2AM8O-U212-2Arm Blood Pressure Monitor

Page 1 of 16 Arm Blood Pressure Monitor Instruction Manual Model: AES-U212 Version:1.1 Date modified: 2023-05-10 Please read this instruction manual carefully before use Page 2 of 16 Table of Contents 1. Introduction ..................................................................................................................................... 3 2. Indications for Use ........................................................................................................................... 3 3. Product information ........................................................................................................................ 3 4. Classification .................................................................................................................................... 3 5. Safety Information ........................................................................................................................... 4 5.1 General usage ............................................................................................................................ 4 5.2 General precautions .................................................................................................................. 5 6. Explanation of Marks or Symbols .................................................................................................... 5 7. Unit Description .............................................................................................................................. 6 8. Display ............................................................................................................................................. 6 9. Charging the Battery ........................................................................................................................ 6 10. Setting the Measurement Unit ........................................................................................................ 7 11. Precautions for Measurement ......................................................................................................... 8 12. Applying the Arm Cuff ..................................................................................................................... 8 13. Correct Measurement Posture ........................................................................................................ 9 14. Taking A Measurement .................................................................................................................... 9 15. Care and Maintenance .................................................................................................................. 10 15.1 Cleaning the monitor and cuff ............................................................................................... 10 15.2 Maintaining the monitor and cuff ......................................................................................... 10 16. Guarantee ...................................................................................................................................... 11 17. Error Messages .............................................................................................................................. 11 18. Technical Specifications ................................................................................................................. 11 19. Blood Pressure Classification for Adult .......................................................................................... 12 20. Disposal ......................................................................................................................................... 12 21. Electromagnetic Compatibility ...................................................................................................... 12 22. FCC Warning .................................................................................................................................. 16 Page 3 of 16 1. Introduction Thank you for purchasing the Arm Blood Pressure Monitor. The blood pressure monitor uses the oscillometric method of blood pressure measurement. This means the monitor detects your blood’s movement through your brachial artery and converts the movements into a digital reading. An oscillometric monitor does not need a stethoscope so the monitor is simple to use. The Blood Pressure Monitor comes with the following components:  Monitor  Arm Cuff  Instruction Manual Please read this instruction manual thoroughly before using the unit. Please keep for future reference. For specific information about your own blood pressure, please consult your doctor. 2. Indications for Use The Arm Blood Pressure Monitor is intended to measure the systolic and diastolic blood pressure as well as the pulse rate of person via non-invasive oscillometric technique in which an inflatable cuff is wrapped around the upper arm. It can be used at medical facilities or at home. The intended upper arm circumference is 22-42cm. Suitable for adults and adolescents who over the age of 12. 3. Product information Product name: Arm Blood Pressure Monitor , Product model: AES-U212 , Software version: A.01.00.00 Standard: The product is made under the IEC 80601-2-30. Manufacturer Company name: Alicn Medical Shenzhen, Inc Address: Room 410, Building A, 3rd Sub-park, Leibo Zhongcheng Life Science Park, No. 22 Jinxiu East Road, Pingshan District, 518118 Shenzhen, Guangdong, PEOPLE'S REPUBLIC OF CHINA Web: www.alicn-med.com Tel: +86 755 26501548 Fax: +86 755 26504849 4. Classification (1) Internally powered equipment; (2) Type BF applied part; (3) IP classification: IP21; (4) Disinfection of 75% medical alcohol; (5) Not Category AP / APG equipment; (6) Mode of operation: continuous operation. Page 4 of 16 5. Safety Information 5.1 General usage  Do not adjust medication based on measurement values from this blood pressure monitor. Take medication as prescribed by your physician. Only a physician is qualifie…

Text truncated - open the document above for the full version.

Alien Medical Shenzhen, Inc U.S. Agent Designation for Service of Process - Certification Attestation Letter July 4, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1 H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AM80-U212-2 FRN: 0026737429 Per section 2.911 (d)(7) of the FCC rules, (" Alien Medical Shenzhen, Inc ") certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Physical U.S. Company Address: Agent name: Agent Email Address: FRN: Global Product Services & Consultation LLC 328 W Palm Ave, Monrovia. CA91016 ChiS.Chan [email protected] 0033406703 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Signed t.a,Mc�. � Printed name: Renxiong.Huang Title: L&R manager Company Alien Medical Shenzhen, Name: Inc Date: July 4, 2023 Designated Agent Signed: (Required, if different to Applicant): Signed & / M Printed name: ChiS.Chan Title: Company Global Product Services Name: Consultation LLC Date: 2023-07-04 & * the applicant must designate a contact located in the United States for purposes of acting as the applicant's agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. Te chnical Director SC 3077466

External photos

FCC ID: 2AM8O-U212-2

AES-U212

Internal photos

Page:1of45 FCCREPORT ForLTECatM ReportNo. ........................................... :CHTEW23060048ReportVerification: ProjectNo.................................：SHT2304055301EW FCCID...................................................:2AM8O-U212-2 Applicant .............................................. :AlicnMedicalShenzhen,Inc Address ................................................. :Room410,BuildingA,3rdSub-park,LeiboZhongchengLife SciencePark,No.22JinxiuEastRoad,PingshanDistrict,518118 Shenzhen,Guangdong,PEOPLE'SREPUBLICOFCHINA ProductName ..................................... :ArmBloodPressureMonitor TradeMark ............................................ :- ModelNo...............................................:AES-U212 ListedModel(s) ..................................... :- Standard .............................................. : FCCCFRTitle47Part2 FCCCFRTitle47Part22SubpartH FCCCFRTitle47Part24SubpartE FCCCFRTitle47Part27 Dateofreceiptoftestsample..........:May.04,2023 Dateoftesting..............................:May.04,2023-Jun.27,2023 Dateofissue...............................:Jun.28,2023 Result .................... ........................:Pass Compiledby (position+printedname+signature)...:FileadministratorsFanghuiZhu Supervisedby (position+printedname+signature) .... :ProjectEngineerXiaodongZhao Approvedby (position+printedname+signature) .... :ManagerHansHu TestingLaboratoryName................:ShenzhenHuatongweiInternationalInspectionCo.,Ltd. Address ................................................. :1/F,Bldg3,HongfaHi-techIndustrialPark,GenyuRoad,Tianliao, Gongming,Shenzhen,China ShenzhenHuatongweiInternationalInspectionCo.,Ltd.Allrightsreserved. Thispublicationmaybereproducedinwholeorinpartfornon-commercialpurposesaslongasthe ShenzhenHuatongweiInternationalInspectionCo.,Ltd.isacknowledgedascopyrightownerandsourceof thematerial.ShenzhenHuatongweiInternationalInspectionCo.,Ltd.takesnoresponsibilityforandwillnot assumeliabilityfordamagesresultingfromthereader'sinterpretationofthereproducedmaterialduetoits placementandcontext. Thetestreportmerelycorrespondtothetestsample. ReportNo.:CHTEW23060048Page:2of44Dateofissue:2023-06-28 ShenzhenHuatongweiInternationalInspectionCo.,Ltd.ReportTemplateVersion:V04(2022-01) Contents 1.TESTSTANDARDSANDREPORTVERSION3 1.1.ApplicableStandards3 1.2.Reportversioninformation3 2.TESTDESCRIPTION4 3.SUMMARY5 3.1.ClientInformation5 3.2.ProductDescription5 3.3.RadioSpecificationDescription5 3.4.TestingLaboratoryInformation6 4.TESTCONFIGURATION7 4.1.Testfrequencylist7 4.2.Testmode8 4.3.Testsampleinformation9 4.4.Supportunitusedintestconfigurationandsystem9 4.5.Testingenvironmentalcondition9 4.6.Statementofthemeasurementuncertainty10 4.7.EquipmentsUsedduringtheTest11 5.TESTCONDITIONSANDRESULTS12 5.1.ConductedOutputPower12 5.2.Peak-to-AverageRatio13 5.3.99%OccupiedBandwidth&26dBBandwidth14 5.4.BandEdge15 5.5.ConductedSpuriousEmissions16 5.6.FrequencystabilityVSTemperaturemeasurement17 5.7.FrequencystabilityVSVoltagemeasurement18 5.8.ERPandEIRP19 5.9.RadiatedSpuriousEmission20 6.TESTSETUPPHOTOSOFTHEEUT38 7.EXTERNALANDINTERNALPHOTOSOFTHEEUT39 7.1Externalphotos39 7.2Internalphotos41 8.APPENDIXREPORT44 ReportNo.:CHTEW23060048Page:3of44Dateofissue:2023-06-28 ShenzhenHuatongweiInternationalInspectionCo.,Ltd.ReportTemplateVersion:V04(2022-01) 1.TESTSTANDARDSANDREPORTVERSION 1.1.ApplicableStandards Thetestswereperformedaccordingtofollowingstandards: FCCCFRTitle47Part2:FrequencyAllocationsandRadioTreatyMatters;GeneralRulesandRegulations FCCCFRTitle47Part22SubpartH:CellularRadiotelephoneService FCCCFRTitle47Part24SubpartE:BroadbandPCS FCCCFRTitle47Part27:MiscellaneousWirelessCommunicationsServices ANSIC63.26-2015:AmericanNationalStandardforComplianceTestingofTransmittersUsedinLicensed RadioServices KDB971168D01PowerMeasLicenseDigitalSystemsv03:MEASUREMENTGUIDANCEFOR CERTIFICATIONOFLICENSEDDIGITALTRANSMITTERS 1.2.Reportversioninformation RevisionNo.DateofissueDescription N/A 2023-06-28 Original ReportNo.:CHTEW23060048Page:4of44Dateofissue:2023-06-28 ShenzhenHuatongweiInternationalInspectionCo.,Ltd.ReportTemplateVersion:V04(2022-01) 2.TESTDESCRIPTION SectionTestItemSectioninCFR47Result #1 TestEngineer 5.1 ConductedOutputPower Part2.1046 Part22.913(a) Part24.232(c) Part27.50 Pass XiaodongZhao 5.2Peak-to-AverageRatio Part24.232 Part27.50 Pass XiaodongZhao 5.3 99%OccupiedBandwidth& 26dBBandwidth Part2.1049 Part22.917(b) Part24.238(b) Part27.53 Pass XiaodongZhao 5.4BandEdge Part2.1051 Part22.917 Part24.238 Part27.53 Pass XiaodongZhao 5.5 ConductedSpurious Emissions Part2.1051 Part22.917 Part24.238 Part27.53 Pass XiaodongZhao 5.6 Frequencystabilityvs temperature Part2.1055(a)(1)(b) Part22.355 Part24.235 Part27.54 Pass XiaodongZhao 5.7Frequencystabilityvsvoltage Part2.1055(d)(1)(2) Part22.355 Part24.235 Part27.54 Pass XiaodongZhao 5.8ERPandEIRP Part22.913(a) Part24.232(b) Part27.50 Pass XiaodongZhao 5.9RadiatedSpuriousEmissions Part2.1053 Part22.917 Part24.238 Part27.53 Pass YifanWang Note: #1:Thetestresultdoesnotincludemeasurementuncertaintyvalue ReportNo.:CHTEW23060048Page:5of44Dateofissue:2023-06-28 ShenzhenHuatongweiInternationalInspectionCo.,Ltd.ReportTemplateVersion:V04(2022-01) 3.SUMMARY 3.1.ClientInformation Applicant:AlicnMedicalShenzhen,Inc Address: Room410,BuildingA,3rdSub-park,LeiboZhongchengLifeScience Park,No.22JinxiuEastRoad,PingshanDistrict,518118Shenzhen, Guangdong,PEOPLE'SREPUBLICOFCHINA Manufacturer:AlicnMedicalShenzhen,Inc Address: Room410,BuildingA,3rdSub-park,LeiboZhongchengLifeScience Park,No.22JinxiuEastRoad,PingshanDistrict,518118Shenzhen, Guangdong,PEOPLE'SREPUBLICOFCHINA 3.2.ProductDescription Mainunitinformation: ProductName:ArmBloodPressureMonitor TradeMark:- ModelNo.:AES-U212 ListedModel(s):- Powersupply:3.7V,1100mAhLi-ionbattery Hardwareversion:AES-066-4G-JV01 Softwareversion:A.01.00.00 3.3.RadioSpecificationDescription SupportLTEtype:CatM1CatM2 SupportOperatingBand: FDDBand2FDDBand4FDDBand5 FDDBand12FDDBand13FDDBand17 FDDBand25FDDBand26TDD…

Text truncated - open the document above for the full version.

Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 1 of 261 APPENDIX REPORT Project No. SHT2304055301EW Radio Specification LTE Cat M Test sample No. YPHT23040553008 Model No. AES-U212 Start test date 2023-06-02 Finish date 2023-06-28 Temperature 25.3°C Humidity 56% Test Engineer Xiaodong Zhao Auditor Appendix clause Test item Result A Conducted Output Power PASS B Peak-to-Average Ratio PASS C 26 dB Bandwidth and Occupied Bandwidth PASS D Band edge PASS E Conducted Spurious Emission PASS F Frequency Stability PASS G ERP and EIRP PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 2 of 261 8.1 Appendix A: Conducted Output Power Test Result Band Bandwidth Modulation Channel RB Size RB Start Result(dBm) Verdict Band12 1.4MHz QPSK 23017 1 0 21.77 PASS Band12 1.4MHz QPSK 23017 1 5 21.77 PASS Band12 1.4MHz QPSK 23017 6 0 21.32 PASS Band12 1.4MHz QPSK 23095 1 0 22.04 PASS Band12 1.4MHz QPSK 23095 1 5 22.04 PASS Band12 1.4MHz QPSK 23095 6 0 21.59 PASS Band12 1.4MHz QPSK 23173 1 0 21.95 PASS Band12 1.4MHz QPSK 23173 1 5 21.95 PASS Band12 1.4MHz QPSK 23173 6 0 21.49 PASS Band12 1.4MHz 16QAM 23017 1 0 20.68 PASS Band12 1.4MHz 16QAM 23017 1 5 20.58 PASS Band12 1.4MHz 16QAM 23017 6 0 19.77 PASS Band12 1.4MHz 16QAM 23095 1 0 20.94 PASS Band12 1.4MHz 16QAM 23095 1 5 20.84 PASS Band12 1.4MHz 16QAM 23095 6 0 20.02 PASS Band12 1.4MHz 16QAM 23173 1 0 20.85 PASS Band12 1.4MHz 16QAM 23173 1 5 20.75 PASS Band12 1.4MHz 16QAM 23173 6 0 19.93 PASS Band12 3MHz QPSK 23025 1 0 21.99 PASS Band12 3MHz QPSK 23025 1 5 21.95 PASS Band12 3MHz QPSK 23025 6 0 19.71 PASS Band12 3MHz QPSK 23095 1 0 22.26 PASS Band12 3MHz QPSK 23095 1 5 22.22 PASS Band12 3MHz QPSK 23095 6 0 19.95 PASS Band12 3MHz QPSK 23165 1 0 22.17 PASS Band12 3MHz QPSK 23165 1 5 22.13 PASS Band12 3MHz QPSK 23165 6 0 19.87 PASS Band12 3MHz 16QAM 23025 1 0 20.88 PASS Band12 3MHz 16QAM 23025 1 5 20.77 PASS Band12 3MHz 16QAM 23025 6 0 19.71 PASS Band12 3MHz 16QAM 23095 1 0 21.14 PASS Band12 3MHz 16QAM 23095 1 5 21.03 PASS Band12 3MHz 16QAM 23095 6 0 19.95 PASS Band12 3MHz 16QAM 23165 1 0 21.05 PASS Band12 3MHz 16QAM 23165 1 5 20.94 PASS Band12 3MHz 16QAM 23165 6 0 19.87 PASS Band12 5MHz QPSK 23035 1 0 21.32 PASS Band12 5MHz QPSK 23035 1 5 21.35 PASS Band12 5MHz QPSK 23035 6 0 20.87 PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 3 of 261 Band12 5MHz QPSK 23095 1 0 21.59 PASS Band12 5MHz QPSK 23095 1 5 21.62 PASS Band12 5MHz QPSK 23095 6 0 21.13 PASS Band12 5MHz QPSK 23155 1 0 21.49 PASS Band12 5MHz QPSK 23155 1 5 21.52 PASS Band12 5MHz QPSK 23155 6 0 21.04 PASS Band12 5MHz 16QAM 23035 1 0 20.94 PASS Band12 5MHz 16QAM 23035 1 5 20.69 PASS Band12 5MHz 16QAM 23035 6 0 20.44 PASS Band12 5MHz 16QAM 23095 1 0 21.20 PASS Band12 5MHz 16QAM 23095 1 5 20.95 PASS Band12 5MHz 16QAM 23095 6 0 20.69 PASS Band12 5MHz 16QAM 23155 1 0 21.11 PASS Band12 5MHz 16QAM 23155 1 5 20.86 PASS Band12 5MHz 16QAM 23155 6 0 20.61 PASS Band12 10MHz QPSK 23060 1 0 21.59 PASS Band12 10MHz QPSK 23060 1 5 21.81 PASS Band12 10MHz QPSK 23060 6 0 21.56 PASS Band12 10MHz QPSK 23095 1 0 21.86 PASS Band12 10MHz QPSK 23095 1 5 22.08 PASS Band12 10MHz QPSK 23095 6 0 21.83 PASS Band12 10MHz QPSK 23130 1 0 21.77 PASS Band12 10MHz QPSK 23130 1 5 21.99 PASS Band12 10MHz QPSK 23130 6 0 21.74 PASS Band12 10MHz 16QAM 23060 1 0 20.92 PASS Band12 10MHz 16QAM 23060 1 5 20.97 PASS Band12 10MHz 16QAM 23060 6 0 20.44 PASS Band12 10MHz 16QAM 23095 1 0 21.18 PASS Band12 10MHz 16QAM 23095 1 5 21.23 PASS Band12 10MHz 16QAM 23095 6 0 20.69 PASS Band12 10MHz 16QAM 23130 1 0 21.09 PASS Band12 10MHz 16QAM 23130 1 5 21.14 PASS Band12 10MHz 16QAM 23130 6 0 20.61 PASS Band13 5MHz QPSK 23205 1 0 21.97 PASS Band13 5MHz QPSK 23205 1 5 21.62 PASS Band13 5MHz QPSK 23205 6 0 20.47 PASS Band13 5MHz QPSK 23230 1 0 21.78 PASS Band13 5MHz QPSK 23230 1 5 21.65 PASS Band13 5MHz QPSK 23230 6 0 20.26 PASS Band13 5MHz QPSK 23255 1 0 21.67 PASS Band13 5MHz QPSK 23255 1 5 21.50 PASS Band13 5MHz QPSK 23255 6 0 20.17 PASS Band13 5MHz 16QAM 23205 1 0 21.79 PASS Band13 5MHz 16QAM 23205 1 5 21.77 PASS Band13 5MHz 16QAM 23205 6 0 20.39 PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 4 of 261 Band13 5MHz 16QAM 23230 1 0 22.02 PASS Band13 5MHz 16QAM 23230 1 5 21.80 PASS Band13 5MHz 16QAM 23230 6 0 20.26 PASS Band13 5MHz 16QAM 23255 1 0 21.05 PASS Band13 5MHz 16QAM 23255 1 5 21.21 PASS Band13 5MHz 16QAM 23255 6 0 20.17 PASS Band13 10MHz QPSK 23230 1 0 22.04 PASS Band13 10MHz QPSK 23230 1 5 21.68 PASS Band13 10MHz QPSK 23230 6 0 20.38 PASS Band13 10MHz 16QAM 23230 1 0 21.95 PASS Band13 10MHz 16QAM 23230 1 5 21.90 PASS Band13 10MHz 16QAM 23230 6 0 20.31 PASS Band2 1.4MHz QPSK 18607 1 0 22.08 PASS Band2 1.4MHz QPSK 18607 1 5 22.01 PASS Band2 1.4MHz QPSK 18607 6 0 19.82 PASS Band2 1.4MHz QPSK 18900 1 0 22.18 PASS Band2 1.4MHz QPSK 18900 1 5 22.08 PASS Band2 1.4MHz QPSK 18900 6 0 19.92 PASS Band2 1.4MHz QPSK 19193 1 0 22.06 PASS Band2 1.4MHz QPSK 19193 1 5 21.88 PASS Band2 1.4MHz QPSK 19193 6 0 19.78 PASS Band2 1.4MHz 16QAM 18607 1 0 21.03 PASS Band2 1.4MHz 16QAM 18607 1 5 20.91 PASS Band2 1.4MHz 16QAM 18607 6 0 19.89 PASS Band2 1.4MHz 16QAM 18900 1 0 21.16 PASS Band2 1.4MHz 16QAM 18900 1 5 20.95 PASS Band2 1.4MHz 16QAM 18900 6 0 19.92 PASS Band2 1.4MHz 16QAM 19193 1 0 20.96 PASS Band2 1.4MHz 16QAM 19193 1 5 20.93 PASS Band2 1.4MHz 16QAM 19193 6 0 19.78 PASS Band2 3MHz QPSK 18615 1 0 22.08 PASS Band2 3MHz QPSK 18615 1 5 21.82 PASS Band2 3MHz QPSK 18615 6 0 19.83 PASS Band2 3MHz QPSK 18900 1 0 22.22 PASS Band2 3MHz QPSK 18900 1 5 22.08 PASS Band2 3MHz QPSK 18900 6 0 19.97 PASS Band2 3MHz QPSK 19185 1 0 22.10 PASS Band2 3MHz QPSK 19185 1 5 21.99 PASS Band2 3MHz QPSK 19185 6 0 19.84 PASS Band2 3MHz 16Q…

Text truncated - open the document above for the full version.

Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 39 of 261 Band2-10MHz-16QAM-18900-6-0-Low-1.1287-1.379-PASS Band2-10MHz-16QAM-19150-6-0-Low-1.1305-1.339-PASS Band2-15MHz-QPSK-18675-6-0-Low-1.1426-1.372-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 40 of 261 Band2-15MHz-QPSK-18900-6-0-Low-1.1332-1.392-PASS Band2-15MHz-QPSK-19125-6-0-Low-1.1324-1.395-PASS Band2-15MHz-16QAM-18675-6-0-Low-1.1475-1.369-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 41 of 261 Band2-15MHz-16QAM-18900-6-0-Low-1.1371-1.451-PASS Band2-15MHz-16QAM-19125-6-0-Low-1.1310-1.372-PASS Band2-20MHz-QPSK-18700-6-0-Low-1.1311-1.388-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 42 of 261 Band2-20MHz-QPSK-18900-6-0-Low-1.1243-1.382-PASS Band2-20MHz-QPSK-19100-6-0-Low-1.1325-1.367-PASS Band2-20MHz-16QAM-18700-6-0-Low-1.1379-1.373-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 43 of 261 Band2-20MHz-16QAM-18900-6-0-Low-1.1291-1.390-PASS Band2-20MHz-16QAM-19100-6-0-Low-1.1307-1.380-PASS Band4-1.4MHz-QPSK-19957-6-0-Low-1.1088-1.360-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 44 of 261 Band4-1.4MHz-QPSK-20175-6-0-Low-1.1060-1.361-PASS Band4-1.4MHz-QPSK-20393-6-0-Low-1.1185-1.333-PASS Band4-1.4MHz-16QAM-19957-6-0-Low-1.1088-1.360-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 45 of 261 Band4-1.4MHz-16QAM-20175-6-0-Low-1.1070-1.344-PASS Band4-1.4MHz-16QAM-20393-6-0-Low-1.1198-1.330-PASS Band4-3MHz-QPSK-19965-6-0-Low-1.1181-1.376-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 46 of 261 Band4-3MHz-QPSK-20175-6-0-Low-1.1128-1.334-PASS Band4-3MHz-QPSK-20385-6-0-Low-1.1181-1.326-PASS Band4-3MHz-16QAM-19965-6-0-Low-1.1147-1.366-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 47 of 261 Band4-3MHz-16QAM-20175-6-0-Low-1.1160-1.330-PASS Band4-3MHz-16QAM-20385-6-0-Low-1.1181-1.333-PASS Band4-5MHz-QPSK-19975-6-0-Low-1.1242-1.333-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 48 of 261 Band4-5MHz-QPSK-20175-6-0-Low-1.1096-1.382-PASS Band4-5MHz-QPSK-20375-6-0-Low-1.1247-1.349-PASS Band4-5MHz-16QAM-19975-6-0-Low-1.1257-1.337-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 49 of 261 Band4-5MHz-16QAM-20175-6-0-Low-1.1104-1.381-PASS Band4-5MHz-16QAM-20375-6-0-Low-1.1266-1.343-PASS Band4-10MHz-QPSK-20000-6-0-Low-1.1170-1.321-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 50 of 261 Band4-10MHz-QPSK-20175-6-0-Low-1.1270-1.394-PASS Band4-10MHz-QPSK-20350-6-0-Low-1.1301-1.338-PASS Band4-10MHz-16QAM-20000-6-0-Low-1.1232-1.335-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 51 of 261 Band4-10MHz-16QAM-20175-6-0-Low-1.1273-1.375-PASS Band4-10MHz-16QAM-20350-6-0-Low-1.1266-1.339-PASS Band4-15MHz-QPSK-20025-6-0-Low-1.1416-1.353-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 52 of 261 Band4-15MHz-QPSK-20175-6-0-Low-1.1364-1.403-PASS Band4-15MHz-QPSK-20325-6-0-Low-1.1279-1.366-PASS Band4-15MHz-16QAM-20025-6-0-Low-1.1406-1.367-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 53 of 261 Band4-15MHz-16QAM-20175-6-0-Low-1.1287-1.375-PASS Band4-15MHz-16QAM-20325-6-0-Low-1.1264-1.351-PASS Band4-20MHz-QPSK-20050-6-0-Low-1.1268-1.350-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 54 of 261 Band4-20MHz-QPSK-20175-6-0-Low-1.1157-1.414-PASS Band4-20MHz-QPSK-20300-6-0-Low-1.1315-1.370-PASS Band4-20MHz-16QAM-20050-6-0-Low-1.1310-1.358-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 55 of 261 Band4-20MHz-16QAM-20175-6-0-Low-1.1233-1.379-PASS Band4-20MHz-16QAM-20300-6-0-Low-1.1274-1.361-PASS Band5-1.4MHz-QPSK-20407-6-0-Low-1.1091-1.359-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 56 of 261 Band5-1.4MHz-QPSK-20525-6-0-Low-1.1070-1.361-PASS Band5-1.4MHz-QPSK-20643-6-0-Low-1.1197-1.353-PASS Band5-1.4MHz-16QAM-20407-6-0-Low-1.1081-1.361-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 57 of 261 Band5-1.4MHz-16QAM-20525-6-0-Low-1.1068-1.318-PASS Band5-1.4MHz-16QAM-20643-6-0-Low-1.1189-1.351-PASS Band5-3MHz-QPSK-20415-6-0-Low-1.1141-1.379-PASS

Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 58 of 261 Band5-3MHz-QPSK-20525-6-0-Low-1.1135-1.377-PASS Band5-3MHz-QPSK-20635-6-0-High-1.1163-1.355-PASS Band5-3MHz-16QAM-20415-6-0-Low-1.1163-1.367-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 59 of 261 Band5-3MHz-16QAM-20525-6-0-Low-1.1144-1.380-PASS Band5-3MHz-16QAM-20635-6-0-High-1.1215-1.356-PASS Band5-5MHz-QPSK-20425-6-0-Low-1.1241-1.344-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 60 of 261 Band5-5MHz-QPSK-20525-6-0-Low-1.1080-1.386-PASS Band5-5MHz-QPSK-20625-6-0-Low-1.1274-1.361-PASS Band5-5MHz-16QAM-20425-6-0-Low-1.1186-1.345-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 61 of 261 Band5-5MHz-16QAM-20525-6-0-Low-1.1117-1.385-PASS Band5-5MHz-16QAM-20625-6-0-Low-1.1259-1.364-PASS Band5-10MHz-QPSK-20450-6-0-Low-1.1181-1.320-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 62 of 261 Band5-10MHz-QPSK-20525-6-0-Low-1.1258-1.443-PASS Band5-10MHz-QPSK-20600-6-0-Low-1.1232-1.348-PASS Band5-10MHz-16QAM-20450-6-0-Low-1.1177-1.332-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 63 of 261 Band5-10MHz-16QAM-20525-6-0-Low-1.1248-1.360-PASS Band5-10MHz-16QAM-20600-6-0-Low-1.1314-1.343-PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 64 of 261 8.4 Appendix D: Band Edge Test Result Band Bandwidth Modulation Channel RB Size RB Start Result(dBm) Verdict Band12 1.4MHz QPSK 23017 1 0 -29.45 PASS Band12 1.4MHz QPSK 23017 6 0 -35.72 PASS Band12 1.4MHz QPSK 23173 1 5 -38.27 PASS Band12 1.4MHz QPSK 23173 6 0 -37.50 PASS Band12 1.4MHz 16QAM 23017 1 0 -26.40 PASS Band12 1.4MHz 16QAM 23017 6 0 -38.20 PASS Band12 1.4MHz 16QAM 23173 1 5 -35.93 PASS Band12 1.4MHz 16QAM 23173 6 0 -36.13 PASS Band12 3MHz QPSK 23025 1 0 -39.12 PASS Band12 3MHz QPSK 23025 6 0 -40.39 PASS Band12 3MHz QPSK 23165 1 5 -41.56 PASS Band12 3MHz QPSK 23165 6 0 -37.28 PASS Band12 3MHz 16QAM 23025 1 0 -34.43 PASS Band12 3MHz 16QAM 23025 6 0 -42.45 PASS Band12 3MHz 16QAM 23165 1 5 -39.64 PASS Band12 3MHz 16QAM 23165 6 0 -37.89 PASS Band12 5MHz QPSK 23035 1 0 -35.87 PASS Band12 5MHz QPSK 23035 6 0 -39.07 PASS Band12 5MHz QPSK 23155 1 5 -36.61 PASS Band12 5MHz QPSK 23155 6 0 -35.74 PASS Band12 5MHz 16QAM 23035 1 0 -33.18 PASS Band12 5MHz 16QAM 23035 6 0 -38.03 PASS Band12 5MHz 16QAM 23155 1 5 -51.41 PASS Band12 5MHz 16QAM 23155 6 0 -37.23 PASS Band12 10MHz QPSK 23060 1 0 -40.18 PASS Band12 10MHz QPSK 23060 6 0 -42.64 PASS Band12 10MHz QPSK 23130 1 5 -41.50 PASS Band12 10MHz QPSK 23130 6 0 -40.00 PASS Band12 10MHz 16QAM 23060 1 0 -40.08 PASS Band12 10MHz 16QAM 23060 6 0 -43.35 PASS Band12 10MHz 16QAM 23130 1 5 -52.05 PASS Band12 10MHz 16QAM 23130 6 0 -39.60 PASS Band13 5MHz QPSK 23205 1 0 -32.02 PASS Band13 5MHz QPSK 23205 6 0 -39.76 PASS Band13 5MHz QPSK 23255 1 5 -40.97 PASS Band13 5MHz QPSK 23255 6 0 -40.08 PASS Band13 5MHz 16QAM 23205 1 0 -35.62 PASS Band13 5MHz 16QAM 23205 6 0 -38.60 PASS Band13 5MHz 16QAM 23255 1 5 -44.24 PASS Project No.: SHT2304055301EW Radio Specification: LTE Cat M Shenzhen Huatongwei International Inspection Co., Ltd. Appendix report page: 65 of 261 Band13 5MHz 16QAM 23255 6 0 -38.00 PASS Band13 10MHz QPSK 23230 1 0 -48.05 PASS Band13 10MHz QPSK 23230 1 5 -45.89 PASS Band13 10MHz QPSK 23230 6 0 -38.70 PASS Band13 10MHz QPSK 23230 6 0 -39.22 PASS Band13 10MHz 16QAM 23230 1 0 -45.31 PASS Band13 10MHz 16QAM 23230 1 5 -44.81 PASS Band13 10MHz 16QAM 23230 6 0 -38.92 PASS Band13 10MHz 16QAM 23230 6 0 -40.26 PASS Band2 1.4MHz QPSK 18607 1 0 -25.24 PASS Band2 1.4MHz QPSK 18607 6 0 -32.36 PASS Band2 1.4MHz QPSK 19193 1 5 -31.69 PASS Band2 1.4MHz QPSK 19193 6 0 -32.48 PASS Band2 1.4MHz 16QAM 18607 1 0 -25.63 PASS Band2 1.4MHz 16QAM 18607 6 0 -32.99 PASS Band2 1.4MHz 16QAM 19193 1 5 -32.34 PASS Band2 1.4MHz 16QAM 19193 6 0 -31.95 PASS Band2 3MHz QPSK 18615 1 0 -33.68 PASS Band2 3MHz QPSK 18615 6 0 -33.76 PASS Band2 3MHz QPSK 19185 1 5 -34.02 PASS Band2 3MHz QPSK 19185 6 0 -35.77 PASS Band2 3MHz 16QAM 18615 1 0 -37.28 PASS Band2 3MHz 16QAM 18615 6 0 -35.49 PASS Band2 3MHz 16QAM 19185 1 5 -33.98 PASS Band2 3MHz 16QAM 19185 6 0 -35.95 PASS Band2 5MHz QPSK 18625 1 0 -29.45 …

Text truncated - open the document above for the full version.
