________________ 产品型号：20.5*40*0.08*24P*2P*10TS*15MM DESE: 日期：2023.2.17 DATE:____________________________________________________________________ 版本：A.0 VERSION:____________________________________________________________________ （客户承认受领印）ACCEPTANCESTAMP Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-063 20.5*40*0.08*24P*2P*10TS*15MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 2 版本 Rev. 变更前 BeforeChange 变更后内容 DESCRIPTION(ContentOrReasonForChanged) 日期 Date 修订者 Revisor A.0--新发行（InitialRelease）2023/2/17王云帆 Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-063 20.5*40*0.08*24P*2P*10TS*15MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 3 1.产品外形尺寸（OVERALLDIMENSIONSOFPRODUCTS): 单位(Unit):毫米(mm) PS: 参考数据RefThickness：线圈Coilthickness0.55mm；胶水EpoxyGlue：0.15mm；铁氧体Ferritecore： 0.8mm；双面胶Doublesidetape：0.08mm；胶布Kaptontape：0.12mm；0.08mm；胶布Kaptontape：0.12mm； 圈数 Turn s 线径 WireDia. 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 线圈正/反贴 Coil Positive/AntiPaste ABCDEFGHI 5.3±0.520.5±0.540±143.5±13±115±11.2±0.052.3MAX7±2 Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-063 20.5*40*0.08*24P*2P*10TS*15MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 4 10TS 0.08*24P*2P热风绞线 （Strandedwire） 密绕（Close） 逆时针 （Anticlockwise） 是（Yes）反贴（Anti/-Paste） 所有材料要求合格ROHS标准 2.电气特性（ELECTRICALCHARACTERISTICS): 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±10% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1INDS-F 线圈加磁片Coil+Ferrite：6.5 uH±10% 1kHz/VLCZMETER1062 2DCRS-F 阻值Resistance：85mΩMAX 1kHz/VLCZMETER1062 3. 材料清单（BILLOFMATERIAIS): 序号 NO. 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 厂商代码 Vendorcode 1 线材Copperwire0.08*24P*2P热风绞线 JX-2U-F-0009 ZY 2 铁氧体Ferritecore G43.5±1*5.3±0.5*0.8±0.1H（带孔，带 双槽L槽） GCP-T-0084HBC 3 双面胶Doubleside tape 42*5.3*0.08H（带孔，带手撕） SMJ-00064NR 4 金手指胶布Kapton tape 8mm 高温胶纸8MMJRM 5 胶水EpoxyglueJS-E7202（加稠）白胶 E7202WHZY 6 锡条Tin环保无铅焊锡条lead-freeTin 无铅高温锡条XC Pageof 4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-063 20.5*40*0.08*24P*2P*10TS*15MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 5

Page1of4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address: 东莞市石碣镇西沙路 2 号 Tel ： 86-076986018114Fax ： 86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 东莞市金赞智能科技有限公司 产品规格书 PRODUCTSPECIFICATION 拟制 PREPAREDBY 跟单员 MERCHANDISER 工程审核 ENGINEER CHECKEDBY 制程审核 PRODUCTION CHECKDEDBY 批准 APPROVEDBY 王云帆 客户：深圳市倍力奇科技有限公司 CUSTOMER:____________________________________________________________________ 客户料号：3-122DX01010AA-062 CUSTP/N:____________________________________________________________________ 金赞料号： KCP/N:____________________________________________________________________ 产品型号：13.5*38*0.08*105P*12TS*50MM DESE: 日期：2023.2.17 DATE:____________________________________________________________________ 版本：A.0 VERSION:____________________________________________________________________ （客户承认受领印）ACCEPTANCESTAMP Pageof4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-062 13.5*38*0.08*105P*12TS*50MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 2 版本 Rev. 变更前 BeforeChange 变更后内容 DESCRIPTION(ContentOrReasonForChanged) 日期 Date 修订者 Revisor A.0--新发行（InitialRelease）2023/2/17王云帆 Pageof4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-062 13.5*38*0.08*105P*12TS*50MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 3 1.产品外形尺寸（OVERALLDIMENSIONSOFPRODUCTS): 单位(Unit):毫米(mm) PS:1.（F）为磁外引线长度；2.（H）包含进线，不包含离型纸；3.引线间距：5mm胶布 圈数 Turn s 线径 WireDia. 绕线方式疏/密 Wdg.Type Spred/Close 绕线方向 Wdg.Direction 相交是/否 Intersect Yes/Not 线圈正/反贴 Coil Positive/AntiPaste 12TS 0.08*105P小线径丝包 线（Silk-CoveredWire） 密绕（Close） 逆时针 （Anticlockwise） 是（Yes）反贴（Anti/-Paste） ABCDEFGHI 5.3±0.513.5±0.538MAX40±13±150±11.05±0.052.8MAX7±2 Pageof4 东莞市金赞智能科技有限公司 DONGGUANKIMCHENINDUSTRYINTLLIMITED Address:东莞市石碣镇西沙路2号Tel：86-076986018114Fax：86-076986015646 Http://www.jzcoil.com文件编号FilNo:KC-JZ-09-008 3-122DX01010AA-062 13.5*38*0.08*105P*12TS*50MM 拟制 PREPAREDBY 工程审核 ENGINEERCHECKEDBY 制程审核 PRODUCTIONCHECKEDBY 4 所有材料要求合格ROHS标准 2.电气特性（ELECTRICALCHARACTERISTICS): 温度TEMPERATURE:25±10°C,湿度RELATIVEHUMIDITY:65±10% 序号 NO. 项目 ITEM 端子 TERMINAL 标准 SPECIFICATION 测试条件 TESTFREQUENCY 测试仪器 TESTEQUIPMENTS 1INDS-F 线圈加磁片：6.2uH±10% 1kHz/VLCZMETER1062 2DCRS-F 阻值：44mΩMAX 1kHz/VLCZMETER1062 3.材料清单（BILLOFMATERIAIS): 序号 NO. 材料名称 Materialname 品名描述 Description 物料代码 MaterialCode 厂商代码 Vendorcode 1 线材0.08*105P小线径丝包线 SBX-2U-F-0011ZY 2 铁氧体40±1*5.3±0.5*0.8±0.1H（带孔，带 U型直槽） GCP-T-0088LX 3 双面胶38.5*5.3*0.08H（带孔，带手撕） SMJ-00056 NR 4 金手指胶布5mm 高温胶纸5MMJRM 5 胶水JS-E7202（加稠）白胶 E7202WHZY 6 锡条环保无铅焊锡条 无铅高温锡条XC

Address: 101, No.7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Report Report No.: MTi230104005-01E1 Date of issue: 2023-02-27 Applicant: Shenzhen powerqi Technology Co.,Ltd Product: 3-in-1 Magnetic Wireless Charging Stand Model(s): LC65C FCC ID: 2AFP2LC65C Shenzhen Microtest Co., Ltd. http://www.mtitest.com Page 2 of 23 Report No.: MTi230104005-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Instructions 1. This test report shall not be partially reproduced without the written consent of the laboratory. 2. The test results in this test report are only responsible for the samples submitted 3. This test report is invalid without the seal and signature of the laboratory. 4. This test report is invalid if transferred, altered, or tampered with in any form without authorization. 5. Any objection to this test report shall be submitted to the laboratory within 15 days from the date of receipt of the report. Page 3 of 23 Report No.: MTi230104005-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Table of contents 1. General Description ........................................................................................................................ 5 1.1 Description of the EUT ....................................................................................................................................... 5 1.2 Description of test modes ................................................................................................................................... 6 1.3 Description of support units ................................................................................................................................ 6 1.4 Environmental conditions ................................................................................................................................... 6 2. Measurement uncertainty ............................................................................................................... 7 3. Test laboratory ................................................................................................................................. 7 4. Summary of Test Result .................................................................................................................. 8 5. List of test equipment ..................................................................................................................... 9 6. Test Results ................................................................................................................................... 10 5.1 Antenna requirement ........................................................................................................................................ 10 5.3 AC power line conducted emissions ........................................................................................................... 11 5.4 Radiated emissions..................................................................................................................................... 14 5.5 Occupied bandwidth test ............................................................................................................................ 21 Photographs of the test setup ............................................................................................................. 23 Photographs of the EUT....................................................................................................................... 23 Page 4 of 23 Report No.: MTi230104005-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Test Result Certification Applicant: Shenzhen powerqi Technology Co.,Ltd Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China. Manufacturer: Shenzhen powerqi Technology Co.,Ltd Address: Room 201, 302, 401 of A4 Building, Block A, Fangxing Science and Technology Park, No. 13 of Baonan Road, Longgang District, Shenzhen, China. Product description Product name: 3-in-1 Magnetic Wireless Charging Stand Trademark: N/A Model name: LC65C Series Model: N/A Standards: FCC 47 CFR Part 15 Subpart C Test method: ANSI C63.10-2013 Date of Test Date of test: 2023-02-03 ~ 2023-02-27 Test result: Pass Test Engineer : (Yanice Xie) Reviewed By: : (Leon Chen) Approved By: : (Tom Xue) Page 5 of 23 Report No.: MTi230104005-01E1 Address: 101, No. 7, Zone2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Tel: (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] 1. General Description 1.1 Description of the EUT Product name: 3-in-1 Magnetic Wireless Charging Stand Model name: LC65C Series Model: N/A Model difference: N/A Electrical rating: Input: DC5V/3A, 9V/3A Output: USB-A+USB-C: 5W Wireless Output: Transmitter 1(Phone): 5W/7.5W/10W/15W Transmitter 2(Airpods): 5W Accessories: Cable: USB-A to USB-C cable (1.5m) Hardware version: V10 Software version: V10 Test sample(s) number: MTi230104005-01S1001 RF specification: Operation frequency: Transmitter 1(Phone): 115 kHz – 205 kHz Transmitter 2(Airpods):115 kHz – 205 kHz Modulation type: ASK Antenna type: Coil Antenna Page 6 of 23 Report No.: MTi230104005-01E1 Address: 101, No…

Text truncated - open the document above for the full version.

Page 1 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Appendix - Test Setup Photos Model: LC65C Radiated emissions – Below 30 MHz Radiated emissions –Below 1 GHz Page 2 of 2 Address: 101, No. 7, Zone 2, Xinxing Industrial Park, Fuhai Avenue, Xinhe Community, Fuhai Street, Bao’an District, Shenzhen, Guangdong, China Te l : (86-755)88850135 Fax: (86-755) 88850136 Web: www.mtitest.com E-mail: [email protected] Conducted emissions MPE ----End of Report----
