2APXW-TMRV5GTBREVVLTAB5G

User Manual English 5G Tablet 2 About this manual.................................................................... Thank you for choosing the REVVL TAB 5G (TMRV5GTB) tablet. In order to maintain your device in optimal condition, please read this manual and keep it for future reference. Table of content ........................................................................ Overview Set up Home screen Status bar Split screen mode Power on/off Battery Language Date & time Display Wallpaper Sound Digital wellbeing & parental controls Gestures Multiple users Backup & Factory Reset ........................................................ ........................................................ About this manual .......................................................... 2 1 Getting started ............................................................3 1.1 ...............................................................3 1.2 ....................................................................4 1.3 ....................................................... 5 1.4 ............................................................ 6 1.5 ...............................................6 2 About your tablet .......................................................7 2.1 ........................................................7 2.2 ..................................................................7 3 Personlize your tablet ................................................8 3.1 ..............................................................8 3.2 ..........................................................8 3.3 .................................................................. ............................................................. 9 3.4 9 3.5 ....................................................................9 3.6 ..............10 3.7 ...............................................................10 3.8......................................................10 4.415 ............................................................. 4.5...............................................................16 4.6................................................................17 4.7...................................................................18 5 Google applications ..................................................19 6 Security.......................................................................21 4 Applications............................................................... 11 6.1.........................................................21 6. 22 1 6.3......................................................... 22 6.4..................................................... 22 6.5..................................22 7 Account .......................................................................22 7.1.........................................22 7.2...............................................22 8 Safety & regulatory information ..............................23 9 Troubleshooting27 4.1 .............................................................11 4.2 ...........................................................12 4.3..................................................................14 3.9.....................................11 Contacts Messages Gmail Calendar Camera Photos Clock Screen lock Face Unlock Smart Lock SIM card lock Encryption & credentials Account information Software update 3 1 Getting Started............................................................ 1.1 Overview Power button • Press and release quickly to lock or light up the screen. •Press and hold to launch Google Assistant. • Press and hold the Power key and Volume up key to select from Power off or Restart. • • Press and hold the Power key and Volume up key for at least 10 seconds to force reboot. Press and hold the Power key and Volume down key to take a screenshot and save it. •Press the Power key twice to access the camera. ΍ Speakers ΐ Microphone Γ
Volume Button Ζ 2MP Assist Ύ SIM Card Slot Α Light Sensor Δ Power Button Η Flash Ώ USB Connector Β 8MP Front Camera Ε 8MP Main 1 1 7 2 8 3 4 5 6 9 10 11 4 1.2 Set up Inserting Nano SIM card You must insert your Nano SIM card to make tablet messages using your network. Your tablet only supports Nano SIM cards. In order to avoid damaging your tablet, do not attempt to insert other SIM types, such as Mini or Micro cards. Note: Even if no SIM card is installed, your tablet will still power on and you will be able to connect to a Wi-Fi network and use some of the tablet’s features. Insert the SIM pin that’s provided to eject the SIM tray and then slide it out gently Place or remove the Nano SIM card and the microSD card in the correct slot as shown back of the tablet Volume button • Use the Volume up or down keys to adjust the ringtone volume, or the media volume while listening to music, watching a video, or streaming content. • While using the Camera, press the Volume up or down key to take a photo. back of the tablet Register an E-sim Set E-sim After downloading E-sim configuration document, access to Mobile network, choose the E-sim document and touch YES. Delete E-sim configuration document Connect the device to WiFi or mobile data. Touch Settings > Mobile network > Carrier > > DELETE. Connect to WiFi, touch Settings > Mobile network > +. Touch Download a SIM instead? > Next. Scan QR code and wait for Downloading. After downloading, touch Settings to set E-sim. • • • • 5 Set up your tablet The first time you power on the tablet, you should set the following options: •Touch English (United States) to choose your language, and touch Vision settings to customize accessibility features. When finished, touch Start on original interface to go on. •Select an available Wi-Fi network. Or touch Set up offline and Continue. •Toggle Toggle • • • • Toggle Click Accept to continue. Set a PIN for screen lock, otherwise touch Skip > Skip anyway to continue. to allow to send usage and diagnostic data, otherwise toggle off . to …

Text truncated - open the document above for the full version.

022423-17 rev 6 Certification Application Attestation Statements Date: April 20, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: Statement for 47 CFR section 2.911(d)(5)(i) ______ Wingtech Group (Hong Kong) Limited ______ certifies that as of the date of the application the equipment for which authorization is sought is not “covered” equipment 1 prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, including affiliates or subsidiaries of the named companies, the applicant must include an explanation on why the equipment is not “covered” equipment. Additional Explanation: <N/A> Statement for 47 CFR section 2.911(d)(5)(ii) ______ Wingtech Group (Hong Kong) Limited ______ (“the applicant”) certifies that, as of the date of the filing of this application, the applicant ☐ - is / ☑- is not identified on the Covered List as an entity producing “covered” equipment. Thank you, By: ______ ___ ________ Rui Sha ________________ (Signature 2 ) (Print name) Title: _____ Manager _______ Company: Wingtech Group (Hong Kong) Limited Telephone: +86-21-53529900 1 ‐ The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist . 2 - Letters must be placed on appropriate letterhead.

U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: WINGTECH INTERNATIONAL, INC. Contact Name: James Yoon Street Address: 21900 Oakview Lane City/Province/Zip: Cupertino/California/95014 Telephone No: 425-365-8532 Email: [email protected] FRN #: 0033455775 This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: James Yoon Date: April 20, 2023 Signed by (Printed Name/Title): The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission- related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Wingtech Group (Hong Kong) Limited Grantee Code: 2APXW Contact Name: Rui Sha Street Address: Flat/RM 1903 19/F, Podium Plaza, 5 Hanoi Road, Tsim Sha Tsui, KL, HK City/Province/Zip: Hong Kong Telephone No: +86-21-53529900 Email: [email protected] Applicant Signature 1: Rui Sha Date: April 20, 2023 Signed by (Printed Name/Title): 1 - Letters must be placed on appropriate letterhead.

____________ THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Authority to Act as Agent Date: Apr 7, 2023 American Certification Body, Inc. 313 Park Avenue Suite 300 Falls Church, VA 22046 To Whom It May Concern: CTTL, Telecommunication Technology Labs, CAICT is authorized to act on our behalf, until otherwise notified, for applications to American Certification Body, Inc. (ACB). We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b), to the application is subject to denial of federal benefits, that includes FCC benefits. We also declare that the information provided to the FCC is true and correct to the best of our knowledge (47 CFR 2.911(d)) and we have been informed of the grantee responsibilities (47 CFR 2.909) with regard to certified equipment. Thank you, Agency Agreement Expiration Date: 12 months By: Rui Sha (Signature 1 ) (Print name) Title: Certification Manager On behalf of: Wingtech Group (Hong Kong) Limited (Company Name) Telephone: _+86-21-53529900 1 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 042622-16

THIS MUST BE SIGNED BY THE APPLICANT/AGENT AND SHOULD BE PLACED ON APPROPRIATE LETTERHEAD Request for Confidentiality Date: June 7, 2023 Subject: Confidentiality Request for: 2APXW-TMRV5GTB Pursuant to FCC 47 CFR 0.457(d) and 0.459 and IC RSP-100, Section 12.4, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit ☐ Short Term ☒ Permanent Block Diagrams ☒ Short Term External Photos ☒ Short Term ☐ Permanent * 1 Internal Photos ☐ Short Term ☒ Permanent Operation Description/Theory of Operation ☐ Short Term ☒ Permanent Parts List & Placement/BOM ☐ Short Term ☒ Permanent Tune-Up Procedure ☐ Short Term ☒ Permanent Schematics ☒ Short Term Test Setup Photos ☒ Short Term ☐ Permanent * 3 User’s Manual Wingtech Group (Hong Kong) Limited has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality for FCC Applications: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify ACB in the event information regarding the product or the product is made available to the public before the requested period has expired. ACB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. Short Term Confidentiality for Industry Canada Applications: Starting May 2022, ISED will recognize short term confidentiality on certain exhibits until the intended date of marketing. The applicant requests the exhibits selected above as short term confidential be withheld from public view until: for a period of _180_ days from the date of the Grant of Equipment Authorization and prior to marketing. Rui Sha (Print name) 1 - The asterisked items (*) require further information to be provided to ACB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. 2 - Must be signed by applicant contact given for applicant on the FCC site, or by the authorized agent if an appropriate authorized agent letter has been provided. Letters should be placed on appropriate letterhead. 042622-16 _ _____________ Sincerely, By: ( Signature/Title 2 )

Wingtech Group (Hong Kong) Limited Flat/RM 1903 19/F, Podium Plaza, 5 Hanoi Road, Tsim Sha Tsui, KL, HK Declaration of Frequency Stability We Wingtech Group (Hong Kong) Limited ensure that the product 2APXW- TMRV5GTB meets e-CFR Title 47 section 15.407(g) and KDB 789033 D02v02r01 frequency stability such that the emissions are maintained within the band of operation under all conditions of normal operation as specified in the user's manual. Sincerely Yours, Print Name: Rui Sha Title: Certification Manager Company Name: Wingtech Mobile Communications Co.,Ltd. Tel:+86-21-53529900 Email: [email protected]

SGA35 SGA35 711300002001

Description of E-Label on the TMRV5GTB Menu Step1 Settings Menu step2 About tablet Step3 Regulatory labels

75X30mm TMO REVVL TAB 5G 128G GRY KIT IMEI 1: 353929580000000 MADE IN CHINA DATE: 03/27/2023 S /W : 98109_1_10M11 H/ W : V1.0 SN: 1234567890123456789 SKU: 610214678577 6 10214 67857 7 IMEI 2: 353929580000000 EID:0000000000000000000000000000000000 W:41.9 L:41.9

No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 1 of 351 SAR TEST REPORT No. I23Z60833-SEM05 For Wingtech Group (Hong Kong) Limited 5G Tablet Model Name: TMRV5GTB with Hardware Version: V1.1 Software Version: REVVLTAB5G_0.01.01 FCC ID: 2APXW-TMRV5GTB Issued Date: 2023-7-5 Note: The test results in this test report relate only to the devices specified in this report. This report shall not be reproduced except in full without the written approval of CTTL. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the U.S.Government. Test Laboratory: CTTL, Telecommunication Technology Labs, CAICT No. 52, Huayuan North Road, Haidian District, Beijing, P. R. China 100191. Tel:+86(0)10-62304633-2512, Fax:+86(0)10-62304633-2504 Email: [email protected], website: www.caict.ac.cn No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 2 of 351 REPORT HISTORY Report Number Revision Issue Date Description I23Z60833-SEM05 Rev.0 2023-6-28 Initial creation of test report I23Z60833-SEM05 Rev.1 2023-7-4 1. Change the Equipment Class from PCB to PCT on page6. 2. Add tune up power for GSM 850 EGPRS(8PSK) 4TX slots on page27. 3. Revise Tune up power of WCDMA HSUPA, HSPA+, HSDPA power level A1/B1/C1 on page31-35. 4. Add spot check results for LTE ULCA 7C and 41C on page 180- 181. I23Z60833-SEM05 Rev.2 2023-7-5 1. Add Note4 for LTE ULCA 7C and 41C on page 180-181. 2. Remove SAR results for ENDC B2- n25 on page173. No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 3 of 351 TABLE OF CONTENT 1 TEST LABORATORY ................................................................................................................. 5 1.1 TESTING LOCATION ........................................................................................................................................ 5 1.2 TESTING ENVIRONMENT ................................................................................................................................. 5 1.3 PROJECT DATA ............................................................................................................................................... 5 1.4 SIGNATURE ..................................................................................................................................................... 5 2 STATEMENT OF COMPLIANCE ................................................................................................ 6 3 CLIENT INFORMATION.............................................................................................................. 8 3.1 APPLICANT INFORMATION .............................................................................................................................. 8 3.2 MANUFACTURER INFORMATION ..................................................................................................................... 8 4 EQUIPMENT UNDER TEST (EUT) AND ANCILLARY EQUIPMENT (AE) ................................ 9 4.1 ABOUT EUT ................................................................................................................................................... 9 4.2 INTERNAL IDENTIFICATION OF EUT USED DURING THE TEST ........................................................................ 10 4.3 INTERNAL IDENTIFICATION OF AE USED DURING THE TEST .......................................................................... 10 5 TEST METHODOLOGY ............................................................................................................ 11 5.1 APPLICABLE LIMIT REGULATIONS ................................................................................................................ 11 5.2 APPLICABLE MEASUREMENT STANDARDS ................................................................................................... 11 6 SPECIFIC ABSORPTION RATE (SAR) .................................................................................... 12 6.1 INTRODUCTION ............................................................................................................................................. 12 6.2 SAR DEFINITION .......................................................................................................................................... 12 7 TISSUE SIMULATING LIQUIDS ............................................................................................... 13 7.1 TARGETS FOR TISSUE SIMULATING LIQUID .................................................................................................... 13 7.2 DIELECTRIC PERFORMANCE ......................................................................................................................... 13 8 SYSTEM VERIFICATION .......................................................................................................... 15 8.1 SYSTEM SETUP ............................................................................................................................................. 15 8.2 SYSTEM VERIFICATION ................................................................................................................................. 16 9 MEASUREMENT PROCEDURES ............................................................................................ 17 9.1 TESTS TO BE PERFORMED ............................................................................................................................. 17 9.2 GENERAL MEASUREMENT PROCEDURE ........................................................................................................ 19 9.3 WCDMA MEASUREMENT PROCEDURES FOR SAR ...................................................................................... 20 9.4 SAR MEASUREMENT FOR LTE ..................................................................................................................... 21 9.5 BLUETOOTH & WI-FI MEASUREMENT PROCEDURES FOR SAR ...............................…

Text truncated - open the document above for the full version.

No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 264 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 265 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 266 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 267 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 268 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 269 of 351 900 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 270 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 271 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 272 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 273 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 274 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 275 of 351 1800 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 276 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 277 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 278 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 279 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 280 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 281 of 351 1900 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 282 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 283 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 284 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 285 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 286 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 287 of 351 2450 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 288 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 289 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 290 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 291 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 292 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 293 of 351 2600 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 294 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 295 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 296 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 297 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 298 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 299 of 351 3300 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 300 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 301 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 302 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 303 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 304 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 305 of 351 3500 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 306 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 307 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 308 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 309 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 310 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 311 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 312 of 351

No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 313 of 351 3700 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 314 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 315 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 316 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 317 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 318 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 319 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 320 of 351 3900 MHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 321 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 322 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 323 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 324 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 325 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 326 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 327 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 328 of 351 5 GHz Dipole Calibration Certificate No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 329 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 330 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 331 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 332 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 333 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 334 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 335 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 336 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 337 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 338 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 339 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 340 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 341 of 351 ANNEX I Sensor Triggering Data Summary No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 342 of 351 No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 343 of 351 Per FCC KDB Publication 616217 D04v01r02, this device was tested by the manufacturer to determine the proximity sensor triggering distances for the rear and bottom edge of the device. The measured output power within ±5mm of the triggering points (or until touching the phantom) is included for rear and each applicable edge. To ensure all production units are compliant it is necessary to test SAR at a distance 1mm less than the smallest distance from the device and SAR phantom (determined from these triggering tests according to the KDB 616217 D04v01r02) with the device at maximum output power without power reduction. These SAR tests are included in addition to the SAR tests for the device touching the SAR phantom, with reduced power. No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 344 of 351 ANT0： Rear Moving device toward the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 21 20 19 18 17 16 15 14 13 12 11 Main antenna Far Far Far Far Far Near Near Near Near Near Near Moving device away from the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 11 12 13 14 15 16 17 18 19 20 21 Main antenna Near Near Near Near Near Near Far Far Far Far Far Bottom Edge Moving device toward the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 21 20 19 18 17 16 15 14 13 12 11 Main antenna Far Far Far Far Far Near Near Near Near Near Near Moving device away from the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 11 12 13 14 15 16 17 18 19 20 21 Main antenna Near Near Near Near Near Near Far Far Far Far Far Right Edge Moving device toward the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 21 20 19 18 17 16 15 14 13 12 11 Main antenna Far Far Far Far Far Near Near Near Near Near Near Moving device away from the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 11 12 13 14 15 16 17 18 19 20 21 Main antenna Near Near Near Near Near Near Far Far Far Far Far No.I23Z60833-SEM05 ©Copyright. All rights reserved by CTTL. Page 345 of 351 ANT1： Rear Moving device toward the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 21 20 19 18 17 16 15 14 13 12 11 Main antenna Far Far Far Far Far Near Near Near Near Near Near Moving device away from the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 11 12 13 14 15 16 17 18 19 20 21 Main antenna Near Near Near Near Near Near Far Far Far Far Far Right Edge Moving device toward the phantom: sensor near or far(KDB 616217 6.2.6) Distance [mm] 21 20 19 18 17 16 15 14 13 12 11 Main antenna Far Far Far Far Far Near Near Near Near Near Near Moving device away from …

Text truncated - open the document above for the full version.
