2AGBW9290022691XHue light strip

Project Manager: Trident Artist: PHILIPS HUE SUBBRAND 2017 B MANUAL N/A N/A Trident UK 3222 639 05751 3241 655 20841 N/A Yana Yusef ARTWORK PHL396406 Trident UK, Connaught House, Connaught Road, Kingswood Business Park, Hull, HU7 3AP, England. T:+44 (0) 01482 828100 Please note that any low resolution paper Canon colour copies associated with this job should be referred to for content, layout and colour separation only. UNDER NO CIRCUMSTANCES SHOULD THIS ARTWORK BE ALTERED WITHOUT PRIOR PERMISSION FROM TRIDENT. Dieline Guides Technical & Non Printing Items TR1705788 28/10/2019 C Glenn Pickersgill Colours: Master Ref: TR Ref: Brand: Brand execution: Product name: Shape: Wattage: Region: Artwork 12NC: Die cut 12NC: Barcode: CRC Number: Action: Date: 1 Black LTH 2 45 3 76 91011 8 03 0401 02 EN SAFETY INSTRUCTIONS – PART B • The manufacturer advises the correct use of luminaires lighting fixtures! Therefore always follow these instructions to ensure correct and safe installation and functioning of the luminaire and keep it for future reference. • Turn off electrical power at main fuse or circuit breaker box before commencing installation, maintenance or repair. • If in doubt, consult a qualified electrician or contact your retail outlet. Ensure that you always install the luminaire to the local electrical code. Certain regulations indicate that luminaires should be installed by a qualified electrician. • Always use wire nuts/connectors rated for the correct gauge and number of wires used. CAUTION: Be certain that no bare wire strands are exposed outside of the wire nuts/connections (if applicable). • Be careful not to damage or cut the wire insulation (covering) during installation. Do not permit wires to contact any sharp edges. • Do not remove thermal insulation pad(s). Doing so will result in increased temperatures and possible risk of fire. • Maintain interior lighting with a dry cloth duster, do not use abrasives or solvents. Avoid liquid on all electrical parts. • Always consider all the technical specifications of the luminaire. Verify the stated icons on the identification label on the luminaire and the icons that are shown in part A of your safety instructions. ATTENTION: Below you will find all the explanations with numeric reference to the icons respectively in front of these PART-B safety instructions. Applicable icons to your fixture are shown in PART-A safety instructions. 01 - This luminaire should only be installed indoors. 02 - Only suitable for dry locations. 03 - This product is not suitable for children under 14 years. 04 - Suitable for under-cabinet mounting. Thank you for purchasing this Philips Hue product, we highly appreciate your choice for the Philips brand and wish you lots of pleasure using your product. Please go to www.meethue.com to learn more about HUE and how to use it. This manual B contains definitions of all potentially applicable parameters & specifications with icons, as per International norms and safety standards. However not all of them may be applicable for the product you purchased - please refer to the icons in the Manual A, for the ones which are particulary applicable for this product. FCC ID: 2AGBW9290022691X IC ID: 20812-2691X This device complies with Part 15 of the FCC Rules and with RSSs of Industry Canada. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. DRYDAMPWET Lightstrip Plus B This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This device generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. This Class B digital apparatus complies with CAN ICES-005 (B) / NMB-005 (B). This digital apparatus does not exceed the class B limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications. NOTICE:Changes or modifications made to this device not expressly approved by Signify North America (USA) and Signify Canada Ltd./Signify Canada Ltée. (collectively “Signify”) may void the U.S. FCC and Canadian authorization to operate this device. The advanced interface module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This device should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna • Increase the separation between the device and receiver • Connect the device into an outlet on a circuit different from that to which the receiver is connected • Consult the dealer or an experienced radio/television technician for help WARNINGS AND CAUTIONS: • Risk of electric shock – Do not use device where directly exposed to water. • The device is for indoor use only. • Dry location use only. OPERATING INSTRUCTIONS: • This device is not a toy designed to be played with by children. • Do not place the device on hot surfaces. • For safety reasons, do not open device, which will also void the warranty. • Only use the adaptor sup…

Text truncated - open the document above for the full version.

Signify (China) Investment Co., Ltd. FCB011_02 //DEKRA Testing and Certification, S.A.U. // www.dekra-product-safety.com/wireless Date: November 15, 2019 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: Agent letter for FCC ID: 2AGBW9290022691X We, Signify (China) Investment Co., Ltd. Building 9,Lane 888,Tianlin Road,Minhang district Shanghai, China hereby authorize DEKRA Testing and Certification (Shanghai) Co., Ltd. 8F, No. 250, Jiangchangsan Road, Shanghai, 200436, P. R. China Mr. /Ms. Gao Han, e-mail: [email protected], Phone: +86 21 6056 7597 to act as our agent in the preparation of this application for equipment certification, including the signing of all documents relating to these matters. The present authorization considers the development of documents on behalf of the client, written under his own letterhead and related to the necessary information to be provided on his behalf to complete the certification process. We also hereby certify that neither we nor any party to this application are subject to a denial of U.S. Federal benefits, which include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862 because of conviction for possession or distribution of controlled substance. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by DEKRA Testing and Certification, S.A.U., still resides with us. This agreement expires one year from the current date. Sincerely, __________________________ By: Yefeng Zhang Title: Approbation Engineer Company: Signify (China) Investment Co., Ltd. Telephone: +86-21-24128779 e-mail: yefeng.zhang@ signify.com

Signify (China) Investment Co., Ltd. FCB012_02 //DEKRA Testing and Certification, S.A.U. // www.dekra-product-safety.com/wireless Date: November 15, 2019 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: Confidentiality request for FCC ID: 2AGBW9290022691X To whom it may concern: Pursuant to §0.457(d)(1)(ii) and §0.459 of the Commission’s Rules (47 C.F.R.) and §552 (b)(4) of the Freedom of Information Act, Signify (China) Investment Co., Ltd. hereby request requests that a part of the subject FCC application be held confidential to avoid release of sensitive information of the product to the public. For the product stated above, we request that the following information be withheld from public disclose: Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Internal Photos Short Term Permanent Operation Description Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term User’s Manual Permanent Confidentiality: The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to us and provide unjustified benefits to our competitors. Short-Term Confidentiality: We hereby request short-term confidentiality for the product stated above to avoid premature release of sensitive information prior to marketing or release of the product to the public. Release date of short term confidentiality is: 45 days from grant date marked 90 days from grant date marked 135 days from grant date marked 180 days from grant date marked Specific date: We are also aware that we are responsible to notify DEKRA in the event information regarding the product or the product is made available to the public. DEKRA will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Sincerely, __________________________ By: Yefeng Zhang Title: Approbation Engineer Company: Signify (China) Investment Co., Ltd. Telephone: +86-21-24128779 e-mail: [email protected]

Signify (China) Investment Co., Ltd. FCB012_02 //DEKRA Testing and Certification, S.A.U. // www.dekra-product-safety.com/wireless Date: November 15, 2019 DEKRA Testing and Certification, S.A.U. Parque Tecnológico de Andalucía C/ Severo Ochoa 2 & 6 29590 Campanillas Málaga, España Ref: sDoC declaration letter for FCC ID: 2AGBW9290022691X To whom it may concern: Pursuant to §15.101 of the Commission’s Rules (47 C.F.R.), Signify (China) Investment Co., Ltd. hereby declare that the device above mentioned is classified under the following equipment class/classes: JAB Part 15 Class B Digital Device JAD Part 15 Class A Digital Device JAV Other Non-Digital SDoC Devices JBP Part 15 Class B Computing Device/Personal Computer JBC Part 15 Class B Computing Device/Personal Computer CXX Communications Rcvr for use w/licensed Tx and CBs CRR Superregenerative Receiver CYY Communications Receiver used w/Pt 15 Transmitter HID Part 15 TV Interface Device And will follow the Authorization procedure Supplier’s Declaration of Conformity prior to the initiation of marketing. Sincerely, __________________________ By: Yefeng Zhang Title: Approbation Engineer Company: Signify (China) Investment Co., Ltd. Telephone: +86-21-24128779 e-mail: [email protected]

Page: 1 of 4 (1) EUT Photo (2) EUT Photo Page: 2 of 4 (3) EUT Photo (4) EUT Photo Page: 3 of 4 (5) EUT Photo (6) EUT Photo Page: 4 of 4 (7) EUT Photo

Page: 1 of 3 (1) EUT Photo (2) EUT Photo Page: 2 of 3 (3) EUT Photo (4) EUT Photo Page: 3 of 3 (5) EUT Photo (6) EUT Photo

DEK No.9 TEL: www Pr Tr FC IC M Ap Te Ve Do Te Ap Da Re KRA Testing a 99 Hongye Rd : +86-512-625 w.dekra-certific roduct Name rademark CC ID C odel and /or pplicant ́s na est method re erdict Summ ocumented B ested by (nam pproved by ( ate of issue eport templa and Certificat ., Suzhou Indu 51-5088 / FAX cation.com e type referen ame / addres equested, st mary By me / position name / posit ate No tion (Suzhou) ustrial Park, S X: +86-512-625 FCC & nce s tandard n & signature tion & signat ) Co., Ltd. Suzhou, 21500 51-5098 & ISE Hu PH 2A 20 92 Sig Bu 20 FC AN KD RS IN Kit e) Fra ure) Ja 20 19 06, Jiangsu, C ED TES ue light strip HILIPS AGBW92900 0812-2691X 290022691, 9 gnify (China) uilding no.9, 00233, China CC CFR Title NSI C63.10: D558074 D0 SS-Gen Issu COMPLIAN tty Li/Project ank He/ Tec ack Zhang/ S 019-11-28 992171R-RF- China ST RE 22691X 9290022692 ) Investment Lane 888, T a e 47 Part 15 2013 1 15.247 Me e 5 / RSS-24 NCE t Assistant hnical Super upervisor -US-P06V01 19 EPOR Co., Ltd ianlin Road, Subpart C S eas Guidance 47 Issue 2 rvisor Test rep 992171R-RF RT Minhang Dis Section 15.24 e v05r02 port No: F-US-P06V01 strict, Shang 47 1 hai, DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 www.dekra-certification.com Report no.: 1992171R-RF-US-P06V01 Page 2 / 157 INDEX page General conditions ............................................................................................................................................................ 4 Environmental conditions .................................................................................................................................................. 4 Possible test case verdicts ................................................................................................................................................ 5 Abbreviations..................................................................................................................................................................... 5 Document History .............................................................................................................................................................. 6 Remarks and Comments .................................................................................................................................................. 6 Used Equipment ................................................................................................................................................................ 7 Uncertainty ........................................................................................................................................................................ 9 1 General Information ............................................................................................................................................... 10 1.1 General Description of the Item(s) ............................................................................................................... 10 1.2 Antenna Information .................................................................................................................................... 11 1.3 Channel List ................................................................................................................................................. 12 2 Description of Test Setup ....................................................................................................................................... 13 2.1 Operating mode(s) used for tests ................................................................................................................ 13 2.2 Auxiliary equipment / Test software for the EUT ......................................................................................... 13 2.3 Test Configuration / Block diagram used for tests ....................................................................................... 14 2.4 Testing process ........................................................................................................................................... 15 3 Verdict summary section ........................................................................................................................................ 16 3.1 Standards .................................................................................................................................................... 16 3.2 Deviation(s) from the Standard(s) / Test Specification(s) ............................................................................ 16 3.3 Overview of results ...................................................................................................................................... 17 3.4 Test Facility .................................................................................................................................................. 18 4 Test Results ........................................................................................................................................................... 19 4.1 AC Power Line Conducted Emission ........................................................................................................... 19 4.1.1 Limit ................................................................................................................................................... 19 4.1.2 Test Setup ......................................................................................................................................... 19 4.1.3 Test Procedure .................................................................................................................................. 19 4.1.4 Test Data ...........................................................................................................................…

Text truncated - open the document above for the full version.

DEK No.9 TEL: www Pr Tr FC IC M Ap Te Ve Do Te Ap Da Re KRA Testing a 99 Hongye Rd : +86-512-625 w.dekra-certific roduct Name rademark CC ID C odel and /or pplicant ́s na est method re erdict Summ ocumented B ested by (nam pproved by ( ate of issue eport templa and Certificat ., Suzhou Indu 51-5088 / FAX cation.com e type referen ame / addres equested, st mary By me / position name / posit ate No tion (Suzhou) ustrial Park, S X: +86-512-625 FCC & nce s tandard n & signature tion & signat ) Co., Ltd. Suzhou, 21500 51-5098 & ISE Hu PH 2A 20 92 Sig Bu 20 FC AN KD RS IN Kit e) Fra ure) Ja 20 19 06, Jiangsu, C ED TES ue light strip HILIPS AGBW92900 0812-2691X 290022691, 9 gnify (China) uilding no.9, 00233, China CC CFR Title NSI C63.10: D558074 D0 SS-Gen Issu COMPLIAN tty Li/Project rank He/ Tec ack Zhang/ S 019-11-28 992171R-RF- China ST RE 22691X 9290022692 ) Investment Lane 888, T a e 47 Part 15 2013 1 15.247 Me e 5 / RSS-24 NCE t Assistant hnical Super upervisor -US-P06V02 19 EPOR Co., Ltd ianlin Road, Subpart C S eas Guidance 47 Issue 2 rvisor 2 Test rep 992171R-RF RT Minhang Dis Section 15.24 e v05r02 port No: F-US-P06V02 strict, Shang 47 2 hai, DEKRA Testing and Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 www.dekra-certification.com Report no.: 1992171R-RF-US-P06V02 Page 2 / 70 INDEX page General conditions ............................................................................................................................................................ 4 Environmental conditions .................................................................................................................................................. 4 Possible test case verdicts ................................................................................................................................................ 5 Abbreviations..................................................................................................................................................................... 5 Document History .............................................................................................................................................................. 6 Remarks and Comments .................................................................................................................................................. 6 Used Equipment ................................................................................................................................................................ 7 Uncertainty ........................................................................................................................................................................ 9 1 General Information ............................................................................................................................................... 10 1.1 General Description of the Item(s) ............................................................................................................... 10 1.2 Antenna Information .................................................................................................................................... 11 1.3 Channel List ................................................................................................................................................. 12 2 Description of Test Setup ....................................................................................................................................... 13 2.1 Operating mode(s) used for tests ................................................................................................................ 13 2.2 Auxiliary equipment / Test software for the EUT ......................................................................................... 13 2.3 Test Configuration / Block diagram used for tests ....................................................................................... 14 2.4 Testing process ........................................................................................................................................... 15 3 Verdict summary section ........................................................................................................................................ 16 3.1 Standards .................................................................................................................................................... 16 3.2 Deviation(s) from the Standard(s) / Test Specification(s) ............................................................................ 16 3.3 Overview of results ...................................................................................................................................... 17 3.4 Test Facility .................................................................................................................................................. 18 4 Test Results ........................................................................................................................................................... 19 4.1 AC Power Line Conducted Emission ........................................................................................................... 19 4.1.1 Limit ................................................................................................................................................... 19 4.1.2 Test Setup ......................................................................................................................................... 19 4.1.3 Test Procedure .................................................................................................................................. 19 4.1.4 Test Data .........................................................................................................................…

Text truncated - open the document above for the full version.

RF Exposure Evaluation Declaration Product Name : Hue light strip Model No. : 9290022691; 9290022692 FCC ID : 2AGBW9290022691X IC : 20812-2691X Applicant : Signify (China) Investment Co., Ltd. Address : Building no.9, Lane 888, Tianlin Road, Minhang District, Shanghai 200233, China Date of Receipt : Sep. 25, 2019 Test Date : Oct. 08, 2019 ~ Nov. 04, 2019 Issued Date : Nov. 28, 2019 Report No. : 1992171R-RF-US-P20V01 Report Version : V1.1 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Issuing CB Testing Laboratory. The measurement result is considered in conformance with the requirement if it is within the prescribed limit, It is not necessary to calculate the uncertainty associated with the measurement result. This report is not used for social proof in China (or Mainland China) market. Report No: 1992171R-RF-US-P20V01 Page: 2 of 5 Test Report Certification Issued Date : Nov 28, 2019 Report No. : 1992171R-RF-US-P20V01 Product Name : Hue light strip Applicant : Signify (China) Investment Co., Ltd. Address : Building no.9, Lane 888, Tianlin Road, Minhang District, Shanghai 200233, China Manufacturer : Signify (China) Investment Co., Ltd. Address : Building no.9, Lane 888, Tianlin Road, Minhang District, Shanghai 200233, China Model No. : 9290022691; 9290022692 FCC ID : 2AGBW9290022691X IC ID 20812-2691X Brand Name : PHILIPS EUT Voltage : 100-240 Vac, 50-60 Hz Test Voltage : AC 120V/60Hz Applicable Standard : KDB 447498D01V06 FCC Part1.1310 RSS-102: Issue 5, 2015 Test Result : Complied Performed Location : DEKRA Testing & Certification (Suzhou) Co., Ltd. No.99 Hongye Rd., Suzhou Industrial Park, Suzhou, 215006, Jiangsu, China TEL: +86-512-6251-5088 / FAX: +86-512-6251-5098 FCC Designation Number: CN1199 ISED CAB identifier: CN0040 Documented By : (Project Assistant: Kitty Li) Reviewed By : (Senior Engineer: Frank He ) Approved By : (Engineer Supervisor: Jack Zhang ) Report No: 1992171R-RF-US-P20V01 Page: 3 of 5 1. RF Exposure Evaluation 1.1. Limits According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Average Time (Minutes) (A) Limits for Occupational/ Control Exposures 300-1500 -- -- F/300 6 1500-100,000 -- -- 5 6 (B) Limits for General Population/ Uncontrolled Exposures 300-1500 -- -- F/1500 6 1500-100,000 -- -- 1 30 F= Frequency in MHz Friis Formula Friis transmission formula: Pd = (Pout*G)/(4*pi*r2) Where Pd = power density in mW/ cm 2 Pout = output power to antenna in mW G = gain of antenna in linear scale Pi = 3.1416 R = distance between observation point and center of the radiator in cm Pd is the limit of MPE, 1 mW/ cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Report No: 1992171R-RF-US-P20V01 Page: 4 of 5 According to RSS 102 Issue 5: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in RSS 102 Clause 4 LIMITS FOR MAXIMUM PERMISSIBLE EXPOSURE (MPE) Report No: 1992171R-RF-US-P20V01 Page: 5 of 5 1.2. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, middle and highest channel individually. The temperature and related humidity: 18and 78 RH. 1.3. Test Result of RF Exposure Evaluation Product : Hue light strip Test Item : RF Exposure Evaluation Test Site : AC-6  Antenna Information: Antenna manufacturer N/A Antenna Delivery 1*TX+1*RX 2*TX+2*RX 3*TX+3*RX Antenna technology SISO MIMO Basic CDD Beam-forming Antenna Type ExternalDipole Internal PIFA PCB Ceramic Chip Antenna Stamping Antenna Metal plate type F antenna Monopole antenna Antenna Gain 2.78 dBi Report No: 1992171R-RF-US-P20V01 Page: 6 of 5  Power Density: The tune-up power is 1dB, so the maximum conducted power of BT we used to calculate RF exposure is 10.47dBm. The tune-up power is 1dB, so the maximum conducted power of Zigbee we used to calculate RF exposure is 10.75dBm. Test Mode Frequency Band (MHz) EIRP (dBm) Limit of Power Density S(mW/cm 2 ) Power Density at R = 20 cm (mW/cm 2 ) BT 2400 ~ 2483.5 13.25 1 0.0042 Zigbee 2400 ~ 2483.5 13.53 1 0.0045 Note: The maximum power density is 0.0045mW/ cm 2 for LED lamp without any other radio equipment. The End

Test Setup Photograph Test Mode: Mode 1 Description: Front View of Conducted emission Test Setup Test Mode: Mode 1 Description: Side View of Conducted emission Test Setup Description: Radiated Emission Test Setup for Below 1GHz Description: Radiated Emission Test Setup for 1~18GHz Description: Radiated Emission Test Setup for Above 18GHz
