2ANMU-C36SPUTSmart Phone

C36 Industrial Park, No. 20, Dafu Industrial Zone, Kukeng Community, Guanlan Street, Longhua District, Shenzhen China Manufacturer Address:202, Building A2, Silicon Valley Power Intelligent Terminal Light Sensing+ Distance Sensing MIC hole horn hole Quick ChargerTYPE-CSIM card pin C36 flash Sub camera cato Fingerprint Scanner Power key FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. FCC/IC RF Radiation Exposure and SAR Statements The Smart Phone C36 has been tested for body-worn Specific Absorption Rate(SAR) compliance. The FCC/IC has established detailed SAR requirements and has established that these requirements. RF Exposure Information The radio module has been evaluated under FCC Bulletin C95.1 and IEEE 1528 and found to be compliant to RF Exposure from radio frequency devices. This model meets the applicable government requirements for exposure to radio frequency waves. The highest reported SAR level for usage near the body (10mm) is 0.565 W/kg, Body simultaneous transmission is 0.923W/kg at the same time.SAR level for usage near the Head is 1.006 W/kg and Head simultaneous transmission is 1.453 W/kg ，SAR level for usage near the Hotspot is 0.573W/kg and Hotspot simultaneous transmission is 0.892 W/kg

SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD 2.911 (d)(5)(i) Equipment Type Attestation v1.2 Section 2.911(d)(5)(i) Certification – Equipment Type Company name: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN, 518XXX China Product Name: Smart Phone FCC ID: 2ANMU-C36SPUT Model(s): C36 S,C36 Pro,C36 Ultra 2.911(d)(5)(i) Equipment Type We, [SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD] (“the applicant”) certify that the equipment for which authorization is sought through certification is not:  Prohibited from receiving an equipment authorization pursuant to § 2.903; of the FCC rules.  Identified as an equipment type in the “Covered List” NOTE 1 Yours sincerely, Name: Date: 2023.8.28 Gaolei Yan Title and Company name: Manager/ SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD NOTE 1 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD 2.911 (d)(5)(ii) Applicant Attestation v1.2 Section 2.911(d)(5)(ii) Certification – Applicant (Covered List ) Company name: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN, 518XXX China Product Name: Smart Phone FCC ID: 2ANMU-C36SPUT Model(s): C36 S,C36 Pro,C36 Ultra 2.911(d)(5)(ii) Applicant filing We, [SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD] (“the applicant”) certify that, as of the date of the filing of the application, the applicant is not identified NOTE 1 on the “Covered List” NOTE 2, established pursuant to § 1.50002 of this chapter, as an entity producing covered communications equipment. Yours sincerely, Gaolei Yan Name: Date: 2023.8.28 Title and Company name: Manager/ SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD NOTE 1 Delete option not applicable to this application. NOTE 2 “Covered List”; is the List of Equipment and Services Covered By Section 2 of The Secure Networks Act, available at https://www.fcc.gov/supplychain/coveredlist References; 1) 986446 D01 Covered Equipment v01 https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=325672 2) Federal Register document 2022-28263 published on 02/06/23 https://www.federalregister.gov/documents/2023/02/06/2022-28263/protecting-against-national-security-threats-to-the-com munications-supply-chain-through-the

SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046, USA ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 2023-08-22 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less t han one year after t erminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Grantee Code: 2ANMU FCC ID : 2ANMU-C36SPUT Contact Name: Gaolei Yan Street Address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN China Telephone No: 0755-61156588 Email: [email protected] Applicant Signature: Date: 2023-08-22 Signed by (Printed Name/Title): Gaolei Yan /Manager

SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Authorization Company: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN, 518XXX China Product Name: Smart Phone Model Number(s): C36 S,C36 Pro,C36 Ultra Product Description: Smart Phone We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2023/08/28 Name: Gaolei Yan Title: Manager Company: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD

SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Subject; Request for Confidentiality FCC ID: 2ANMU-C36SPUT Date: 2023/09/12 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description BOM Tune-up Procedure software security operational description In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Gaolei Yan Title: Manager

SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Model Difference 2023/08/28 EUT NAME: Smart Phone FCC ID: 2ANMU-C36SPUT MODEL : C36, C36 S,C36 Pro,C36 Ultra All the model are the same circuit and RF module, except model names. Sincerely Client’s signature Client’s name / title : Gaolei Yan / manager Contact information / address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN, 518XXX China

External Photos

Size:40*20mm Smart Phone FCC ID: 2ANMU-C36SPUT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Label location

Internal Photos Antenna BT/WIFI Antenna Main GSM/WCDMA/LTE Antenna DIV GSM/WCDMA/LTE

No.：BCTC/RF-EMC-005 Page 1 of 242 Edition：B.0 1of 242 Edition：B.0 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2307096488-7E Applicant: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Product Name: Smart Phone Model/Type Ref.: C36 Tested Date: 2023-09-04 to 2023-09-11 Issued Date: 2023-09-21 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 2 of 242 Edition：B.0 2of 242 Edition：B.0 FCC ID: 2ANMU-C36SPUT The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Smart Phone Trademark: OUKITEL Model/Type Ref.: C36 C36 S, C36 Pro, C36 Ultra Applicant: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN, 518XXX China Manufacturer: SHENZHEN YUNJI INTELLIGENT TECHNOLOGY CO.,LTD Address: A2 2F BUILDING ENET NEW INDUSTRIAL PARK, DAFU INDUSTRIAL ZONE, GUANLAN, LONGHUA SHENZHEN, 518XXX China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2023-09-04 Sample tested Date: 2023-09-04 to 2023-09-11 Issue Date: 2023-09-21 SAR Max. Values is： 1.006 W/kg (1g) for Head 0.923 W/kg (1g) for Body 0.892 W/kg (1g) for Hotspot Test Standards: IEEE Std C95.1, 2019/ IEEE Std 1528™-2013/FCC Part 2.1093 Test Results: PASS Remark: This is SAR test report Tested by: Approved by: Approved by: Min Zhi Cheng/ Project Handler Zero Zhou/Reviewer Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 3 of 242 Edition：B.0 3of 242 Edition：B.0 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Standards ...................................................................................................... 6 3. Test Summary ....................................................................................................... 7 4. SAR Limits............................................................................................................. 8 5. Measurement Uncertainty ..................................................................................... 9 6. Product Information and Test Setup .................................................................... 10 6.1 Product Information ............................................................................................... 10 6.2 Test Setup Configuration ....................................................................................... 13 6.3 Support Equipment ................................................................................................ 13 6.4 Test Environment .................................................................................................. 13 7. Test Facility and Test Instrument Used ............................................................... 14 7.1 Test Facility ........................................................................................................... 14 7.2 Test Instrument Used ............................................................................................ 14 8. Specific Absorption Rate (SAR) .......................................................................... 16 8.1 Introduction ............................................................................................................ 16 8.2 SAR Definition ....................................................................................................... 16 9. SAR Measurement System ................................................................................. 17 9.1 The Measurement System ..................................................................................... 17 9.2 Probe ..................................................................................................................... 17 9.3 Probe Calibration Process ..................................................................................... 19 9.4 Phantom ................................................................................................................ 20 9.5 Device Holder ........................................................................................................ 20 10. Tissue Simulating Liquids .................................................................................... 21 10.1 Composition of Tissue Simulating Liquid ............................................................. 21 10.2 Limit ..................................................................................................................... 22 10.3 Tissue Calibration Result ..................................................................................... 23 11. System Check ..................................................................................................... 24 11.1 Purpose of System Performance Check .............................................................. 24 11.2 System Setup ...................................................................................................... 24 11.3 Validation Results ................................................................................................ 25 12. EUT Testing Position ........................................................................................... 26 12.1 Define Two Imaginary Lines on the Handset ....................................................... 26 12.2 Cheek Position .................................................................................................... 26 12.3 Tilted Position ..................................................................…

Text truncated - open the document above for the full version.

Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 46 of 242 Edition：B.0 Band Bandwidth (MHz) RB Size RB Position Modulation Channel 23017 23095 23173 Band12 1.4 1 #0 QPSK 23.09 23.25 23.32 1 #Mid 23.17 23.21 23.37 1 #Max 23.11 23.28 23.42 3 #0 23.16 23.20 23.37 3 #Mid 23.25 23.21 23.39 3 #Max 23.25 23.15 23.38 6 #0 22.64 22.78 22.95 1.4 1 #0 QAM16 23.38 22.69 23.81 1 #Mid 23.39 22.75 23.82 1 #Max 23.37 22.76 23.81 3 #0 22.78 22.67 22.92 3 #Mid 22.80 22.65 23.01 3 #Max 22.80 22.58 23.03 6 #0 22.02 21.77 21.89 Band Bandwidth (MHz) RB Size RB Position Modulation Channel 23025 23095 23165 Band12 3 1 #0 QPSK 23.06 23.31 23.40 1 #Mid 23.05 23.28 23.39 1 #Max 23.06 23.36 23.42 8 #0 22.63 22.72 22.81 8 #Mid 22.73 22.63 22.75 8 #Max 22.70 22.60 22.72 15 #0 22.65 22.75 22.85 3 1 #0 QAM16 23.68 22.73 22.91 1 #Mid 23.66 22.77 22.93 1 #Max 23.59 22.68 22.97 8 #0 21.97 21.76 21.86 8 #Mid 22.01 21.71 21.89 8 #Max 22.04 21.68 21.88 15 #0 22.16 21.76 21.94 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 47 of 242 Edition：B.0 Band Bandwidth (MHz) RB Size RB Position Modulation Channel 23035 23095 23155 Band12 5 1 #0 QPSK 23.11 23.19 23.05 1 #Mid 23.02 23.21 23.08 1 #Max 23.09 23.19 23.04 12 #0 22.65 22.67 22.78 12 #Mid 22.71 22.79 22.82 12 #Max 22.71 22.70 22.75 25 #0 22.64 22.69 22.84 5 1 #0 QAM16 22.82 22.80 23.33 1 #Mid 22.82 22.89 23.31 1 #Max 22.74 22.77 23.33 12 #0 22.05 21.48 21.77 12 #Mid 21.98 21.58 21.77 12 #Max 21.97 21.51 21.77 25 #0 22.20 21.74 21.95 Band Bandwidth (MHz) RB Size RB Position Modulation Channel 23060 23095 23130 Band12 10 1 #0 QPSK 23.19 23.15 23.10 1 #Mid 23.16 23.30 23.18 1 #Max 23.18 23.34 23.44 25 #0 22.76 22.58 22.80 25 #Mid 22.64 22.83 22.69 25 #Max 22.77 22.77 22.76 50 #0 22.76 22.69 22.67 10 1 #0 QAM16 23.81 23.45 23.19 1 #Mid 23.76 23.50 23.17 1 #Max 23.83 23.54 23.30 25 #0 21.97 21.74 21.79 25 #Mid 22.05 21.82 21.82 25 #Max 21.66 21.80 21.88 50 #0 22.09 21.87 21.78 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 48 of 242 Edition：B.0 Band Bandwidth (MHz) RB Size RB Position Modulation Channel 23755 23790 23825 Band17 5 1 #0 QPSK 23.07 22.99 23.21 1 #Mid 23.11 22.97 23.24 1 #Max 23.12 23.02 23.23 12 #0 22.75 22.71 22.70 12 #Mid 22.72 22.68 22.85 12 #Max 22.72 22.74 22.81 25 #0 22.73 22.81 22.75 5 1 #0 QAM16 22.35 23.24 22.83 1 #Mid 22.34 23.25 22.83 1 #Max 22.42 23.34 22.89 12 #0 21.57 21.62 21.68 12 #Mid 21.53 21.68 21.67 12 #Max 21.60 21.68 21.69 25 #0 21.69 21.80 21.99 Band Bandwidth (MHz) RB Size RB Position Modulation Channel 23780 23790 23800 Band17 10 1 #0 QPSK 23.10 23.16 23.19 1 #Mid 23.17 23.20 23.12 1 #Max 23.30 23.24 23.39 25 #0 22.66 22.65 22.87 25 #Mid 22.67 22.72 22.74 25 #Max 22.68 22.82 22.86 50 #0 22.74 22.82 22.88 10 1 #0 QAM16 23.73 23.51 23.14 1 #Mid 23.80 23.48 23.16 1 #Max 23.88 23.53 23.26 25 #0 21.52 21.79 21.72 25 #Mid 21.57 21.84 21.82 25 #Max 21.65 21.80 21.85 50 #0 21.64 21.85 21.76 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 49 of 242 Edition：B.0 WLAN 2.4G Mode Frequency Maximum Conducted Output Power Tune-up power (MHz) (dBm) (dBm) 802.11b 2412 10.19 12.0 2437 11.50 2462 10.95 802.11g 2412 10.09 11.5 2437 10.79 2462 10.82 802.11n20 2412 9.21 10.5 2437 9.86 2462 9.77 802.11n40 2422 8.53 9.5 2437 9.12 2452 8.95 Note: 1. When the same transmission mode configurations have the same maximum output power on the same channel for the 802.11 b/g/n modes, the channel in the lower order/sequence 802.11 mode (i.e. g, n) is selected. Therefore the SAR measurements performed for the 802.11b modes, as the lowest order modulation, cover 802.11g/n modes. 2. SAR is not required for the following 2.4 GHz OFDM conditions as the highest reported SAR for DSSS is adjusted by the ratio of OFDM to DSSS specified maximum output power and the adjusted SAR is ≤ 1.2 W/kg. 3. Per KDB 248227 D01 v02r02, For 802.11b DSSS SAR measurements ,when the reported SAR of the highest measured maximum output power channel for the exposure configuration is ≤ 0.8 W/kg, no further SAR testing is required for 802.11b DSSS in that exposure configuration. When the reported SAR is > 0.8 W/kg, SAR is required for that exposure configuration using the next highest measured output power channel. When any reported SAR is > 1.2 W/kg, SAR is required for the third channel; i.e., all channels require testing. Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 50 of 242 Edition：B.0 WLAN 5.1G Mode Frequency Maximum Conducted Output Power Tune-up power (MHz) (dBm) (dBm) 802.11a 5180 11.46 12.0 5200 11.05 5240 9.91 802.11n20 5180 10.13 10.5 5200 9.23 5240 9.40 802.11n40 5190 8.86 10.0 5230 9.56 802.11nac20 5180 9.99 10.5 5200 8.85 5240 9.96 802.11nac40 5190 8.97 10.0 5230 9.61 802.11nac80 5210 8.30 9.0 WLAN 5.8G Mode Frequency Maximum Conducted Output Power Tune-up power (MHz) (dBm) (dBm) 802.11a 5745 11.59 12.0 5785 10.70 5825 10.42 802.11n20 5745 10.44 11.0 5785 9.67 5825 9.46 802.11n40 5755 9.01 9.5 5795 8.54 802.11nac20 5745 10.49 11.0 5785 9.73 5825 9.38 802.11nac40 5755 9.48 10.0 5795 8.67 802.11nac80 5775 7.90 8.5 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 51 of 242 Edition：B.0 Bluetooth Modulation Frequency (MHz) Output Power (dBm) Tune-up power (dBm) 1-DH1 2402 -1.11 0.5 2441 -0.07 2480 0.08 2-DH1 2402 -0.17 2.0 2441 1.12 2480 1.33 3-DH1 2402 0.25 2.0 2441 1.50 2480 1.72 BLE Modulation Frequency (MHz) Output Power (dBm) Tune-up power (dBm) GFSK 1Mbps 2402 -0.72 1.0 2440 0.48 2480 0.69 GFSK 2Mbps 2402 -0.92 2440 0.27 2480 0.49 Note: Per KDB 447498 D01v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for1-g SAR and ≤ 7.5 for 10-g extremity SAR f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison Bluetooth Turn up Power (dBm) Bluetooth Turn u…

Text truncated - open the document above for the full version.

Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 80 of 242 Edition：B.0 15.2 SAR Test Graph Results SAR plots for the highest measured SAR in each exposure configuration, wireless mode and frequency band combination according to FCC KDB 865664 D02 Plot 1 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 0.81 Area Scan dx=12mm dy=12mm, Adaptative 1 max Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Left head Device Position Cheek Band GSM850 Channels Higher (251) Signal TDMA (Crest factor: 8.0) B. Permitivity Frequency (MHz) 848.800 Relative permitivity (real part) 42.930 Relative permitivity (imaginary part) 19.340 Conductivity (S/m) 0.920 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=-36.00, Y=-12.00 ; SAR Peak: 0.52 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.133 SAR 1g (W/Kg) 0.324 Variation (%) -0.317 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 4.00 9.00 14.00 19.00 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 81 of 242 Edition：B.0 SAR (W/Kg) 0.815 0.326 0.244 0.242 0.164 F. 3D Image 3D screen shot Hot spot position Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 82 of 242 Edition：B.0 Plot 2 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 0.81 Area Scan surf_sam_plan.txt Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Validation plane Device Position Body Band GPRS850_1TX Channels Lower (128) Signal Custom (Crest factor: 4.0) B. Permitivity Frequency (MHz) 824.200 Relative permitivity (real part) 42.930 Relative permitivity (imaginary part) 19.340 Conductivity (S/m) 0.920 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=8.00, Y=12.00 ; SAR Peak: 0.69 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.207 SAR 1g (W/Kg) 0.396 Variation (%) 1.902 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 0.681 0.517 0.341 0.200 0.096 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 83 of 242 Edition：B.0 F. 3D Image 3D screen shot Hot spot position Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 84 of 242 Edition：B.0 Plot 3 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 1.04 Area Scan dx=12mm dy=12mm, Adaptative 1 max Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Right head Device Position Cheek Band GSM1900 Channels Middle (661) Signal TDMA (Crest factor: 8.0) B. Permitivity Frequency (MHz) 1880.000 Relative permitivity (real part) 39.943 Relative permitivity (imaginary part) 13.408 Conductivity (S/m) 1.365 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=-25.00, Y=12.00 ; SAR Peak: 1.07 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.235 SAR 1g (W/Kg) 0.490 Variation (%) -2.050 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 0.938 0.693 0.446 0.310 0.257 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 85 of 242 Edition：B.0 F. 3D Image 3D screen shot Hot spot position Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 86 of 242 Edition：B.0 Plot 4 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 1.04 Area Scan surf_sam_plan.txt Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Validation plane Device Position Body Band GPRS1900_1TX Channels Middle (661) Signal Custom (Crest factor: 4.0) B. Permitivity Frequency (MHz) 1880.000 Relative permitivity (real part) 39.943 Relative permitivity (imaginary part) 13.408 Conductivity (S/m) 1.365 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=21.00, Y=47.00 ; SAR Peak: 0.65 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.149 SAR 1g (W/Kg) 0.367 Variation (%) 3.016 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 2.272 0.422 0.155 0.319 0.141 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 87 of 242 Edition：B.0 F. 3D Image 3D screen shot Hot spot position Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 88 of 242 Edition：B.0 Plot 5 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 1.04 Area Scan dx=12mm dy=12mm, Adaptative 1 max Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Right head Device Position Cheek Band Band2_WCDMA1900 Channels Higher (9538) Signal WCDMA (Crest factor: 1.0) B. Permitivity Frequency (MHz) 1907.600 Relative permitivity (real part) 40.990 Relative permitivity (imaginary part) 13.408 Conductivity (S/m) 1.427 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=-22.00, Y=18.00 ; SAR Peak: 1.19 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.203 SAR 1g (W/Kg) 0.383 Variation (%) -1076 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 4.00 9.00 14.00 19.00 SAR (W/Kg) 1.184 0.849 0.556 0.368 0.248 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 89 of 242 Edition：B.0 F. 3D Image 3D screen shot Hot spot position Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 90 of 242 Edition：B.0 Plot 6 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 1.04 Area Scan surf_sam_plan.txt Zoom Scan 7x7x7,dx=5mm dy=5mm dz=5mm Phantom Validation plane Device Position Body Band Band2_WCDMA1900 Channels Higher (9538) Signal WCDMA (Crest factor: 1.0) B. Permitivity Frequency (MHz) 1907.600 Relative permitivity (real part) 40.990 Relative permitivity (imaginary part) 13.408 Conductivity (S/m) 1.427 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=7.00, Y=12.00 ; SAR Peak: 0.99 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.147 SAR 1g (W/Kg) 0.295 Variation (%) 3.921 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 4.00 9.00 14.00 19.0…

Text truncated - open the document above for the full version.

Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 126 of 242 Edition：B.0 Plot 24 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 1.18 Area Scan surf_sam_plan.txt Zoom Scan 7x7x12,dx=4mm dy=4mm dz=2mm Phantom Validation plane Device Position Body Band IEEE 802.11a U-NII-1 Channels Lower (36) Signal IEEE802.a (Crest factor: 1.0) B. Permitivity Frequency (MHz) 5180.000 Relative permitivity (real part) 36.294 Relative permitivity (imaginary part) 16.130 Conductivity (S/m) 4.488 C. SAR Surface and Volume SURFACE SAR VOLUME SAR Maximum location: X=-19.00, Y=-19.00 ; SAR Peak: 1.27 W/kg D. SAR 1g & 10g SAR 10g (W/Kg) 0.199 SAR 1g (W/Kg) 0.309 Variation (%) 1.392 Horizontal validation criteria: minimum distance (mm) 0.000000 Vertical validation criteria: SAR ratio M2/M1 (%) 0.000000 E. Z Axis Scan Z (mm) 0.00 2.00 4.00 6.00 8.00 10.00 12.00 14.00 16.00 SAR (W/Kg) 1.210 0.658 0.323 0.142 0.057 0.022 0.009 0.004 0.003 Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 127 of 242 Edition：B.0 F. 3D Image 3D screen shot Hot spot position Report No：BCTC2307096488-7E No.：BCTC/RF-EMC-005 Page 128 of 242 Edition：B.0 Plot 25 A. Experimental conditions. Probe SN 26/23 EPGO420 ConvF 1.15 Area Scan dx=8mm dy=8mm, A…
