Titan Smart watch Quick Start Guide What’s in the Box Quick Start Guide Watch–Quick start guideWatchCharging cableCharger Getting started •Getting started with your Titan Smartwatch is super simple. When the watch is shipped from the factory, it’s charged and in shipment mode. •To wake-up your Watch, all you need to do is to charge it . Watch comes to normal mode & you’re good to go! Turn on the Band: App installation Install the Titan Connected App •Please download the “Titan Connected “ app from Google play store or Apple App store Pairing the band •Open the app and follow the on-screen instructions. •App will search for the near by Watch & display. •Select Titan_Watch_34w3 and click start pairing. •Watch will show a pairing pin, enter the same on App & you will find pairing successful. Pair your smart band Select to Pair Titan_Watch_34w3 Note : It is recommended to keep the band close to phone. Features •Activity Tracker ( Steps , Distance & Calories ) •Auto Time Sync •Second City Time zone •Compass •Timer , Stop Watch & Alarm •Find your phone •Music control •Camera control •Weather •All Notifications Product Specifications Band Dimension Case material Glass material Strap 43 X 14.5 mm Stainlesssteel / Titanium MineralGlass Leather Sensors Connectivity Sensors Feedback BLE4.2 Accelerometer & Gyro Vibrator Battery Batterytype Battery capacity Battery life Li Polymer –Rechargeable 40mAh Minimum3 Days Water Resistance Rating3ATM Hazardous / Toxic substances / Elements FCC statement FCC ID: 2AK9F-90120 Note:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device maynot cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment can be installed and operated with a minimum distance 0 millimeters between the radiator and user’s body. This equipment has been evaluated to meet general RF exposure requirement at 0 millimeters distance. CE Statement Max RF Power level: BLE (2402~2480MHz)<5dBm RF exposure information: The Maximum Permissible Exposure (MPE) level has been calculated based on a distance of 0mm between the device and the human body. To maintain compliance with RF exposure requirement , use product that maintain a 0mmdistance between the device and the human body . Hereby , Titan Company Limited declared that the radio equipment type ( SmartWatch–xxxxxx) is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address : http://www.titanworld.com/in-en/ Titan Company Limited Integrity , #193, Veerasandra,Electronic City P.O.,OffHosur Main Road,Bangalore-560100, Karnataka, India Telephone : +91-(0)80-6704 7000 Fax : +91-(0)80-6704 6262 Email :[email protected] Note on the accuracy of Activity tracker

Appendix Model: 90120

Scale 1:1 Scale 1:1 TL01 Scale 1:1 KL01 Scale 1:1 WL01 90120QL0190120TL0190120KL0190120WL01 TI44400TI44401TI44402TI44403 A L L T I T A N I U M

Appendix Model: 90120

Report Number: 60.790.20.077.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page1of44 FCC - TEST REPORT Report Number:60.790.20.077.01R01Date of Issue:November 16, 2020 Model:90120 Product Type:Smart Watch Applicant: TITAN COMPANY LIMITED Address: INTEGRITY #193, Veerasandra, Electronic City P.O., Off Hosur Main Road, Bangalore - 560100, Karnataka, India. Production Facility:Kendy Electronics (Dongguan) Co., Ltd Address: Xingsi Huangtang Village, Hengli Town, Dongguan City, Guangdong Province, P. R. China Test Result:nPositiveoNegative Total pages including Appendices : 44 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch is a subcontractor to TÜV SÜD Product Service GmbH according to the principles outlined in ISO 17025. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch reports apply only to the specific samples tested under stated test conditions. Construction of the actual test samples has been documented. It is the manufacturer's responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical components. The manufacturer/importer is responsible to the Competent Authorities in Europe for any modifications made to the production units which result in non-compliance to the relevant regulations. TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch shall have no liability for any deductions, inferences or generalizations drawn by the client or others from TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch issued reports. This report is the confidential property of the client. As a mutual protection to our clients, the public and ourselves, extracts from the test report shall not be reproduced except in full without our written approval Report Number: 60.790.20.077.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page2of44 1 Table of Contents 1 Table of Contents ............................................................................................................ 2 2 Description of Equipment Under Test ............................................................................. 3 3 Summary of Test Standards ........................................................................................... 4 4 Details about the Test Laboratory ................................................................................... 5 4.1 Test Equipment Site List ................................................................................................... 6 4.2 Measurement System Uncertainty .................................................................................... 7 5 Summary of Test Results ................................................................................................ 8 6 General Remarks ............................................................................................................ 9 7 Test Setups ................................................................................................................... 10 7.1 Radiated test setups Below 1GHz................................................................................... 10 7.2 Radiated test setups Above 1GHz .................................................................................. 10 7.3 AC Power Line Conducted Emission test setups ............................................................ 11 7.4 Conducted RF test setups............................................................................................... 11 8 Emission Test Results .................................................................................................. 12 8.1 Spurious Radiated Emission ........................................................................................... 12 8.2 Conducted Emission at AC Power line ............................................................................ 16 8.3 6dB & 99% Bandwidth .................................................................................................... 18 8.4 Peak Output Power ......................................................................................................... 21 8.5 Spurious Emissions at Antenna Terminals ...................................................................... 24 8.6 100kHz Bandwidth of band edges................................................................................... 30 8.7 Power Spectral Density ................................................................................................... 32 8.8 Antenna Requirement ..................................................................................................... 35 9 Test setup procedure .................................................................................................... 36 10 Appendix A - General Product Information ................................................................. 44 Report Number: 60.790.20.077.01R01 TÜV SÜD Certification and Testing (China) Co., Ltd. Shenzhen Branch Building 12&13, Zhiheng W isdomland Business Park, Nantou Checkpoint Road 2, Nanshan District, 518052 Shenzhen, CHINA Page3of44 2 Description of Equipment Under Test Description of the Equipment Under Test Product: Smart Watch Model no.: 90120 FCC ID: 2AK9F-90120 Rating: 3.7V DC (form internal rechargable battery) 5V DC (fromsupporting AC/DC adapter) Frequency: 2402MHz-2480MHz (Tx and Rx) Antenna gain: 0 dBi Number of operated channel: 40 Modulation: GFSK Auxiliary Equipment and Software Used during Test: DESCRIPTION MANUFACTURERMODEL NO.S/N AC/DC adapterAppleA1357NA Auxiliary Software Used during Test: DESCRIPTION SOFTWARE NAMEVERSIONREMARK Special RF test mode firmware NANAPre-installed by manufacture Repor…
