2AO94-LW003Bluetooth-LoRaWAN Gateway

LW003-B Product Specification MOKO TECHNOLOGY LTD. Version 3.1 www.mokosmart.com/www.mokolora.com Version 3.1 CONTENT 1 Product Introduction ......................................................................................................................... 4 2 Application Scenarios ........................................................................................................................ 4 3 Product Specifications ....................................................................................................................... 4 3.1 Appearance ............................................................................................................................ 4 3.2 Mechanical Size ...................................................................................................................... 4 3.2 LED Indicators......................................................................................................................... 5 3.3 General Specifications ............................................................................................................ 6 4 User Guidance ................................................................................................................................... 7 4.1 How to make device working quickly .................................................................................... 7 4.2 How to connect to APP and configure parameters ............................................................... 8 5 General Function ............................................................................................................................... 8 5.1 Introduction to Device Application ........................................................................................ 8 5.1.1 Indoor Positioning ....................................................................................................... 8 5.1.2 Asset Monitoring ......................................................................................................... 9 5.1.3 Environment Monitoring .......................................................................................... 10 5.2 Multiple Scan & Report Strategies ....................................................................................... 11 5.2.1 Overview ................................................................................................................... 11 5.2.2 Periodic Scan & Immediately Report ........................................................................ 11 5.2.3 Timing Scan & Immediately Report .......................................................................... 12 5.2.4 Scan Always On & Periodic Report ........................................................................... 13 5.2.5 Periodic Scan & Periodic Report ............................................................................... 14 5.2.6 Scan Always On & Timing Report .............................................................................. 15 5.2.7 Timing Scan & Timing Report .................................................................................... 15 5.2.8 Periodic Scan & Timing Report ................................................................................. 16 5.3 Bluetooth Scanning Filtering Rules ...................................................................................... 17 5.3.1 Filter Repeating Data ................................................................................................ 17 5.4 Bluetooth Broadcast Capabilities ......................................................................................... 18 5.5 LoRaWAN Capabilities .......................................................................................................... 18 5.5.1 Uplink message type selection.................................................................................. 19 5.5.2 Multicast Group ........................................................................................................ 19 5.6 Heartbeat Mechanism ......................................................................................................... 19 5.7 Local Data Sync .................................................................................................................... 19 5.8 Temperature and Humidity Monitoring .............................................................................. 19 5.9 Continuity Transfer Function ............................................................................................... 19 5.10 Default Power Status ......................................................................................................... 19 5.11 Time Synchronization ......................................................................................................... 20 5.12 Battery Performance .......................................................................................................... 20 5.13 Bluetooth Configuration Tool ............................................................................................ 21 6 Uplink Payload ................................................................................................................................. 21 6.1 Device Information Payload ................................................................................................. 21 6.2 Shut Down Payload .............................................................................................................. 22 6.3 Heartbeat Payload ............................................................................................................... 22 6.4 Bluetooth Broadcast Event Payload ..................................................................................... 23 6.5 Beacon Payload .................................................................................................................... 23 6.5.1 The report content of each type .............................…

Text truncated - open the document above for the full version.

Phuntion LLC * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter May 15, 2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AO94-LW003 Per section 2.911(d)(7) of the FCC rules, MOKO TECHNOLOGY Ltd certifies that the equipment for which authorization is sought is designated to the following U.S. Designated agent* for service of process: Company Name: Phuntion LLC Physical U.S. Company Address: 25214 Spectrum, Irvine, CA92618 Agent name: Jun.Tian Agent Email Address: [email protected] FRN: 0033422403 The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed: Designated Agent Signed: (Required, if different to Applicant): Signed: Signed: Printed name: jinghui.chen Printed name: Jun.Tian Title: SEO Title: CEO Company Name: MOKO TECHNOLOGY Ltd Company Name: Phuntion LLC Date: May 15, 2023 Date: May 15, 2023

MOKO TECHNOLOGY Ltd Covered Equipment Certification Attestation Letter 5/15/2023 Nemko North America, Inc. 303 River Road Ottawa K1V 1H2 Canada ATTN.: Reviewing Engineer FCC ID: 2AO94-LW003 MOKO TECHNOLOGY Ltd (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. MOKO TECHNOLOGY Ltd (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: Jinghui.Chen Title: SEO Company Name: MOKO TECHNOLOGY Ltd Date: 5/15/2023

MOKO TECHNOLOGY Ltd 5/15/2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 AUTHORITY TO ACT AS AGENT - FCC On our behalf, I appoint MOKO TECHNOLOGY Ltd Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in FCC regulations will have affixed to it a label identical to that submitted for approval with this application. In signing this letter, Applicant certifies that neither the applicant nor any party to the application is not subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, as specified by Nemko North America Inc., still resides still resides with us. Sincerely, Printed name: Jinghui.Chen

MOKO TECHNOLOGY Ltd 5/15/2023 Nemko North America, Inc. 303 River Road Ottawa, Ontario, Canada K1V 1H2 REQUEST FOR CONFIDENTIALITY - FCC FCC ID: 2AO94-LW003 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules and FCC Guidance document 726920, we hereby request confidential treatment of information accompanying this application as outlined below: PERMANENT LONG-TERM CONFIDENTIALITY: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation The above information contains trade secrets and proprietary information not customarily released to the public. The public disclosure of this information might be harmful to the applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Sincerely, Signed: Printed name:Jinghui.Chen Title:SEO

FCC ID: 2AO94-LW003 Page 1/4 External photo FCC ID: 2AO94-LW003 Page 2/4 External photo FCC ID: 2AO94-LW003 Page 3/4 FCC ID: 2AO94-LW003 Page 4/4 --END---

FCC ID: 2AO94-LW003 Page 1/3 Internal photo FCC ID: 2AO94-LW003 Page 2/3 2402-2480MHz BT Antenna 915MHz FCC ID: 2AO94-LW003 Page 3/3 ---END---

Page 1 of 2 Address: No.11, WuSong Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com RF EXPOSURE EVALUATION EUT Specification EUT Bluetooth-LoRaWAN Gateway Model Number LW003-B FCC ID 2AO94- LW003 Antenna gain (Max) 4.51dBi Operation Frequency 2402-2480MHz, 915MHz Input Rating DC 3.7V Standard 47 CFR Part 1.1307 47 CFR Part 1.1310 KDB447498D01 General RF Exposure Guidance v06 Modulation BLE, LoRa Limits The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation17 • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion According to KDB447498D01 General RF Exposure Guidance v06 Standalone SAR test exclusion considerations Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Exclusion Threshold condition, listed below, is satisfied. 90174-23-72-23-PP003 Page 2 of 2 Address: No.11, WuSong Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 GuangdongProvince,China523117 http://www.cpcteam.com Calculated Result and Limit Operation Mode: GFSK, 8DPSK Channel Maximum Peak Conducted Output Power (dBm) Tune up tolerance (dBm) Maximum tune-up Power Calculated value Exclusion threshold (dBm) (mW) GFSK -Lowest (2402MHz) 4.01 4±1 5 3.16 0.98 3.0 GFSK -Middle (2440MHz) 3.77 3±1 4 2.51 0.78 GFSK -Highest (2480MHz) 2.90 3±1 4 2.51 0.79 Conclusion: the calculated value ≤3.0, SAR is exempted. The Maxinum power is less than the limit, complies with the exemption requirements, SAR is exempted. For 915MHz SRD Ant gain=2.0dBi Ant numeric gain= 1.58 Field strength = 80.22dBuV/m@3m P={[10 ( 80.22 20 ) /10 6 ∗3] 2 /(30∗1.58}∗1000mw=0.0199mW Pd= (30*0.003*1.58) / (377*20^2)=0.000000942<1 Remark: The Max Conducted Peak Output Power data refer to report Report No.: 90174-23-72-23-PP001 , 90174-23-72-23-PP002 BLE and LoRa can be launched simultaneously. Simultaneous evaluation of compliant RF exposur：0.98/3+0.000000942/1=0.327000942<1

Page 1 of 33 Address: No. 11, Wu Song Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 Guangdong Province, China 523117 http://www.cpcteam.com TEST REPORT Report Number. ........................ : 90174-23-72-23-PP002 Date of issue ............................ : 2023.05.15 Tested by (+signature) ............ : Duke Chen Approved by (+signature) ....... : Jason Gao Testing Laboratory name ........ : SLG-CPC Testlaboratory Co., Ltd. Address .................................... : No. 11, Wu Song Road, Dongcheng District, Dongguan, Guangdong Province, China 523117 Applicant’s name ..................... : MOKO TECHNOLOGY Ltd Address .................................... : Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 Manufacturer’s name ............. : MOKO TECHNOLOGY Ltd Address .................................... : Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 Factory’s name ....................... : MOKO TECHNOLOGY Ltd Address .................................... : Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 Standard(s) ............................... : FCC 47 CFR Part 15, Subpart C EUT ............................................ : Bluetooth-LoRaWAN Gateway Trade Mark ................................ : MOKO SMART Model/Type reference .............. : LW003-B FCC ID ....................................... : 2AO94-LW003 Date of receipt of test item ..... : 2023.03.10 Date (s) of performance of test: 2023.03.10- 2023.04.10 Summary of Test Results ........ : Pass The Summary of Test Results based on a technical opinion belongs to the standard(s). General disclaimer: This report shall not be reproduced except in full, without the written approval of SLG-CPC Testlaboratory Co., Ltd. The test results in the report only apply to the tested sample. 90174-23-72-23-PP002 Page 2 of 33 Address: No. 11, Wu Song Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 Guangdong Province, China 523117 http://www.cpcteam.com Table of Contents 1 EUT TECHNICAL DESCRIPTION ............................................................................................. 4 2 SUMMARY OF TEST RESULT ................................................................................................. 5 3 TEST METHODOLOGY ............................................................................................................ 6 3.1 GENERAL DESCRIPTION OF APPLIED STANDARDS .................................................... 6 3.2 MEASUREMENT EQUIPMENT USED .............................................................................. 6 3.3 DESCRIPTION OF TEST MODES ..................................................................................... 7 4 FACILITIES AND ACCREDITATIONS ....................................................................................... 8 4.1 FACILITIES ........................................................................................................................ 8 4.2 LABORATORY ACCREDITATIONS AND LISTINGS .......................................................... 8 5 TEST SYSTEM UNCERTAINTY ............................................................................................... 9 6 SETUP OF EQUIPMENT UNDER TEST ................................................................................ 10 6.1 RADIO FREQUENCY TEST SETUP 1 ............................................................................ 10 6.2 RADIO FREQUENCY TEST SETUP 2 ............................................................................ 10 7 TEST REQUIREMENTS ......................................................................................................... 12 7.1 DTS 6DB BANDWIDTH ................................................................................................... 12 7.2 MAXIMUM PEAK CONDUCTED OUTPUT POWER ....................................................... 15 7.3 MAXIMUM POWER SPECTRAL DENSITY ..................................................................... 17 7.4 RADIATED SPURIOUS EMISSION ................................................................................. 20 7.5 CONDUCTED EMISSION TEST ...................................................................................... 30 7.6 ANTENNA APPLICATION ................................................................................................ 33 90174-23-72-23-PP002 Page 3 of 33 Address: No. 11, Wu Song Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 Guangdong Province, China 523117 http://www.cpcteam.com Modified Information Version Report No. Revision Data Summary Ver.1.0 90174-23-72-23-PP002 2023.05.15 Original Version 90174-23-72-23-PP002 Page 4 of 33 Address: No. 11, Wu Song Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 Guangdong Province, China 523117 http://www.cpcteam.com 1 EUT TECHNICAL DESCRIPTION Product: Bluetooth-LoRaWAN Gateway Model Number: LW003-B Power supply: : DC 3.7V :Adapter information Modulation: BLE Frequency Range: 2402MHz～2480MHz Number of Channels: 40channels Channel Space: 1MHz Antenna Gain: 4.51dBi Antenna: FPC Antenna Note: for more details, please refer to the User’s manual of the EUT. 90174-23-72-23-PP002 Page 5 of 33 Address: No. 11, Wu Song Road, Tel: 86-769-22607797 DongchengDistrict,Dongguan, Fax: 86-769-22607907 Guangdong Province, China 523117 http://www.cpcteam.com 2 SUMMARY OF TEST RESULT FCC Part Clause Test Parameter Verdict Remark 15.247(a)(2) DTS (6dB) Bandwidth PASS 15.247(b)(3) Maximum Peak Conducted Output Power PASS 15.247(e) Maximum Power Spectral Density Level PASS 15.247(d) Unwanted Emission Into Non-Restricted Frequency Bands PASS 15.247(d) 15.209 Radiated Spurious Emission PASS 15.207 Conducted Emission Test PASS 15.247(b) Antenna Application PASS NOTE1: N/A (Not Applicable) NOTE2: According t…

Text truncated - open the document above for the full version.

1 承 认 书 Specification for approval 客户名称： MOKO TECHNOLOGY Ltd 型号： LW003 料 号： M2M.0133-R0A 产品名称： BLE 天线 外形尺寸： 40.6*13.75mm 地址： 样品类别： 样品 文件版本： A 供应商 supplier 客户 customer 编 制 采 购 审 核 工 程 批 准 品 质 新物料 □回收(需回收的编号:A版本 ) 公章 2021 年 01 月 14 日 公章 年 月 日 Factory 201, 107 Pinshun Rd Guixiang community, Guanlan Street, Longhua, Shenzhen, China 518110 2 目录 1.封面 ........................................................................................................1 2.目录 ........................................................................................................2 3.工程图 ....................................................................................................3 4.天线测试 ................................................................................................4 4.1 处理方式 .......................................................................................4 4.1.1 匹配电路 ................................................................................4 4.1.2 环境处理 ................................................................................4 4.2 性能测试 .......................................................................................4 4.2.1 VSWR ...................................................................................4 4.2.2 有源测试 ...............................................................................4 4.2.3 无源测试 ...............................................................................5 4.2.4 3D ..........................................................................................6 4.2.5 2D ...................................................................................... 6-7 5.天线放置 ...............................................................................................7 6.承认书样品尺寸检验报告 ...................................................................8 7.ROHS 检测报告 .....................................................................................9 3 3.工程图 5 0～10 ±0.10 10～18 ±0.15 18～30 ±0.20 30～40 ±0.25 Third Angle 40～ ±0.30 Approved by Part No. Date Designed by Checked by Scale mm Location Project Material Part Name Unit RF Angle 1:1 深 圳 摩 天 射 频 技 术 有 限 公 司 ShenZhen MyAntenna RF Technology Co.,Ltd DWG No. Date BLE 天线 A0 Rev New drawing Description Date 20210114 Remark M2M.0133-R0A No. Name Material ColorTreatment AmountRemark 1 黑色 1 1 2 黑色 同轴线 FPC LW003 1.各零件中Pb、Hg、Cr+6、PBBs、PBDEs各项小于500PPM，Cd小于50PPM. 备注： 2.没标公差的尺寸为参考尺寸 LW003 BLE V1.2 一代端子朝下 1 2 ?1.13mm 黑色 4 4.天线测试 4.1 处理方式 4.1.1匹配电路（无） 4.1.2环境处理（无） 4.2 性能测试 4.2.1 VSWR 4.2.2 有源测试（无） 5 4.2.3 无源测试 效率及增益 6 4.2.4 3D 图 4.2.5 2D 图 7 天线性能审核： 天线性能批准： 5.天线放置图 8 6.承认书样品尺寸检验报告 项目名称 LW003 天线类型 BLE天线 检验日期 2021-01-14 外观检查标准 1、天线表面等无异常 尺寸检验标准 2、图纸所要求的公差范围内 代号 检查项目 规格 检验工 具 抽样数 判定 说明 1 外观 如上标准 目视 6PCS OK 2 尺寸 如下表 游标卡 尺 6PCS OK 序号 检验项目 规格 检测工 具 检测结果（含最高最低值记载6数据） 1 2 3 4 5 6 1 外形尺寸 40.6±0.4 卡尺 40.68 40.69 40.61 40.65 40.67 40.63 2 13.75±0.2 13.72 13.76 13.78 13.72 13.79 13.79 3 56.0±2.0 56.5 56.8 56.1 56.7 56.9 56.3 4 5 6 7 8 备注 核准：杨永成 审核:陈建尤 检验员：董春玲 9 7.ROHS 检测报告 项目物料名称 物料编码 报告检测样本名称 检测机构 检测时间 检测报告编号 测试结论 备注 LW003 M2M.0133-R0A 同轴线(镀银铜线) SGS 2020/1/08 SHAEC1928362919 OK 同轴线(镀锡铜线) CTI 2019/6/14 A2190138284101E OK 同轴线(FEP 绝缘) SGS 2020/1/06 SHAEC1928831729 OK 同轴线(FEP 护套) SGS 2020/1/19 SHAEC2000864703 OK 同轴线(黑色色母) SGS 2020/3/30 SHAEC2003955101 OK FPC 基材 SGS 2020/3/2 SHAEC2001939104 OK 油墨 SGS 2019/10/14 CE/2019/A0149 OK 背胶 SGS 2019/12/27 CANEC1925631401 OK 拟制：董春玲 审核：陈建尤 日期：2021-01-14 盖章处：

FCC ID: 2AO94-LW003 Test photo Radiated emission FCC ID: 2AO94-LW003 Conduction
