READ CAREFULLY BEFORE OPERATION OF THE DEVICE LEGAL DISCLAIMERS ► Comply with applicable laws and regulations governing use of metal detectors while using this detector. Do not use the detector without authorization in protected or archeological sites. Do not use this detector around unexploded ordnance or in restricted military zones without authorization. Notify appropriate authorities with details of any historical or culturally significant artifacts you find. WARNINGS ► SIMPLEX+ is a state-of-the-art electronic device. Do not assemble or operate the device before reading the user manual. ► Do not store the device and search coil under extremely low or high temperatures for extended periods. (Storage Temperature: - 20°C to 60°C / - 4°F to 140°F) ► The device has been designed with IP68 rating as a waterproof unit up to 3 meters / 10ft. (except for the wireless headphones included in the WHP pack!) ► Pay attention to the items below after using the device especially under salty water: 1. Wash the system box, shaft and the coil with tap water and be sure no salt water is left in the connectors. 2. Do not use any chemicals for cleaning and/or for any other purposes. 3. Wipe the screen and the shaft dry with a soft, non-scratch cloth. ► Protect the detector against impacts during normal use. For shipping, carefully place detector in original carton and secure with shock resistant packaging. ► SIMPLEX+ metal detector may only be disassembled and repaired by Nokta Makro Authorized Service Centers. Unauthorized disassembly/intrusion into the metal detector control housing for any reason voids the warranty. IMPORTANT ► Do not use the device indoors. The device may constantly give target signals indoors where there are many metals present. Use the device outdoors, in open fields. ► Do not let another detector or an electromagnetic device come in close proximity (10m (30ft.)) to the device. ► Do not carry any metal objects while using the device. Keep the device away from your shoes while walking. The device may detect the metals on you or inside your shoes as targets. For Consumers within the European Union: Do not dispose of this equipment in general household waste. The crossed wheeled bin symbol on this equipment indicates this unit should not be disposed of in general household waste, but recycled in compliance with local government regulations and environmental requirements. WARNINGS FCC STATEMENT This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. READ CAREFULLY BEFORE OPERATION OF THE DEVICE LEGAL DISCLAIMERS ► Comply with applicable laws and regulations governing use of metal detectors while using this detector. Do not use the detector without authorization in protected or archeological sites. Do not use this detector around unexploded ordnance or in restricted military zones without authorization. Notify appropriate authorities with details of any historical or culturally significant artifacts you find. WARNINGS ► SIMPLEX+ is a state-of-the-art electronic device. Do not assemble or operate the device before reading the user manual. ► Do not store the device and search coil under extremely low or high temperatures for extended periods. (Storage Temperature: - 20°C to 60°C / - 4°F to 140°F) ► The device has been designed with IP68 rating as a waterproof unit up to 3 meters / 10ft. (except for the wireless headphones included in the WHP pack!) ► Pay attention to the items below after using the device especially under salty water: 1. Wash the system box, shaft and the coil with tap water and be sure no salt water is left in the connectors. 2. Do not use any chemicals for cleaning and/or for any other purposes. 3. Wipe the screen and the shaft dry with a soft, non-scratch cloth. ► Protect the detector against impacts during normal use. For shipping, carefully place detector in original carton and secure with shock resistant packaging. ► SIMPLEX+ metal detector may only be disassembled and repaired by Nokta Makro Authorized Service Centers. Unauthorized disassembly/intrusion into the metal detector control housing for any reason voids the warranty. IMPORTANT ► Do not use the device indoors. The device may constantly give target signals indoors where there are many metals present. Use the device outdoors, in open fields. ► Do not let another detector or an electromagnetic device come in close proximity (10m (30ft.)) to the device. ► Do not carry any metal objects while using the device. Keep the device away from your shoes while walking. The device may detect the metals on you or inside your shoes as targets. ASSEMBLY INTRODUCTION TO THE DEVICE DISPLAY BATTERY INFORMATION WIRELESS HEADPHONE INFORMATION CORRECT USE QUICK GUIDE TARGET ID SEARCH MODES SENSITIVITY TARGET DEPTH SETTINGS PINPOINT LARGE OR SHALLOW TARGETS FALSE SIGNALS AND REASONS ROCKS AND SEARCHING IN ROCKY TERRAINS METALS UNDER ROCKS DETECTION ON THE BEACH AND UNDERWATER CHECK COIL ICON SOFTWARE UPDATE TECHNICAL SPECIFICATIONS ........................................................................................................................................................................................................................................................................ ................................................................................................................................................................. .................................................................................................................................................................................................................................................................................... .............................................................................................…
Text truncated - open the document above for the full version.
Date: 2020-01-10 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AJJ2-SIMPLEX Product Name: METAL DETECTOR Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: Schematics Long-term confidential Block diagram Long-term confidential Operation description Long-term confidential These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Signature: Name DILEK GONULAY Position SALES & MARKETING DIRECTOR Company Name NOKTA MUHENDISLIK A.S. Address EMEK MAH. SAKIZ SOK. NO: 4/1, 34785 SANCAKTEPE, ISTANBUL, TURKEY Tel 902164155686 Fax 902164156343 Email [email protected] NOKTA MUHENDISLIK A.S.
FCC ID: 2AJJ2-SIMPLEX
30mm 20mm FCC ID: 2AJJ2-SIMPLEX NOKTA MUHENDISLIK A.S. Model name: METAL DETECTOR Model No.: SIMPLEX This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) thi s device may not cause harmful interference, and (2) this device must accept any interference received, including int erference that may cause undesired operation. Label Location
FCC ID: 2AJJ2-SIMPLEX Antenna
FCC ID: 2AJJ2-SIMPLEX RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06: The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation. The result is rounded to one decimal place for comparison. eirp = p t x g t = (E x d) 2 /30 where: p t = transmitter output power in watts, g t = numeric gain of the transmitting antenna (unitless), E = electric field strength in V/m, --- 10 ((dBuV/m)/20) /10 6 , d = measurement distance in meters (m)--- 3m. So p t = (E x d) 2 /(30 x g t ) Worse case is as below: Field strength = 70.55 dBuV/m @3m(AV) Ant gain 0 dBi; so Ant numeric gain=1 So p t ={[10 (70.55/20) /10 6 x3] 2 /(30x1)}x1000mW =0.0034mW So (0.0034mW/5mm)x √2.480GHz = 0.001<3.0 for 1-g SAR Then SAR evaluation is not required.
FCC TEST REPORT FCC ID: 2AJJ2-SIMPLEX On Behalf of NOKTA MUHENDISLIK A.S. METAL DETECTOR Model No.: SIMPLEX, SIMPLEX+, SIMPLEX+WHP, SIMPLEX+PRO, SIMPLEX+PRO WHP Prepared for : NOKTA MUHENDISLIK A.S. Address : EMEK MAH. SAKIZ SOK. NO: 4/1, 34785 SANCAKTEPE, ISTANBUL, TURKEY Prepared By : Shenzhen Alpha Product Testing Co., Ltd. Address : Building i, No.2, Lixin Road, Fuyong Street, Bao'an District, 518103, Shenzhen, Guangdong, China Report Number : A1907364-C01-R05 Date of Receipt : November 20, 2019 Date of Test : November 20, 2019-December 18, 2019 Date of Report : December 18, 2019 Version Number : V0 Page 2 of 46 Report No.: A1907364-C01-R05 TABLE OF CONTENTS Description Page 1. Summary of Standards And Results ................................................................................. 6 1.1. Description of Standards and Results ......................................................................... 6 2. General Information ........................................................................................................... 7 2.1. Description of Device (EUT) ...................................................................................... 7 2.2. Accessories of Device (EUT) ..................................................................................... 8 2.3. Tested Supporting System Details .............................................................................. 8 2.4. Block Diagram of connection between EUT and simulators ...................................... 8 2.5. Test Mode Description ................................................................................................ 8 2.6. Test Conditions ........................................................................................................... 9 2.7. Test Facility ................................................................................................................ 9 2.8. Measurement Uncertainty ........................................................................................... 9 2.9. Test Equipment List .................................................................................................. 10 3. Power Line Conducted Emission Test ............................................................................. 11 3.1. Block Diagram of Test Setup .................................................................................... 11 3.2. Test Limits ................................................................................................................ 11 3.3. Configuration of EUT on Test .................................................................................. 11 3.4. Operating Condition of EUT .................................................................................... 11 3.5. Test Procedure .......................................................................................................... 12 3.6. Test Results ............................................................................................................... 12 4. Radiated Emission Test ..................................................................................................... 14 4.1. Block Diagram of Test Setup .................................................................................... 14 4.2. Test Limit .................................................................................................................. 15 4.3. Configuration of EUT on Test .................................................................................. 16 4.4. Operating Condition of EUT .................................................................................... 16 4.5. Test Procedure .......................................................................................................... 16 4.6. Test Results ............................................................................................................... 17 5. Band Edge Test .................................................................................................................. 22 5.1. Block Diagram of Test Setup .................................................................................... 22 5.2. Test Limit .................................................................................................................. 22 5.3. Configuration of EUT on Test .................................................................................. 23 5.4. Operating Condition of EUT .................................................................................... 23 5.5. Test Procedure .......................................................................................................... 23 5.6. Test Results ............................................................................................................... 25 6. Occupied bandwidth Test ................................................................................................. 27 6.1. Block Diagram of Test Setup .................................................................................... 27 6.2. Test Limit .................................................................................................................. 27 6.3. Test Procedure .......................................................................................................... 27 6.4. Test Results ............................................................................................................... 27 7. Antenna Requirement ....................................................................................................... 31 7.1. Standard Requirement ............................................................................................... 31 Page 3 of 46 Report No.: A1907364-C01-R05 7.2. Antenna Connected Construction ............................................................................. 31 7.3. Results .........................................................................................................…
