2AGGZ003B9ACA50Transmitter(Push one channel remote)

INSTALLER INSTALLER STEP 1.STEP 2. A division of Rollease Acmeda FACTORY RESET MOTOR RESET PROCEDURE STEP 3.STEP 5. STEP 6. STEP 4. Press up or down to check the motor direction. If correct skip to step 5. Move shade to desired top limit by pressing the up arrow repeatedly. Then press and hold up & stop together for 5 sec to save limit. Move shade to desired bottom limit by pressing the down arrow repeatedly. Then press and hold down & stop together for 5 sec to save limit. To reset all settings in the motor press and hold the P1 Button for 14 seconds, you should see 4 independent jogs followed by 4x Beeps at the end. (Internal Tubular pictured above. Refer to “P1 Locations” for specific devices.) Tap the arrow several times or hold down if needed; press arrow to stop. Tap the arrow several times or hold down if needed; press arrow to stop. If the shade direction needs to be reversed; press and hold the UP & DOWN arrow together for 5 seconds until the motor jogs. Reversing motor direction using this method is only possible during initial set-up. OR * Internal Tubular Motor pictured. Refer to “P1 Locations” for specific devices. Press the P1 button on the motor for 2 Seconds until the motor responds as below. Within 4 seconds hold the stop button on the remote for 3 seconds. The motor will respond with Jog and Beep. CHECK DIRECTIONSET TOP LIMITSET BOTTOM LIMIT CHANGE DIRECTION ON REMOTE This setup wizard should be used for new installation or factory reset motors only. Individual steps may not work if you haven’t followed the setup from the beginning. MT02-0101-xxx010_v1.0_07062023 INSTALLER BEST PRACTICE AND TIPSBUTTON OVERVIEW WALL MOUNTING REPLACE BATTERYASSEMBLY BATTERY MANAGEMENT PRODUCT RANGE & P1 LOCATIONS FCC & ISED STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device contains licence-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Please refer to separate Rollease Acmeda System Assembly Manual for full assembly instructions relevant to the hardware system being used. For battery motors; Prevent discharging the battery completely for extended periods, recharge as soon as the battery is discharged. CHARGING NOTES Charge your motor for 6-8hours, depending on the motor model, as per motor instructions. The Quick Start Programming Guide is universal for all Automate Motors including: SLEEP MODE If pre-programmed: before shipping the motor ensure the motor is put into sleep mode so it doesn’t activate during transit. LOCK REMOTE Prevent users accidentally changing the limit; ensure the remote is locked as your last step of programming. ZONE/GROUPS Ask the customer the day before to think how shades will be zoned on the remote. This may save an extra call out. SETTLE FABRIC Run the fabric up and down several times to ensure fabric has settled to some extent and re adjust the limits if needed. CHARGE 100% For battery motors ensure the motor is fully charged as per instructions. INSTALLERS REMOTE Use a spare remote to individually program each shade. Then use that remote to group rooms as per the user’s needs. If you go back and service the installation later then, that same remote can be used to check the individual shades. STEP 1. Use a tool (such as a SIM card pin, mini screwdriver, etc.) to push the battery cover release button and simultaneously slide the battery cover in the direction shown. STEP 2. Install CR2450 Battery with positive (+) side facing up. STEP 3. Slide up to lock the battery door Note: On startup, remove battery isolation tab. Use supplied fasteners and anchors to attach the base to wall. LED UP STOP DOWN BAT TERY ISOLATION TAB 3V (CR2450) SETTING (P2) LOCK Do not ingest battery, Chemical Burn Hazard. During operation, if battery is low, the motor will beep 10 times to prompt the user it needs charging. Note: Curtain motor does not Jog but instead LED flashes Internal Tu b ular 0.8 Cord Lift 0.6 Cord Lift Tilt Motor Large Tubular Curtain Incorrect installation or use can lead to serious injury and will void manufacturer’s liability and warranty.…

Text truncated - open the document above for the full version.

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06-21-2023 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AGGZ003B9ACA50 Rollease Acmeda Inc certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Applicant signature: Applicant printed name: Jonny.Matuichuk

Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06-21-2023 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AGGZ003B9ACA50 Rollease Acmeda Inc certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Applicant signature: Applicant printed name: Jonny.Matuichuk

To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 06-21-2023 Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2AGGZ003B9ACA50 Rollease Acmeda Inc. certifies that, as of the date of the filing of the application, we designate ourselves as the U. S. agent for service of process. Designated U.S. Agent Information: FRN: 0025043381 Name: Rollease Acmeda Inc Address: 7th Floor / 750 East Main Street,Stamford, CT 06902, USA Contact Person: Jonny.Matuichuk Tel.: 2034906191 Email: [email protected] Sincerely, Jonny.Matuichuk

Rev 11/20/07 Rollease Acmeda Inc Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID:2AGGZ003B9ACA50 . Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (Block Diagram, Schematics, Operation description) (Block Diagram, Schematics, Operation description.pdf”) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. Pursuant to DA04-1705 June 15, 2004 of the Commission’s public notice, we also request temporary confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name (Internal Photos, Test Setup Photos, User manual) (Internal Photos, Test Setup Photos, User manual.pdf”) Number of days: 180 days Sincerely, (signature) (printed name)Jonny.Matuichuk

C:\Users\jonny.matuichuk\Downloads\Certification\More\FCC IC application Form-1225 mm Motors\FCC IC application Form-1225 mm Motors\FCC POA _Letter.docx Rollease Acmeda Inc Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Date: May 29,2023 SUBJECT: FCC Application for FCCID:2AGGZ003B9ACA50 To Whom It May Concern: We, the undersigned, hereby authorize Yu Anlu at TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, PrintedName: Jonny.Matuichuk Signature：

1 of 1 To whom it may concern, Letter of Declaration We, Rollease Acmeda Inc, hereby declare the models below: Model(S): MT02-0101-050010, MT02-0101-067010 FCC ID: 2AGGZ003B9ACA50 IC ID: 21769-003B9ACA50 are the same except for the different model name and colour Print name: Jonny Matuichuk Title: Product Manager Signature /Date: 25/05/2023

Date: 06-21-2023 To: Federal Communications Commission 7435 Oakland Mills Road Columbia MD FCC ID: 2AGGZ003B9ACA50 To Whom It May Concern: This letter is to ascertain that Product name: Transmitter (Push one Channel Remote) , Models: MT02- 0101-067010 (White) and MT02-0101-050010 (Black) have been the units used for conducting FCC compliance testing, the SDoC part will be tested by FCC recognized test lab. If you have any question or concerns, please contact us. Sincerely, Company name: Rollease Acmeda Inc Address: 7th Floor / 750 East Main Street,Stamford, CT 06902, USA Contact Person: Jonny.Matuichuk Tel.: 2034906191 Email: [email protected]

External Photos Documentation Applicant: Rollease Acmeda Inc Page 1 of 3 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-050010 External Photos Documentation Applicant: Rollease Acmeda Inc Page 2 of 3 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-050010 External Photos Documentation Applicant: Rollease Acmeda Inc Page 3 of 3 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-050010

External Photos Documentation Applicant: Rollease Acmeda Inc Page 1 of 3 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-067010 External Photos Documentation Applicant: Rollease Acmeda Inc Page 2 of 3 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-067010 External Photos Documentation Applicant: Rollease Acmeda Inc Page 3 of 3 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-067010

PRODUCT LABEL LOCATION NOTES FOR PRINTING: 30mm 27.5mm For US Market 63mm 23mm For EU Market For AU Market For EU Market For AU MarketFor AU Market For US MarketFor US Market For EU MarketFor EU Market For EU MarketFor EU Market Warning Symbol ! Warning Symbol ! Operating Instructions Operating Instructions MT02-0101-067010MT02-0101-050010 PUSH ONE CHANNEL REMOTE FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 For UK Market ITEM NO.DESCRIPTION 1PRODUCT NAMEPLATE 2BOX NAMEPLATE 1 2 C PROPRIETARY & CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF ROLLEASE ACMEDA. ANY REPRODUCTION IN PART OR WHOLE WITHOUT THE WRITTEN PERMISSION OF ROLLEASE ACMEDA IS PROHIBITED. COPYRIGHT 2023 DIMENSIONS IN MILLIMETERS DRAWN BY: DRAWN DATE: APPROVED BY: DRAWING NUMBER: PART NUMBER: TITLE: DO NOT SCALEDWG 1 OF 1 SCALE 1:1 REV. SIZE: A4 PRODUCT MANAGERPROJECT LEADCOMPLIANCE ENGINEER REVDESCRIPTIONPROJECTDATE 1.0NEW LABEL CREATEDNPD-22017 31 MAY 2023 MT02-0101-xxx010_PLAB MT02-0101-xxx010 AUTOMATE | PUSH ONE CHANNEL REMOTE 1.0 D. RAJPUT31 MAY 2023 PUSH ONE CHANNEL REMOTE 433.92MHz MT02-0101-xxx010 PUSH ONE CHANNEL REMOTE 5mm 1.5mm FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 For UK Market For AU Market For US Market For EU Market For EU Market Warning Symbol ! Operating Instructions PUSH ONE CHANNEL REMOTE MT02-0101-xxx010 FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 For UK Market For AU Market For US Market For EU Market For EU Market Warning Symbol ! Operating Instructions PUSH ONE CHANNEL REMOTE MT02-0101-xxx010 FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 For UK Market For UK Market COLOUR FOR PART NUMBER TEXT: PANTONE COOL GRAY 11C TRANSPARENT LABEL

Internal Photos Documentation Applicant: Rollease Acmeda Inc Page 1 of 1 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-050010 Antenna for 433.92MHz

Internal Photos Documentation Applicant: Rollease Acmeda Inc Page 1 of 1 Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Model: MT02-0101-067010 Antenna for 433.92MHz

Report No: 709502303684-00B EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 2 Rev. 171.00 RF Exposure Estimation 1. Introduction Applicant: Rollease Acmeda Inc Address: 7th Floor / 750 East Main Street, Stamford, CT 06902, USA Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 Model No.: MT02-0101-050010, MT02-0101-067010 Reference RF report # 709502303684-00A 2. B.2 Blanket 1 mW Blanket Exemption According to KDB 447498 D04, the 1 mW Blanket Exemption of § 1.1307(b)(3)(i)(A) applies for single fixed, mobile, and portable RF sources with available maximum time-averaged power of no more than 1 mW, regardless of separation distance. The 1 mW blanket exemption applies at separation distances less than 0.5 cm, including where there is no separation. This exemption shall not be used in conjunction with other exemption criteria other than those for multiple RF sources in paragraph § 1.1307(b)(3)(ii)(A). The 1 mW exemption is independent of service type and covers the full range of 100 kHz to 100 GHz, but it shall not be used in conjunction with other exemption criteria or in devices with higher-power transmitters operating in the same time-averaging period. Exposure from such higher-power transmitters would invalidate the underlying assumption that exposure from the lower-power transmitter is the only contributor to SAR in the relevant volume of tissue. 3. RF Exposure Evaluation Per the test report included herein, for 433.92MHz According to C63.10 Annex G EIRP = pt × gt =( E × d) 2 /30, so pt=( E × d) 2 /30* gt where pt is the transmitter output power in watts gt is the numeric gain of the transmitting antenna (dimensionless) E is the electric field strength in V/m d is the measurement distance in meters (m) transmitter output power for 433.92MHz Function Field strength (E): 89.093 (dBuV/m) = 0.0285 (V/m) Measurement distance (D): 3 (m) Antenna Gain, typical (dBi): 3 Numerical gain of the transmit antenna (gt): 2 Transmitter output power (TP): 0.000122(W) Transmitter output power (TP): 0.122(mW) Report No: 709502303684-00B EMC_SHA_F_R_02.06E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 2 Rev. 171.00 We used the maximum ERP/EIRP to perform RF exposure exemption evaluation. Evaluation method Exempt Limit (mW) Verdict ◼ Blanket 1 mW Blanket Exemption 1mW Yes  MPE-based Exemption (ERP) 7mW (ERP) N/A  SAR-based Exemption (Pth) 3060mW N/A So, the device is qualified for SAR test exemption, the exemption report is in lieu of the SAR report. - TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch Reviewed by: Prepared by: Tested by: _____________________ _____________________ ______________________ Hui TONG Wenqiang LU Cheng Huali EMC Section Manager EMC Project Engineer EMC Test Engineer Date: July 17, 2023 Date: July 17, 2023 Date: July 17, 2023 -------------------------------------------------------End of Test Report--------------------------------------------------------------------

Report Number: 709502303684-00A EMC_SHA_F_R_02.05E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 1 of 20 Rev. 171.00 FCC/IC- TEST REPORT Report Number : 709502303684-00A Date of Issue: July 17, 2023 Model : MT02-0101-050010, MT02-0101-067010 Product Type : Transmitter (Push one channel remote) Applicant : Rollease Acmeda Inc Address : 7th Floor / 750 East Main Street, Stamford, CT 06902, USA Production Facility : Ningbo Dooya Mechanic & Electronic Technology Co., Ltd. Address : No.168 Shengguang Road, Luotuo, Zhenhai 315202 Ningbo, : Zhejiang province People's Republic of China Test Result : ◼ Positive  Negative Total pages including Appendices : 20 TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval. dc Report Number: 709502303684-00A EMC_SHA_F_R_02.05E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 2 of 20 Rev. 171.00 1 Table of Contents 1 Table of Contents .................................................................................................................. 2 2 Details about the Test Laboratory ......................................................................................... 3 3 Description of the Equipment Under Test .............................................................................. 4 4 Summary of Test Standards .................................................................................................. 5 5 Summary of Test Results ...................................................................................................... 6 6 General Remarks .................................................................................................................. 7 7 Systems test configuration .................................................................................................... 8 8 Test Setups ........................................................................................................................... 9 9 Test Methodology ................................................................................................................ 10 9.1 Radiated Emission ........................................................................................................ 10 9.2 Bandwidth Measurement & 99% Occupied Bandwidth ................................................. 14 9.3 Deactivation Time ......................................................................................................... 16 10 Test Equipment List ............................................................................................................ 17 11 System Measurement Uncertainty ...................................................................................... 18 12 Photographs of Test Set-ups ........................................................................................... 19 13 Photographs of EUT ........................................................................................................ 20 Report Number: 709502303684-00A EMC_SHA_F_R_02.05E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 3 of 20 Rev. 171.00 2 Details about the Test Laboratory Details about the Test Laboratory Test Site 1 Company name: TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch No.16 Lane, 1951 Du Hui Road, Shanghai 201108, P.R. China FCC Registration Number: 820234 Designation Number: CN1183 IC Company Number: 25988 CAB identifier: CN0101 Telephone: +86 21 6141 0123 Fax: +86 21 6140 8600 Report Number: 709502303684-00A EMC_SHA_F_R_02.05E TÜV SÜD Certification and Testing (China) Co., Ltd. Shanghai Branch 3-13, No.151, Heng Tong Road, Shanghai, 200070, P.R. China Phone: +86 21 61410123, Fax:+86 21 61408600 Page 4 of 20 Rev. 171.00 3 Description of the Equipment Under Test Product: Transmitter (Push one channel remote) Model no./HVIN: MT02-0101-050010, MT02-0101-067010 FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 Rating: DC 3.3V RF Transmission Frequency: 433.92 MHz No. of Operated Channel: 1 Modulation: FSK Antenna Type: PCB Antenna Antenna Gain: 3 dBi for 433.92MHz SRD Description of the EUT: The Equipment Under Test (EUT) is a Transmitter (Push one channel remote) with SRD function. We tested it and listed the worst data in this report. Test sample no.: SHA-733645-1 The sample’s mentioned in this report is/are submitted/ supplied/ manufactured by client. The laboratory therefore assumes no responsibility for accuracy of information on the brand name, model number, origin of manufacture, consign…

Text truncated - open the document above for the full version.

Rollease Acmeda Inc 7th Floor / 750 East Main Street,Stamford, CT 06902, USA Antenna Information To whom it may concern, Product name: Transmitter (Push one channel remote) Model: MT02-0101-050010, MT02-0101-067010 FCC ID: 2AGGZ003B9ACA50 The applicable FCC rule part of this product is § 15.231, radiated measurements are used to show compliance with FCC limits for fundamental and spurious emissions. The Antenna information as below for your reference. Antenna photo: Antenna transmission frequency: 433.92MHz Antenna type: PCB antenna Antenna Gain: 3 dBi Yours sincerely, Company Officer: Jonny.Matuichuk Telephone Number: 2034906191 Email: [email protected] Antenna

Applicant: Rollease Acmeda Inc Product: Transmitter (Push one channel remote) FCC ID: 2AGGZ003B9ACA50 IC: 21769-003B9ACA50 ©2023 Not to be reproduced, except in its entirety, Page 1 of 1 without the Permission of TÜ V SÜ D Certification and Testing (China) Co., Ltd. Shanghai Branch PHOTOGRAPHS OF TEST SET UP Field Strength and Harmonics Test Setup Radiated Emission Setup 30MHz ~ 1GHz 1GHz ~ 4.5GHz
