2AHJMRXAJJWalkie Talkie Two-way Radio

TWO-WAY RADIO MODEL RX100 Antenna Installing Batteries Printed in China, Part No. AL-ML100303 Buit-In Microphone Buit-In Speaker LCD Display Talk Button Call Button Menu/Power Button Making Life Easier And Safer Staying in touch with your family and friends is convenient and easy when using your microTALK ® radio. Some of the many uses you will discover include: Communicating with others while hiking, biking, and working; keeping track of family and friends at a crowded public event; checking with travel companions in another car; talking with neighbors; arranging meeting spots with others while shopping at the mall. User’s Guide Press one time to alert others that you are calling, this will send a ringtone to the other person. Press and hold the Talk button to communicate with others. The microphone should be placed about 2 inches away from your mouth. When talking, speak in normal voice. Release the Talk button when you finish talking and listen for a response from the other person. You cannot receive at the same time while pressing the Talk button. NOTE: Both radios must be set at the same channel/privacy code to communicate. Press and hold Menu button for 3 seconds to turn the radio on or off. There are 8 options you may set to your preferences. Each press of the Menu button advances you to the next option setting. Press the + or – buttons to change the setting, you may also press Talk button to enter new setting and return to standby mode. To Install or Replace Batteries: 1. Remove belt clip by pressing on the release tab and sliding belt clip up at the same time. 2. Pull up on the battery door latch to remove the battery compartment cover. 3. Insert 3 (AAA) batteries (not included) per radio and position batteries according to polarity markings. • Do not attempt to charge alkaline batteries. • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable (Ni-Cd, Ni-MH, etc.) batteries. Volume / Menu options (+) and (–) Buttons Press the + or – buttons to increase or decrease the volume. Level 8 is the highest volume. Press the Menu button for going through the menu options, and then press the + or – buttons to change the setting. Press and hold – button to use the monitor function, it can temporarily turn off auto squelch for allowing all signals (including static noise) to be received and extending the maximum range of your radio. Press and hold – button again to turn the monitor function off. Menu CTCSS # DCS # Off On/Off On/Off 1-83 VOX 1-51-381-22* On/OffOn/Off Channel Selection Channel Scan § On/Off VOX Sensitivity ◊ Roger Beep ^ Key Tone Key Lock ‡ * Ch1-22 will be shown on display as the selected channel mode for two seconds once activated. # Your radio incorporates two advanced coded squelch systems that can help to reduce interference from other users on any given channel. CTCSS (Continuous Tone Coded Squelch System) and DCS (Digitally Coded Squelch) provide 38 or 83 privacy codes respectively. Either system can be used on any channels, but cannot be used on the same channel at the same time. ◊ With level 1 being the least sensitive level. § Press Call or Talk button to exit channel scanning mode. ^ The Roger Beep conrmation tone alerts the other party that you have nished talking and it is OK for them to speak, after you release the Talk button. ‡ Press and hold Menu/Power button to turn the keypad lock off. Wrist Strap Connection Belt Clip Battery Cover ß The NOAA NWR Frequency Table Channel No. NWR Frequency 1162.550MHz 2162.400MHz 3162.475MHz 4162.425MHz 5162.450MHz Channel No. NWR Frequency 6162.500MHz 7162.525MHz 8161.650MHz 9161.775MHz 10 163.275MHz Battery Level Indicator Indicates the battery level. The last status bar of the battery low icon will blink when battery power is low. Lock Icon Visible when keypad lock turned on. Channel / Volume Numbers While in Standby mode or when selecting a channel, shows current channel (1 through 22). When adjusting the volume, shows current level (1 through 8). Receive/Transmit Icon Visible when receiving or transmitting a message. Scan Icon Visible when in Scan mode. CTCSS/DCS Icon Shown in either Privacy Code system selected. VOX Icon Visible when VOX feature turned on. The VOX sensitivity level can be adjusted from level 1 to 5, with level 1 being the least sensitive level. Weather Alert Icon Visble when in Weather Alert mode. If the radio is turned ON, it will alert to Weather and other emergency alerts broadcast by NOAA. ß Weather Icon Visible when in NOAA weather radio mode. You can use your microTALK ® radio to listen to weather channels transmitting in your area. Privacy Code Numbers Code 0 in either code system is not a privacy code as default, that allows all signals to be heard on a channel. Features • 22 Channels •10 Channels Weather Radio • Weather Alert • 121 Privacy Codes (38 CTCSS codes / 83 DCS codes) • Hands-Free Operation (VOX) • Scan Channels, privacy codes • LCD Display • Call Alert • Button Lock • Roger Beep Selectable On/Off • Battery/Power Saver • Keystroke Tones • Battery Level Indicator • Low Battery Audible Alert • Auto Squelch • Belt Clip Maximum range may vary and is based on unobstructed line-of-sight communication under ideal conditions. For detailed instructions, please visit www.cobrawalkietalkie.com for the full version of user manuals. Important Notice: WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference, and 2) this device must accept any interference received,including interference that may cause undesired operation. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provi…

Text truncated - open the document above for the full version.

AltisTechnology(HongKong)Ltd. Address:26/F,RykadanCapitalTower,135HoiBunRoad,KwunTong,HongKong,China Tel:+852-27971111 Fax:+852-23415922 E-Mail:[email protected] Date:2021-1-3 Declarationletter FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 DearSir/Madam, We,AltisTechnology(HongKong)Ltd.herebydeclarethatwehaveaproductnamedas WalkieTalkieTwo-wayRadio,(model:RX100,FCCID:2AHJMRXAJJ)weretestedby BACL.Meanwhile,forourmarketingpurpose,wewouldliketolistaseriesmodel(RX100- 3,RX100-4,RX100B,RX100P,RX100K,RX100G,RX100R,RX100O,RX100Y,RX100 W,RX1001P)onreportsandcertificate.Theyaredifferentincolorandmodelname,allthe othercharacteristiclikePCBLayout,circuits,enclosure(dimensionsandmaterial),areexactly same.Nootherchangesweremadetothem. Weconfirmthatallinformationaboveistrue,andwe’llberesponsibleforalltheconsequences. Pleasecontactmeifyouhaveanyquestion. SincerelyYours, Signature: VincentKwok Title:Manger

AltisTechnology(HongKong)Ltd. Address:26/F,RykadanCapitalTower,135HoiBunRoad,KwunTong,Hong Kong,China Tel:+852-27971111 Fax:+852-23415922 E-Mail:[email protected] FCCConfidentialAuthorization 2020/12/25 FEDERALCOMMUNICATIONSCOMMISSIONS AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Subject:ConfidentialityRequestregardingapplicationforcertificationof FCCID:2AHJMRXAJJ InaccordancewithSections0.457and0.459oftheCommission’sRules,(Altis Technology(HongKong)Ltd.)herebyrequestslong-termconfidentialtreatmentof informationaccompanyingthisapplicationasoutlinedbelow: BlockDiagram Schematics OperationDescription Theabovematerialscontainproprietaryandconfidentialinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesematerialsprovidesunjustified benefitstoitscompetitorsinthemarket. Sincerely, Signature: VincentKwok Title:Manager

EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS

A B C D 2314 SERIAL NO: MODEL NO: RX150 MYMMXXXXXX FCC ID: 2AHJMRXAJJ IC: 21854-RXAJJ MADE IN CHINA SERIAL NO: MODEL NO: RX105 MYMMXXXXXX FCC ID: 2AHJMRXAJJ IC: 21854-RXAJJ MADE IN CHINA SERIAL NO: MODEL NO: RX100 MYMMXXXXXX FCC ID: 2AHJMRXAJJ IC: 21854-RXAJJ MADE IN CHINA SERIAL NO: MODEL NO: RX100 MYMMXXXXXX FCC ID: 2AHJMRXAJJ IC: 21854-RXAJJ MADE IN CHINA SERIAL NO: MODEL NO: RX120 MYMMXXXXXX FCC ID: 2AHJMRXAJJ IC: 21854-RXAJJ MADE IN CHINA SERIAL NO: MODEL NO: RX110 MYMMXXXXXX FCC ID: 2AHJMRXAJJ IC: 21854-RXAJJ MADE IN CHINA * 20mm 1:1 * 21mm * 20mm 1:1 * 21mm * 20mm 1:1 * 21mm * 20mm 1:1 * 21mm * 20mm 1:1 * 21mm

EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Antenna

Note: This test report is prepared for the customer shown above and for the device described herein. It may not be duplicated or used in part without prior written consent from Bay Area Compliance Laboratories Corp. (Dongguan). This report must not be used by the customer to claim product certification, approval, or endorsement by A2LA* or any agency of the Federal Government. * This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “*”. SAR EVALUATION REPORT For Altis Technology (Hong Kong) Ltd. 26th Floor, Rykadan Capital Tower, 135 Hoi Bun Road, Kwun Tong, Hong Kong FCC ID: 2AHJMRXAJJ Report Type: Original Report Product Type: Walkie Talkie Two-way Radio Report Number: RSZ201209006-20A Report Date: 2021-01-03 Reviewed By: Brave Lu SAR Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ201209006-20A SAR Evaluation Report 2 of 36 Attestation of Test Results EUT Information EUT Description Walkie Talkie Two-way Radio Tested Model RX100 Multiple Models RX100-3, RX100-4, RX100 B, RX100 P, RX100 K, RX100 G, RX100 R, RX100 O, RX100 Y, RX100 W, RX100 1P FCC ID 2AHJMRXAJJ Serial Number RSZ201209006-SA-S1 Test Date 2020-09-22 MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) PTT 1g Head SA R (Face Up) 0.27 1.6 1g Body SAR (Body Back) 0.55 Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices RF Exposure Procedures: TCB Workshop April 2019 IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques IEC 62209-1:2016 Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Part 1: Devices used next to the ear (Frequency range of 300 MHz to 6 GHz) KDB procedures KDB 447498 D01 General RF Exposure Guidance v06 KDB 865664 D01 SAR Measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 KDB 643646 D01 SAR Test for PTT Radios v01r03 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ201209006-20A SAR Evaluation Report 3 of 36 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ............................................................................................................................ 4 EUT DESCRIPTION ........................................................................................................................................................ 5 TECHNICAL SPECIFICATION............................................................................................................................................. 5 REFERENCE, STANDARDS, AND GUIDELINES .................................................................................................... 6 SAR LIMITS ..................................................................................................................................................................... 7 FACILITIES ...................................................................................................................................................................... 8 DESCRIPTION OF TEST SYSTEM ............................................................................................................................. 9 EQUIPMENT LIST AND CALIBRATION ................................................................................................................ 14 EQUIPMENTS LIST & CALIBRATION INFORMATION ...................................................................................................... 14 SAR MEASUREMENT SYSTEM VERIFICATION ................................................................................................ 15 LIQUID VERIFICATION ................................................................................................................................................... 15 SYSTEM ACCURACY VERIFICATION .............................................................................................................................. 16 SAR SYSTEM VALIDATION DATA ........................................................................................................................ 17 EUT TEST STRATEGY AND METHODOLOGY .................................................................................................... 18 TEST POSITIONS FOR DEVICE OPERATING NEXT TO A PERSON’S EAR ......................................................................... 18 CHEEK/TOUCH POSITION .............................................................................................................................................. 19 EAR/TILT POSITION ....................................................................................................................................................... 19 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS ................................................................................ 20 TEST DISTANCE FOR SAR EVALUATION ....................................................................................................................... 20 SAR EVALUATION PROCEDURE ..............................................................................................................…

Text truncated - open the document above for the full version.

Report No.: RSZ201209006-20A Page 1 of 2 APPENDIX B EUT TEST POSITION PHOTOS Liquid depth ≥ 15cm Report No.: RSZ201209006-20A Page 2 of 2 Face Up Setup Photo(25mm) Body Back Setup Photo(0mm) 39mm 15mm 25mm

FCC PART 95 MEASUREMENT AND TEST REPORT For Altis Technology (Hong Kong) Ltd. 26th Floor, Rykadan Capital Tower, 135 Hoi Bun Road, Kwun Tong, Hong Kong FCC ID: 2AHJMRXAJJ Report Type: Original Report Product Type: Walkie Talkie Two-way Radio Report Number: RSZ201209006-00A Report Date: 2020-12-29 Reviewed By: Ivan Cao Assistant Manager Test Laboratory: Bay Area Compliance Laboratories Corp. (Dongguan) No.12, Pulong East 1 st Road, Tangxia Town, Dongguan, Guangdong, China Tel: +86-769-86858888 Fax: +86-769-86858891 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Dongguan) Report No.: RSZ201209006-00A Page 2 of 23 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 3 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) .................................................................................... 3 OBJECTIVE ................................................................................................................................................................... 3 RELATED SUBMITTAL(S)/GRANT(S) ............................................................................................................................. 3 TEST METHODOLOGY .................................................................................................................................................. 3 MEASUREMENT UNCERTAINTY .................................................................................................................................... 4 TEST FACILITY ............................................................................................................................................................. 4 DECLARATIONS ............................................................................................................................................................ 4 SYSTEM TEST CONFIGURATION .......................................................................................................................... 5 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 5 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 5 EUT EXERCISE SOFTWARE .......................................................................................................................................... 5 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 6 SUMMARY OF TEST RESULTS ............................................................................................................................... 7 FCC §2.1093 - RF EXPOSURE INFORMATION ..................................................................................................... 8 APPLICABLE STANDARD .............................................................................................................................................. 8 TEST RESULT ............................................................................................................................................................... 8 FCC §2.1046, §95.567 - RF OUTPUT POWER .......................................................................................................... 9 APPLICABLE STANDARD .............................................................................................................................................. 9 TEST PROCEDURE ........................................................................................................................................................ 9 TEST EQUIPMENT LIST AND DETAILS ........................................................................................................................... 9 TEST DATA ................................................................................................................................................................ 10 FCC §2.1047 & §95.575 - MODULATION CHARACTERISTIC .......................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 11 TEST PROCEDURE ...................................................................................................................................................... 11 TEST DATA ................................................................................................................................................................ 11 FCC §2.1049,§95.573, §95.579 - AUTHOURIZED BANDWIDTH AND EMISSION MASK ............................. 15 APPLICABLE STANDARD ............................................................................................................................................ 15 TEST PROCEDURE ...................................................................................................................................................... 15 TEST EQUIPMENT LIST AND DETAILS ......................................................................................................................... 15 TEST DATA ................................................................................................................................................................ 16 FCC §2.1053 & §95.579 - RADIATED SPURIOUS EMISSION ............................................................................ 19 APPLICABLE STANDARD ..................................................................................................…

Text truncated - open the document above for the full version.

EXHIBIT D - TEST SETUP PHOTOGRAPHS Radiated Emission -View (Below 1GHz) Radiated Emission -View (Above 1GHz)
