2APXW-TMRV065G5G Mobile Phone

User Manual English 2 About this manual............................................................... Thank you for choosing the REVVL® 6x 5G (Model name: TMRV065G). I n order to maintain your device in optimal condition, please read this manual and keep it for future refer ence. Your phone’s screens and app layouts are subject to change. This user guide uses sample images only. Table of content .................................................................. 1 About this manual ........................................................2 1 Getting started ........................................................3 1. 1 Overview ................................................................3 1.2 Setup .....................................................................4 1.3 Home screen ........................................................5 1.4 Status bar .............................................................5 2 About your phone ........................................................6 2. 1 Power on/off .........................................................6 2.2 Batt ery ....................................................................6 3 Per sonlize your phone ................................................7 3. 1 Language ..............................................................7 3.2 Date & time ..........................................................7 3.3 NFC .......................................................................7 3.4 Display ..................................................................8 3.5 Wallpaper ............................................................. .................................................................... 8 3.6 Sound 8 3.7 Digital wellbeing & parental contr ols ..............9 4 Applications .................................................................9 4. 1 Call .........................................................................9 4.2 Conta cts .............................................................10 4.3 Messages ............................................................11 4.4 Gmail ..................................................................12 4.5 Chrome ...............................................................14 4.6 Calendar .............................................................14 4.7 Camera ...............................................................15 4.8 Photos ................................................................16 4. 9 Clock ....................................................................17 5 Google applications ..................................................18 6 Mor e applications......................................................19 7 Security .......................................................................19 7.1 Screen lock ..........................................................19 7.2 SIM card lock ......................................................19 7.3 Lock screen prefer ences ...................................20 7.4 Fingerprint sensor .............................................20 7.5 Face unlock .........................................................20 7.6 Smart lock ...........................................................20 7.7 Encryption & credentials ..................................20 8 Account .......................................................................20 8. 1 Account information .........................................20 8.2 Softwar e update ...............................................20 9 Gestures .....................................................................21 10 Safety & r egulatory information .............................26 11 Troubleshooting .......................................................26 3 1 Getting Started ................................................................ 1 .1 Overview Note: The fingerprint sensor is located on the power k ey. Power k ey • Press and rel ease quickly to lock or light up the screen. •Press the Power key and the Volume up key to select fr om Emergency, Power off or Restart. Microphone Microphone SpeakerHeadset connector USB type-C Front Camera Top of the phone Bott om of the phone SIM and microSD™ tr ay Volume key Power key Touch Screen 2MP macro 50MP main 2MP depth assist Flash • • Press and hold the Power key to access Google Assistant. • Press the Power key twice to access the camera. Press and hold the Power key and Volume down key to take a screenshot and save it. Volume key • Use the Volume up or down keys to adjust the ringtone volume, the call volume during a phone call, or the media volume while listening to music, watching a video, or s tr eaming content. • Press the Volume key during an incoming call to mute the ringtone. • While using the Camera, press the Volume up or down key to take a photo. 4 1.2 Set up Inserting Nano SIM card You must insert your Nano SIM card to make phone calls using your network. Your phone only supports Nano SIM cards. I n order to avoid damaging your phone, do not att empt to insert other SIM types, such as Mini or Micro cards. Note: Even if no SIM card is installed, your phone will still power on and you will be able to connect to a Wi-Fi network and use some of the phone’s features. Set up your phone The first time you power on the phone, you should set the following options: • Touch English (United States) to choose your language, and touch Vision settings to customize accessibility features. When finished, touch Start to go on. Insert the SIM pin that’ s provided to eject the SIM tr ay and then slide it out gentl y Place or r emove the Nano SIM card and the ni drac DSorcim the correct slot as shown • Select an available Wi-Fi network. Or touch Set up offline and Continue. • Toggle Toggle • • • • Toggle Click More to continue, and press Accept. Set a PIN for screen lock, o therwise touch Skip on the screen twice to continue. to opt in or out of the Device Dia gnostics Collection, o therwise toggle off . to…

Text truncated - open the document above for the full version.

022423-17 rev 6 Certification Application Attestation Statements Date: April 20, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______ Wingtech Group (Hong Kong) Limited ______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______ Wingtech Group (Hong Kong) Limited ______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☑- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ______ ___ ________ Rui Sha ________________ (Signature 2 ) (Print name) Title: _____ Manager _______ Company: Wingtech Group (Hong Kong) Limited Telephone: +86-21-53529900 1 ‐ The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: WINGTECH INTERNATIONAL, INC. Contact Name: James Yoon Street Address: 21900 Oakview Lane City/Province/Zip: Cupertino/California/95014 Telephone No: 425-365-8532 Email: [email protected] FRN #: 0033455775 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: James Yoon Date: April 20, 2023 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Wingtech Group (Hong Kong) Limited Grantee Code: 2APXW Contact Name: Rui Sha Street Address: Flat/RM 1903 19/F, Podium Plaza, 5 Hanoi Road, Tsim Sha Tsui, KL, HK City/Province/Zip: Hong Kong Telephone No: +86-21-53529900 Email: [email protected] Applicant Signature 1: Rui Sha Date: April 20, 2023 Signed by (Printed Name/Title): 1 - Letters must be placed on appropriate letterhead.

____________ THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Authority to Act as Agent Date: Apr 7, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: CTTL, Telecommunication Technology Labs, CAICT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 12 months By: Rui Sha (Signature 1 ) (Print name) Title: Certification Manager On behalf of: Wingtech Group (Hong Kong) Limited (Company Name) Telephone: _+86-21-53529900 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 042622-16

______________ THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Confidentiality Date: Apr 7, 2023 Subject: Confidentiality Request for: 2APXW-TMRV065G Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☒ Short Term External Photos ☒ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☒ Permanent Parts List & Placement/BOM ☐ Short Term ☒ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☒ Short Term Test Setup Photos ☒ Short Term ☐ Permanent * 3 User’s Manual Wingtech Group (Hong Kong) Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. Sincerely, By: Rui Sha (Signature/Title 2 ) (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 042622-16

RE001 RE001 USB AM TO TYPE-C2.0

Description of E-Label on the TMRV065G Menu Step1 Settings Menu Step2 About phone Step3 Regulatory labels

Label 1 Label 2

©Copyright. All rights reserved by CTTL. FCC PART 15B TEST REPORT No. I23Z60340-EMC01 for Wingtech Mobile Communications Co.,Ltd. 5G Mobile Phone Model name: TMRV065G FCC ID: 2APXW-TMRV065G with Hardware Version: V1.0 Software Version: TMRV065G_0.01.01 Issued Date: 2023-04-12 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL-Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I23Z60340-EMC01 ©Copyright. All rights reserved by CTTL. Page 2 of 29 REPORT HISTORY Report Number Revision Description Issue Date I23Z60340-EMC01 Rev.0 1 st edition 2023-04-12 Note: the latest revision of the test report supersedes all previous version. No.I23Z60340-EMC01 ©Copyright. All rights reserved by CTTL. Page 3 of 29 CONTENTS 1. TEST LABORATORY ............................................................................................................... 4 1.1. TESTING LOCATION ........................................................................................................... 4 1.2. TESTING ENVIRONMENT ................................................................................................... 4 1.3. PROJECT DATA ................................................................................................................... 4 1.4. SIGNATURE .......................................................................................................................... 4 2. CLIENT INFORMATION ........................................................................................................... 5 2.1. APPLICANT INFORMATION ................................................................................................ 5 2.2. MANUFACTURER INFORMATION ...................................................................................... 5 3. EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ............................ 6 3.1. ABOUT EUT .......................................................................................................................... 6 3.2. INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ................................... 6 3.3. INTERNAL IDENTIFICATION OF AE USED DURING THE TEST ...................................... 6 3.4. EUT SET-UPS ....................................................................................................................... 6 4. REFERENCE DOCUMENTS .................................................................................................... 8 4.1. REFERENCE DOCUMENTS FOR TESTING....................................................................... 8 5. LABORATORY ENVIRONMENT .............................................................................................. 9 6. SUMMARY OF TEST RESULTS ............................................................................................ 10 7. TEST EQUIPMENTS UTILIZED ............................................................................................. 11 ANNEX A: MEASUREMENT RESULTS ....................................................................................... 12 No.I23Z60340-EMC01 ©Copyright. All rights reserved by CTTL. Page 4 of 29 1. Test Laboratory 1.1. Testing Location CTTL (huayuan North Road) Address: No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191 1.2. Testing Environment Normal Temperature: 15-35ºC Relative Humidity: 20-75% 1.3. Project data Testing Start Date: 2023-03-09 Testing End Date: 2023-03-14 1.4. Signature Wang Xue (Prepared this test report) Zhang Ying (Reviewed this test report) Zhang Xia (Approved this test report) No.I23Z60340-EMC01 ©Copyright. All rights reserved by CTTL. Page 5 of 29 2. Client Information 2.1. Applicant Information Company Name: Wingtech Group (Hong Kong) Limited Address: Flat/RM 1903 19/F, Podium Plaza, 5 Hanoi Road, Tsim Sha Tsui, KL, HK Contact sharui Email [email protected] Tel. +86-21-53529900 Fax: / 2.2. Manufacturer Information Company Name: Wingtech Group (Hong Kong) Limited Address: Flat/RM 1903 19/F, Podium Plaza, 5 Hanoi Road, Tsim Sha Tsui, KL, HK Contact sharui Email [email protected] Tel. +86-21-53529900 Fax: / No.I23Z60340-EMC01 ©Copyright. All rights reserved by CTTL. Page 6 of 29 3. Equipment Under Test (EUT) and Ancillary Equipment (AE) 3.1. About EUT Description 5G Mobile Phone Model Name TMRV065G FCC ID: 2APXW-TMRV065G Note: Components list, please refer to documents of the manufacturer; it is also included in the original test record of CTTL, Telecommunication Technology Labs, CAICT. 3.2. Internal Identification of EUT used during the test EUT ID* SN or IMEI HW Version SW Version EUT1 861690060030646 V1.0 TMRV065G_0.01.01 *EUT ID: is used to identify the test sample in the lab internally. 3.3. Internal Identification of AE used during the test AE ID* Description SN Remarks AE1 Battery / / AE2 Charger / / AE3 USB Cable / / AE1 Model RE001 Manufacturer SUNWODA ELECTRONIC CO ., LTD Capacity 4500mAh Nominal Voltage AE2 Model BLJ-QC06HU Manufacturer Zhongshan Baolijin Electronic Co., Ltd Length of cable / AE3 Model USB AM TO TYPE-C2.0 Manufacturer Huizhou WASHIN Electronics Co.，Ltd Length of cable / *AE ID: is used to identify the test sample in the lab internally. 3.4. EUT set-ups EUT set-up No. Combination of EUT and AE Remarks Set.1 EUT1 + AE1 + AE2 + AE3 Charger1+REAR Camera+GSM 850 idle Set.2 EUT1 + AE1 + AE2 + AE3 Charger1+MP4+WCDMA 850 idle Set.3 EUT1 + AE1 + AE2 Charger1+ front camera+LTE B5 idle Set.4 EUT1 + AE1 + AE2 USB+ NR n71 idle No.I23Z60340-EMC01 ©Copyright. All rights rese…

Text truncated - open the document above for the full version.

Type and shape of antenna PIFA Antenna Directional characteristics Omni‐directional Deflection Characteristics of Antenna Linear Type of connection with transmitter antenna shrapnel Manufacturer Kunshan Ruixiang Communication Technology Co., LTD Measuring Organization Kunshan Ruixiang Communication Technology Co., LTD 1.EUT Reference Setup 2.Antenna distribution 3.Antenna Pattern ANT0&ANT1 ANT2 ANT3 ANT4&5 ANT6 ANT7 4.Antenna Gain： main frequency Frequency （MHz） Gain （dBi） Frequency （MHz） Gain （dBi） Frequency （MHz） Gain （dBi） 610 -7.91 1700 -3.8 2490 -3.33 620 -7.17 1720 -3.65 2510 -3.05 630 -6.56 1740 -3.26 2530 -2.97 640 -6.11 1760 -2.83 2550 -2.02 650 -6 1780 -2.61 2570 -2.46 660 -6.2 1800 -2.36 2590 -1.97 670 -6.72 1820 -2.6 2610 -1.81 680 -6.3 1840 -2.44 2630 -1.4 690 -6 1860 -2.51 2650 -1.63 700 -5.69 1880 -2.5 2670 -1.67 710 -6.61 1900 -3.16 2690 -1.86 720 -5.63 1920 -3.42 730 -5.25 1940 -4.08 3300 -7.36 740 -5.34 1960 -3.44 3350 -7.31 750 -5.44 1980 -2.83 3400 -5.78 760 -5.26 2000 -2.69 3450 -4.5 770 -5.5 2020 -2.36 3500 -3.88 780 -5.71 2040 -2.18 3550 -2.39 790 -5.9 2060 -2.17 3600 -2.46 800 -5.99 2080 -1.6 3650 -2.25 810 -6.17 2100 -3.61 3700 -2.39 820 -6.02 2120 -3.1 3750 -2.20 830 -6.33 2140 -2.75 3800 -1.94 840 -6.21 2160 -2.46 3850 -2.69 850 -5.81 2180 -2.25 3900 -3.05 860 -5.51 2200 -2.22 3950 -3.35 870 -5.58 4000 -3.27 880 -5.83 4050 -4.00 890 -6.17 4100 -4.29 900 -6.57 4150 -4.71 910 -5.92 4200 -5.63 920 -6.54 930 -6.98 940 -7.2 950 -7.81 960 -8.72 GPS/WIFI Frequency （MHz） Gain （dBi） Frequency （MHz） Gain （dBi） 1565 -0.4 5500 -2.65 1570 -0.27 5520 -2.66 1575 -0.23 5540 -3.01 1580 0.28 5560 -2.83 1585 0.27 5580 -2.93 2400 -1.72 5600 -3.33 2410 -1.8 5620 -3.4 2420 -2.04 5640 -3.42 2430 -2.24 5660 -3.46 2440 -2.22 5680 -3.37 2450 -2.46 5700 -3.28 2460 -2.17 5720 -3.28 2470 -2.28 5740 -3.3 2480 -2.56 5760 -3.53 2490 -2.41 5780 -3.57 2500 -2.42 5800 -3.9 5100 -1.16 5820 -3.88 5120 -0.62 5840 -4.02 5140 -0.7 5860 -4.35 5160 -0.57 5880 -3.7 5180 -0.28 5900 -2.97 5200 -0.39 5220 -0.16 5240 -0.95 5260 -1.44 5280 -1.79 5300 -1.72 5320 -1.74 5340 -2.12 5360 -1.94 5380 -1.84 5400 -1.97 5420 -1.72 5440 -2.17 5460 -2.13 5480 -2.55 5.3D map 650MHz 750MHz 850MHz 1760MHz 1840MHz 1980MHz 2550MHz 2610MHz 2650MHz 3300MHz 3800MHz 4200MHz 1575MHz 2460MHz 5160MHz 5300MHz 5500MHz 5800MHz

15B 15C/15E Spurious Emission
