2AIOC-100008727Clock Radio With Wireless Charging

LED Digital Display ItemDescription# Current time Displays the current time. Alarm Lights when alarm has been set and enabled. AM/PM “AM” lights after midnight and before noon, and “PM” lights after noon and before midnight. Bluetooth Lights when BT mode is selected. AUX Lights when an external audio is connected. FM Lights when FM mode is selected. MHz Lights when FM mode is selected. Play/Pause In AUX mode and BT mode, press to play or pause audio; in FM mode, press to enter preset station play mode, press and hold 2 seconds to set preset station. In BT mode, press to switch to next track; In FM Mode, press to tune in 0.1MHz increments or switch preset stations, double-click to start auto scan until find an upper available channel. In any modes, press and hold to increase volume. Volume Up/ Next Track Features Top ItemDescription# Mode button Clock button In other modes, press to return to Clock mode; In any modes, press and hold 3 seconds to enter clock settings. Alarm button In Clock mode, press to turn on or turn o alarm; In other modes, press to return to Clock mode; In any mode, press and hold 3 seconds to enter alarm clock settings. Dimmer/Snooze/ Sleep When alarm rings, you can press to adjust the interval to repeat alarm. The alarm repeats ringing 10 minutes later. When alarm not rings, press it to adjust LED brightness, press and hold 2 seconds to set up sleep timer. Volume Down/ Previous Track In BT mode, press to switch to previous track; In FM Mode, press to tune in 0.1MHz increments or switch preset stations, double-click to start auto scan until find a lower available channel, and press and hold to decrease volume. In any modes, press and hold to decrease volume. (1) Press Mode button to power at Bluetooth mode as default (2) Press Mode button to switch between Bluetooth and FM mode (3) Press and hold Mode button x 3 seconds for OFF mode 1 1 2 3 4 7 6 5 Rear ItemDescription# AUX IN jack Connect to an external audio device. USB port Connect to charge an external device. FM antenna The FM antenna is an 80cm pigtail cable, keep it fully extended to get the best signal reception. DC IN jack Connect to the included power adapter. DC IN 9V 1342 234567 Clock Radio With Wireless Charging Model: 100008727 PRODUCT GUIDE 12/09/2019_Revision 12/09/2019_Revision We ‘d love to hear from you. Scan with your Walmart app and let us know what you think. 12/09/2019_Revision12/09/2019_Revision Press and hold or together for 10 seconds until “beep” to return factory default. The previous Clock settings, Alarm settings and Bluetooth paring settings will be cleared. Set Alarm Sound After set the alarm minute, press button two times to enter alarm tone selection, then press or button to choose the tone you want (1, 2, 3, 4 tones plus 5 FM radio tone), after tone is set, press button to confirm setting (If no button is pressed for 15 seconds, the setting is saved automatically). When FM is set as alarm tone, press or to adjust the Alarm volume. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. FCC RF EXPOSURE STATEMENT: This device complies with Innovation, Science, and Economic Development Canada licence exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Blackweb is a trademark of Walmart Stores, Inc. The ‘Qi’ symbol is a trademark of the Wireless Power Consortium. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Blackweb is under license. Distributed by Walmart Stores, Inc., Bentonville, AR; 72716 1-800-925-6278 . 2018 Walmart Stores, Inc. All rights reserved. ISEDC CAUTION: The device is in compliance with RF exposure guidelines, users can obtain Canadian information on RF exposure and compliance. ISEDC RF EXPOSURE STATEMENT: IMPORTANT SAFEGUARDS: When using an electrical product, basic precautions should always be followed, including the following: Please use the standard power adapter equipped with this unit. The charging input and output ports, please do not connect to any faulty equipment to avoid the irreversible damage of the unit. Do not use in a strong magnetic or strong interference field, otherwise it may cause the machine to be functionally unusual. The product is for indoor use only. IMPORTANT LEGAL INFORMATION READ ALL INSTRUCTIONS BEFORE USING A MESSAGE FROM THE ENVIRONMENT WARNING: This product has an internal, non-replaceable lithium-ion battery. Please dispose of in accordance with your local, state, province, and country guidelines. This product contains small parts that may present a choking hazard for young children. CAUTION: All servicing of this product must be performed by authorized service personnel only. • WARNING: Listen responsibly. To avoid hearing damage, make sure the volume on your device is turned down before connecting to the speaker. After turning on your speaker, gradually turn up the volume until you reach a comfortable listening volume. • Use this product only for its intended use as described in this manual. Do not use attachments not recommended by Blackweb. • Blackweb is not liable for any damage caused to smartphones, iPod/MP3 players, or any other device. • Do not place or store this product where it can fall or be d…

Text truncated - open the document above for the full version.

HANK ELECTRONICS CO., LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020.01.13 Subject; Request for Long Term Confidentiality FCC ID: 2AIOC-100008727 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: GuangCan Yang Title: N/A

HANK ELECTRONICS CO., LTD. Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Statement Product: Clock Radio With Wireless Charging Model: 100008727 Additional Model: HKBT914 Trademark: N/A We hereby state that All models above are identical in interior structure, electrical circuits and components, and just model names are different for the marketing requirement. Your assistance on this matter is highly appreciated. Yours sincerely, Signature: Date: 2020/01/13 Name: GuangCan Yang Company Name : HANK ELECTRONICS CO., LTD. Address: Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Tel / Fax: 0755-82024967/0755-82025852 E-Mail: [email protected]

HANK ELECTRONICS CO., LTD. Agent Authorization Company: HANK ELECTRONICS CO., LTD. Address: Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Product Name: Clock Radio With Wireless Charging Model Number(s): 100008727, HKBT914 Product Description: Clock Radio With Wireless Charging We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020-01-13 Name: GuangCan Yang Title: N/A Company: HANK ELECTRONICS CO., LTD.

HANK ELECTRONICS CO., LTD. 2019-01-13 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD FCC ID: 2AIOC-100008727 To Whom It May Concern: This letter is to ascertain that HANK ELECTRONICS CO., LTD. Product Clock Radio With Wireless Charging has been the units used for conducting FCC compliance testing, the sDoC part will be tested by FCC accredited test lab. The result shows that the EUT has complied to unintentional Radiators requirements (15.101). Test lab information: FCC-Registration No.: 645098 Shenzhen Tongce Testing Lab. Adress: 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China If you have any question or concerns, pls. contact us. Sincerely, (signed) Name / Title: GuangCan Yang Company: HANK ELECTRONICS CO., LTD. Address: Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Phone: 0755-82024967 Fax: 0755-82025852 Email: [email protected]

Page 1 of 4 Appendix B: Photographs of EUT Product: Clock Radio With Wireless Charging Model: 100008727 External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

Label Artwork and Location Model: 100008727 Label: Size: L*W=100*30mm Location

Page 1 of 10 Appendix B: Photographs of EUT Product: Clock Radio With Wireless Charging Model: 100008727 Internal Photos Page 2 of 10 Page 3 of 10 Page 4 of 10 Page 5 of 10 Page 6 of 10 Antenna Page 7 of 10 Page 8 of 10 Page 9 of 10 Page 10 of 10

RF exposure evaluation FCC ID: 2AIOC-100008727 §2.1093 Radiofrequency radiation exposure evaluation: Portable Devices. According to§15.247(i) and§1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the commission’s guidance. The 1-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  When the minimum test separation distance is < 5 mm, a distance of 5 mm according is applied to determine SAR test exclusion.  The result is rounded to one decimal place for comparison  Channel Frequency (GHz) Max. Power (dBm) Tune up Power (dBm) Max. Tune up Power (dBm) Max. Tune up Power (mW) Test distance (mm) Result exclusion thresholds for 1-g SAR CH 78 2.480 -4.71 -4.5±1 -3.5 0.45 5 0.14 3.0 Result: Base on the calculation value, No SAR measurement is required.

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID: 2AIOC-100008727 Product: Clock Radio With Wireless Charging Model No.: 100008727 Additional Model No.: HKBT914 Trade Mark: N/A Report No.: TCT191219E014 Issued Date: Jan. 08, 2020 Issued for: HANK ELECTRONICS CO., LTD. Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Issued By: Shenzhen Tongce Testing Lab. 1B/F., Building 1, Yibaolai Industrial Park, Qiaotou, Fuyong, Baoan District, Shenzhen, Guangdong, China TEL: +86-755-27673339 FAX: +86-755-27673332 Note: This report shall not be reproduced except in full, without the written approval of Shenzhen Tongce Testing Lab. This document may be altered or revised by Shenzhen Tongce Testing Lab. personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT191219E014 Page 2 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TABLE OF CONTENTS 1. Test Certification ..................................................................................... 3 2. Test Result Summary .............................................................................. 4 3. EUT Description ....................................................................................... 5 4. General Information ................................................................................. 6 4.1. Test environment and mode ................................................................................. 6 4.2. Description of Support Units ................................................................................ 6 5. Facilities and Accreditations .................................................................. 7 5.1. Facilities ................................................................................................................. 7 5.2. Location ................................................................................................................. 7 5.3. Measurement Uncertainty ..................................................................................... 7 6. Test Results and Measurement Data ..................................................... 8 6.1. Antenna requirement ............................................................................................ 8 6.2. Conducted Emission ............................................................................................. 9 6.3. Conducted Output Power ................................................................................... 13 6.4. 20dB Occupy Bandwidth .................................................................................... 17 6.5. Carrier Frequencies Separation ......................................................................... 21 6.6. Hopping Channel Number .................................................................................. 25 6.7. Dwell Time ............................................................................................................ 28 6.8. Pseudorandom Frequency Hopping Sequence ................................................ 32 6.9. Conducted Band Edge Measurement ................................................................ 33 6.10. Conducted Spurious Emission Measurement ................................................. 36 6.11. Radiated Spurious Emission Measurement .................................................... 39 Appendix A: Photographs of Test Setup Appendix B: Photographs of EUT Report No.: TCT191219E014 Page 3 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. Test Certification Product: Clock Radio With Wireless Charging Model No.: 100008727 Additional Model No.: HKBT914 Trade Mark: N/A Applicant: HANK ELECTRONICS CO., LTD. Address: Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Manufacturer: HANK ELECTRONICS CO., LTD. Address: Floor 2nd-7th, A8, Hongye Industry City, Lezhujiao, Zhoushi Road, Baoan District, Shenzhen, China Date of Test: Dec. 20, 2019 – Jan. 07, 2020 Applicable Standards: FCC CFR Title 47 Part 15 Subpart C Section 15.247 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 ANSI C63.10:2013 The above equipment has been tested by Shenzhen Tongce Testing Lab. and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Tested By: Date: Jan. 07, 2020 Aaron Mo Reviewed By: Date: Jan. 08, 2020 Beryl Zhao Approved By: Date: Jan. 08, 2020 Tomsin Report No.: TCT191219E014 Page 4 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. Test Result Summary Requirement CFR 47 Section Result Antenna Requirement §15.203/§15.247 (c) PASS AC Power Line Conducted Emission §15.207 PASS Conducted Peak Output Power §15.247 (b)(1) PASS 20dB Occupied Bandwidth §15.247 (a)(1) PASS Carrier Frequencies Separation §15.247 (a)(1) PASS Hopping Channel Number §15.247 (a)(1) PASS Dwell Time §15.247 (a)(1) PASS Radiated Emission §15.205/§15.209 PASS Band Edge §15.247(d) PASS Note: 1. PASS: Test item meets the requirement. 2. Fail: Test item does not meet the requirement. 3. N/A: Test case does not apply to the test object. 4. The test result judgment is decided by the limit of test standard. Report No.: TCT191219E014 Page 5 of 64 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. EUT Description Product: Clock Radio With Wireless Charging Model No.: 100008727 Additional Model No.: HKBT914 Trade Mark: N/A Bluetooth Version: V5.0 Operation Frequency: 2402MHz~2480MHz Transfer Rate: 1/2 Mbits/s Number of Channel: …

Text truncated - open the document above for the full version.

Page 1 of 2 Appendix A: Photographs of Test Setup Product: Clock Radio With Wireless Charging Model: 100008727 Radiated Emission Page 2 of 2 Conducted Emission
