2AG87RM-5800Smart Radio

Compliance list INTEGRATION INSTRUCTIONS for 996369 D03 OEM the and 996369 D03 OEM by Sections 2.2 through 2.10. RequirementYesN/A Comment 2.2 List of applicable FCC rules List the FCC rules that are applicable to the modular transmitter. These are the rules that specifically establish the bands of operation, the power, spurious emissions, and operating fundamental frequencies. DO NOT list compliance to unintentional‐radiator rules (Part 15 Subpart B) since that is not a condition of a module grant that is extended to a host manufacturer. See also Section 2.10 below concerning the need to notify host manufacturers that further testing is required. 3 YESRefer to instruction FCC standards: FCC CFR Title 47 Part 15 Subpart E Section 15.407: 2016 2.3 Summarize the specific operational use conditions Describe use conditions that are applicable to the modular transmitter, including for example any limits on antennas, etc. For example, if point‐to‐point antennas are used that require reduction in power or compensation for cable loss, then this information must be in the instructions. If the use condition limitations extend to professional users, then instructions must state that this information also extends to the host manufacturer’s instruction manual. In addition, certain information may also be needed, such as peak gain per frequency band and minimum gain, specifically for master devices in 5 GHz DFS bands. YESRefer to instruction Antenna Type: External Antenna Antenna Gain: 3dBi 2.4 Limited module procedures If a modular transmitter is approved as a “limited module,” then the module manufacturer is responsible for approving the host environment that the limited module is used with. The manufacturer of a limited module must describe, both in the filing and in the installation instructions, the alternative means that the limited module manufacturer uses to verify that the host meets the necessary requirements to satisfy the module limiting conditions. A limited module manufacturer has the flexibility to define its alternative method to address the conditions that limit the initial approval, such as: shielding, minimum NoRefer to instruction Antenna Type: External Antenna Antenna Gain: 3dBi signaling amplitude, buffered modulation/data inputs, or power supply regulation. The alternative method could include that the limited module manufacturer reviews detailed test data or host designs prior to giving the host manufacturer approval. This limited module procedure is also applicable for RF exposure evaluation when it is necessary to demonstrate compliance in a specific host. The module manufacturer must state how control of the product into which the modular transmitter will be installed will be maintained such that full compliance of the product is always ensured. For additional hosts other than the specific host originally granted with a limited module, a Class II permissive change is required on the module grant to register the additional host as a specific host also approved with the module. 2.5 Trace antenna designs For a modular transmitter with trace antenna designs, see the guidance in Question 11 of KDB Publication 996369 D02 FAQ – Modules for Micro‐Strip Antennas and traces. The integration information shall include for the TCB review the integration instructions for the following aspects: layout of trace design, parts list (BOM), antenna, connectors, and isolation requirements. 4 a) Information that includes permitted variances (e.g., trace boundary limits, thickness, length, width, shape(s), dielectric constant, and impedance as applicable for each type of antenna); b) Each design shall be considered a different type (e.g., antenna length in multiple(s) of frequency, the wavelength, and antenna shape (traces in phase) can affect antenna gain and must be considered); c) The parameters shall be provided in a manner permitting host manufacturers to design the printed circuit (PC) board layout; d) Appropriate parts by manufacturer and specifications; e) Test procedures for design verification; and YesThe module has its own fixed antenna path f) Production test procedures for ensuring compliance. The module grantee shall provide a notice that any deviation(s) from the defined parameters of the antenna trace, as described by the instructions, require that the host product manufacturer must notify the module grantee that they wish to change the antenna trace design. In this case, a Class II permissive change application is required to be filed by the grantee, or the host manufacturer can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. 2.6 RF exposure considerations It is essential for module grantees to clearly and explicitly state the RF exposure conditions that permit a host product manufacturer to use the module. Two types of instructions are required for RF exposure information: (1) to the host product manufacturer, to define the application conditions (mobile, portable – xx cm from a person’s body); and (2) additional text needed for the host product manufacturer to provide to end users in their end‐product manuals. If RF exposure statements and use conditions are not provided, then the host product manufacturer is required to take responsibility of the module through a change in FCC ID (new application). YESRefer to instruction The modular can be installed or integrated in mobile or fix devices only. This modular cannot be installed in any portable device. This modular complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. This modular must be installed and operated with a minimum distance of 20 cm between the radiator and user body. 2.7 Antennas A list of antennas included in the application for certification must be provided in the instructions. For modular tra…

Text truncated - open the document above for the full version.

Apr 20, 2020 © 2020 Doodle Labs. All rights reserved.Page 1 Datasheet Doodle Labs Smart Radio – RM-5800 Advanced MIMO Mesh Router in a tiny Form Factor Smart Radio Overview The Smart Radio is an advanced 2×2 MIMO mesh router designed for easy plug & play integration. The tiny module carries all bi-directional communication (e.g. Telemetry, Video) in a single high-speed broadband RF channel. Due to its very low SWaP-C (Space, Weight and Power, Cost), the Smart Radio is very popular for mobile IIoT (Industrial Internet of Things) applications like drones and autonomous vehicles across various industries. The Smart Radio employs Doodle Labs’ patentedMesh Rider® technology with state-of-the-art RF and networking capabilities that enable communication further, faster, and more reliably than any comparable solution on the market. For example, the Ultra Reliable Low Latency Channel (URLLC) transports important command and control data over the wireless link,while a concurrent video-optimized streaming channel carries crystal clear 4K video. The Smart Radio is available in many frequency bands between 100 MHz and 6 GHz in form- factor compatible models. This allows customers to switch the operating band by simply swapping radio module, avoiding costly re-design efforts when expanding to new markets that require new frequencies. The Smart Radio is available in Embedded, External and Pocketable form factors. For more information, please visit -https://doodlelabs.com/smart-radio/ Samples available on Mouser:https://www.mouser.com/search/refine.aspx?N=4248121056 Apr 20, 2020 © 2020 Doodle Labs. All rights reserved.Page 2 Datasheet Key Features - Smart Radio Platform PERFORMANCE RF  Long range (field tested >100km) and high throughput (up to 100 Mbps)  Interference resistant COFDM for robust link quality in difficult RF environments  Exceptional Multipath and NrLOSMIMO performance  Adaptive radio modulations from BPSK up to 64QAM, with continuous per packet optimization to maximize link performance in dynamic environments  Software defined channel size for efficient re-use of spectrum  Convolutional coding, Forward Error Correction (FEC), ACK-retransmits, Maximal Ratio Combining, Spatial Multiplexing, and Space Time Block Coding for robust data transmission over noisy spectrum  Single channel, Time Division Duplexing (TDD) for bi-directional traffic  Resistant to high-power jamming signals  ATPC for widely dispersed mesh network  Built-in Spectrum Scanner to help mitigate interference issues PERFORMANCE NETWORKING  Ultra-Reliable Low Latency Channel (URLLC) for Command and Control  Optimized video streaming channel for Unicast and Multicast transport  Self-healing/self-forming multi-frequency mobile mesh for highly reliable network with redundancy  AES 256 and 128 bit encryption; FIPS-2, Level 2 compliant  End-to-end IP architecture with Ad Hoc, WDS transparent bridge, Client, AP, and Internet Gateway operating modes  Embedded network management APIs ADDITIONAL FEATURES  Very small size, weight, and power (SWaP-C) for mobile applications  Ethernet, USB, and UART interfaces to allow easy integration into different system architectures  Leverage the benefits of the most extensible OpenWrt ecosystem and install 3 rd party IoT applications  Rugged, vibration resistant constructionto meet MIL-specs  MIL-spec temp range (-40C to +85C)  High quality, manufactured in ISO9001 and ISO14001 certified facilities COTS – Commercial off the Shelf  Extended lifespan and availability Band Introduction – 5725~5875 MHz ISM Band Apr 20, 2020 © 2020 Doodle Labs. All rights reserved.Page 3 Datasheet The 5.8 GHz ISM Band ranges from 5735~5840 MHz. Due to it's globally unlicensed nature, the 5.8 GHz ISM band is popular for establishing wireless data links for Industrial IoT use cases. The major functions of systems operating in this band are point-to-point communications, video surveillance, control of robotic systems and unmanned aerial vehicles data links supporting exchange of sensor data. System Integration The Smart Radio has been designed to be nearly plug and play. Only Ethernet/USB, power supply, and antenna connections are required for integration. Doodle Labs provides extensive design-in documents at: https://www.doodlelabs.com/technologies/technical-library/ Ethernet DC Power Smart Radio ANT 0 ANT 1 USB, UART GPIO Apr 20, 2020 © 2020 Doodle Labs. All rights reserved.Page 4 Datasheet Technical Specifications (5725-5875MHz ISMBand) Model CategoryProXtreme ORDERING CODES Radio Configuration 2x2 MIMO, with 2x Ethernet, 2x USB and 1x UART interfaces Model # (Embedded)RM-5800-2J-PMRM-5800-2J-XM Model # (External) RM-5800-2J-PERM-5800-2J-XE Integrated GPS (Optional)-G suffix Evaluation Kit EK-5800-SR Design-In Documentation https://www.doodlelabs.com/technologies/technical-library/ PERFORMANCE OVERVIEW Max Operating Range >10 Km (Recommended) >20 Km (Recommended), (Max field demonstrated range >100km) Max Data Throughput at 10- meter range (Indicative) 80 Mbps (20 MHz Channel) 40 Mbps (10 MHz Channel) 100 Mbps (40 MHz Channel) 80 Mbps (20 MHz Channel) 40 Mbps (10 MHz Channel) 20 Mbps (5 MHz Channel) 12 Mbps (3 MHz Channel) Over the Air Data Encryption 128-bit AES (Full throughput)256-bit AES (12 Mbps max throughput) (FIPS140-2, Level 2 compliant) Operating Modes Mesh, AP, Client, Transparent WDS Bridge + Internet Gateway Command & Control channel Ultra-Reliable Low Latency Channel (URLLC). Latency (6 ms Min, 30 ms Typical) Video Channel Optimized video streaming with Unicast and Multicast transmission RF SPECIFICATIONS Frequency Range 5735-5840 MHz Channel Sizes (Software Selectable) 10, 20MHz 3, 5, 10, 20, 40 MHz Radio Data Rate (Modulation Coding Scheme – MCS) Dynamic Link Auto Adaptation Apr 20, 2020 © 2020 Doodle Labs. All rights reserved.Page 5 Datasheet Model CategoryProXtreme RF Power Output (Typ) Each radio individually calibrated 400mW (26 dBm), @ MCS 0,8 200mW (23 dBm), @ MCS 3,11 125mW…

Text truncated - open the document above for the full version.

DoodleLabs(SG)PteLtd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date:2020-09-08 Subject; Request for Long Term Confidentiality FCC ID: 2AG87RM-5800 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description FCC SOFTWARE SECURITY DESCRIPTION It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dr Aaron Do Title: Senior RF Engineer

Doodle Labs (SG) Pte Ltd FCC Modular Approval Request Rev 3.0 Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020-09-08 Subject;Modular Transmitter Application Company name: Doodle Labs (SG) Pte Ltd FCC ID: 2AG87RM-5800 Dear Sir/Madam, This letter includes the FCC application requirements for Modular Transmitter Approval Request for;- FCC KDB 996369 D01 ‘Module Certification Guide v02; and FCC KDB 996369 D03 OEM Manual v01 In accordance with 47CFR 15.212 Modular Transmitters and KDB 996369 D01 ‘Module Equip Auth Guide v02’. FCC ID:2AG87RM-5800has been examined against the following requirements. Requirement per 15.212 and KDB 996369 D01Explanation from Grantee (do not write yes/no, but explain why product complies/how it is achieved) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly. The modular have RF own shielding The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal. The modular transmitter have buffered modulation/data inputs The module must contain power supply regulation on the module. The modular transmitter have its own power supply regulation. The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per §§ 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b). The modular has a External Antenna, which has a unique antenna connector. The module must demonstrate compliance in a stand-alone configuration. The module compliance in a stand-alone configuration. The module must be labeled with its permanently affixed FCC ID label, or use an electronic display (see KDB Publication 784748). The FCC identification number can put on the modular with either a permanently affixed label The module must comply with all specific rules applicable to the transmitter, including all the conditions provided in the integration instructions by the grantee. The instructions will be provided and apply to a complete transmitter and comply with specific rule. The module must comply with RF exposure requirements The total power density of modular transmitter final configuration comply with FCC RF Exposure Doodle Labs (SG) Pte Ltd FCC Modular Approval Request Rev 3.0 Name: Dr Aaron DoDate: 2020-09-08 Title: Senior RF Engineer Signature of applicant

FCC Software Configuration Control Declaration Rev1.1 Doodle Labs (SG) Pte Ltd FCC Software Configuration Control Declaration Date: September 30, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: Smart Radio / RM-5800 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Dr Aaron DoDate: 2020-09-08 Title: Senior RF Engineer Signatureof applicant

Page 1 of 4 Appendix B: Photographs of EUT Product: Smart Radio Model: RM-5800 External Photos Antenna 1 Antenna 0 Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: RM-5800 Label: Size: L*W=28*20mm MAC: 00301A4E00XX RM-5800 D2418 FCC ID: 2AG87RM-5800 IC: 21411-RM5800 Contains FCC ID: Z9W-CM4 & IC: 11468A-CM4 Location

Page 1 of 6 Appendix B: Photographs of EUT Product: Smart Radio Model: RM-5800 Internal Photos Page 2 of 6 Page 3 of 6 Page 4 of 6 Page 5 of 6 Page 6 of 6

Maximum Permissible Exposure Applicable Standard According to §1.1307(b), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. Remark: 1) MIMO MPE: The maximum output power for antenna 0 is 25.24dBm (334.20mW) at 5840MHz, 3dBi antenna gain(with 2.00 numeric antenna gain.) The maximum output power for antenna 0 is 25.13dBm (325.84mW) at 5840MHz, 3dBi antenna gain(with 2.00 numeric antenna gain.) 2) For mobile or fixed location transmitters, no SAR consideration applied. The minimum separation generally be used is at least 20cm, even if the calculation indicate that the MPE distance would be lesser. Substituting the MPE safe distance using d=20cm into above equation. Yields: S=0.000199*P*G MPE 0: Power(mW) numeric antenna gain Power density (mW/cm 2 ) 334.20 2.00 0.133012 MPE 1: Power(mW) numeric antenna gain Power density (mW/cm 2 ) 325.84 2.00 0.129684 Total MPE: Maximum Emissions Level MPE 0 MPE 1 Total MPE Limit (mW/cm 2 ) Result 0.133012 0.129684 0.262696 1.0 PASS

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AG87RM-5800 Product: Smart Radio Model No.: RM-5800 Additional Model No.: N/A Trade Mark: N/A Report No.: TCT200624E025 Issued Date: Aug. 28, 2020 Issued for: Doodle Labs (SG) Pte Ltd 150 Kampong Ampat, KA Center, Suite 05-03, Singapore 368324, Singapore Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT200624E025 Page 2 of 51 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification....................................................................................... 3 2. Test Result Summary ............................................................................... 4 3. EUT Description ........................................................................................ 5 4. General Information .................................................................................. 7 4.1. Test environment and mode ................................................................................. 7 4.2. Description of Support Units ................................................................................ 8 5. Facilities and Accreditations ................................................................... 9 5.1. Facilities ................................................................................................................. 9 5.2. Location ................................................................................................................. 9 5.3. Measurement Uncertainty ..................................................................................... 9 6. Test Results and Measurement Data .................................................... 10 6.1. Antenna requirement .......................................................................................... 10 6.2. Conducted Emission ........................................................................................... 11 6.3. Maximum Conducted Output Power .................................................................. 15 6.4. 6dB Emission Bandwidth ................................................................................... 18 6.5. 99% Occupied Bandwidth ................................................................................... 22 6.6. Power Spectral Density ....................................................................................... 26 6.7. Band edge ............................................................................................................ 30 6.8. Unwanted Emission ............................................................................................ 35 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT200624E025 Page 3 of 51 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Smart Radio Model No.: RM-5800 Additional Model No.: N/A Trade Mark: N/A Applicant: Doodle Labs (SG) Pte Ltd Address: 150 Kampong Ampat, KA Center, Suite 05-03, Singapore 368324, Singapore Manufacturer: Doodle Labs (SG) Pte Ltd Address: 150 Kampong Ampat, KA Center, Suite 05-03, Singapore 368324, Singapore Date of Test: Jun. 25, 2020 – Aug. 27, 2020 Applicable Standards: FCC CFR Title 47 Part 15 Subpart E Section 15.407: 2016 KDB662911 D01 Multiple Transmitter Output v02r01 KDB789033 D02 General U-NII Test Procedures New Rules v02r01 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Aug. 27, 2020 Rleo Reviewed By: Date: Aug. 28, 2020 Beryl Zhao Approved By: Date: Aug. 28, 2020 Tomsin Report No.: TCT200624E025 Page 4 of 51 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna requirement §15.203 PASS AC Power Line Conducted Emission §15.207 PASS Maximum Conducted Output Power §15.407(a) PASS 6dB Emission Bandwidth §15.407(a) PASS 99% Occupied Bandwidth §15.407(a) PASS Power Spectral Density §15.407(a) PASS Restricted Bands around fundamental frequency §15.407(a) PASS Radiated Emission §15.407(a) PASS Frequency Stability §15.407(g) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT200624E025 Page 5 of 51 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: Smart Radio Model No.: RM-5800 Additional Model No.: N/A Trade Mark: N/A Hardware Version: V1.0 Software Version: V1.0 Operation Frequency: 5735 MHz - 5840 MHz Channel Bandwidth: 20MHz Modulation Technology: Orthogonal Frequency Division Multiplexing(OFDM) Modulation Type 256QAM, 64QAM, 16QAM, BPSK, QPSK Antenna Type: External Antenna Antenna Gain: 3dBi Power Supply: Input: AC120V/60Hz, Output: DC 5V from adapter (voltage range: 5V up to 42V) Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. Report No…

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Smart Radio Model: RM-5800 Radiated Emission Page 2 of 2 Conducted Emission
