Scan the QR code to access the tutorial Foldable 3-Axis AI Tracking Smartphone Gimbal User Manual V1.0 Warning & Disclaimer Thank you for purchasing the Hohem product. By using this product, you hereby signify that you have read this disclaimer and warning carefully. In addition, you understand and agree to abide by the terms and conditions herein. You acknowledge that you are solely responsible for your own conduct while interacting with this product, and for any consequences thereof. You agree to use this product only for purposes that are proper and in accordance with all applicable laws, rules, and regulations, and all terms, precautions, practices, policies and guidelines Hohem has made and may make available. Hohem accepts no liability for damage, injury, or any legal responsibility incurred directly or indirectly from the use of this product. The user shall observe safe and lawful practices including, but not limited to, those set forth in this document. This document and all other collateral documents are subject to change at the sole discretion of Hohem. For up-to-date product information, visit www.hohem.com and click on the product page for this product. Email [email protected] Website www.hohem.com Manufacturer Hohem Technology Co., Ltd Hohem Technology Co., Ltd Connect us at Facebook iSteady V2S Overview 03 ○ Items marked "*" are optional accessories which are sold separately. ○ Mount your mobile phone before powering on iSteady V2S. ○ If no mobile phone is detected or the motor is overloaded because phone is not balanced well, the gimbal will shut down after a warning beeping. ① AI Vision Sensor & LED Video Light Power Button ② AI Vision Indicator ③ AI Vision Sensor ④ LED Video Light ⑤ Phone Clamp ⑥ Folding Lock A ⑦ Folding Lock B ⑧ Working Mode Indicator (Battery Indicator) ⑨ Zoom Slider ⑩ Shutter Button ⑪ Tilt Motor ⑫ Knob ⑬ Pan Motor ⑭ Bluetooth Light ⑮ Joystick ⑯ Function Button ⑰ Roll Motor ⑱ M Button (Power On/Off) ⑲ Charging Port (Type C) ⑳ Handle Battery built-in) ㉑ Lanyard Hole ㉒ 1/4 inch Screw Port ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮ ⑯ ⑰ ⑱ ⑲ ⑳ ㉑ ㉒ 04 Booting up iSteady V2S Battery and Charging Long press M button for 3 seconds to power on Charging Method: To charge the iSteady V2S, connect a USB adapter (not included, choose 5V-2A for better results) into the charging port with the provided USB-C charging cable. Mount & Balance Mobile Phone on the Gimbal? ① Expand the gimbal ② Tighten the knob by turning it clockwise. ③ Make sure that the phone camera is on the left side of the clamp. Insert your mobile device by putting it stuck in the bottom of phone clamp and pulling the top side of the clamp to clip it into place. ④ Slide the phone and keep it clamped and balanced centrally before powering on. USB adapter （5V-2A） Type A-Type C charging cable Please fully charge the iSteady V2S before using it for the first time. The gimbal would not function properly if the knob was not tightened. Ensure your phone is centrally clamped to the rubber pads, otherwise the gimbal would vibrate or turn off automatically. AI Visual Tracking & LED Video Light ① ② ③ ① AI Tracking & Gesture Control AI Tracking: Single press the AI Vision Sensor & LED Video Light Power Button to start tracking. The indicator light shows red, and the LED video light double flashes to indicate that the AI visual tracking has been activated (long press the button to turn off). ② Gesture Control (Note: The best distance of gesture control is between 0.5 and 1.5 meters (1.6 - 5 ft), and make sure that both gesture and face are shown in front of AI sensor within this range.) Start smart tracking: Take a OK gesture towards AI vision sensor, AI indicator turns green. Turn off smart tracking: Show a palm gesture towards the AI vision sensor and AI vision indicator turns red. Switch between landscape and portrait mode: 05 Before operation, ensure that the gimbal is powered on. Portrait mode: Two thumbs right; Landscape mode: Two thumbs up ③ LED Video Light (make sure that AI vision sensor is started) Single press AI Vision Sensor & LED Video Light Power Button to turn on the light and adjust the light intensity. LED turns according to low-medium- high-close modes. FAQ: How to make AI vision positioning adjustments? (Customized Composition) Scan the QR code for tutorial of customized composition If the framed subject cannot be centered on the phone screen, or you want to customize the AI vision position to be tracked: 1. Make sure the gimbal & AI vision sensors are on. 2. Take the gesture "" towards the AI vision sensor and and the indicator light will quickly blink in green color. 3. Move in front of the screen until you find the preferred position to be tracked. 4. Show the gesture ""to lock the position and create the ideal composition (the indicator light will stop flashing). Button Function 06 ① ② ③ ④⑤ ③ Zoom Slider (Available in the Hohem Joy / Android 10.0 or later, please ensure the Bluetooth pairing.) Push up: Zoom in Push down: Zoom out ④ Shutter Button (Please ensure the Bluetooth pairing) Press once: Take photo; Start/End video Press twice: PHOTO/VIDEO switch Press three times: Front/Rear camera switch (Available in the Hohem Joy / Android 10.0 or later, please ensure the Bluetooth pairing.) ⑤ Function Button Press once: Landscape mode/Portrait mode switch Press twice: Recenter the gimbal Press three times: 180° inception mode/ 180° spin shot (auto rotation) Press seven times: Remote control* pairing When paired with a remote control* Press function button once: Cancel pairing Press function button twice: Clear the paired remote control* (The paired remote control will be unavailable and needs to be re-paired.) Press on function button: Check the gimbal battery level (Remote control is sold separately.) ① M Button(Power Button) Press and hold for 3s: Power on/off Press once: Switch between working modes (PTF-PF-L-POV) Press twice: Standby mode (Press any button to exit) Press five times: Auto calibration ② J…

Text truncated - open the document above for the full version.

Shenzhen Hohem Technology Co., Ltd. To: Federal Communications Commission Date: 2023-03-28 7435 Oakland Mills Road Columbia, MD 21046 USA Attestation Section 2.911(d)(5)(i) and Section 2.911(d)(5)(ii) (KDB 986446 D01 Covered Equipment) Section 2.911(d)(5)(i) Shenzhen Hohem Technology Co., Ltd. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Section 2.911(d)(5)(ii) Shenzhen Hohem Technology Co., Ltd. (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Type of Equipment subject to FCC Certification: FCC ID: 2AIB7V2S If you have any questions, please feel free to contact me Contact Person: June Zhou Position in the Company: R&D Specialist Date of Signature: 2023-03-28 ___________________________ Signatory (signature of the applicant)

FCC ID: 2AIB7V2S IC: 28400-V2S MODEL NAME: iSV2S External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

1、 Label Size:24*8.1mm Color: Black lettering on a white background Material: Sticker 2、 Label location

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 9 REPORT No.：SZ23030034S01 RF EXPOSURE EXEMPT REPORT APPLICANT : Shenzhen Hohem Technology Co., Ltd. PRODUCT NAME : iSteady V2S Foldable 3-Axis AI-tracking Smartphone Gimbal MODEL NAME : iSV2S BRAND NAME :hohem FCC ID : 2AIB7V2S STANDARD(S) : 47 CFR Part 2(2.1093) RECEIPT DATE : 2023-02-07 TEST DATE :2023-02-16 to 2023-03-28 ISSUE DATE :2023-04-04 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 9 REPORT No.：SZ23030034S01 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1 Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2 Equipment Under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.3 Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2. Device Category and RF Exposure Limit ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 3. RF Output Power ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4. RF Exposure Assessment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 7 Annex A Testing Laboratory Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 9 Change History Version Date Reason for change 1.0 2023-04-04 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 9 REPORT No.：SZ23030034S01 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: Shenzhen Hohem Technology Co., Ltd. Applicant Address: B106,University Creative Park, Xili, Nanshan, Shenzhen, China Manufacturer: Shenzhen Hohem Technology Co., Ltd. Manufacturer Address: B106,University Creative Park, Xili, Nanshan, Shenzhen, China 1.2 Equipment Under Test (EUT) Description Product Name: iSteady V2S Foldable 3-Axis AI-tracking Smartphone Gimbal Sample No.: 1# Hardware Version: V1.00 Software Version: V1.001 Equipment Type: Bluetooth LE Bluetooth Version: 5.3 Operating Frequency Range: 2402MHz-2480MHz Modulation Type: GFSK(1Mbps, 2Mbps) Antenna Type: PCB Antenna Antenna Gain: -2.16dBi MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 9 REPORT No.：SZ23030034S01 1.3 Applied Reference Documents Leading reference documents for testing: Identity Document Title Method Determination /Remark 47 CFR Part 2(2.1093) Radio Frequency Radiation Exposure Assessment: Portable devices No deviation KDB 447498 D04v01 RF Exposure Procedures and Equipment Authorization Policies for Mobile and Portable Devices No deviation Note 1: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 2: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 5 of 9 REPORT No.：SZ23030034S01 2. Device Category and RF Exposure Limit Per user manual, based on 47 CFR 2.1093, this device belongs to portable device category with General Population/Uncontrolled exposure. Portable Devices: 47 CFR 2.1093(b) For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. General Population/Uncontrolled Exposure: 47 CFR 2.1093(d) (2) Limits for General Population/Uncontrolled exposure: 0.08 W/kg as averaged over the whole-body and spatial peak SAR not exceeding 1.6 W/kg as averaged over any 1 gram of tissue (defined as a tissue volume in the shape of a cube). Exceptions are the hands, wrists, feet and ankles where the spatial peak SAR shall not exceed 4 W/kg, as averaged over any 10 grams of tissue (defined as a tissue volume in the shape of a cube). General Population/Uncontrolled limits apply when the general public may be exposed, or when persons that are exposed as a consequence of their employment may not be fully aware of the potential for exposure or do not exercise control over …

Text truncated - open the document above for the full version.

NOTE:ThisdocumentisissuedbyShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,thetestreportshallnotbereproducedexceptin fullwithoutpriorwrittenpermissionofthecompany.Thetestresultsapplyonlytotheparticularsample(s)testedandtothespecifictestscarried outwhichisavailableonrequestforvalidationandinformationconfirmedatourwebsite. MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page1of 13 REPORTNo.：SZ21080442E10A TESTREPORT APPLICANT:HohemTechnologyCo.,Ltd. PRODUCTNAME:Splashproof3-AxisActionCameraGimbal MODELNAME:iSteadyPro4 TRADENAME: hohem BRANDNAME:hohem STANDARD(S):ANSI/IEEEStd149-2008 RECEIPTDATE:2021-10-14 TESTDATE:2021-10-18 ISSUEDATE:2023-03-13 Editedby: : KeZhiqing(Rapporteur) Approvedby: : ChiShide(Supervisor) Testedby MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page2of13 REPORTNo.：SZ21080442E10A DIRECTORY 1.TechnicalInformation ........................................................................................................3 1.1.ApplicantandManufacturerInformation ....................................................................3 1.2.EquipmentUnderTest(EUT)Description...................................................................3 2.TestResults........................................................................................................................4 2.1.AppliedReferenceDocuments.....................................................................................4 2.2.TestConditions...............................................................................................................4 2.3.MeasurementUncertainty.............................................................................................4 2.4.TestResultslists.............................................................................................................5 AnnexATestSetupPhotos..................................................................................................6 AnnexBFigures .....................................................................................................................7 1.2DRadiationPattern .........................................................................................................7 2.3DRadiationPattern .........................................................................................................9 AnnexCEUTPhotos ...........................................................................................................11 AnnexDGeneralInformation .............................................................................................13 1.1IdentificationoftheResponsibleTestingLaboratory..............................................13 1.2IdentificationoftheResponsibleTestingLocation..................................................13 1.3TestEquipmentsUtilized..............................................................................................13 ChangeHistory VersionDateReasonforchange 1.0 2023-03-13 Firstedition MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page3of13 REPORTNo.：SZ21080442E10A 1.TechnicalInformation Note:Providebymanufacturer. 1.1.ApplicantandManufacturerInformation Applicant:HohemTechnologyCo.,Ltd. ApplicantAddress:B106,UniversityCreativePark,Xili,Nanshan,Shenzhen,China Manufacturer:HohemTechnologyCo.,Ltd. ManufacturerAddress:B106,UniversityCreativePark,Xili,Nanshan,Shenzhen,China 1.2.EquipmentUnderTest(EUT)Description WirelessTypeBluetooth Testfrequencyband2400MHz-2500MHz Brandnamehohem AntennamodeliSteadyPro4 HardwareVersionV1.00 SoftwareVersionV1.001 IMEIN/A Samplenumber2# Dimensions: Note1:TheoriginalreportSZ21080442E10hasbeenreplacedbytheSZ21080442E10A. Note2:ThesamplephotosshallbeprovidedseparatelyinAnnexCaccordingtocustomer requirements. MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page4of13 REPORTNo.：SZ21080442E10A 2.TestResults 2.1.AppliedReferenceDocuments Leadingreferencedocumentsfortesting: No.IdentityDocumentTitle 1 ANSI/IEEEStd149-2008 IEEEStandardTestProceduresforAntennas 2.2.TestConditions TestEnvironmentConditions： RelativeHumidity:25...75% Temperature:+10°Cto+30°C 2.3.MeasurementUncertainty Theuncertaintyiscalculatedusingthemethodssuggestedinthe"GuidetotheExpressionof UncertaintyinMeasurement"(GUM)publishedbyISO. ItemMeasurementUncertainty(dB) Gain±0.5 VSWR±0.2 MeasurementUncertainty(95%ConfidenceInterval)K=2 MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page5of13 REPORTNo.：SZ21080442E10A 2.4.TestResultslists 2.4.1. Gain FrequencyGain(dBi) 2400MHz-6.22 2410MHz -5.42 2420MHz-5.27 2430MHz -4.57 2440MHz-4.49 2450MHz -3.82 2460MHz-4.17 2470MHz -4.08 2480MHz-3.94 2490MHz -2.92 2500MHz-2.16 MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA, FeiYangSciencePark,No.8LongChangRoad,Block67,BaoAnDistrict, ShenZhen,GuangDongProvince,P.R.China Tel:86-755-36698555Fax:86-755-36698525 Http://www.morlab.cnE-mail:[email protected] Page6of13 REPORTNo.：SZ21080442E10A AnnexATestSetupPhotos MORLAB ShenzhenMorlabCommunicationsTechnologyCo.,Ltd.,FL.1-3,BuildingA…

Text truncated - open the document above for the full version.

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 72 REPORT No.：SZ23030034W01 TEST REPORT APPLICANT : Shenzhen Hohem Technology Co., Ltd. PRODUCT NAME : iSteady V2S Foldable 3-Axis AI-tracking Smartphone Gimbal MODEL NAME : iSV2S BRAND NAME :hohem FCC ID :2AIB7V2S STANDARD(S) :47 CFR Part 15 Subpart C RECEIPT DATE : 2023-02-07 TEST DATE :2023-02-16 to 2023-03-28 ISSUE DATE :2023-04-12 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 72 REPORT No.：SZ23030034W01 DIRECTORY 1. Summary of Test Result ················································································ 4 1.1. Testing Applied Standards ·········································································· 5 1.2. Test Equipment List ··················································································· 6 1.3. Measurement Uncertainty ··········································································· 8 1.4. Testing Laboratory ····················································································· 8 2. General Description ····················································································· 9 2.1. Information of Applicant and Manufacturer ··················································· 9 2.2. Information of EUT ····················································································· 9 2.3. Channel List of EUT ·················································································· 10 2.4. Test Configuration of EUT ·········································································· 11 2.5. Test Conditions ························································································ 11 2.6. Test Setup Layout Diagram ········································································ 11 3. Test Results ······························································································· 14 3.1. Antenna Requirement ··············································································· 14 3.2. Duty Cycle of Test Signal ··········································································· 15 3.3. Maximum Peak Conducted Output Power ···················································· 16 3.4. Maximum Average Conducted Output Power ··············································· 17 3.5. 6 dB Bandwidth ························································································ 18 3.6. Conducted Spurious Emissions and Band Edge ··········································· 19 3.7. Power Spectral Density ············································································· 20 3.8. Conducted Emission ················································································· 21 3.9. Restricted Frequency Bands ······································································ 22 3.10. Radiated Emission ···················································································· 23 Annex A Test Data and Result ·········································································· 25 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 72 REPORT No.：SZ23030034W01 Change History Version Date Reason for change 1.0 2023-04-12 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL.1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 72 REPORT No.：SZ23030034W01 1. Summary of Test Result No. Section Description Test Date Test Engineer Result Method Determination /Remark 1 15.203 Antenna Requirement N/A N/A PASS No deviation 2 N/A Duty Cycle of Test Signal Feb. 16, 2023 Su Xiaoxian PASS No deviation 3 15.247(b) Maximum Peak Conducted Output Power Feb. 16, 2023 Su Xiaoxian PASS No deviation 4 15.247(b) Maximum Average Conducted Output Power Feb. 16, 2023 Su Xiaoxian PASS No deviation 5 15.247(a) Bandwidth Feb. 16, 2023 Su Xiaoxian PASS No deviation 6 15.247(d) Conducted Spurious Emission and Band Edge Feb. 16, 2023 Su Xiaoxian PASS No deviation 7 15.247(e) Power Spectral Density Feb. 16, 2023 Su Xiaoxian PASS No deviation 8 15.207 Conducted Emission Mar. 28, 2023 Wu Zhaoling PASS No deviation 9 15.247(d) Restricted Frequency Bands Mar. 26, 2023 Gao Jianrou PASS No deviation 10 15.209, 15.247(d) Radiated Emission Mar. 26, 2023 Gao Jianrou PASS No deviation Note 1: The tests were performed according to the method of measurements prescribed in ANSIC63.10-2013 and KDB558074 D01 v05r02. Note 2: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 3: When the test result is a critic…

Text truncated - open the document above for the full version.

FCC ID: 2AIB7V2S IC: 28400-V2S Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (9KHz-30MHz) 4. Radiated emission (30MHz-1GHz) 5. Radiated emission (above 1GHz) 6. RF measurement setup (Bluetooth LE)
