Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
FCC Statement Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modi This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body. ED Statement French: Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest susceptible d'encompromettre le fonctionnement. l'appareil numérique du ciem conforme canadien peut 3 (b) / nmb 3 (b). This device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and compliance with RSS 102 RF exposure, users can obtain Canadian information on RF exposure and compliance. cet appareil est conforme à l'exemption des limites d'évaluation courante dans la section 2.5 du cnr - 102 et conformité avec rss 102 de l'exposition aux rf, les utilisateurs peuvent obtenir des données canadiennes sur l'exposition aux champs rf et la conformité. This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre corps.
CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2021-5-16> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AMFC-MS1P MS1P For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title: wang mao/Manager Company: Dalian Cloud Force Technologies Co., Ltd. Address: Unit1,Block B,6th Floor, No.23 Honggang Rd. Ganjingzi Distr. Dalian, Liaoning Province,Dalian China Phone: +86 041186686675 Fax: 0411-86686691 E-Mail: [email protected]
Dalian Cloud Force Technologies Co., Ltd. Unit1,Block B,6th Floor, No.23 Honggang Rd. Ganjingzi Distr. Dalian, Liaoning Province,Dalian China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2021-5-16 To whom it may concern: We, Dalian Cloud Force Technologies Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AMFC-MS1P including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title: wang mao/Manager Company: Dalian Cloud Force Technologies Co., Ltd. Address: Unit1,Block B,6th Floor, No.23 Honggang Rd. Ganjingzi Distr. Dalian, Liaoning Province,Dalian China Phone: +86 041186686675 Fax: 0411-86686691 E-Mail: [email protected]
GTSL202104000279 Product Name: Wireless Motion Sensor Test Model No.: MS1P EUT Constructional Details External Photo Fig.1 Fig.2 GTSL202104000279 Fig.3 Fig.4 GTSL202104000279 Fig.5
FCC ID: 2AMFC-MS1P IC: 24405-MS1P Label and Location Size: L: 3.0cm*W: 2.0cm Label and Location Wireless Motion Sensor Model No.: MS1P FCC ID: 2AMFC-MS1P IC: 24405-MS1P
GTSL202104000279 Product Name: Wireless Motion Sensor Test Model No.: MS1P EUT Constructional Details Internal Photo Fig.1 Fig.2 GTSL202104000279 Fig.3 Fig.4 Antenna GTSL202104000279 Fig.5 Fig.6 GTSL202104000279 Fig.7
RF Exposure evaluation FCC ID: 2AMFC-MS1P Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Mobile Device 1. Reference According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1091 RF exposure is calculated. KDB447498 D01: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 2. Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 3. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 4. Antenna Information HC500 can only use antennas certificated as follows provided by manufacturer; Antenna No. Model No. of antenna: Antenna type and antenna number Operate frequency band Maximum antenna gain BT ANT / PCB Antenna 2.4GHz – 2.5 GHz 0 dBi 2.4GWIFI ANT / PCB Antenna 2.4GHz – 2.5 GHz 0 dBi 5. Conducted power [2.4GHz WIFI] Mode Channel Frequency Peak Conducted Output Power (dBm) IEEE 802.11b 1 2412 12.68 6 2437 12.67 11 2462 12.61 IEEE 802.11g 1 2412 13.26 6 2437 14.34 11 2462 13.82 IEEE 802.11n HT20 1 2412 12.82 6 2437 13.93 11 2462 13.66 [2.4GHz BLE] Mode Channel Frequency Peak Conducted Output Power (dBm) BLE 00 2402 1.12 19 2440 0.74 39 2480 0.4 [2.4GHz BT] Mode Channel Frequency Peak Conducted Output Power (dBm) GFSK 00 2402 4.1 39 2441 4.19 78 2480 4.2 GFSK 00 2402 4.46 39 2441 4.76 78 2480 4.54 GFSK 00 2402 4.94 39 2441 5.22 78 2480 4.9 6. Manufacturing Tolerance B mode (Peak) Channel Channel 0 Channel 6 Channel 11 Target (dBm) 12.0 13.0 12.0 Tolerance ±(dB) 1.0 1.0 1.0 G mode(Peak) Channel Channel 0 Channel 6 Channel 11 Target (dBm) 12.0 14.0 13.0 Tolerance ±(dB) 1.0 1.0 1.0 N20 mode(Peak) Channel Channel 0 Channel 6 Channel 11 Target (dBm) 12.0 13.0 13.0 Tolerance ±(dB) 1.0 1.0 1.0 BT Classics GFSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 4.0 4.0 4.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4-DQPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 4.0 4.0 4.0 Tolerance ±(dB) 1.0 1.0 1.0 8-DPSK (Peak) Channel Channel 0 Channel 39 Channel 78 Target (dBm) 4.0 5.0 4.0 Tolerance ±(dB) 1.0 1.0 1.0 BT LE GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 1.0 0 0 Tolerance ±(dB) 1.0 1.0 1.0 7. Standalone MPE Result As declared by the Applicant, the EUT is a wireless device used in a fix application, at least 20 cm from any body part of the user or nearby persons; from the maximum EUT RF output power, the minimum separation distance, r =20cm, as well as the gain of WIFI antenna is 0dBi, the gain of BT antenna is 0dBi.the RF power density can be obtained. Modulation Type Output power Antenna Gain (dBi) Antenna Gain (linear) MPE (mW/cm 2 ) MPE Limits (mW/cm 2 ) dBm mW WIFI 15.0 31.6228 0.00 1.00000 0.0063 1.0000 BLE 6.00 3.9811 0.00 1.00000 0.0008 1.0000 BT 2.00 1.5849 0.00 1.00000 0.0003 1.0000 Remark: 1. Output power (Peak) including turn-up tolerance; 2. Output power was adjust to duty cycle at 100% if measured duty cycle less than 98%; 3. MPE evaluate distance is 20cm from user manual provide by manufacturer. 8. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure of mobile device. ----------------THE END OF REPORT---------------
Global United Technology Services Co., Ltd. Report No.: GTSL202104000279-02 Authorized Signature: Robinson Luo Laboratory Manager This results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Page 1 of 52 TEST Report Applicant: Dalian Cloud Force Technologies Co., Ltd. Address of Applicant: Unit1, Block B, 6th Floor, No.23 Honggang Road, Ganjingzi District, Dalian, Liaoning Province, China Manufacturer : Dalian Cloud Force Technologies Co., Ltd. Address of Manufacturer : Unit1, Block B, 6th Floor, No.23 Honggang Road, Ganjingzi District, Dalian, Liaoning Province, China Equipment Under Test (EUT) Product Name: Wireless Motion Sensor Model No.: MS1P Series model: N/A Trade Mark: Ubibot FCC ID: 2AMFC-MS1P IC: 24405-MS1P Applicable standards: FCC Part 15.247 RSS 247 Issue 2, February 2017 RSS-GEN Issue 5 ANSI C63.10: 2013 Date of sample receipt: Sep.14,2020 Date of Test: Sep.14,2020- Apr.30,2021 Date of report issued: Apr.30,2021 Test Result : PASS * * In the configuration tested, the EUT complied with the standards specified above. Report No.: GTSL202104000279-02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 52 2 Version Version No. Date Description 00 Apr.30,2021 Original Tested/ Prepared By Date: Apr.30,2021 Project Engineer Check By: Date: Apr.30,2021 Reviewer Report No.: GTSL202104000279-02 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 3 of 52 3 Contents Page 1 COVER PAGE ...........................................................................................................................................1 2 VERSION ...................................................................................................................................................2 3 CONTENTS ...............................................................................................................................................3 4 TEST SUMMARY ......................................................................................................................................4 5 GENERAL INFORMATION .......................................................................................................................5 5.1 GENERAL DESCRIPTION OF EUT ..........................................................................................................5 5.2 TEST MODE .........................................................................................................................................7 5.3 DESCRIPTION OF SUPPORT UNITS ........................................................................................................7 5.4 DEVIATION FROM STANDARDS ..............................................................................................................7 5.5 ABNORMALITIES FROM STANDARD CONDITIONS ....................................................................................7 5.6 TEST FACILITY.....................................................................................................................................7 5.7 TEST LOCATION...................................................................................................................................7 5.8 ADDITIONAL INSTRUCTIONS ..................................................................................................................7 6 TEST INSTRUMENTS LIST ......................................................................................................................8 7 TEST RESULTS AND MEASUREMENT DATA .....................................................................................10 7.1 ANTENNA REQUIREMENT ....................................................................................................................10 7.2 CONDUCTED EMISSIONS ....................................................................................................................11 7.3 CONDUCTED PEAK OUTPUT POWER ...................................................................................................14 7.4 20DB EMISSION BANDWIDTH & 99% OCCUPY BANDWIDTH .................................................................15 7.5 FREQUENCIES SEPARATION ...............................................................................................................22 7.6 HOPPING CHANNEL NUMBER .............................................................................................................24 7.7 DWELL TIME ......................................................................................................................................26 7.8 PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ...........................................................................31 7.9 BAND EDGE.......................................................................................................................................32 7.9.1 Conducted Emission Method ......................................................................................................32 7.9.2 Radiated Emission Method .........................................................................................................36 7.10 SPURIOUS EMISSION .........................................................................................................................39 7.10.1 Conducted Emission Method ........................................................................................…
Text truncated - open the document above for the full version.
GTSL202104000279 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 1 of 2 Product Name: Wireless Motion Sensor Test Model No.: MS1P Test Setup Photo Test Setup Photo(s) of Radiated Emissions Measurement Fig. 1 GTSL202104000279 Global United Technology Services Co., Ltd. No. 123-128, Tower A, Jinyuan Business Building, No.2, Laodong Industrial Zone, Xixiang Road, Baoan District, Shenzhen, Guangdong, China 518102 Telephone: +86 (0) 755 2779 8480 Fax: +86 (0) 755 2779 8960 Page 2 of 2 Fig. 2 Test Setup Photo of Line Conducted Emissions Measurement ------End------
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 3.30 mW |
