2ALJJJ600MiFi

J600 User Manual Interface key Illustrate Power key Long press over 5 seconds to power on and long press to power off WPS Press to active the WPS Reset The Reset button is on the opposite side of the machine. If you forget Administrator password or Wireless network key, you can press the Reset key to restore factory default settings. LED light color Indication Indicator Color Working Status Power LED Green Solid:booting up the device Amber Blink:Charging Blink: Turn on-0.5s Turn off-0.5s Blue Solid:Battery High(100%-60%) or Charge Completed Amber Solid:Battery Middle(60%-15%) Red Solid: Battery too low nearly shutdown(〈15%) SMS LED Blue Blink:NewSMS Signal LED Blue Solid: Regiester to LTE(not connect) Blink: Connected toLTE network Green Solid: Regiester to 3G(not connect) Blink: Connected to3G network Purple Solid: Regiester to2G(not connect) Blink: Connected to2G network Red Blink:No Service/Device Error WiFi LED Blue Solid:No Client Slow Blink: Client is actived Fast Blink: WPS is actived Blink: Turn on-0.2s Turn off-0.1s Installation Follow the diagram to install the SIM card and SD card Tips: Always switch the device off and disconnect the charger before removing the battery. 1. Remove the back cover and battery; 2. Insert the SIM card and SD card. Ensure that the contact area on the card is facing down and that the beveled corner on the card is facing the beveled corner on the holder. 3. Align the battery contacts with the battery compartment connectors, and insert the battery. Replace the back cover lastly. Charge Your battery has been partially charged at the factory. If the device indicates a low charge, do the following: 1. Connect the charger to an outlet. 2. Connect the USB charger plug to your device’s USB port. 3. When the device indicates a full charge, disconnect the charger from the device, then from the outlet. One：Using charge adapter Two：Using USB port J600 Usage J600 support 4G/3G/2G networks. Insert the SIM card, Wi-Fi devices and the computer can access the Internet through J600, enjoy high-speed network services.Smart phones, tablet computers, game consoles and other Wi-Fi devices can be connected with the J600 Wi-Fi connection for Internet access. Computers & laptops etc. may be connected to the J600 via USB cable for Internet Access. J600 connects computer for the first time via a USB connection, you need to follow the prompts to install the driver Wi-Fi wireless Internet access In order for a WiFi device to establish a connection with the J600 for the first time, you will need to select the J600 SSID (WiFi name) & enter the relevant WiFi password, which you may find in the following ways: Method one: on the nameplate view the default SSID and Wi-Fi passwords Method Two: Login management page view 1. Computer, open your browser, input http://192.168.0.1 and enter. ●The default Account is admin ●The default Password is C1@r0 Enter the Account and Password, login the administration pages 2. Enter the Wi-Fi menu, view the default SSID and Wi-Fi password ●The default SSID is Claro-last 6 MAC address (ex:Claro-127FEB) ●The default Wi-Fi Password is clar0123 ★Recommend that you start using J600 administration pages after setting a convenient landing memorizing SSID and a higher safety factor Wi-Fi passwords. Install the driver and connecting the device USB Connection:Windows 7 for example 1. Keep J600 powering on,Plug the device into your computer,it will shows like the following pictures step by step. 2. Double-click the , wait for the installation to complete. 3. Check the network card is installed correctly,like the following pictures. Establish Wi-Fi connection:you must ensure that the computer equipped with a wireless network card. If the computer showed the presence of Wi-Fi connectivity, the wireless LAN is available. Otherwise, you need to check your wireless network card is working properly. 1. In the Wi-Fi list, select the SSID consistent with J600 Wi-Fi, click Connect 2. Enter the correct Wi-Fi password, click OK 3. Wait a moment, Wi-Fi connection is displayed next to the name, Wi-Fi connection is successful 4. Check the network card is installed correctly,like the following pictures WebUI ●Home First part of the main display settings and network status information, such as IPaddress, SIM card status, type and quality of the network signal, whether it is roaming, with or without a new message, and traffic statistics,and system uptime,and so on. ●Wizard You can quickly change the lan configuration, set the apn , and change the SSID \ password through the wizard function. ●WAN 1. Connection Dialing Mode: Select the Auto Mode, after you turn on J600 without additional operations, the device will automatically connect to the network; select the Manual Mode, you need to manually connect to the network after opening the J600 management page. 2. APN Setting You can customize the network configuration or manually add the new APN and set default APN. 3. 4G/3G/2GModem There are four types of networks can be choose: Auto is 4G/3G/2G, LTE Only is using only 4G, WCDMA Only is using only 3G,GSM Only is using only 2G. 4. PIN Open your PIN, if you reboot the device, you need to login management page,and the page will prompted to enter the correct PIN code, you can use the SIM card. PIN / PUK code supplied with the SIM card provided by your carrier, please consult your carrier. 5. PLMN Into automatic and manual setting options Automatic selection: Select this mode the device automatically selects the best network registration status Manual setting: Select this mode before, if your device is in the state of dial-up Internet, disconnect the network, and then click the query, wait a moment, the device will search for all nearby networks, select a network, click to update, the device registers to the network that you selected. ●LAN 1. LAN We can change IP address in this page. 2. DHCP DHCP Mode: Select the server mode, the device can be done using a DHCP server; choose None, wh…
