2ANM3T8812C1WIFI Module

Shenzhen Chuangwei-RGB Electronics Co., Ltd. Model: T8812C1 Operation Instruction Respect of customer, sincerely thank you for purchasing SKYWORTH equipped with wireless Wi-Fi T8812C1 - type USB peripheral products. This product can support USB2.0 protocol, based on the IEEE802.11 a/b/g/n/ac standard design. With all the way to send and receive all the way (2T2R) dual channel work, maximum transmission rate of up to 866.7 Mbps.Ensure that users browse and download data flow, security and stability. T8812C1 wireless Wi-Fi USB peripheral product support Windows XP/Vista / 7 / Linux operating system.In SKYWORTH TV, have complete embedded in the product and the driver, without user to install, and at the same time support Linux and Android. Used in TV production operation is as follows: 1.Turn on the TV, switch to the "home page" interface; 2.Select "Settings" feature. "OK" to enter; 3.Select "network setup" function. "OK" to enter; 4.Choose the "wireless network", "OK" to enter; 5.According to the needs, select "auto search", "manual connection", etc. Press the "OK" to enter; 6.Choose their own after the AP name "OK" to enter, Enter the password; Television system has the memory function, for the first time to use should be according to the above steps, later need not operation, boot automatically connected. If need to change the AP or change the mode of connection, need according to the above steps again; FCC regulatory compliance statement §15.19 Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. §15.21 Information to user Warning: changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. #List of applicable FCC Rules: 47 CFR Part 15, Subpart C 15.247 47 CFR Part 15, Subpart E 15.407 47 CFR Part 2.1091 #Summarize the specific operational use conditions This module can be used in IOT devices, the input voltage to the module is nominally 3.3V. #Limited module procedures This module is not a limited module. #Trace antenna designs The antenna is not a trace antenna. #RF Exposure compliance statement This Module complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. # Antenna Change Notice to Host manufacturer If you desire to increase antenna gain and either change antenna type or use same antenna type certified, a Class II permissive change application is required to be filed by us, or you (host manufacturer) can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application. § 15.19 Labelling requirements shall be complied on end user device. Labelling rules for special device, please refer to §2.925, § 15.19 (a)(5) and relevant KDB publications. For E-label, please refer to §2.935. #Labelling Instruction for Host Product Integrator Please notice that if the FCC identification number is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording such as the following: “Contains FCC ID: 2ANM3T8812C1” any similar wording that expresses the same meaning may be used. #Information on test modes and additional testing requirements The OEM integrator is responsible for ensuring that the end-user has no manual instruction to remove or install module. The module is limited to installation in mobile application, a separate approval is required for all other operating configurations, including portable configurations with respect to §2.1093 and difference antenna configurations. Test software access to different test modes: MP819xVC Testing item, Frequencies, Transmit Power, Modulation Type can be selected on the test script instructions. #FCC other Parts, Part 15B Compliance Requirements for Host product manufacturer This modular transmitter is only FCC authorized for the specific rule parts listed on our grant, host product manufacturer is responsible for compliance to any other FCC rules that apply to the host not covered by the modular transmitter grant of certification. Host manufacturer in any case shall ensure host product which is installed and operating with the module is in compliant with Part 15B requirements. Please note that For a Class B or Class A digital device or peripheral, the instructions furnished the user manual of the end-user product shall include statement set out in §15.105 Information to the user or such similar statement and place it in a prominent location in the text of host product manual. Original texts as following: For Class B Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequenc y energy and, if not installed and used in accordance with the instructions, may cautest softwarese harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: — Reorient or relocate the receiving antenna. —Increase…

Text truncated - open the document above for the full version.

Applicant Declaration QSF27-14-04 Rev 1.0 Rev. Feb 6, 2023 Page 1 of 1 Original Issue: Jan. 4, 2021 SGS North America Inc. 620 Old Peachtree Road SUITE 100 Suwanee, Georgia 30024 United States Applicant Legal Business Name Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address 13F-16F,Unit A,Skyworth Building,Shennan Road, Nanshan District,Shenzhen 518108 China Grantee Code 2ANM3 FCC ID 2ANM3T8812C1 Authorized Contact Name Dan Fang Contact Email [email protected] Contact Phone +86-18820267050 I, the undersigned, certify that I am an authorized signatory for the Applicant and therefore declare; a) in accordance with 47CFR2.911(d), all of the statements herein and the exhibits attached hereto are true and correct to the best of my knowledge and belief. b) in accepting a Grant of Equipment Authorization issued by a TCB, under the authority of the FCC, as a result of the representations made in this application, the Applicant is responsible for: (1) labeling the equipment with the exact FCC ID as specified in this application, (2) compliance statement labeling pursuant to the applicable rules, (3) compliance of the equipment with the applicable technical rules, c) if the Applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC’s technical requirements. d) in accordance with 47 CFR 2.909 and KDB394321, the Applicant has read, understood and agrees to accept that they are the responsible party and agree to abide by their responsibilities as specified under 47 CFR 2.909 and KDB394321. e) in accordance with ISO 17065, FCC KDB641163, FCC KDB610077, KDB394321 and RSP-100, the Applicant has read, understood, accepts and agrees to abide by the post market surveillance requirements. (1) the Applicant understands, accepts and agrees that a sample may be requested for surveillance testing. (2) the Applicant shall make provisions to always have a production sample available upon request by SGS, FCC and/or ISED. (3) the Applicant shall, upon request by SGS, at the Applicant’s expense, provide a production sample of the requested product to SGS, FCC and/or ISED as instructed. The sample shall include all support devices, cables, software, accessories or other hardware or software required for evaluation, review, certification and audit surveillance of products certified by SGS. f) neither the Applicant nor any party to the application is subject to a denial of Federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. §862 because of a conviction for possession or distribution of a controlled substance. See 47CFR 1.2002(b) for the definition of a “party” for these purposes. g) the Applicant has read, understood, accepts and agrees to abide by the SGS North America, Inc.(TCB) terms and conditions. Link to CFRs: https://www.fcc.gov/wireless/bureau-divisions/technologies-systems-and-innovation-division/rules-regulations-title-47 Link to KDBs: https://apps.fcc.gov/oetcf/kdb/index.cfm Link to RSP-100: https://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf01130.html Link to the Covered List: Covered List [Shenzhen Chuangwei-RGB Electronics Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. [Shenzhen Chuangwei-RGB Electronics Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [ is not] identified on the Covered list, established pursuant to §1.50002, as an entity producing “covered” equipment. Applicant Signature: Date:2024-07-01 Print Name: Dan Fang Title: Manager *NOTE: This declaration cannot be signed by an Agent, it shall be signed by an authorized person listed in the FCC database

UNITED STATES DESIGNATED AGENT LETTER Date: 2024-03-11 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Colum bia, MID 21046 Applicant Company Name: Shenzhen Chuangwei-RGB Electronics Co., Ltd. U.S. designated agent Company Name: Skyworth USA Corporation FRN: 0026833426 Grantee Code: 2ANM3 Contact Name: Ms Carol Wang Contact Name: Dan Fang Address: 14586 Central Ave, Chino, CA 91710, United States Address: 13F-16F,Unit A,Skyworth City/Province/Zip: Building,Shennan Road, Nanshan District,Shenzhen 518108 China City/Province/Zip: T elephone: 626-408-0506 Telephone: +86-18820267050Fax: Fax: +86-755-27354190Email: [email protected] Email: [email protected] Applicable Equipment: FCC ID: 2ANM3T8812C1 ATTN: Director of Certification: W e, Shenzhen Chuangwei-RGB Electronics Co., Ltd. and Skyworth USA Corporation understand and acknowledge the applicants consent and the designated agent’s obligation to accept service of process in t he United States for matters related to the applicable equipment, and at the physical U.S. address and e- mail of the designated agent listed above. We, Shenzhen Chuangwei-RGB Electronics Co., Ltd. and Skyworth USA Corporation acknowledge the applicant’s acceptance of its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. Applicant U.S. designated agent Name (Printed): Dan Fang Name (P rinted): Ms Carol Wang Title: Manager Title: Manager Signature: Sig nature: 03/11/2024

Shenzhen Chuangwei-RGB Electronics Co., Ltd. Date: 2024-07-01 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: FCC ID: 2ANM3T8812C1 To whom it may concern: We, the undersigned, hereby authorize SGS-CSTC Standards Technical Services Co., Ltd. (SGS) to act on our behalf in all manners relating to application for equipment authorization with respect to the FCC ID above, including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides with Shenzhen Chuangwei-RGB Electronics Co., Ltd. This authorization is valid until further written notice from the applicant. Print Name: Dan Fang Title:Manager Signature: On behalf of Company: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Telephone: +86-18820267050 E-mail: [email protected]

Shenzhen Chuangwei-RGB Electronics Co., Ltd. TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding: Confidentiality Request regarding application for FCC ID: 2ANM3T8812C1 LONG TERM CONFIDENTIALITY Pursuant to 47 CFR Section 0.459 and 0.457 of the commission’s rules, the applicant hereby request confidential treatment of the documents listed below, associated with the certification application referenced above. Schematic(s) Block Diagrams Operational Descriptions Software Security Description The documents above contain proprietary information not released to the public. Public disclosure of this information may prove harmful to the business of the applicant. SHORT TERM CONFIDENTIALITY Additionally, the applicant requests the following documents be held confidential until the device is marketed or 0 days from the grant date, whichever is less. If the device is marketed within 0 days of the Grant Date, the applicant will notify the TCB per FCC KDB 726920 D01 Confidentiality Request Procedures. Delete any document that is NOT included in your application External Photos Internal Photos Test Setup Photos User manual(s) Sincerely, Print Name: Dan Fang Title:Manager Signature: On behalf of Company: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Telephone: +86-18820267050 E-mail: [email protected]

Shenzhen Chuangwei-RGB Electronics Co., Ltd. Cover Letter-Modular Approval FCC ID: 2ANM3T8812C1 Date: 2024-06-27 Gentlemen: There’s an WIFI Module that would like to have your authorization as a modular approval. The specific product as below, WIFI Module with its designed features and specified description, meets special requirements for Full modular approval on FCC KDB996369 by cross-reference list below. Company Shenzhen Chuangwei-RGB Electronics Co., Ltd. Model Name WIFI Module Model Number T8812C1 FCC ID 2ANM3T8812C1 Requirement of FCC KDB996369 Comply（Y/N） 1. The modular transmitter must have its own RF shielding. Y The EUT provides the RF shielding. See EUT photo. 2. The modular transmitter must have buffered modulation/data inputs (if such inputs are provided) to ensure that the module will comply with Part 15 requirements under conditions of excessive data rates or over-modulation. Y The EUT has its buffered modulation. Please see the Schematic Diagram. 3. The modular transmitter must have its own power supply regulation. Y The EUT has its own power supply regulation, please see the Schematic Diagram. 4. The modular transmitter must comply with the antenna and transmission system requirements of Sections 15.203, 15.204(b) and 15.204(c). The antenna must either be permanently attached or employ a “unique” antenna coupler (at all connections between the module and the antenna, including the cable). The “professional installation” provision of Section 15.203 is not applicable to modules but can apply to limited modular approvals under paragraph (b) of this section. Y The EUT meets the FCC antenna requirements; unique antenna connector and photo of antenna are shown in the test report. 5. The modular transmitter must be tested in a stand‐ alone configuration, i.e., the module must not be inside another device during testing. Y The EUT was tested with a test board, Please see test report and setup photo 6. The modular transmitter must be labeled with its own FCC ID number, and, if the FCC ID is not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module. This exterior Y Please see exhibition label sample for the FCC ID of this module. And also in the exhibition Users manual, there are instructions give to the OEM on how to label the end product. Shenzhen Chuangwei-RGB Electronics Co., Ltd. label can use wording such as the following: “Contains Transmitter Module FCC ID:2ANM3T8812C1” or “Contains FCC ID: 2ANM3T8812C1” Any similar wording that expresses the same meaning may be used. The Grantee may either provide such a label, an example of which must be included in the application for equipment authorization, or, must provide adequate instructions along with the module which explain this requirement. In the latter case, a copy of these instructions must be included in the application for equipment authorization. 7. The modular transmitter must comply with any specific rule or operating requirements applicable to the transmitter and the manufacturer must provide adequate instructions along with the module to explain any such requirements. A copy of these instructions must be included in the application for equipment authorization. Y The EUT is compliant with all applicable FCC rules. Details instructions for maintaining compliance are give in the User Manual. 8. The modular transmitter must comply with any applicable RF exposure requirements. For example, FCC Rules in Sections 2.1091, 2.1093 and specific Sections of Part 15, including 15.319(i), 15.407(f), 15.253(f) and 15.255(g), require that Unlicensed PCS, UNII and millimeter wave devices perform routine environmental evaluation for RF Exposure to demonstrate compliance. In addition, spread spectrum transmitters operating under Section 15.247 are required to address RF Exposure compliance in accordance with Section 15.247(b)(4). Y The EUT complies with RF exposure requirement. Thank you. Sincerely, Print Name: Dan Fang Title:Manager Signature: On behalf of Company: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Telephone: +86-18820267050 E-mail: [email protected]

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 3 External Photos for SZCR2311003756AT FCC ID: 2ANM3T8812C1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 3 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 3

SIZE:1.8cm*1.4cm

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 2 Internal Photos for SZCR2311003756AT FCC ID: 2ANM3T8812C1 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 2 EUT Constructional Details (EUT Photos) - End of the Appendix -

創 維 集 團 有 限 公 司 SKYWORTH (GROUP) CO., LTD. ENGINEERING EVALUATION REPORT (COMPONENTS) REPORT NO. : EDE2110025 SAMPLE IS : MODEL :  NEW PARTS DATE COMPLETED : 2021-10-13  1 st SUBMISSION QTY SUBMITTED :  2 nd SUBMISSION DESCRIPTIONS :  ALTERNATE SOURCE On- board antenna 2.4~5.8GHz 10mm 6mm 6mm Stainless steel SMD type 85°C REACH RoHS Universal  OTHER REMARKS SPECIFICATION ATTACHED  YES  NO REMARKS : SUPPLIER’S PART NO. : OUR PARTS NO. : N012101-000025-001 SUPPLIER : MANUFACTURER : 东莞市泰康电子科技有限公司 TEST RESULT :  APPROVED  REJECTED  CONDITIONALLY APPROVED : SEE ITEMS LISTED BELOW TEST ENGINEERS : 余佳喜 COMMENTS : . 1. 所有壞料包退換。 2.如有因元件質量問題而引起的損失，元件生產廠家需負全責。 3.请在内/外包装箱上打印我公司物料编号:N012101-000025-001。 IF CONDITIONALLY APPROVED :  (a) SUPPLIER IS REQUESTED TO SUBMIT _________ PIECES SAMPLES AGAIN.  (b) FOR PURCHASING TO BUY _________ PIECES FOR PILOT PRODUCTION. TESTED BY ENGINEER (S) APPROVED BY ENGINEERING MANAGER ELECTRICAL Rm. 1601-04 Westlands Centre, 20 Westlands Road, Quarry Bay, H.K. Tel: 2856 3138 SKYWO HX Fax:2586 3590 东莞市泰康电子科技有限公司版本号：V2.0 （DONGGUAN TECONN ELECTRONICS TECHNOLOGY CO .,LTD. ） 规格书 SPECIFICATION FOR APPROVAL 供应商名称： SUPPL IER： 东莞市泰康电子科技有限公司 制造商名称名称： MANUFACTURER： 东莞市泰康电子科技有限公司 客户名称： CUSTOMER： 深圳创维-RGB电子有限公司 SHENZHEN CHUANGWEI-RGB ELECTRONICS CO., LTD 部品名称： PARTNAME： U型天线固定片 产品型号： SPEC TYPE： W300232-B-0N-R 创维物料编码： SKYWORTHPART NO： 规格描述： SPECIFICATIONSICES： 制表日期： D A T E： 2021.09.17 承制方名称（盖章）：东莞市泰康电子科技有限公司 地址： 广东省东莞市虎门镇太安路虎门段 29 号 7 栋 电话：86-769-85322066传真：86-769-85440789 网址: www.teconn.com.cn E-MAIL: [email protected] 承制方 MANUFACTURER 拟 制 DRAFTER 审核 CHECK 批准 APPROVER 雍丽江 韩锋辉 李胡彬 目录 1.工程图 ...............................................................................................................4 2.材料清单 ...............................................................................................................5 3. 产品规格书 ............................................................................................................6-13 4. 产品测试报告......................................................................................................... 14-17 5. 产品包装图 ............................................................................................................18-19 6. Reach 及 RoHS2.0 符合声明.......................................................................................20 7. 有害物质含量声明表 ................................................................................................21 8. 进出口料报关信息表 .............................................................................................22-23 更 改 记 录 版 本更改日期更改原因（内容）更改提出者 确认者 1.0 2021.09.17 新版发行雍丽江 张景 1.原材料清单 序号 部件名称材料 材料规格 产地供方名称（或代理商） 1 SUS201 中国深圳市鑫普金属材料有限公司 2 镀镍层 中国东莞市顺航金属制品有限公司 U型天线固定片 固定片 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 1 - SPECIFICATION 规格书 Customer Name 创维 Product name U 型天线固定片 4.4 款 Product number W300232-B-0N-R Customer P/N : Prepared By 张景 Date 2021年09月17日 频率范围Frequency range 2400~2500 5200-5800（MHz） 驻波比系数VSWR <3.0 输入阻抗Input Impedance 50±5（Ω） 极化方式Polarization 垂直极化 Vertical Polarization 半功率波束（3dB）HPW180°H-plane 120°E-plane Antenna Type:PIFA 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 2 - Revision History 1 Technical Summary This report summarizes the electrical results of the proposed antenna to support the W300232-B-0N-R 2.4~5.8G Antenna program. We test the antenna with the latest version handset. And it seems to be acceptable. 2 General Description 2.1 Components/Part revisions VSWR: Voltage Standing Wave Rate. 3 Mechanical Description 4 Electrical Performance 4.1 Set-up 4.1.1 VSWR VSWR measurements (S11) were performed using an Agilent 8753D Network Analyzer and the previously described test fixture. Coaxial chokes were used to mitigate surface currents on the outside of the cabling. The testing was performed in free space. 4.1.2 Gain & Radiation Patterns The gain of the antenna was measured in the HT’s anechoic chamber. Coaxial chokes on the feed cable were used to mitigate surface currents. The chamber provides less than –30 dB reflectivity from 800 MHz through 3 GHz and an 18” diameter spherical quite zone. The measurement results are calibrated using both dipole and leaky wave horn standards. 4.1.3 Matching Circuit Description No changed.. DateRevision Description of Changes 2021-08-19 RA Measured with 2.4G Antenna sample. 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 3 - 4.2 Measurement Data 4.2.1 Active result(BT天线) Passive Test For wifi 2.4G Freq Effi Gain (MHz) (%%) (dBi) 240045.182.19 241046.052.4 242047.572.55 243048.292.68 244050.143.09 245051.83.14 246050.463.11 247048.952.91 248046.752.58 249045.462.26 250044.262.11 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 4 - Passive Test For WIFI 5G Freq Effi Gain (MHz) (%) (dBi) 520043.372.11 525042.352.02 530045.482.35 535050.823.08 540051.43.14 545049.492.72 550048.042.67 555047.352.53 560045.322.39 565050.033.03 570051.493.28 575047.282.55 5 85046.472.46 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 5 - 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 6 - 5 Plots 5.1 SWR 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 7 - S11 东莞市泰康电子科技有限公司 Dongguan Teconn Electronics Technology Co., Ltd. Dongguan Teconn Electronics Technology Co., Ltd. 地址: 东莞市虎门镇358省道虎门路段村头村58号 - 8 - 隔离度 6 Mechanical drawing 7 Reliability tests 7.1 Test content N o 试验项目 试验方法 判定基准 1 盐水喷雾试验 把盐浓度5%的溶液喷雾 24H 不能有变色…

Text truncated - open the document above for the full version.

SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231100375601 Page: 1 of 165 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2311003756AT Applicant: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address of Applicant: 13F-16F, Unit A, Skyworth Building, Shennan Road, Nanshan District, Shenzhen 518108 China Manufacturer: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address of Manufacturer: 13F-16F, Unit A, Skyworth Building, Shennan Road, Nanshan District, Shenzhen 518108 China Factory: Shenzhen Chuangwei-RGB Electronics Co., Ltd. Address of Factory: 13F-16F, Unit A, Skyworth Building, Shennan Road, Nanshan District, Shenzhen, China Equipment Under Test (EUT): EUT Name: WIFI Module Model No.: T8812C1 Trade Mark: Philco, Noblex, BGH, Sharp, skyworth FCC ID: 2ANM3T8812C1 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-11-22 Date of Test: 2023-11-28 to 2023-12-26 Date of Issue: 2023-12-28 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231100375601 Page: 2 of 165 Revision Record Version Chapter Date Modifier Remark 01 2023-12-28 Original Authorized for issue by: Bill Chen/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231100375601 Page: 3 of 165 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.2 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/1 Report No.: SZCR231100375601 Page: 4 of 165 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 6 4.3 Measurement Uncertainty .................................................................................................................. 6 4.4 Test Location ...................................................................................................................................... 8 4.5 Test Facility ........................................................................................................................................ 8 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ...............................................................................…
