2APA9-CMSXJ55AIMILAB EC5 Floodlight Camera

12345 108967 Please read this manual carefully before using the device and retain it for future reference. Product IntroductionInstalling the Device “works with mijia” signifies that the product herein is designed to connect and interact with Mi Home app or Mi AI. Please be noted that the product herein is certified by the app interaction only. Xiaomi and Mijia are not responsible for anyof the product manufacturing, safety and regulatory standards, or quality supervision. Precautions The working temperature of the device is -30°C to 60°C. Do not use the device when the temperature is too high or too low. For better results, avoid placing the camera in front of or next to a glass surface, a white-colored wall or other reflective surfaces as this may cause the recording to have un-even lighting between the foreground and background or be over-exposed. Please ensure that the device is within Wi-Fi signal coverage. Place it at a location with good Wi-Fi signal strength. Try to avoid placing the device near a metallic object, a microwave oven or other objects that may cause signal interference. Specifications 封面封底 CMSXJ55AIMILAB EC5 Floodlight Camera 封二 封三 Manufacturer: Shanghai Imilab Technology Co., Ltd. Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China For further information, please go to www.imilab.com. Support: [email protected] www.imilabhelp.com 上海创米科技有限公司 V1.1 2021-12-24 结构设计师 平面设计师 修改内容版本 修 改 记 录 105*148mm 骑马钉 IMILAB EC5 Floodlight Camera User Manual Wall mounting packWall/ceiling mounting positioning stickers User manual IMILAB EC5 Floodlight CameraPower adapter Package lis Wall mounting The device can be wall mounted, ceiling mounted or tied around a support. Product Appearance Note: Actual operation may differ due to Mi Home app update. Please follow the on-screen instructions of the Mi Home app. Lens Mic Reset button White light Speaker Wall bracket Micro SD card slot 64295C5D 2021 3 2 20:51:05 Full Color Night Vision The light sensor can automatically switch the device to night vision mode through IR-CUT based on changes in the lighting of the environment. Built-in high power exposure light can present colorful images even in the darkness. Video Playback Past videos can only be viewed when a compatible micro SD card is inserted in IMILAB EC5 Floodlight Camera. After inserting a micro SD card and turning on the device, the camera will automatically start recording. In the control interface for IMILAB EC5 Floodlight Camera in the Mi Home app, tap the playback button to enter the video playback page. You can also view a recording by selected a time period. Night vision effect illustration 12MB / s 06:20 IMILAB EC5 Floodlight Camera 1. Attach the wall mounting positioning sticker on the desired installation location on a wall. Drill two holes at the positions indicated on the sticker. Drilling diameter of around 6.0 mm; drilling depth of around 30mm. Connecting the Device Turn on the camera Insert the power supply cable into the camera's power supply port. Connect the other end of the power supply cable to a power source. Insert a micro SD card. Ensure that the camera is disconnected from the power supply. Use a screwdriver to remove the protective case and expose the micro SD card slot. The contact points of the micro SD card should be facing down. Insert the micro SD card into the slot. Restoring factory settings Press and hold the reset button to restore the factory settings. The content inside the micro SD card will not be deleted. Note: When inserting or removing the micro SD card, please disconnect the camera from the power supply. Please use a micro SD card from a reputable manufacturer (up to 256GB). The recommended read and write speed of the micro SD card is at least U1/Class 10. Ceiling mountingPole mounting 1. Attach the ceiling mounting positioning sticker on the desired installation location on the ceiling. Drill two holes at the positions indicated on the sticker. Drilling diameter of around 6.0 mm; drilling depth of around 30mm. 2. Insert two plastic expansion nuts into the wall. Put the base plate on the wall. Secure the base plate by inserting the screws into the expansion nuts. 2. Insert two plastic expansion nuts into the wall. Put the base plate on the ceiling. Secure the base plate by inserting the screws into the expansion nuts. About works with mijia This product works with Mi Home and can be controlled using the Mi Home app. Scan the QR code to download and install the Mi Home app. If you already have Mi Home app installed, you will be directed to the device connection page. You can also search for "Mi Home" in an app store to download and install the Mi Home app. Open the Mi Home app. Tap “+” at the top right corner and following the on-screen instructions to add the device.an app store to download and install the Mi Home app. Open the Mi Home app. Tap “+” at the top right corner and following the on-screen instructions to add the device. Name：IMILAB EC5 Floodlight Camera Model：CMSXJ55A Input：12V 1A Resolution：2304 x 1296 Operating Temperature：-30°C ～ 60°C Wireless Connectivity：Wi-Fi IEEE 802.11 b/g/n 2.4GHz Item Dimensions：139 x 128 x 135 mm Net Weight：618 g Viewing Angle：95° Aperture：F2.1 Video Codec：H.265 IP rating：IP66 Connecting to Mi Home App Home Security The Home Security function can be turned on/off in the control interface for IMILAB EC5 Floodlight Camera in the Mi Home app. The device can detect and record movements within the viewing angle and push the recording to the client. Users can set the surveillance time, alert sensitivity, alert interval, etc. Sharing a Video In the control interface for IMILAB EC5 Floodlight Camera in the Mi Home app, you can set the device as a shared device in the settings menu and invite others to watch the recordings. Users must download the Mi Home app and login to their Xiaomi account in order to view the recordings of the shared device. Note: The illustrations are for…

Text truncated - open the document above for the full version.

Shanghai Imilab Technology Co., Ltd. Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China Agent Authorization Company: Shanghai Imilab Technology Co., Ltd. Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China Product Name: IMILAB EC5 Floodlight Camera Model Number(s): CMSXJ55A Product Description: IMILAB EC5 Floodlight Camera We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Mar.14, 2022 Name: Wang Hesong Title: General Manager Company: Shanghai Imilab Technology Co., Ltd.

Shanghai Imilab Technology Co., Ltd. Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District, Shanghai, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: Mar.14, 2022 Subject: Declaration Operating Channel Limitation FCC ID: 2APA9-CMSXJ55A To Whom it may concern, This device is acting as slave/client device under the control of a master. The operating channels in 802.11 b/g/n mode for this device marketed to the US are firmware limited to channel 1 ~ 11 (2412 ~ 2462 MHz). The end-user has no possibility to select any other operating channels. If you have any questions, please feel free to contact me. Thank you. Sincerely, Signatory Shanghai Imilab Technology Co., Ltd. Contact person: Wang Hesong Title: General Manager

ShanghaiImilabTechnologyCo., Ltd. Room001A,Floor 11, Block 1, No. 588 ZixingRoad,MinhangDistrict,Shanghai,China Office of EngineeringTechnology FederalCommunicationsCommission 7435 OaklandMills Road Columbia,MD 21046 USA Date: Mar.14,2022 Subject;Requestfor Confidentiality FCC ID: 2APA9-CMSXJ55A To WhomIt May Concern, Pursuantto the provisionsof the Commission’s rules Title 47 Sections§0.457 and §0.459,we are requestingthe Commissionto withholdthe followingattachment(s)as confidential documentsfrom public disclosureindefinitely. Thesedocumentscontaindetailedsystemand equipmentdescriptionsand are consideredas proprietaryinformationin operationof the equipment.The public disclosureof these documents might be harmfulto our companyand would give competitorsan unfair advantagein the market. SchematicDiagram Block Diagram OperationalDescription It is our understandingthat all measurementtest reports,FCC ID label formatand correspondenceduringthe certificationreviewprocesscannotbe grantedas confidential documentsand this informationwill be availablefor public reviewonce the grant of equipment authorizationis issued. Sincerely, Signature: Name:Wang Hesong Title: GeneralManager

Report No.: AGC05877220112AP03 Page 1 of 6 EXTERNAL PHOTOS ALL VIEW OF EUT TOP VIEW OF EUT Report No.: AGC05877220112AP03 Page 2 of 6 BOTTOM VIEW OF EUT FRONT VIEW OF EUT Report No.: AGC05877220112AP03 Page 3 of 6 BACK VIEW OF EUT LEFT VIEW OF EUT Report No.: AGC05877220112AP03 Page 4 of 6 RIGHT VIEW OF EUT PORT VIEW OF EUT (FIGURE 1) Report No.: AGC05877220112AP03 Page 5 of 6 PORT VIEW OF EUT (FIGURE 2) ADAPTER CLOSE-UP PHOTO-1 Report No.: AGC05877220112AP03 Page 6 of 6 ADAPTER CLOSE-UP PHOTO-2 ****************************************End of Report****************************************

FCC ID Label Location 10mm*10mm FCC ID: 2APA9-CMSXJ55A

Report No.: AGC05877220112AP03 Page 1 of 5 INTERNAL PHOTOS OPEN VIEW OF EUT ANTENNA CLOSE-UP PHOTO-1 WIFI Antenna Report No.: AGC05877220112AP03 Page 2 of 5 INTERNAL VIEW OF EUT (FIGURE 1) INTERNAL VIEW OF EUT (FIGURE 2) Report No.: AGC05877220112AP03 Page 3 of 5 INTERNAL VIEW OF EUT (FIGURE 3) INTERNAL VIEW OF EUT (FIGURE 4) Report No.: AGC05877220112AP03 Page 4 of 5 INTERNAL VIEW OF EUT (FIGURE 5) INTERNAL VIEW OF EUT (FIGURE 6) Report No.: AGC05877220112AP03 Page 5 of 5 INTERNAL VIEW OF EUT (FIGURE 7) INTERNAL VIEW OF EUT (FIGURE 8) ****************************************End of Report****************************************

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description IMILAB EC5 Floodlight Camera Model Name CMSXJ55A FCC ID 2APA9-CMSXJ55A 2. EVALUATION METHOD AND LIMIT Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minutes) 0.3 -- 1.34 614 1.63 (100)* 30 1.34 -- 30 824/f 2.19/f (180/f 2 )* 30 30 -- 300 27.5 0.073 0.2 30 300 -- 1500 -- -- f/1500 30 1500 -- 100,000 -- -- 1.0 30 *Note: 1. f= Frequency in MHz * Plane-wave Equivalent Power Density 2. The averaging time for General Population/Uncontrolled exposure to fixed transmitters is not applicable for mobile and portable transmitters. See 47 CFR §§2.1091 and 2.1093 on source-based time-averaging requirement for mobile and portable transmitters. S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 3. CALCULATION A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be at least 20 cm and fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of § 2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. Antenna Gain=1dBi (Numeric 1.26), π=3.14 Note: 1. Only the worst case recorded. Frequency Output Power Output Power Power Density Power Density Limit MHz dBm mW mW/cm 2 mW/cm 2 2462 16.73 47.10 0.01181 1

Page 1 of 72 Report No.: AGC05877220112FE05 FCC ID : 2APA9-CMSXJ55A APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : IMILAB EC5 Floodlight Camera BRAND NAME : N/A MODEL NAME : CMSXJ55A APPLICAN : Shanghai Imilab Technology Co., Ltd. DATE OF ISSUE : Mar. 11, 2022 STANDARD(S) TEST PROCEDURE(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance (Shenzhen) Co., Ltd FCC Test Report Report No.: AGC05877220112FE05 Page 2 of 72 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / Mar. 11, 2022 Valid Initial Release Report No.: AGC05877220112FE05 Page 3 of 72 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ........................................................................................................................ 6 2.2. TABLE OF CARRIER FREQUENCYS ....................................................................................................... 6 2.3. IEEE 802.11N MODULATION SCHEME .................................................................................................... 7 2.4. RELATED SUBMITTAL(S) / GRANT (S) .................................................................................................... 7 2.5. TEST METHODOLOGY ............................................................................................................................. 7 2.6. SPECIAL ACCESSORIES ......................................................................................................................... 7 2.7. EQUIPMENT MODIFICATIONS ................................................................................................................. 7 2.8. ANTENNA REQUIREMENT....................................................................................................................... 7 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 8 4. DESCRIPTION OF TEST MODES ................................................................................................................... 9 5. SYSTEM TEST CONFIGURATION ................................................................................................................ 10 5.1. CONFIGURATION OF EUT SYSTEM ...................................................................................................... 10 5.2. EQUIPMENT USED IN EUT SYSTEM ..................................................................................................... 10 5.3. SUMMARY OF TEST RESULTS .............................................................................................................. 10 6. TEST FACILITY ............................................................................................................................................... 11 7. OUTPUT POWER ........................................................................................................................................... 12 7.1. MEASUREMENT PROCEDURE ............................................................................................................. 12 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 12 7.3. LIMITS AND MEASUREMENT RESULT .................................................................................................. 13 8. BANDWIDTH .................................................................................................................................................. 14 8.1. MEASUREMENT PROCEDURE ............................................................................................................. 14 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 14 8.3. LIMITS AND MEASUREMENT RESULTS ............................................................................................... 15 9. CONDUCTED SPURIOUS EMISSION........................................................................................................... 26 9.1. MEASUREMENT PROCEDURE ............................................................................................................. 26 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) .................................................................... 26 9.3. MEASUREMENT EQUIPMENT USEDJN ................................................................................................ 26 9.4. LIMITS AND MEASUREMENT RESULT .................................................................................................. 26 Report No.: AGC05877220112FE05 Page 4 of 72 10. MAXIMUM CONDUCTED OUTPUT POWER SPECTRAL DENSITY ........................................................ 38 10.1 MEASUREMENT PROCEDURE ............................................................................................................ 38 10.2 TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ................................................................... 38 10.3 MEASUREMENT EQUIPMENT USED ................................................................................................... 38 10.4 LIMITS AND MEASUREMENT RESULT ................................................................................................. 38 11. RADIATED EMISSION ................................................................................................................................. 44 11.1. MEASUREMENT PROCEDURE............................................................................................................ 44 11.2. TEST SETUP .......................................................................................…

Text truncated - open the document above for the full version.

Report No.: AGC05877220112FE05 Page 41 of 72 Test_Graph_802.11g_ANT1_2437_6Mbps_PSD Test_Graph_802.11g_ANT1_2462_6Mbps_PSD Report No.: AGC05877220112FE05 Page 42 of 72 Test_Graph_802.11n20_ANT1_2412_MCS0_PSD Test_Graph_802.11n20_ANT1_2437_MCS0_PSD Report No.: AGC05877220112FE05 Page 43 of 72 Test_Graph_802.11n20_ANT1_2462_MCS0_PSD Report No.: AGC05877220112FE05 Page 44 of 72 11. RADIATED EMISSION 11.1. MEASUREMENT PROCEDURE 1. The EUT was placed on the top of the turntable 0.8 or 1.5 meter above ground. The phase center of the receiving antenna mounted on the top of a height-variable antenna tower was placed 3 meters far away from the turntable. 2. Power on the EUT and all the supporting units. The turntable was rotated by 360 degrees to determine the position of the highest radiation. 3. The height of the broadband receiving antenna was varied between one meter and four meters above ground to find the maximum emissions field strength of both horizontal and vertical polarization. 4. For each suspected emission, the antenna tower was scan (from 1 M to 4 M) and then the turntable was rotated (from 0 degree to 360 degrees) to find the maximum reading. 5. Set the test-receiver system to Peak or CISPR quasi-peak Detect Function with specified bandwidth under Maximum Hold Mode. 6. For emissions above 1GHz, use 1MHz RBW and 3MHz VBW for peak reading. Place the measurement antenna away from each area of the EUT determined to be a source of emissions at the specified measurement distance, while keeping the measurement antenna aimed at the source of emissions at each frequency of significant emissions, with polarization oriented for maximum response. The measurement antenna may have to be higher or lower than the EUT, depending on the radiation pattern of the emission and staying aimed at the emission source for receiving the maximum signal. The final measurement antenna elevation shall be that which maximizes the emissions. The measurement antenna elevation for maximum emissions shall be restricted to a range of heights of from 1 m to 4 m above the ground or reference ground plane. 7. When the radiated emissions limits are expressed in terms of the average value of the emissions, and pulsed operation is employed, the measurement field strength shall be determined by averaging over one complete pulse train, including blanking intervals, as long as the pulse train does not exceed 0.1 seconds. As an alternative (provided the transmitter operates for longer than 0.1 seconds) or in cases where the pulse train exceeds 0.1 seconds, the measured field strength shall be determined from the average absolute voltage during a 0.1 second interval during which the field strength is at its maximum values. 8.If the emissions level of the EUT in peak mode was 3 dB lower than the average limit specified, then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions which do not have 3 dB margin will be repeated one by one using the quasi-peak method for below 1GHz. 9. For testing above 1GHz, the emissions level of the EUT in peak mode was lower than average limit (that means the emissions level in peak mode also complies with the limit in average mode), then testing will be stopped and peak values of EUT will be reported, otherwise, the emissions will be measured in average mode again and reported. 10. In case the emission is lower than 30MHz, loop antenna has to be used for measurement and the recorded data should be QP measured by receiver. High - Low scan is not required in this case. Report No.: AGC05877220112FE05 Page 45 of 72 11.2. TEST SETUP Radiated Emission Test-Setup Frequency Below 30MHz RADIATED EMISSION TEST SETUP 30MHz-1000MHz RADIATED EMISSION TEST SETUP ABOVE 1000MHz Report No.: AGC05877220112FE05 Page 46 of 72 11.3. LIMITS AND MEASUREMENT RESULT 15.209(a) Limit in the below table has to be followed Frequencies (MHz) Field Strength (microvolts/meter) Measurement Distance (meters) 0.009~0.490 2400/F(kHz) 300 0.490~1.705 24000/F(kHz) 30 1.705~30.0 30 30 30~88 100 3 88~216 150 3 216~960 200 3 Above 960 500 3 Note: All modes were tested for restricted band radiated emission, the test records reported below are the worst result compared to other modes. 11.4. TEST RESULT Radiated emission below 30MHz The amplitude of spurious emissions from 9kHz to 30MHz which are attenuated more than 20 dB below the permissible value need not be reported. Report No.: AGC05877220112FE05 Page 47 of 72 Radiated emission from 30MHz to 1000MHz Adapter 1 EUT IMILAB EC5 Floodlight Camera Model Name CMSXJ55A Temperature 21.8°C Relative Humidity 58% Pressure 985hPa Test Voltage Normal Voltage Test Mode 802.11b with date rate 1 2412MHz Antenna Horizontal RESULT: PASS Report No.: AGC05877220112FE05 Page 48 of 72 EUT IMILAB EC5 Floodlight Camera Model Name CMSXJ55A Temperature 21.8°C Relative Humidity 58% Pressure 985hPa Test Voltage Normal Voltage Test Mode 802.11b with date rate 1 2412MHz Antenna Vertical RESULT: PASS Note: 1. Factor=Antenna Factor + Cable loss, Over=Measurement-Limit. 2. The “Factor” value can be calculated automatically by software of measurement system. 3. All test modes had been pre-tested. The 802.11b at low channel is the worst case and recorded in the report. Report No.: AGC05877220112FE05 Page 49 of 72 Adapter 2 EUT IMILAB EC5 Floodlight Camera Model Name CMSXJ55A Temperature 21.8°C Relative Humidity 58% Pressure 985hPa Test Voltage Normal Voltage Test Mode 802.11b with date rate 1 2412MHz Antenna Horizontal RESULT: PASS Report No.: AGC05877220112FE05 Page 50 of 72 EUT IMILAB EC5 Floodlight Camera Model Name CMSXJ55A Temperature 21.8°C Relative Humidity 58% Pressure 985hPa Test Voltage Normal Voltage Test Mode 802.11b with date rate 1 2412MHz Antenna Vertical RESULT: PASS Note: 1. Factor=Antenna Factor + Cable loss, Over=Measurement-Limit. 2. The “Factor” value can be calculated automatically by software of measurement system. 3. All test modes had been pre-tested. The 802…

Text truncated - open the document above for the full version.

Report No.: AGC05877220112AP02 Page 1 of 3 TEST SETUP PHOTOS RADIATED EMISSION TEST SETUP BELOW 1GHz RADIATED EMISSION TEST SETUP ABOVE 1GHz Report No.: AGC05877220112AP02 Page 2 of 3 AC POWER LINE CONDUCTED TEST SETUP (adapter 1) AC POWER LINE CONDUCTED TEST SETUP (adapter 2) Report No.: AGC05877220112AP02 Page 3 of 3 RF CONDUCTED TEST SETUP ****************************************End of Report*************************************
