2AHKM-ARIA2110Wi-Fi 6 Extender

Read me first! ¡Léame primero! Check the box contents/ Revise el contenido del embalaje QUICK START GUIDE GUÍA DE INICIO RÁPIDO ARIA2110 Cat6.a ETHERNET CABLE Cat6.a CABLE ETHERNET POWER ADAPTER ADAPTADOR DE ALIMENTACIÓN 6ARIA2110LA1G HITRON Wi-Fi 6 Extender ARIA2110 Look in the box and make sure you have the following: Observe en la caja y asegúrese de tener lo siguiente : 1 Method/ Método Method/ Método Method/ Método 2 3 QUICK START GUIDE GUÍA DE INICIO RÁPIDO Use your mobile application to add the extender to your network. Mobile application guide is included in the box. Use su aplicación móvil para agregar el extensor a su red. La guía de la aplicación móvil está incluida en la caja. Connect the ARIA2110 to a Power Outlet. Conecte el ARIA2110 a una Slida de Alimentación. Wait for the steady green Power LED. Espere a que el LED de encendido verde fijo. Start the onboarding process via the mobile app. Inicie el proceso de incorporación a través de la aplicación móvil. Connect an Ethernet cable to your ARIA2110 in the first LAN port. Conecte un cable Ethernet a su ARIA2110 en el primer puerto LAN Connect t1he other end of Ethernet Cable to the supported Hitron Wi-Fi modem or router. Conecte el otro extremo del cable Ethernet al módem o enrutador Hitron Wi-Fi compatible. Connect the ARIA2110 to a Power Outlet. Conecte el ARIA2110 a una toma de corriente. Your Hitron Wi-Fi modem or router will automatically configure your new ARIA2110. Su módem Hitron Wi-Fi o enrutador configurará automáticamente su nuevo ARIA2110. Wait until the LED is steady white. At that point, your ARIA2110 is in sync with your network. You can unplug the ARIA2110 and move it to the location that you desire. After bootup, the ARIA2110 will connect automatically to your Wi-Fi network. Espere hasta que el LED esté fijo en blanco. En ese momento, su ARIA2110 está sincronizado con su red. Puede desconectar el ARIA2110 y moverlo a la ubicación que desee. Después del arran- que, el ARIA2110 se conectará automáticamente a su red Wi-Fi. Connect the ARIA2110 to a Power Outlet. Conecte el ARIA2110 a una toma de corriente. Wait for the steady green Power LED. Espere a que el LED de encendido verde fijo. Search for the ARIA2110 default Wi-Fi name with your mobile device (default SSID\printed on bottom of the ARIA2110). You will be redirected to the EasyConnect menu to setup your ARIA2110 with your existing network credentials. Busque el nombre Wi-Fi predeterminado del ARIA2110 con su dispositivo móvil. If you have supported Hitron Wi-Fi modem or router but no app, you can simply set up your ARIA2110: Si posee un equipo compatible Hitron Wi-Fi o un enrutador sin aplicación, simplemente puede configurar su ARIA2110: If you do not have a supported Hitron Wi-Fi modem or router, follow the below steps. Si no tiene un módem Hitron Wi-Fi o enrutador compatible, siga los pasos a continuación. A B C A B C D E Note : LED may turn to amber if the Wi-Fi connection is weak or red if there is no connection to the Hitron Wi-Fi router. You may want to bring your ARIA2110 closer to the modem-router or choose to have a Ethernet backhaul. Nota: el LED puede volverse ámbar si la conexión Wi-Fi es débil o rojo si no hay conexión con el enrutador Hitron Wi-Fi. Es posible que desee acercar su ARIA2110 al módem-enrutador o elegir tener un backhaul Ethernet. Modem onboarding process/ Proceso de incorporación de módem Method/ Método *黑色機台圖示為 Hitron CGN5-AP路由器 Connect to the Internet Connecte al Internet Configure wireless network Configure la red inalámbrica Installation complete/ Instalación completa LED display/ Visualización de las luces LED Congratulations! You have successfully set up your device. If you have any problems, see the LED display section below to help identify the problem. ¡Felicitaciones! Ha configurado correctamente su dispositivo. Si tiene algún problema, consulte la sección siguiente para obtener ayuda para identificar la causa. Green-Steady Verde Constante Red-Steady Rojo Constante Amber-Blinking Ámbar Parpadeante Green-Steady Verde Constante Green-Blinking Verde Parpadeante Red-Steady Rojo Constante Green-Steady Verde Constante Green-Blinking Verde Parpadeante Blue-Blinking Azul Parpadeante Dark Oscuro Green-Steady Verde Constante Blue-Steady Azul Constante Blue-Blinking Azul Parpadeante Amber-Steady Ámbar Constante Amber-Blinking Ámbar Parpadeante White(Purple)-Steady Blanco(Morado) Parpadeante The device is power-on. El dispositivo está alimentado de corriente eléctrica. Abnormal Anormal Software update in progress Actualización de software en curso. Tech Support Soporte Técnico Power Poder Internet Internet Wi-Fi Wi-Fi Wi-Fi connected Wi-Fi conectada Wi-Fi data transmitting Datos Wi-Fi están transmitiendo Wi-Fi disabled Wi-Fi deshabilitada You may turn on/off Wi-Fi via Wi-Fi on/off button in rear panel Puede encender/apagar Wi-Fi a través del botón de encendido/apagado de Wi-Fi en el panel posterior Wireless backhaul signal is great La señal de backhaul inalámbrica es excelente Wireless backhaul signal is ok. WPS paired La señal de backhaul inalámbrica está bien. WPS emparejado WPS is pairing WPS está emparejamiento Wireless backhaul signal is weak La señal de backhaul inalámbrica es débil Establishing connection Conexión está estableciendo Reset to factory default Restablecer la configuración a predeterminados de fábrica Connected to Internet successfully Conectado a internet con éxito Connected to Internet successfully, data transmitting Conectado a Internet con éxito, datos están transmi- tiendo Internet connect failure Fallo de conexión a Internet To access user manuals, Frequently Asked Questions etc, visit our website at: https://www.hitrontech.com/support/faq-wifi-extender-aria2110/ Para acceder a los manuales de usuario, Preguntas frecuentes, etc., visite nuestro sitio web en: https://www.hitrontech.com/support/faq-wifi-extender-aria2110/ COPYRIGHT © 2023 HITRON TECHNOLOGIES, INC. WARNING/ ADVERTENCIA Ris k of electric…

Text truncated - open the document above for the full version.

PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 1 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 Brand Name: Hitron Model Name: ARIA2110 EUT 1 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 2 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 3 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 4 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 5 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 EUT 2 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 6 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 7 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 8 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 9 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 Adapter PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 10 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 RJ-45 cable 1 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 11 of 11 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 RJ-45 cable 2

Label and location (bottom of the device)

PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 1 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 Brand Name: Hitron Model Name: ARIA2110 Ant. 4 Ant. 2 Ant. 1 Ant. 3 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 2 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 3 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 4 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 5 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 6 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 7 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 8 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 9 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 10 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 11 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 12 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 13 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 14 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 15 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 16 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 17 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 18 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 19 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01 PHOTOGRAPHS OF EUT EP260727 Sporton International Inc. Page No. : 20 of 20 Report Template No.: SE Ver 1.0_EP Issued Date : May 15, 2023 Report Version : 01

RADIO EXPOSURE TEST REPORT Report No. : FA260727 TEL : 886-3-656-9065 Page Number : 2 of 11 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 EUT General Information ....................................................................................................................... 5 1.2 Antenna Information ............................................................................................................................... 6 1.3 Accessories ............................................................................................................................................ 7 1.4 EUT Support Function ............................................................................................................................ 7 1.5 Applicable Standards ............................................................................................................................. 7 1.6 Testing Location ..................................................................................................................................... 8 2 Maximum Permissible Exposure ........................................................................................................ 9 2.1 Limit of Maximum Permissible Exposure ............................................................................................... 9 2.2 MPE Calculation Method ........................................................................................................................ 9 2.3 MPE Exemption .................................................................................................................................... 10 2.4 Calculated Result and Limit .................................................................................................................. 11 Photographs of EUT v01 RADIO EXPOSURE TEST REPORT Report No. : FA260727 TEL : 886-3-656-9065 Page Number : 3 of 11 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 History of this test report Report No. Version Description Issued Date FA260727 01 Initial issue of report May 15, 2023 RADIO EXPOSURE TEST REPORT Report No. : FA260727 TEL : 886-3-656-9065 Page Number : 4 of 11 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 2 - Exposure evaluation PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Viola Huang RADIO EXPOSURE TEST REPORT Report No. : FA260727 TEL : 886-3-656-9065 Page Number : 5 of 11 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1 General Description 1.1 EUT General Information RF General Information Evaluation Mode Frequency Range (MHz) Operating Frequency (MHz) Modulation Type 2.4GHz WLAN 2400-2483.5 2412-2462 802.11b: DSSS (DBPSK, DQPSK, CCK) 802.11g/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) VHT: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) 5GHz WLAN 5150-5250 5250-5350 5470-5725 5725-5850 5180-5240 5260-5320 5500-5720 5745-5825 802.11a/n: OFDM (BPSK, QPSK, 16QAM, 64QAM) 802.11ac: OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM) 802.11ax: OFDMA (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) RADIO EXPOSURE TEST REPORT Report No. : FA260727 TEL : 886-3-656-9065 Page Number : 6 of 11 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 1.2 Antenna Information Ant. Port Brand Model Name Antenna Type Connector Gain (dBi) 1 2 HONGBO 290-20487 Dipole Antenna I-PEX Note 1 2 1 HONGBO 290-20486 Dipole Antenna I-PEX 3 2 HONGBO 290-20489 Dipole Antenna I-PEX 4 1 HONGBO 290-20490 Dipole Antenna I-PEX Note 1: Ant. Gain (dBi) WLAN 2.4GHz WLAN 5GHz UNII 1 WLAN 5GHz UNII 2A WLAN 5GHz UNII 2C WLAN 5GHz U NII 3 1 3.6 - - - - 2 3.6 - - - - 3 - 3.5 4.3 4.2 3.5 4 - 3.1 3.1 3.1 3.3 RADIO EXPOSURE TEST REPORT Report No. : FA260727 TEL : 886-3-656-9065 Page Number : 7 of 11 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A1_1 Ver1.1 Report Version : 01 Note 3: The above information was declared by manufacturer. Note 4: For 2.4GHz function: For IEEE 802.11 b/g/n/VHT/ax (2TX/2RX): Port 1 and Port 2 can be used as transmitting/receiving antenna. Port 1 and Port 2 could transmit/receive simultaneously. For 5GHz function: For IEEE 802.11a/n/ac/ax (2TX/2RX): Port 1 and Port 2 can be used as transmitting/receiving antenna. Port 1 and Port 2 could transmit/receive simultaneously. 1.3 Accessories Accessories Equipment Name Brand Name Model Name Rating Adapter AMIGO AMS200-1202000FU Input: 100-240V ~ 50/60Hz, 0.8A Max Output: 12V, 2.0A Others RJ-45 cable 1*1, Color: Green, Non-shielded, 1.5m RJ-45 cable…

Text truncated - open the document above for the full version.

RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 71 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 72 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 73 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 74 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 75 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 76 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 77 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 78 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 79 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 80 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 81 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 82 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 83 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 84 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 85 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 86 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 87 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 88 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 89 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 90 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 91 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 92 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 93 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 94 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 95 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 96 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 97 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 98 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 99 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 100 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 101 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 102 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 103 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 104 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 105 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 106 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 107 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 108 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 109 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 110 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 111 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 112 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 113 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 114 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 115 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 116 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 117 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 118 of 169 Report No. : FR260727AB RSE TX above 1GHz Appendix E.2 Sporton International Inc. Hsinchu Laboratory Page No. : 119 of 169 Report No. : FR260727AB RS…

Text truncated - open the document above for the full version.

RADIO TEST REPORT Report No. : FR260727AB TEL : 886-3-656-9065 Page Number : 2 of 35 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Applicable Standards ........................................................................................................................... 11 1.3 Testing Location Information ................................................................................................................ 11 1.4 Measurement Uncertainty .................................................................................................................... 11 2 Test Configuration of EUT ................................................................................................................. 12 2.1 Test Channel Mode .............................................................................................................................. 12 2.2 The Worst Case Measurement Configuration ...................................................................................... 15 2.3 EUT Operation during Test .................................................................................................................. 16 2.4 Accessories .......................................................................................................................................... 16 2.5 Support Equipment ............................................................................................................................... 16 2.6 Test Setup Diagram ............................................................................................................................. 18 3 Transmitter Test Result ..................................................................................................................... 21 3.1 AC Power-line Conducted Emissions .................................................................................................. 21 3.2 Emission Bandwidth ............................................................................................................................. 23 3.3 Maximum Output Power ....................................................................................................................... 24 3.4 Power Spectral Density ........................................................................................................................ 27 3.5 Unwanted Emissions ............................................................................................................................ 30 4 Test Equipment and Calibration Data .............................................................................................. 34 Appendix A. Test Results of AC Power-line Conducted Emissions Appendix B. Test Results of Emission Bandwidth Appendix C. Test Results of Maximum Output Power Appendix D. Test Results of Power Spectral Density Appendix E. Test Results of Unwanted Emissions Appendix F. Test Photos Photographs of EUT v01 RADIO TEST REPORT Report No. : FR260727AB TEL : 886-3-656-9065 Page Number : 3 of 35 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 History of this test report Report No. Version Description Issued Date FR260727AB 01 Initial issue of report May 15, 2023 RADIO TEST REPORT Report No. : FR260727AB TEL : 886-3-656-9065 Page Number : 4 of 35 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 Summary of Test Result Report Clause Ref Std. Clause Test Items Result (PASS/FAIL) Remark 1.1.2 15.203 Antenna Requirement PA SS - 3.1 15.207 AC Power-line Conducted Emissions PA SS - 3.2 15.407(a) Emission Bandwidth PA SS - 3.3 15.407(a) Maximum Output Power PA SS - 3.4 15.407(a) Power Spectral Density PA SS - 3.5 15.407(b) Unwanted Emissions PA SS - Conformity Assessment Condition: 1. The test results (PASS/FAIL) with all measurement uncertainty excluded are presented against the regulation limits or in accordance with the requirements stipulated by the applicant/manufacturer who shall bear all the risks of non-compliance that may potentially occur if measurement uncertainty is taken into account. 2. The measurement uncertainty please refer to each test result in the chapter "Measurement Uncertainty". Disclaimer: The product specifications of the EUT presented in the test report that may affect the test assessments are declared by the manufacturer who shall take full responsibility for the authenticity. Reviewed by: Sam Chen Report Producer: Viola Huang RADIO TEST REPORT Report No. : FR260727AB TEL : 886-3-656-9065 Page Number : 5 of 35 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A12_1 Ver1.4 Report Version : 01 1 General Description 1.1 Information 1.1.1 RF General Information Frequency Range (MHz) IEEE Std. 802.11 Ch. Frequency (MHz) Channel Number 5150-5250 a, n (HT20), ac (VHT20), ax (HEW20) 5180-5240 36-48 [4] 5250-5350 5260-5320 52-64 [4] 5470-5725 5500-5720 100-144 [12] 5725-5850 5745-5825 149-165 [5] 5150-5250 n (HT40), ac (VHT40), ax (HEW40) 5190-5230 38-46 [2] 5250-5350 5270-5310 54-62 [2] 5470-5725 5510-5710 102-142 [6] 5725-5850 5755-5795 151-159 [2] 5150-5250 ac (VHT80), ax (HEW80) 5210 42 [1] 5250-5350 5290 58 [1] 5470-5725 5530-5690 106-138 [3] 5725-5850 5775 155 [1] …

Text truncated - open the document above for the full version.

DFS TEST REPORT Report No. : FZ260727 TEL : 886-3-656-9065 Page Number : 2 of 121 FAX : 886-3-656-9085 Issued Date : May 15, 2023 Report Template No.: CB-A12_4 Ver1.1 Report Version : 01 Table of Contents History of this test report ................................................................................................................................. 3 Summary of Test Result................................................................................................................................... 4 1 General Description ............................................................................................................................. 5 1.1 Information .............................................................................................................................................. 5 1.2 Support Equipment ......................................................................................................…

Text truncated - open the document above for the full version.
