2AHRD-EPEP9651Bluetooth PCI-E WiFi Card

PdfEditor 4.0.0.14 Testversion - https://www.pixelplanet.com/de/pdfeditor/

FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. PdfEditor 4.0.0.14 Testversion - https://www.pixelplanet.com/de/pdfeditor/

FCC Software Configuration Control Declaration Rev1.1.docx Shenzhen EDUP Electronics Technology Co.,Ltd. FCC Software Configuration Control Declaration Date: 2022.03.03 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: Shenzhen EDUP Electronics Technology Co.,Ltd. Product Name: Bluetooth PCI-E WiFi Card Model Number(s): EP-EP9651, EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH- 9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT- AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT- AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW- AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX- AX5400GS FCC ID: 2AHRD-EPEP9651 Regarding FCC Country Code Selection guidelines identified in KDB 594280. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Signature: Date: 2022.03.03 Name: Zhou chunping Title: Manager Company: Shenzhen EDUP Electronics Technology Co.,Ltd.

Shenzhen EDUP Electronics Technology Co.,Ltd. Agent Authorization Company: Shenzhen EDUP Electronics Technology Co.,Ltd. Address: 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Product Name: Bluetooth PCI-E WiFi Card Model Number(s): EP-EP9651, EP-9651S, EP-9651GS, EP-9651GS Pro, EP- AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH- 9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS Product Description: Bluetooth PCI-E WiFi Card We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2022.03.03 Name: Zhou chunping Title: Manager Company: Shenzhen EDUP Electronics Technology Co.,Ltd.

Shenzhen EDUP Electronics Technology Co.,Ltd. Authorization Letter We, (the approval holder) Company name Shenzhen EDUP Electronics Technology Co.,Ltd. Address 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China declare that the following representative (agent): Name (person) Bovey Yang Company name Shenzhen STS Test Services Co., Ltd. Addresss 1/F., Building B, Zhuoke Science Park, No.190, Chongqing Road, Fuyong Street, Bao’an District, Shenzhen, Guangdong,China City Shenzhen Country China to act on our behalf on all matters concerning the application and documents submitted to Micom Labs for product certification below Product Description Bluetooth PCI-E WiFi Card Type or Model(s) EP-EP9651, EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH- AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS- Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS Tradename or Brand(s) EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill FCC ID 2AHRD-EPEP9651 Attestation: City: Date: Name: (this must be a person) Function: Signature: (or official company stamp) SHENZHEN 2022.03.03 Zhou chunping Manager

Differences Description We Shenzhen EDUP Electronics Technology Co.,Ltd. state: Product： Bluetooth PCI-E WiFi Card Model Name： EP-EP9651, EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS Brand Name： EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill FCC ID： 2AHRD-EPEP9651 The internal structure and design of the product are completely the same, Different appearance size and shape. Signature: Date: 2022.03.03 Name: Zhou chunping Title: Manager Company: Shenzhen EDUP Electronics Technology Co.,Ltd.

Shenzhen EDUP Electronics Technology Co.,Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2022.03.03 Subject; Request for Confidentiality FCC ID: 2AHRD-EPEP9651 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description SOFTWARE SECURITY REQUIREMENTS FOR U-NII DEVICES In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Signature: Date: 2022.03.03 Name: Zhou chunping Title: Manager Company: Shenzhen EDUP Electronics Technology Co.,Ltd.

Page 1 of 4 Report No.: STS2202110 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: EP-EP9651 Photo 1 Photo 2 Page 2 of 4 Report No.: STS2202110 Photo 3 Photo 4 BT/WIFI Antenna Page 3 of 4 Report No.: STS2202110 Photo 5 Photo 6 Page 4 of 4 Report No.: STS2202110 Photo 7

FCC Label W:15mm L:30mm Note:The label is silk-screen on the sample Bluetooth PCl-E WiFi Card Model name: EP-EP9651 FCC ID: 2AHRD-EPEP9651

Page 1 of 5 Report No.: STS2202110 APPENDIX-PHOTOGRAPHS OF EUT CONSTRUCTIONAL DETAILS Model: EP-EP9651 Photo 1 Photo 2 Page 2 of 5 Report No.: STS2202110 Photo 3 Photo 4 Page 3 of 5 Report No.: STS2202110 Photo 5 Photo 6 Page 4 of 5 Report No.: STS2202110 Photo 7 Photo 8 Page 5 of 5 Report No.: STS2202110 Photo 9 Photo 10

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2202110H01 Issued for Shenzhen EDUP Electronics Technology Co.,Ltd. 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Product Name: Bluetooth PCl-E WiFi Card Brand Name: EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill Model Name: EP-EP9651 Series Model: EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS FCC ID: 2AHRD-EPEP9651 Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 8 Report No.: STS2202110H01 Test Report Certification Applicant’s Name ................. : Shenzhen EDUP Electronics Technology Co.,Ltd. Address .................................. : 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Manufacturer's Name ........... : Shenzhen EDUP Electronics Technology Co.,Ltd. Address .................................. : 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Product Description Product Name ........................ : Bluetooth PCl-E WiFi Card Brand Name ......................... : EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill Model Name ........................... : .. : EP-EP9651 Series Model .......................... : EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS Standards .............................. : FCC 47CFR §2.1091 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 23 Feb. 2022 Date (s) of performance of tests ............. : 23 Feb. 2022 ~ 26 Feb. 2022 Date of Issue .......................................... : 26 Feb. 2022 Test Result .............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Vita Li) Page 3 of 8 Report No.: STS2202110H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 6 2. FCC 47CFR §2.1091 REQUIREMENT 7 2.1 TEST STANDARDS 7 2.2 LIMIT 7 2.3 EUT OPERATION CONDITION 7 2.4 CLASSIFICATION 7 2.5 TEST RESULT 8 Page 4 of 8 Report No.: STS2202110H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 26 Feb. 2022 STS2202110H01 ALL Initial Issue Page 5 of 8 Report No.: STS2202110H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Bluetooth PCl-E WiFi Card Brand Name EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill Model Name EP-EP9651 Series Model EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS Model Difference Different appearance size and shape Product Description The EUT is Bluetooth PCl-E WiFi Card Operation Frequency: Bluetooth: 2402 – 2480 MHz 2.4G WLAN: 802.11b/g/n 20: 2412~2462 MHz 802.11n(40MHz):2422~2452MHz 5G WLAN: IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.180GHz-5.240GHz IEEE 802.11n(HT40)/ac(VHT40)/ax(HE40): 5.190GHz-5.230GHz IEEE 802.11ac(VHT80) /ax(HE80): 5.210GHz IEEE 802.11a/ n(HT20)/ac(VHT20)/ax(HE20): 5.745GHz-5.825GHz IEEE 802.11n(HT40)/ac(VHT40)/ax(HE40): 5.755GHz-5.795GHz IEEE 802.11ac(VHT80)/ax(HE80): 5.775GHz Modulation Type: Bluetooth: GFSK(1Mbps), π/4-DQPSK(2Mbps), 8DPSK(3Mbps) BLE: GFSK 2.4G WLAN: 802.11b(DSSS):CCK,DQPSK,DBPSK 802.11g(OFDM):BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM):BPSK,QPSK,16-QAM,64-QAM 5G WLAN: BPSK,QPSK,16-QAM,64-QAM 802.11n(OFDM): BPSK,QPSK,16-QAM,64-QAM 802.11ac(OFDM): BPSK,QPSK,16-QAM,64-QAM,256-QAM Antenna gain: BT/BLE: 5dBi 2.4G WLAN/5G WLAN: ANT A: 5 dBi ANT B: 5 dBi MIMO A+B: 8.01 dBi Antenna Designation: Dipole Page 6 of 8 Report No.: STS2202110H01 Rating Input: AC 120V/60Hz Hardware Version V1.0 Software Version V22.0 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 7 of 8 Report No.: STS2202110H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and al…

Text truncated - open the document above for the full version.

Page 1 of 16 Report No.: STS2202110W04 Power Spectrum Density-Ant A WLAN_Band-1 WLAN_Band-1 W52_11a20_Lower_Power Spectrum DensityW52_11a20_Middle_Power Spectrum Density W52_11a20_Higher_Power Spectrum DensityW52_11n20_Lower_Power Spectrum Density W52_11n20_Middle_Power Spectrum DensityW52_11n20_Higher_Power Spectrum Density Page 2 of 16 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11n40_Lower_Power Spectrum DensityW52_11n40_Higher_Power Spectrum Density W52_11ac20_Lower_Power Spectrum DensityW52_11ac20_Middle_Power Spectrum Density W52_11ac20_Higher_Power Spectrum Density W52_11ac40_Lower_Power Spectrum Density Page 3 of 16 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11ac40_Higher_Power Spectrum Density W52_11ac80_CH42(5210MHz)_Power Spectrum Density W52_11ax20_Lower_Power Spectrum DensityW52_11ax20_Middle_Power Spectrum Density W52_11ax20_Higher_Power Spectrum Density W52_11ax40_Lower_Power Spectrum Density Page 4 of 16 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11ax40_Higher_Power Spectrum Density W52_11ax80_CH42(5210MHz)_Power Spectrum Density Page 5 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11a20_Lower_Power Spectrum DensityW58_11a20_Middle_Power Spectrum Density W58_11a20_Higher_Power Spectrum DensityW58_11n20_Lower_Power Spectrum Density W58_11n20_Middle_Power Spectrum DensityW58_11n20_Higher_Power Spectrum Density Page 6 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11n40_Lower_Power Spectrum DensityW58_11n40_Higher_Power Spectrum Density W58_11ac20_Lower_Power Spectrum DensityW58_11ac20_Middle_Power Spectrum Density W58_11ac20_Higher_Power Spectrum Density W58_11ac40_Lower_Power Spectrum Density Page 7 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ac40_Higher_Power Spectrum Density W58_11ac80_Power Density_5775M W58_11ax20_Lower_Power Spectrum DensityW58_11ax20_Middle_Power Spectrum Density W58_11ax20_Higher_Power Spectrum Density W58_11ax40_Lower_Power Spectrum Density Page 8 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ax40_Higher_Power Spectrum Density W58_11ax80_Power Density_5775M Page 9 of 16 Report No.: STS2202110W04 Power Spectrum Density-Ant B WLAN_Band-1 WLAN_Band-1 W52_11a20_Lower_Power Spectrum DensityW52_11a20_Middle_Power Spectrum Density W52_11a20_Higher_Power Spectrum DensityW52_11n20_Lower_Power Spectrum Density W52_11n20_Middle_Power Spectrum DensityW52_11n20_Higher_Power Spectrum Density Page 10 of 16 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11n40_Lower_Power Spectrum DensityW52_11n40_Higher_Power Spectrum Density W52_11ac20_Lower_Power Spectrum DensityW52_11ac20_Middle_Power Spectrum Density W52_11ac20_Higher_Power Spectrum Density W52_11ac40_Lower_Power Spectrum Density Page 11 of 16 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11ac40_Higher_Power Spectrum Density W52_11ac80_CH42(5210MHz)_Power Spectrum Density W52_11ax20_Lower_Power Spectrum DensityW52_11ax20_Middle_Power Spectrum Density W52_11ax20_Higher_Power Spectrum Density W52_11ax40_Lower_Power Spectrum Density Page 12 of 16 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11ax40_Higher_Power Spectrum Density W52_11ax80_CH42(5210MHz)_Power Spectrum Density Page 13 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11a20_Lower_Power Spectrum DensityW58_11a20_Middle_Power Spectrum Density W58_11a20_Higher_Power Spectrum DensityW58_11n20_Lower_Power Spectrum Density W58_11n20_Middle_Power Spectrum DensityW58_11n20_Higher_Power Spectrum Density Page 14 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11n40_Lower_Power Spectrum DensityW58_11n40_Higher_Power Spectrum Density W58_11ac20_Lower_Power Spectrum DensityW58_11ac20_Middle_Power Spectrum Density W58_11ac20_Higher_Power Spectrum Density W58_11ac40_Lower_Power Spectrum Density Page 15 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ac40_Higher_Power Spectrum Density W58_11ac80_Power Density_5775M W58_11ax20_Lower_Power Spectrum DensityW58_11ax20_Middle_Power Spectrum Density W58_11ax20_Higher_Power Spectrum Density W58_11ax40_Lower_Power Spectrum Density Page 16 of 16 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ax40_Higher_Power Spectrum Density W58_11ax80_Power Density_5775M

Page 1 of 8 Report No.: STS2202110W04 26BW and 99% WLAN_Band-1 WLAN_Band-1 W52_11a20_Lower_26BW and 99% W52_11a20_Middle_26BW and 99% W52_11a20_Higher_26BW and 99% W52_11n20_Lower_26BW and 99% W52_11n20_Middle_26BW and 99% W52_11n20_Higher_26BW and 99% Page 2 of 8 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11n40_Lower_26BW and 99% W52_11n40_Higher_26BW and 99% W52_11ac20_Lower_26BW and 99% W52_11ac20_Middle_26BW and 99% W52_11ac20_Higher_26BW and 99% W52_11ac40_Lower_26BW and 99% Page 3 of 8 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11ac40_Higher_26BW and 99% W52_11ac80_CH42(5210MHz)_26BW and 99% W52_11ax20_Lower_26BW and 99% W52_11ax20_Middle_26BW and 99% W52_11ax20_Higher_26BW and 99% W52_11ax40_Lower_26BW and 99% Page 4 of 8 Report No.: STS2202110W04 WLAN_Band-1 WLAN_Band-1 W52_11ax40_Higher_26BW and 99% W52_11ax80_CH42(5210MHz)_26BW and 99% Page 5 of 8 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11a20_Lower_26BW and 99% W58_11a20_Middle_26BW and 99% W58_11a20_Higher_26BW and 99% W58_11n20_Lower_26BW and 99% W58_11n20_Middle_26BW and 99% W58_11n20_Higher_26BW and 99% Page 6 of 8 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11n40_Lower_26BW and 99% W58_11n40_Higher_26BW and 99% W58_11ac20_Lower_26BW and 99% W58_11ac20_Middle_26BW and 99% W58_11ac20_Higher_26BW and 99% W58_11ac40_Lower_26BW and 99% Page 7 of 8 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ac40_Higher_26BW and 99% W58_11ac80_26BW_99%_Bandwidth_5775M W58_11ax20_Lower_26BW and 99% W58_11ax20_Middle_26BW and 99% W58_11ax20_Higher_26BW and 99% W58_11ax40_Lower_26BW and 99% Page 8 of 8 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ax40_Higher_26BW and 99% W58_11ax80_26BW_99%_Bandwidth_5775M

Page 1 of 4 Report No.: STS2202110W04 6BW WLAN_Band-2 WLAN_Band-2 W58_11a20_Lower_6BW W58_11a20_Middle_6BW W58_11a20_Higher_6BW W58_11n20_Lower_6BW W58_11n20_Middle_6BW W58_11n20_Higher_6BW Page 2 of 4 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11n40_Lower_6BW W58_11n40_Higher_6BW W58_11ac20_Lower_6BW W58_11ac20_Middle_6BW W58_11ac20_Higher_6BW W58_11ac40_Lower_6BW Page 3 of 4 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ac40_Higher_6BW W58_11ac80_-6_Bandwidth_5775M W58_11ax20_Lower_6BW W58_11ax20_Middle_6BW W58_11ax20_Higher_6BW W58_11ax40_Lower_6BW Page 4 of 4 Report No.: STS2202110W04 WLAN_Band-2 WLAN_Band-2 W58_11ax40_Higher_6BW W58_11ax80_-6_Bandwidth_5775M

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No.:STS2202110W04 Issued for Shenzhen EDUP Electronics Technology Co.,Ltd. 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Product Name: Bluetooth PCl-E WiFi Card Brand Name: EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill Model Name: EP-EP9651 Series Model: EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT- AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS FCC ID: 2AHRD-EPEP9651 Test Standard: FCC Part 15.407 S T L A B S Page 2 of 65 Report No.: STS2202110W04 TEST RESULT CERTIFICATION Applicant’s Name ................. : Shenzhen EDUP Electronics Technology Co.,Ltd. Address ................................. : 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Manufacturer's Name .......... : Shenzhen EDUP Electronics Technology Co.,Ltd. Address ................................. : 6 Floor, #6 Building, No.48, Kangzheng Road, Liantang Industrial Area, Buji Town, Longgang District, Shenzhen, China Product Description Product Name ........................ : Bluetooth PCl-E WiFi Card Brand Name ......................... : EDUP, EDUP HOME, EDUP LOVE, WISE TIGER, EPSKY, Card-King, Rosewill Model Name .......................... : EP-EP9651 Series Model .......................... : EP-9651S, EP-9651GS, EP-9651GS Pro, EP-AX210 Pro, EP-AX210GS, EP-AX210, WT-AX210, EP-AX210S, EH-9651, EH-9651S, EH-9651GS, EH-9651GS Pro, EH-AX210 Pro, EH-AX210GS, EH-AX210, EH-AX210S, WT-AX210, WT-9651, WT-9651S, WT-9651GS, WT-9651GS Pro, WT-AX210 Pro, WT-AX210GS, WT-AX210S, KW-9651, KW-9651, KW-9651GS, KW-9651GS-Pro, KW-AX210Pro, KW-AX210GS, KW-AX210, KW-AX210S, RNX-AX5400Pro, RNX-AX5400GS Test Standards ..................... : FCC Part15.407 Test Procedure ..............................ANSI C63.10-2013 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the FCC requirements. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ............................................ : Date of receipt of test item ...................... : 21 Feb. 2022 Date (s) of performance of tests ............. : 21 Feb. 2022 ~ 26 Feb. 2022 Date of Issue ........................................... : 26 Feb. 2022 Test Result ............................................... : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory: (Vita Li) Page 3 of 65 Report No.: STS2202110W04 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2 . GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF TEST MODES 11 2.3 TEST SOFTWARE AND POWER LEVEL 12 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 14 2.6 EQUIPMENTS LIST FOR ALL TEST ITEMS 15 3 . EMC EMISSION TEST 17 3.1 CONDUCTED EMISSION MEASUREMENT 17 3.2 RADIATED EMISSION AND ( BANDEDGE) MEASUREMENT 21 4. POWER SPECTRAL DENSITY TEST 42 4.1 LIMIT 42 4.2 TEST PROCEDURE 42 4.3 DEVIATION FROM STANDARD 43 4.4 TEST SETUP 43 4.5 EUT OPERATION CONDITIONS 43 4.6 TEST RESULTS 44 5. BANDWIDTH MEASUREMENT 46 5.1 EMISSION BANDWIDTH (EBW) 26 BANDWID PROCEDURES / LIMIT 46 5.2 OCCUPIED BANDWIDTH ( 99%) TEST APPLIED PROCEDURES / LIMIT 49 5.3 MINIMUM EMISSION BANDWIDTH(6 DB) PROCEDURES / LIMIT 52 6. MAXIMUM CONDUCTED OUTPUT POWER 54 6.1 LIMIT 54 6.2 TEST PROCEDURE 54 6.3 DEVIATION FROM STANDARD 54 6.4 TEST SETUP 54 6.5 EUT OPERATION CONDITIONS 54 6.6 TEST RESULTS 55 7. AUTOMATICALLY DISCONTINUE TRANSMISSION 63 7.1 LIMIT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 63 7.2 TEST RESULT OF AUTOMATICALLY DISCONTINUE TRANSMISSION 63 Page 4 of 65 Report No.: STS2202110W04 Table of Contents Page 8. ANTENNA REQUIREMENT 64 8.1 STANDARD REQUIREMENT 64 8.2 EUT ANTENNA 64 APPENDIX - PHOTOS OF TEST SETUP 65 Page 5 of 65 Report No.: STS2202110W04 Revision History Rev. Issue Date Report NO. Effect Page Contents 00 26 Feb. 2022 STS2202110W04 ALL Initial Issue Page 6 of 65 Report No.: STS2202110W04 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: § 15.407,KDB 789033 D02 General U-NII Test Procedures New Rules v02r01 FCC Part 15.407 FCC standard Test Item Results 15.207 AC Conducted Emission PASS 15.407 (a) /15.407 (e) 26dB/6dB &99% Bandwidth PASS 15.407(a) Maximum Conducted Output Power PASS 15.407(b)/15.205/15.209 Radiated Emission And (bandedge Emissions) Measurement PASS 15.407(a) Power Spectral Density PASS 15.407(c) Automatically Discontinue Transmission PASS 15.203/15.204 Antenna Requirement PASS NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2013. Page 7 of 65 Report No.: STS2202110W04 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub…

Text truncated - open the document above for the full version.

Page 1 of 2 FCC ID: 2AHRD-EPEP9651 DSS&DTS&DXX Setup photo Model name: EP-EP9651 DSS&DTS&DXX conduction DSS&DTS&DXX radiation L Page 2 of 2 FCC ID: 2AHRD-EPEP9651 DSS&DTS&DXX radiation H
