PREFACE Thank you for purchasing P15UV Two Way Radio, It is a multitask GMRS transceiver. Combining the latest technology in radio communication along with a sturdy mechanical frame, P15UV is the ideal and effective solution for the professionals who need to stay in touch with the working team (in construction sites, buildings, shows, trade fairs or hotels) or for leisure users that just want to keep up with friends and family. This manual is applicable to the following product: P15UV,UV-15R,GMR-15S ,GM-898,GM-15X, TH-15S,AI-15X,AT-15UV and G-15UV Two Way Radios. IMPORTANT NOTICE To help you ward off bodily injury or property loss that may arise from improper operation, please read all the information carefully before using our products. This contains instructions for safe usage and RF energy awareness and control for compliance with applicable standards and regulation. Safety Information for Pofung Radios Your wireless handheld portable transceiver contains a low power transmitter. When the talk button is pushed, it sends out radio frequency (RF) signals. The device is authorized to operate at a duty factor not to exceed 50%. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless devices. Table of Contents 1. GETTING STARTED 1.1 Regulations and Safety Warnings 1.2 Content of the packaging 1.3 Main features 1.4 Maintenance 2. BATTERY INFORMATION 2.1 Charging the Battery Pack 2.2 Charger Supplied 2.3 Use Caution with the Li-ion Battery 2.4 How to Charge 2.5 LED Indicator 2.6 How to Store the Battery 2.7 Using the Type-C USB Charger 3. INSTALLATION OF ACCESSORIES 3.1 Installing / Removing the Antenna 3.2 Installing the belt clip 3.3 Installing the battery pack 3.4 Additional Speaker/Microphone (Optional) 4. RADIO OVERVIEW 4.1 Buttons and controls of the radio 4.2 Main controls and parts of the radio 4.3 Status Indications 4.4 Main keypad controls 5. BASIC OPERATIONS 5.1 Power on the radio 5.2 Adjusting the volume 5.3 Channel selection 5.4 Making a call 5.5 Frequency (VFO) mode 5.6 Channel (MR) mode 6. ADVANCED FEATURES 6.1 Frequency scanning 6.2 Channel scanning 6.3 CTCSS scanning 6.4 DCS scanning 6.5 CursorConversion (A/B) 6.7 Keypad lock 6.8 FM Radio (FM) 6.9 TX 1000Hz, 1450Hz, 1750Hz, 2100Hz repeaters tone 6.10 Manual Programming (Channels Memory) 6.11 Built-in LED Flashlight 6.12 NOAA weather Receiver /Scan 7. WORKING THE MENU SYSTEM 7.1 Basic use 7.2 Using short-cuts 7.3 Functions and operations 8. ON-LINE SERVICE AND SUPPORT Appendix A. - Trouble shooting guide Appendix B. - Technical Specifications Appendix C. - Shortcut Menu operations 1. GETTING STARTED 1.1 Regulations and Safety Warnings ■ FCC COMPLIANCE This device complies with Part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. Our radio generators RF electromagnetic energy during transmit mode. This radio is designed for and classified as“General Population”,meaning it must be used only during the course of employment by individuals aware of the hazards, and the ways To Minimize Such hazards. This radio is NOT intended for use by the“General Population” in an uncontrolled environment. This radio has been tested and complies with the FCC RF exposure limits for“General Population”. In addition, our radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: ---IEEE Std. 1528:2013 and KDB447498, Evaluating Compliance with FCC Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields. ---American National Standards Institute (C95.1-1992), IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. ---American National Standards Institute (C95.3-1992), IEEE Recommended Practice for the Measurement of Potentially Hazardous Electromagnetic Fields-RF and Microwave. The information listed above provides the user with the information needed to make him or her aware of RF exposure, and what to do to as-sure that this radio operates with the FCC RF exposure limits of this radio. Electromagnetic Interference/Compatibility During transmissions, The radio generates RF energy that can possibly cause interference with other devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so. DO NOT operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospitals, aircraft, and blasting sites. Occupational/Controlled Use The radio transmitter is used in situations in which persons are exposed as consequence of their employment provided those persons are fully aware of the potential for exposure and can exercise control over their exposure. Attention: This radio complies with IEEE and ICNIRP exposure limits for General Population/Uncontrolled Environments RF exposure environment at operating duty factors of up to 50% and is authorized by the FCC for Occupational use only. An appropriate warning lable is affixed to all units. In order to comply with RF exposure requirements, a minimum distance of 2.5 cm must be maintained when held-to-face, and body-worn operations are restricted to the approved original accessories (belt clip), a minimum distance of 0 cm. Do not use this device when antenna shows obvious damages. This product is compliance to FCC RF Exposure requirements and refers to FCC website https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm search for FCC ID: 2AJGM-P15UV to gain further information include SAR Values. ■Licensing Information Use our radio in Canada/USA is subject to the rules & regulations of IC/FCC. Changes or modifications not expressly approved by our may void the user authority granted by the IC/FCC to operate this radio and should not be made. To comply with IC/FCC requirements, transmitter adjustments should be…

Text truncated - open the document above for the full version.

PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Office of Engineering Technology Date: Mar. 30, 2021 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA FCC ID: 2AJGM-P15UV Subject: Declaration of compliance to the requirements of §15.121 We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. If you have any questions, please feel free to contact me. Thank you. Sincerely, Signatory [Peter Wang, General Manager]

PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Agent Authorization Company: PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY Address: 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Product Name: Two-way radio Model Number(s): P15UV, UV-15R, GMR-15S, GM-898, GM-15X, TH-15S, AI-15X, AT-15UV, G-15UV Product Description: GMRS Two-way radio We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Mar. 30, 2021 Name: Peter Wang Title: General Manager Company: PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY

PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Mar. 30, 2021 Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject: Explanation of differences between product types FCC ID: 2AJGM-P15UV Models: P15UV, UV-15R, GMR-15S, GM-898, GM-15X, TH-15S, AI-15X, AT-15UV, G-15UV To Whom It May Concern: We, The PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY hereby declare that the model : P15UV, UV-15R, GMR-15S, GM-898, GM-15X, TH-15S, AI-15X, AT-15UV, G-15UV have the same PCB & electrical specifications, different models & appearance line design & shell color. Except for the different above, no other modification is performed. Sincerely, PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY Signature: [Peter Wang, General Manager]

P0 FUNG ELECTRONTC(HK) TNTERNATTOANL GROUP COMPANY 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Mar. 30,2021 Subject; Request for Confidentiality FCC lD:2AJGM-P1sUV To lfll/hom Jf IMay Conc.ern, Pursuant to the provisions of the Commission's nules Title 47 Sections50.457 and $0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents mffi be 'ffiul to our company and'would give cornpetitors an unfiair adv'antage in the rnarket. X Schematic Diagram X Btock Diagram X Parts tist X Operational Description XTune-up Procedure It is our understanding that all measurement test reports, FCC lD labelformat and conespondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: .,l$f)-, ^,^^J[. Name: Peter Wang Title: General Manager

External Photos ALL VIEW OF SERIAES MODEL ALL VIEW OF SERIES MODEL-BACK VIEW ALL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT

POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:P15UV Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNG ELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:GMR 15S Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNG ELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:UV 15R Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:GM-898 Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:GM-15X Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:TH 15S Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:AI-15X Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:AT 15UV Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:G 15UV Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! UV 13 - UV 13A - UV 13B - BAOFENG LABEL 20mm*15mm POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China GMRS TWO WAY RADIO Model:P15UV Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNG ELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:GMR 15S Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNG ELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:UV-15R Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:GM-898 Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:GM-15X Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNG ELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:TH 15S Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:AI-15X Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNGELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:AT 15UV Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! POFUNG ELECTRONIC (HK) INTERNATIOANL GROUPCOMPANY Made in China Model:G 15UV Frequency:GMRS Voltage:DC7.4V FCC ID:2AJGM-P15UV - to satisfy FCC RF exposure compliance. Beforeusingthisdevice,readtheRFExposure andSafetyGuidethatshipswiththeradio. Device must be restricted to occupational use ATTENTION! UV 13 - UV 13A - UV 13B - GMRS TWO WAY RADIO GMRS TWO WAY RADIO GMRS TWO WAY RADIO GMRS TWO WAY RADIO GMRS TWO WAY RADIO GMRS TWO WAY RADIO GMRS TWO WAY RADIO GMRS TWO WAY RADIO POFUNG LABEL 20mm*15mm

Internal Photos OPEN VIEW OF EUT-1 OPEN VIEW OF EUT-2 OPEN VIEW OF EUT-3 INTERNAL VIEW-1 OF EUT Antenna INTERNAL VIEW OF EUT-2 INTERNAL VIEW OF EUT-3 INTERNAL VIEW OF EUT-4 INTERNAL VIEW OF EUT-5 INTERNAL VIEW OF EUT-6

Page 1 of 27 FCC Test Report Report No.: AGC02294201008FE08 FCC ID : 2AJGM-P15UV PRODUCT DESIGNATION : Two-way radio BRAND NAME : POFUNG,BAOFENG MODEL NAME : P15UV, UV-15R, GMR-15S, GM-898, GM-15X, TH-15S, AI-15X, AT-15UV, G-15UV APPLICANT : PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY DATE OF ISSUE : Dec. 04, 2020 STANDARD(S) : FCC Part 15 Rules REPORT VERSION : V 1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd Report No.: AGC02294201008FE08 Page 2 of 27 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Dec. 04, 2020 Valid Initial release Report No.: AGC02294201008FE08 Page 3 of 27 TABLE OF CONTENTS 1. VERIFICATION OF COMPLIANCE ................................................................................................................. 4 2. PRODUCT INFORMATION .............................................................................................................................. 5 3. IDENTIFICATION OF THE RESPONSIBLE TESTING LOCATION ............................................................... 6 4. SUPPORT EQUIPMENT LIST ......................................................................................................................... 7 5. SYSTEM DESCRIPTION .................................................................................................................................. 7 6. MEASUREMENT UNCERTAINTY ................................................................................................................... 8 7. SUMMARY OF TEST RESULTS ..................................................................................................................... 8 8. FCC RADIATED EMISSION TEST .................................................................................................................. 9 8.1 PROVISIONS APPLICABLE ................................................................................................................... 9 8.2 TEST SETUP BLOCK DIAGRAM ........................................................................................................... 9 8.3 TEST PROCEDURE .............................................................................................................................. 11 8.4 TEST RESULT ....................................................................................................................................... 12 9. FCC CONDUCTED EMISSION TEST ............................................................................................................ 16 9.1 PROVISIONS APPLICABLE ................................................................................................................. 16 9.2 TEST SETUP BLOCK DIAGRAM ......................................................................................................... 16 9.3 TEST PROCEDURE .............................................................................................................................. 17 9.4 TEST RESULT ....................................................................................................................................... 18 10. ANTENNA CONDUCTED POWER FOR RECEIVERS ............................................................................... 20 10.1 PROVISIONS APPLICABLE ............................................................................................................... 20 10.2 TEST SETUP BLOCK DIAGRAM ....................................................................................................... 20 10.3 TEST PROCEDURE ............................................................................................................................ 20 10.4 TEST RESULT ..................................................................................................................................... 21 11. SANNING RECEIVERS AND FREQUENCY CONVERTERS USED WITH SANNING RECEIVERS ....... 23 11.1 PROVISIONS APPLICABLE ............................................................................................................... 23 11.2 TEST SETUP BLOCK DIAGRAM ....................................................................................................... 23 11.3 TEST PROCEDURE ............................................................................................................................ 23 11.4 TEST RESULT ..................................................................................................................................... 24 APPENDIX I PHOTOGRAPHS OF TEST SETUP ............................................................................................. 25 APPENDIX II: PHOTOGRAPHS OF EUT .......................................................................................................... 27 Report No.: AGC02294201008FE08 Page 4 of 27 1. VERIFICATION OF COMPLIANCE Applicant: PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY Address 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Manufacturer: PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY Address 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Factory PO FUNG ELECTRONIC(HK) INTERNATIOANL GROUP COMPANY Address 3/F FULOK BLDG 131-133 WING LOK ST SHEUNG WAN, Hong Kong Product Designation: Two-way radio Brand Name: POFUNG, BAOFENG Test Model P15UV Serial Model UV-15R, GMR-15S, GM-898, GM-15X, TH-15S, AI-15X, AT-15UV, G-15UV Difference Description The same PCB & electrical specifications, different models & appearance line design & shell color Measurement Procedure ANSI C63.4: 2014 Deviation No any deviation from the test method. Date of Test: Oct. 29, 2020~Dec. 07, 2020 Condition of Test Sample Normal Test Result Pass Report Template AGCRT-US-PTT/EMC The above equipment was tested by Attestation Of Global Compliance (Shenzhen) Co., Ltd. for compliance with the requirements set forth in the FCC Rules and Regulations Part 15, the measurement procedure according to ANSI C63.4:2014. This said equipment in the configur…
