Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
FCC compliance statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference including received interference that may cause undesired operation. The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. Replacement of any transmitter component (crystal, semiconductor, etc.) not authorized by the FCC equipment authorization for this radio could violate FCC rules. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. FCC RF Exposure and Separation Distance WARNING: MODIFICATION OF THIS DEVICE TO RECEIVE CELLULAR RADIOTELEPHONE SERVICE SIGNALS IS PROHIBITED UNDER FCC RULES AND FEDERAL LAW. SAR tests are conducted using standard operating positions accepted by FCC with the device transmitting at its highest certified power level in all tested frequency bands, although the SAR is determined at the highest certified power level, the actual SAR level of the device while operating can be well below the maximum value. Before a new model is an available for sale to the public, it must be tested and certified to the FCC that is does not exceed the exposure limit established by the FCC. Tests for each product are performed in positions and locations as required by the FCC. For body worn operation, this device has been tested and meets the FCC RF exposure guidelines when used with and accessory designated for this product or when used with and accessory that contains no metal. To maintain compliance with FCC RF exposure guidelines, hold the transmitter and antenna at least 1 inch (2.5 centimeters) from your face and speak in a normal voice, with the antenna pointed up and away from the face.
SAIN3 LLC Covered Equipment Certification Attestation Letter 6/12/2026 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AN62-X1PRO SAIN3 LLC (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. SAIN3 LLC (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. SAIN3 LLC (“the applicant”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Signed: Printed name: Damon Cheng Title: President Company Name: SAIN3 LLC Date: 6/12/2026
2.911 (d)(7)USA Agent v1.2 Section 2.911(d)(7) USA Agent for Service of Process Company name: SAIN3 LLC Address: 36 Berkley Drive Newark, DE 19702 United States FCC ID: 2AN62-X1PRO 2.911(d)(7) USA Designated Agent for Service of Process We, SAIN3 LLC (“the applicant”) designate SAIN3 LLC NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. address and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent & Applicant Company name: SAIN3 LLC Address: 36 Berkley Drive Newark, DE 19702 United States FRN:0026960740 Contact Name: Damon Cheng Telephone No: 408455 3566 Email: [email protected] Signature: Title: President Date: 12 June 2026 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the
SAIN3 LLC DATE: June 12, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Tongzhou Testing Co.,Ltd. (1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with SAIN3 LLC (36 Berkley Drive Newark, DE 19702 United States) <Signature> Name: Damon Cheng Title: President Applicant Company: SAIN3 LLC
Date: June 12, 2026 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Compliance Testing, LLC to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). Sincerely, <Signature> Name: Damon Cheng Title: President Company: SAIN3 LLC
DATE: June 12, 2026 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AN62-X1PRO Product Name: GMRS Radio Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: (List here the documents for which you are seeking confidentiality – for example ...) • Schematics • Block diagram • Operation description • Tune-up procedure • Part lists These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name: Damon Cheng Title: President Company: SAIN3 LLC
SAIN3 LLC 36 Berkley Drive Newark, DE 19702 United States Date: 2026-06-12 Declaration Letter FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Declaration of compliance to the requirements of §15.121 FCC ID: 2AN62-X1PRO Dear Sir/Madam, We declare that, this scanning receiver is incapable of operating (tuning), or readily being altered by the users to operate, within the frequency bands allocated to the Cellular Radiotelephone Service in part 22 of this chapter (cellular telephone bands). This device will not be able to receive transmissions in the cellular telephone bands by means of clipping the leads of, or installing, a simple component such as a diode, resistor or jumper wire; replacing a plug-in semiconductor chip; or programming a semiconductor chip using special access codes or an external device, such as a personal computer. This device is also incapable of converting digital cellular communication transmissions to analog voice audio. This device is designed so that the tuning, control and filtering circuitry is inaccessible. Any attempts to modify the equipment to receive transmissions from the Cellular Radiotelephone Service will render the receiver inoperable. This scanning receiver rejects any signals from the Cellular Radiotelephone Service frequency bands that are 38 dB or lower based upon a 12 dB SINAD measurement. We are aware that the modification of this device to receive transmissions from Cellular Radiotelephone Service frequency bands will be considered to constitute manufacture of such equipment. This includes any individual, individuals, entity or organization that modifies one or more scanners. Any modification to receive transmissions from the Cellular Radiotelephone Service frequency bands voids the certification of the scanning receiver, regardless of the date of manufacture of the original unit. Sincerely Yours, Signature: ___________________________ Name: Damon Cheng Title: President
Report No.: TZ0413260401PH02 Page 1 of 4 External Photographs of EUT External Photo 1 External Photo 2 Report No.: TZ0413260401PH02 Page 2 of 4 External Photo 3 External Photo 4 Report No.: TZ0413260401PH02 Page 3 of 4 External Photo 5 External Photo 6 Report No.: TZ0413260401PH02 Page 4 of 4 External Photo 7
The size of the label is 15mm*10mm with White forecolor. The size of the logo is 5mm*5mm. FCC ID: 2AN62-X1PRO
Report No.: TZ0413260401PH03 Page 1 of 9 Internal Photographs of EUT Internal Photo 1 Internal Photo 2 Antenna Report No.: TZ0413260401PH03 Page 2 of 9 Internal Photo 3 Internal Photo 4 Report No.: TZ0413260401PH03 Page 3 of 9 Internal Photo 5 Internal Photo 6 Report No.: TZ0413260401PH03 Page 4 of 9 Internal Photo 7 Internal Photo 8 Report No.: TZ0413260401PH03 Page 5 of 9 Internal Photo 9 Internal Photo 10 Report No.: TZ0413260401PH03 Page 6 of 9 Internal Photo 11 Internal Photo 12 Report No.: TZ0413260401PH03 Page 7 of 9 Internal Photo 13 Internal Photo 14 Report No.: TZ0413260401PH03 Page 8 of 9 Internal Photo 15 Internal Photo 16 Report No.: TZ0413260401PH03 Page 9 of 9 Internal Photo 17 Internal Photo 18
Page 1 of 18 CALIBRATION DATA PROBE CALIBRATION DATA Page 2 of 18 Page 3 of 18 Page 4 of 18 Page 5 of 18 Page 6 of 18 Page 7 of 18 Page 8 of 18 Page 9 of 18 Page 10 of 18 DAE CALIBRATION DATA Page 11 of 18 Page 12 of 18 Page 13 of 18 DIPOLE CALIBRATION DATA Page 14 of 18 Page 15 of 18 Page 16 of 18 Page 17 of 18 Page 18 of 18
Page 1 of 47 SAR Test Report Report No.: AGC10211260502FH01 FCC ID : 2AN62-X1PRO PRODUCT DESIGNATION : GMRS Radio BRAND NAME : Radioddity MODEL NAME : X1 Pro APPLICANT : SAIN3 LLC DATE OF ISSUE : Jun. 04, 2026 STANDARD(S) : IEEE Std. 1528:2013 FCC 47 CFR Part 2§2.1093 IEEE Std C95.1 ™-2019 REPORT VERSION : V1.0 Attestation of Global Compliance(Shenzhen) Co., Ltd. Report No.: AGC10211260502FH01 Page 2 of 47 Report Revise Record Report Version Revise Time Issued Date Valid Version Notes V1.0 / Jun. 04, 2026 Valid Initial Release Report No.: AGC10211260502FH01 Page 3 of 47 Test Report Applicant Name SAIN3 LLC Applicant Address 36 Berkley Drive Newark, DE 19702 United States Manufacturer Name SAIN3 LLC Manufacturer Address 36 Berkley Drive Newark, DE 19702 United States Factory Name SAIN3 LLC Factory Address 36 Berkley Drive Newark, DE 19702 United States Product Designation GMRS Radio Brand Name Radioddity Test Model X1 Pro Series Model N/A Declaration of Difference N/A EUT Voltage DC 7.4V Applicable Standard IEEE Std. 1528:2013 FCC 47 CFR Part 2§2.1093 IEEE Std C95.1 ™-2019 Date of receipt of test item May 06, 2026 Test Date May 07, 2026 Report Template AGCRT- US -PTT/SAR (2021-04-20) Note: The results of testing in this report apply to the product/system which was tested only. Prepared By Thea Huang (Project Engineer) Jun. 04, 2026 Reviewed By Jack Gui (Reviewer) Jun. 04, 2026 Approved By Angela Li (Authorized Officer) Jun. 04, 2026 Report No.: AGC10211260502FH01 Page 4 of 47 TABLE OF CONTENTS 1. SUMMARY OF MAXIMUM SAR VALUE ....................................................................................................... 5 2. GENERAL INFORMATION ............................................................................................................................ 6 2.1. EUT DESCRIPTION ...................................................................................................................................... 6 3. SAR MEASUREMENT SYSTEM ..................................................................................................................... 7 3.1. THE DASY5 SYSTEM USED FOR PERFORMING COMPLIANCE TESTS CONSISTS OF FOLLOWING ITEMS.................... 7 3.2. DASY5 E-FIELD PROBE .............................................................................................................................. 8 3.3. DATA ACQUISITION ELECTRONICS DESCRIPTION ............................................................................................. 8 3.4. ROBOT ....................................................................................................................................................... 9 3.5. LIGHT BEAM UNIT ....................................................................................................................................... 9 3.6. DEVICE HOLDER ....................................................................................................................................... 10 3.7. MEASUREMENT SERVER ............................................................................................................................ 10 3.8. PHANTOM ............................................................................................................................................... 11 4. SAR MEASUREMENT PROCEDURE .......................................................................................................... 12 4.1. SPECIFIC ABSORPTION RATE (SAR) ........................................................................................................... 12 4.2. SAR MEASUREMENT PROCEDURE ............................................................................................................. 13 5. TISSUE SIMULATING LIQUID ..................................................................................................................... 15 5.1. THE COMPOSITION OF THE TISSUE SIMULATING LIQUID ................................................................................... 15 5.2. TISSUE DIELECTRIC PARAMETERS FOR HEAD AND BODY PHANTOMS .............................................................. 15 5.3. TISSUE CALIBRATION RESULT ..................................................................................................................... 16 6. SAR SYSTEM CHECK PROCEDURE ......................................................................................................... 17 6.1. SAR SYSTEM CHECK PROCEDURES ........................................................................................................... 17 6.2. SAR SYSTEM CHECK ................................................................................................................................ 18 7. EUT TEST POSITION ................................................................................................................................... 19 7.1. BODY WORN POSITION .............................................................................................................................. 19 8. SAR EXPOSURE LIMITS ............................................................................................................................ 20 9. TEST FACILITY ........................................................................................................................................... 21 10. TEST EQUIPMENT LIST ........................................................................................................................... 22 11. MEASUREMENT UNCERTAINTY .............................................................................................................. 23 12. POWER MEASUREMENT .......................................................................................................................... 27 13. TEST RESULTS ........................................................................................................................................ 28 13.1. SAR TEST RESULTS SUMMARY ......…
Text truncated - open the document above for the full version.
Report No.: TZ0413260401FRF19 Page 1 of 47 This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Tongzhou Testing Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Tongzhou Testing Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. The test report apply only to the specific sample(s) tested under stated test conditions. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. TEST REPORT Report Number : TZ0413260401FRF19 Product Name : GMRS Radio Model/Type reference : X1 Pro FCC ID : 2AN62-X1PRO Prepared for : SAIN3 LLC 36 Berkley Drive Newark, DE 19702 United States Prepared By : Shenzhen Tongzhou Testing Co.,Ltd. 1st Floor, Building 1, Haomai High-tech Park, Huating Road 387, Dalang Street, Longhua, Shenzhen, China Standards : FCC CFR Title 47 Part 95 Subpart E, ANSI C63.26-2015 Date of Test : 2026-05-06 ~ 2026-05-26 Date of Issue : 2026-06-03 Prepared by : Nancy Li Reviewed by : Allen Lai Approved by : Max Zhang (Authorized Officer) Report No.: TZ0413260402FRF19 Page 2 of 47 Page 2 of 47 ** Report Revise Record ** Report Version Revise Time Issued Date Valid Version Notes V1.0 / 2026-06-03 Valid Initial release Report No.: TZ0413260402FRF19 Page 3 of 47 Page 3 of 47 TABLE OF CONTENTS 1. G E N E R A L I N F O R M A T I O N ....................................................... 4 1.1. Client Information ................................................................................................................... 4 1.2. Description of Device (EUT) ................................................................................................... 4 1.3. Wireless Function Tested in this Report .............................................................................. 4 1.4. Description of Test Facility .................................................................................................... 5 1.5. Statement of the Measurement Uncertainty ......................................................................... 5 1.6. Measurement Uncertainty ...................................................................................................... 6 1.7. Frequency of Channels .......................................................................................................... 6 1.8. Description of Test Modes ..................................................................................................... 7 2. T E S T M E T H O D O L O G Y ............................................................ 8 2.1. EUT Configuration .................................................................................................................. 8 2.2. EUT Related Submittal (s) / Grant (s) .................................................................................... 8 2.3. Test Sample ............................................................................................................................. 8 3. S Y S T E M T E S T C O N F I G U R A T I O N .............................................. 9 3.1. Justification ............................................................................................................................. 9 3.2. Special Accessories ............................................................................................................... 9 3.3. Block Diagram/Schematics .................................................................................................... 9 3.4. Equipment Modifications ....................................................................................................... 9 3.5. Test Setup ................................................................................................................................ 9 4. S U M M A R Y O F T E S T R E S U L T S ............................................... 10 5. T E S T R E S U L T .................................................................... 11 5.1. Frequency Stability ............................................................................................................... 11 5.2. Occupied Bandwidth and Emission Mask .......................................................................... 15 5.3. Transmitter Power................................................................................................................. 25 5.4. Modulation Characteristics .................................................................................................. 27 5.5. Spurious Emission on Antenna Port .................................................................................. 37 5.6. Spurious Radiated Emission ............................................................................................... 42 6. L I S T O F M E A S U R I N G E Q U I P M E N T S ....................................... 46 7. T E S T S E T U P P H O T O G R A P H S O F E U T ..................................... 47 8. E X T E R I O R P H O T O G R A P H S O F T H E E U T ................................. 47 9. I N T E R I O R P H O T O G R A P H S O F T H E E U T .................................. 47 Report No.: TZ0413260402FRF19 Page 4 of 47 Page 4 of 47 1. G E N E R A L I N F O R M A T I O N 1.1. Client Information Applicant : SAIN3 LLC Address : 36 Berkley Drive Newark, DE 19702 United States Manufacturer : SAIN3 LLC Address : 36 Berkley Drive Newark, DE 19702 United States 1.2. Description of Device (EUT) Product Name : GMRS Radio Trade Mark : Radioddity Model Number : X1 Pro Power Supply : DC 7.4V by battery Hardware version : Ver 1.0 Software version : Ver 1.0 1.3. Wireless Function Tested in this Report GMRS Operation Frequency Range : 462.5500-462.7250MHz (GMRS 462MHz Main channels) 462.5625-462.7125MHz (GMRS 462MHz Interstitial channels) 467.5500-467.7250MHz (GMRS 467M…
Text truncated - open the document above for the full version.
Report No.: TZ0413260401PH05 Page 1 of 2 Test Setup Photos of the EUT Radiated Emission Below 1GHz Radiated Emission Above 1GHz Report No.: TZ0413260401PH05 Page 2 of 2 RF Conducted Test
36 Berkley Drive · Delaware, 19702 · United States
| # | Rule Parts | Frequency Range | Power Output | Emission | Tolerance |
|---|---|---|---|---|---|
| 1 | 95E | 462.55 MHz - 462.725 MHz | 6.05 W | 9K90F3E | 0.29ppm |
| 2 | 95E | 462.55 MHz - 462.725 MHz | 590.00 mW | 9K90F3E | 0.29ppm |
| 3 | 95E | 462.5625 MHz - 462.7125 MHz | 3.86 W | 9K90F3E | 0.27ppm |
| 4 | 95E | 462.5625 MHz - 462.7125 MHz | 510.00 mW | 9K90F3E | 0.27ppm |
| 5 | 95E | 467.55 MHz - 467.725 MHz | 5.98 W | 9K90F3E | 0.28ppm |
| 6 | 95E | 467.55 MHz - 467.725 MHz | 540.00 mW | 9K90F3E | 0.28ppm |
| 7 | 95E | 467.5625 MHz - 467.7125 MHz | 430.00 mW | 9K90F3E | 0.28ppm |

Two Way Radio
Equipment Class
FRF - Part 95 Family Radio Face Held Transmitter
Mobile Radio
Equipment Class
TNF - Licensed Non-Broadcast Transmitter Held to Face
Mobile Radio
Equipment Class
CSR - Scanning Receiver
Mobile Radio
Equipment Class
CSR - Scanning Receiver
Two Way Radio
Equipment Class
JAV - Other Non-Digital SDoC Devices
