2ANM3HS7ABRemote Controller

W ilson Tech Service LLC 2.911 (d)(7)USA Agentv1.3 Section 2.911(d)(7) USA Agent for Service of Process Company name: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address: 13F-16F, Unit A, Skyworth Building, Shennan Road,Nanshan District, Shenzhen, Guangdong, P.R.China Product Name: Remote Controller FCC ID: 2ANM3HS7AB Model(s): HS-7AB 2.911(d)(7) USA Designated Agent for Service of Process We, [Shenzhen Chuangwei-RGB Electronics Co., Ltd.] (“the applicant”) designate [Wilson Tech Service LLC] NOTE1 for the purpose of accepting service of process on behalf of the applicant. Applicant consent: We Acknowledge our consent to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address of the designated agent and acknowledge our acceptance of our obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Agent obligation: We Acknowledge our obligation to accept service of process in the United States for matters related to the applicable equipment at our physical U.S. addre ss and email address for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. USA Agent Company name: Wilson Tech Service LLC Address: 1312 17th Street Suite 692, Denver, CO, 80202, US Contact Name: Wilson Cheung Telephone No: +1-716-965-5112 Email: [email protected] FCC Registation Number(FRN): 0033402033 Applicant Company name: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address: 13F-16F, Unit A, Skyworth Building, Shennan Road,Nanshan District, Shenzhen, Guangdong, P.R.China FCC Grantee Code:2ANM3 Contact Name: Dan Fang Telephone No: +86-18820267050 Email: [email protected] FCC Registation Number(FRN): 0026807446 Wilson Tech Service LLC 2.911 (d)(7)USA Agentv1.3 Signature: Title: Manager Date: 2024-03-27 Signature: Title: Manager Date: 2024.03.27 NOTE 1: An applicant located in the United States may designate itself as the agent for service of process. Reference; Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-nation al-security-threats-to-the-communications-supply-chain-through-the

Shenzhen Chuangwei-RGB Electronics Co., Ltd. Attestation Statements Not Covered Entity Applicant To: Federal Communications Commission Date: 03-19-2024 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(ii) filing FCC ID:2ANM3HS7AB [Shenzhen Chuangwei-RGB Electronics Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely yours, Applicant Signature Printed Name: Dan Fang Title: Certification Engineer Address: 13F-16F,Unit A,Skyworth Building,Shennan Road, Nanshan District, Shenzhen, China Email: [email protected]

Shenzhen Chuangwei-RGB Electronics Co., Ltd. Attestation Statements Not Covered Equipment To: Federal Communications Commission Date: 03-19-2024 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Information Required by Section 2.911(d)(5)(i) filing FCC ID:2ANM3HS7AB [Shenzhen Chuangwei-RGB Electronics Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section § 2.903 of the FCC rules. Sincerely yours, Applicant Signature Printed Name: Dan Fang Title: Certification Engineer Address: 13F-16F,Unit A,Skyworth Building,Shennan Road, Nanshan District, Shenzhen, China Email: [email protected]

Shenzhen Chuangwei-RGB Electronics Co., Ltd. (03-19-2024) Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize (sisa/ Shenzhen Central Standard International Center Co., Ltd./ Room 201, Building 1, Mogen Fashion Industrial Park, No. 10, Shilongzai Road, Xinshi Community, Dalang Street, Longhua District, Shenzhen.) to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Signed: Printed Name: Dan Fang Title: Certification Engineer Date: 2024-03-12

Shenzhen Chuangwei-RGB Electronics Co., Ltd. Date: 03-19-2024 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR (Remote Controller #FCC ID: 2ANM3HS7AB#) To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the (Confidential information is shown in the list) required to be submitted with this application be permanently withheld from public review. Exhibits Allowed for Long Term Confidentiality* Allowed for Short Term Confidentiality ID Label and Label Location No No Attestation Statements No No External Photos No Yes Block Diagram Yes No Schematics Yes No Test Report No No Test Setup Photos No Yes User Manual *** Yes Internal Photos *** Yes Parts List / Tune Up Procedure No No RF Exposure / MPE / SAR No No Operational Description Yes No Cover Letter(s) No No SDR Software / Security Info ** No No The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. And confidentiality period of 180 days. Please contact me if there is any information you may need. Sincerely, Signed: Printed Name: Dan Fang Title: Certification Engineer

序号 数量 物 料 号/品 号 品 名 认证标签 0 1 1/1 2 1 3 1 1 4 5 1 6 7 哈隆电子有限公司 物料号 设计 版本 1.1 B 2024.3.19 2024.3.19 V1.0--V1.1 认证标签内容"型号"更改为""，其余不变。郑培凤MODEL 外观类型 日期 环保标准 RoHS 质量标准 文件编号 版本号 国标 许永乐 审核 批准 客户型号 01 HELLO-T&D-EQR-014 郑培凤 认证标签 HOF-44Q 技术要求 1、认证标签尺寸为22*7mm； 2、标签为不干胶,底色白色,文字黑体,生产自行打印 3、标签黏贴位置，电池仓右侧 4、打印效果依生产实际打印为准 标签内容放大图 批号标签 黏贴在电池仓左侧 MODEL:HS-7AB FCC ID:2ANM3HS7AB IC:23165-HS7AB M O D E L : H S - 7 A B F C C I D : 2 A N M 3 H S 7 A B I C : 2 3 1 6 5 - H S 7 A B 1202602009

Page 1 of 6 Report No: C240111042-RF02 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 1.1310&2.1093 & RSS-102_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] RF Exposure Report Product name ......................... : Remote Controller Trademark ................................ : / Model no. .................................. : HS-7AB Series Model(s). ....................... : HS-7AB, HS-7A21, HS-7A21-00, HS-7A2X FCC ID ...................................... : 2ANM3HS7AB IC ............................................... : 23165-HS7AB HVIN .......................................... : HS-7AB Report No ................................. : C240111042-RF02 Test Standards ......................... : CFR47 FCC Part 2: Section 2.1093 CFR47 FCC Part 1: Section 1.1310 RSS-102 Issue 5 February 2021 Applicant .................................. : Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address of applicant ............... : 13F-16F, Unit A, Skyworth Building, Shennan Road,Nanshan District, Shenzhen, China Manufacturer ............................ : Shenzhen Chuangwei-RGB Electronics Co., Ltd. Manufacturer Address ............. : 13F-16F, Unit A, Skyworth Building, Shennan Road,Nanshan District, Shenzhen, China Date of Test Date ...................... : N/A Date of issue. ........................... : Mar 09,2024 Test result................................. : Compliance Reviewed By : Adil Yang Approved Signatory : Tom Gan The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CSIC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Page 2 of 6 Report No: C240111042-RF02 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 1.1310&2.1093 & RSS-102_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Table of Contents Page 1 TEST SUMMARY ....................................................................................................................................................... 3 1.1 TEST FACILITY .............................................................................................................................................................. 3 2 GENERAL INFORMATION .......................................................................................................................................... 4 2.1 GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 4 3 MAXIMUM PERMISSIBLE EXPOSURE (MPE) .............................................................................................................. 5 3.1 RF EXPOSURE .............................................................................................................................................................. 5 Page 3 of 6 Report No: C240111042-RF02 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 1.1310&2.1093 & RSS-102_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] 1 TEST SUMMARY 1.1 Test Facility Shenzhen Central Standard International Center Co., Ltd. (CSIC) Room 201, Building 1, Mogen Fashion Industrial Park, No. 10, Shilongzai Road, Xinshi Community, Dalang Street, Longhua District, Shenzhen. The test facility is recognized, certified or accredited by the following organizatios: CNAS Registration No.: L11671 FCC Registration No.: 0031378433 Designation Number: CN1317 IC CAB identifier: CN0051 A2LA Lab Cert. No.: 6426.01 Page 4 of 6 Report No: C240111042-RF02 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 1.1310&2.1093 & RSS-102_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] 2 GENERAL INFORMATION 2.1 General Description of EUT Product information Product Name: Remote Controller Trademark: / Model No: HS-7AB Series Model: HS-7AB, HS-7A21, HS-7A21-00, HS-7A2X Power supply: DC 3V for 2*AAA Battery Hardware version: HOF-44Q-CW44TLS V1.0 Software version: 220055030601002303152555240103 Technical Specification of Bluetooth LE Frequency Range: 2402 MHz to 2480 MHz Type of Modulation: GFSK Channel Number: 40 channels Data Rate: 1 Mbps, 2 Mbps Channel Separation: 2 MHz Antenna type: PCB antenna Antenna gain: 1.5dBi Remark: Remark：The above information and materials are provided by the Manufacturer. and full tests were applied to the sample(C240111042-Y01/01) only in this document. Page 5 of 6 Report No: C240111042-RF02 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 1.1310&2.1093 & RSS-102_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] 3 Maximum Permissible Exposure (MPE) 3.1 RF Exposure 3.1.1 Limit The limit for Maximum Permissible Exposure (MPE) specified in FCC 1.1310 and RSS-102 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio frequency (RF) radiation as specified in 1.1307 (b). According to RSS-102: The criteria listed in the following table shall be used to evaluate the environmental impact of the human exposure to radio frequency (RF) radiation as specified in 2.5.2 For FCC: Frequency Range Electric Field Strength Magnetic Field Strength Power…

Text truncated - open the document above for the full version.

Manufacturer：Fujian Putian xinhongyi Electronic Technology Co., Ltd. Address：High tech Development Zone,Hanjiang District, Putian City, Fujian Province (No. 1289, shiting East Road) 1: Antenna model：Inverted F antenna（IFA） 2：Antenna type：PCB antenna 3：Gain：1.5dBi 4：The antenna size is shown in Figure 1 Figure 1 18.2*5.5mm 5：Antenna efficiency Freq （MHz） Effi （%） Effi （dB） Gain （dBi） 2400 36.8 -4.3 0.8 2410 40.3 -3.9 1.3 2420 40.4 -3.8 1.4 2430 41.6 -3.8 1.5 2440 40.5 -3.7 1.4 2450 40.7 -3.7 1.4 2460 41.2 -3.8 1.5 2470 40.0 -4 1.4 2480 38.0 -4.2 1.1 2490 35.9 -4.5 0.9 2500 34 -4.7 0.7 6. The antenna performance is shown in Figure 2.The working frequency band covers the entire 2.4G ISM frequency band。 Figure 2 7：2D and 3D antenna gains are shown in Figures 3 and 4，reaching around 1.5dBi： Figure 3 2D antenna efficiency Figure 4 3D Antenna effiiciency

Page 1 of 17 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Appendix A: Test Results of BLE Table of Contents Page APPENDIX A.1 TEST RESULTS OF RADIATED SPURIOUS EMISSION ................................................................................. 2 APPENDIX A.2 TEST RESULTS OF CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH .................. 7 APPENDIX A.3 TEST RESULTS OF CONDUCTED POWER SPECTRAL DENSITY .................................................................. 12 APPENDIX A.4 TEST RESULTS OF 6DB AND 99% BANDWIDTH ...................................................................................... 14 APPENDIX A.5 TEST RESULTS OF MAXIMUM CONDUCTED POWER .............................................................................. 17 Page 2 of 17 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Appendix A.1 Test Results of Radiated Spurious Emission All modes have been tested, and the report only reflects the worst mode Below 1GHz： Test Mode: Mode 1(worst mode) Horizontal Vertical Page 3 of 17 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Above 1GHz： All modes have been tested, and the report only reflects the worst mode(1Mbps) GFSK-Low Horizontal No. Frequency Reading Correct Result Limit Margin Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) 1 4808 71.44 -21.5 49.94 74 -24.06 peak 2 4808 61.36 -21.5 39.86 54 -14.14 AVG 3 6202 67.82 -19.16 48.66 74 -25.34 peak 4 6202 53.72 -19.16 34.56 54 -19.44 AVG 5 9058 64.67 -17.79 46.88 74 -27.12 peak 6 9058 50.49 -17.79 32.7 54 -21.3 AVG 7 14090 64.72 -14.13 50.59 74 -23.41 peak 8 14090 49.15 -14.13 35.02 54 -18.98 AVG 9 15008 63.71 -12.4 51.31 74 -22.69 peak 10 15008 48.88 -12.4 36.48 54 -17.52 AVG 11 15722 64.42 -12.33 52.09 74 -21.91 peak 12 15722 49.47 -12.33 37.14 54 -16.86 AVG GFSK-Low Vertical No. Frequency Reading Correct Result Limit Margin Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) 1 4808 71.98 -21.5 50.48 74 -23.52 peak 2 4808 60.45 -21.5 38.95 54 -15.05 AVG 3 6202 66.78 -19.16 47.62 74 -26.38 peak 4 6202 52.64 -19.16 33.48 54 -20.52 AVG 5 10588 63.93 -16.74 47.19 74 -26.81 peak 6 10588 51.3 -16.74 34.56 54 -19.44 AVG 7 13444 64.65 -15.18 49.47 74 -24.53 peak 8 13444 49.24 -15.18 34.06 54 -19.94 AVG 9 15382 64.54 -12.36 52.18 74 -21.82 peak 10 15382 48.65 -12.36 36.29 54 -17.71 AVG 11 16776 65.44 -12.07 53.37 74 -20.63 peak 12 16776 49.09 -12.07 37.02 54 -16.98 AVG GFSK- Middle Horizontal No. Frequency Reading Correct Result Limit Margin Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) 1 4880 63.27 -13.4 49.87 74 -24.13 peak 2 4880 53.26 -13.4 39.86 54 -14.14 AVG 3 6202 58.91 -10.93 47.98 74 -26.02 peak 4 6202 43.08 -10.93 32.15 54 -21.85 AVG 5 7426 57.77 -10.79 46.98 74 -27.02 peak 6 7426 42.08 -10.79 31.29 54 -22.71 AVG 7 9058 57.29 -10.31 46.98 74 -27.02 peak 8 9058 42.16 -10.31 31.85 54 -22.15 AVG 9 12458 54.86 -6.37 48.49 74 -25.51 peak 10 12458 39.83 -6.37 33.46 54 -20.54 AVG 11 15382 51.56 -0.7 50.86 74 -23.14 peak 12 15382 36.11 -0.7 35.41 54 -18.59 AVG Page 4 of 17 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] GFSK-Middle Vertical No. Frequency Reading Correct Result Limit Margin Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) 1 4880 52.4 -13.4 39 54 -15 AVG 2 4910 63.41 -13.16 50.25 74 -23.75 peak 3 6236 59.07 -11.11 47.96 74 -26.04 peak 4 6236 43.26 -11.11 32.15 54 -21.85 AVG 5 7562 57.41 -10.71 46.7 74 -27.3 peak 6 7562 42.49 -10.71 31.78 54 -22.22 AVG 7 10418 55.97 -8.71 47.26 74 -26.74 peak 8 10418 41.4 -8.71 32.69 54 -21.31 AVG 9 13886 54.11 -4.09 50.02 74 -23.98 peak 10 13886 39.51 -4.09 35.42 54 -18.58 AVG 11 15008 52.94 -1.62 51.32 74 -22.68 peak 12 15008 37.71 -1.62 36.09 54 -17.91 AVG GFSK-High Horizontal No. Frequency Reading Correct Result Limit Margin Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) 1 4960 52.67 -13.26 39.41 54 -14.59 AVG 2 4978 61.92 -13.31 48.61 74 -25.39 peak 3 6202 57.46 -10.93 46.53 74 -27.47 peak 4 6202 42.78 -10.93 31.85 54 -22.15 AVG 5 12458 54.53 -6.37 48.16 74 -25.84 peak 6 12458 39.83 -6.37 33.46 54 -20.54 AVG 7 13920 53.54 -4.04 49.5 74 -24.5 peak 8 13920 38.56 -4.04 34.52 54 -19.48 AVG 9 15280 51.97 -0.95 51.02 74 -22.98 peak 10 15280 37.74 -0.95 36.79 54 -17.21 AVG 11 16742 52.68 0.7 53.38 74 -20.62 peak 12 16742 36.38 0.7 37.08 54 -16.92 AVG GFSK-High Vertical No. Frequency Reading Correct Result Limit Margin Remark (MHz) (dBuV) Factor(dB/m) (dBuV/m) (dBuV/m) (dB) 1 4960 52.31 -13.26 39.05 54 -14.95 AVG 2 4978 62.25 -13.31 48.94 74 -25.06 peak 3 6202 59.45 -10.93 48.52 74 -25.48 peak 4 6202 44.34 -10.93 33.41 54 -20.59 AVG 5 7018 58.65 -11.57 47.08 74 -26.92 peak 6 7018 44.32 -11.57 32.75 54 -21.25 AVG 7 12458 54.43 -6.37 48.06 74 -25.94 peak 8 12458 39.66 -6.37 33.29 54 -20.71 AVG 9 13920 53.49 -4.04 49.45 74 -24.55 peak 10 13920 38.9 -4.04 34.86 54 -19.14 AVG 11 15756 52.64 -0.15 52.49 74 -21.51 peak 12 15756 37.04 -0.15 36.89 54 -17.11 AVG Page 5 of 17 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Node: 1、 Testing was carried out within frequency range 9kHz to the tenth harmonics. The measurement results below 30MHz and 18GHz - 26.5GHz were greater than 20dB below the limit, so only the radiated spurious emissions from 30MHz to 18GHz were reported.. 2、 Radiated emissions measured in frequency above 1GHz were made with an instrument …

Text truncated - open the document above for the full version.

Page 1 of 28 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Test Report Product name .......................... : Remote Controller Trademark ................................ : / Model no. .................................. : HS-7AB Series Model(s). ....................... : HS-7AB, HS-7A21, HS-7A21-00, HS-7A2X FCC ID ...................................... : 2ANM3HS7AB IC ............................................... : 23165-HS7AB HVIN .......................................... : HS-7AB Report No ................................. : C240111042-RF01 Test Standards ......................... : CFR47 FCC Part 15: Subpart C Section 15.247 CFR47 FCC Part 15: Subpart C Section 15.207 CFR47 FCC Part 15: Subpart C Section 15.209 RSS-247 Issue 3 RSS-Gen Issue 5 Applicant .................................. : Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address of applicant ............... : 13F-16F, Unit A, Skyworth Building, Shennan Road,Nanshan District, Shenzhen, China Manufacturer ............................ : Shenzhen Chuangwei-RGB Electronics Co., Ltd. Manufacturer Address ............. : 13F-16F, Unit A, Skyworth Building, Shennan Road,Nanshan District, Shenzhen, China Date of Test Date ...................... : Jan 11,2024 to Mar 14,2024 Date of issue. ........................... : Mar 14,2024 Test result................................. : Compliance Testing Engineer : Jeff Fang Reviewed By : Adil Yang Approved Signatory : Tom Gan The test results in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CSIC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. Page 2 of 28 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Revision History Rev. Issue Date Revisions Effect Page Revised By 00 Mar.14, 2024 Initial Issue ALL Adil Yang Page 3 of 28 Report No: C240111042-RF01 Shenzhen Central Standard International Center Co., Ltd. TRF_FCC Part 15.247 & RSS-247_Rev.01 Tel.: (86)0755-85283385 www.csicsz.com Email: [email protected] Table of Contents Page 1. TEST SUMMARY ..................................................................................................................................................... 4 1.1. TEST DESCRIPTION ................................................................................................................................................ 4 1.2. TEST FACILITY ........................................................................................................................................................ 5 1.3. MEASUREMENT UNCERTAINTY ............................................................................................................................ 5 2. GENERAL INFORMATION ....................................................................................................................................... 6 2.1. GENERAL DESCRIPTION OF EUT ............................................................................................................................ 6 2.2. DESCRIPTION OF TEST MODES AND TEST FREQUENCY ......................................................................................... 7 2.3. MEASUREMENT INSTRUMENTS LIST .................................................................................................................... 8 2.4. DESCRIPTION OF THE TEST MODES ..................................................................................................................... 10 2.5. TEST SOFTWARE AND POWER LEVEL .................................................................................................................. 11 2.6. BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED ............................................................... 11 2.7. DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS ..................................................................... 12 2.8. ENVIRONMENTAL CONDITIONS FOR TESTING .................................................................................................... 12 3. EMC TEST ............................................................................................................................................................. 13 3.1. CONDUCTED EMISSION ON AC MAINS MEASUREMENT .................................................................................................. 13 3.2. RADIATED SPURIOUS EMISSION MEASUREMENT ............................................................................................................ 15 3.3. CONDUCTED SPURIOUS EMISSIONS MEASURED IN 100 KHZ BANDWIDTH MEASUREMENT .................................................... 20 3.4. CONDUCTED POWER SPECTRAL DENSITY MEASUREMENT ................................................................................................ 21 3.5. 6DB BANDWIDTH MEASUREMENT .......................................................................................................................... 22 3.6. MAXIMUM CONDUCTED OUTPUT POWER MEASUREMENT .............................................................................................. 24 3.7. ANTENNA REQUIREMENT ................................................................................................................................... 26 4. TEST PHOTOS ....................................................................................................................................................... 27 5. EUT PHOTOS .....................................................................................................................................................…

Text truncated - open the document above for the full version.
