2APZQ-ZYGO2HUnderwater Communication Radio Headset

For assistance, email us on [email protected] This device operates on a no-interference, no-protection basis. Should the user seek to obtain protection from other radio services operating in the same TV bands, a radio license is required. For further details, consult Innovation, Science and Economic Development Canada's Client Procedures Circular CPC-2-1-28, Voluntary Licensing of Licence-Exempt Wireless Microphones in the TV Bands.

August 24, 2024 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(5)(i) and Part 2.911(d)(5)(ii) Filing Re. KDB 986446 D01 FCC ID: 2APZQ-ZYGO2H Dear Sir or Madam, Swimmersive Co. (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. If you have any questions, please contact us. Designated U.S. Agent Information: Name: Swimmersive Co Address: 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 Contact Person: Sheera Goren Tel.: Email: [email protected] Sincerely, Sheera Goren

August 26, 2024 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Ref: Attestation Statements Part 2.911(d)(7) Filing FCC ID: 2APZQ-ZYGO2H FRN: 0027573781 Dear Sir or Madam, Swimmersive Co. (“the applicant”) certifies that, as of the date of the filing of the application, Sheera Goren is our designated U.S. agent for service of process for the above referenced FCC ID. Swimmersive Co. accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Swimmersive Co. accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for the above referenced FCC ID. Designated U.S. Agent Information: Name: Swimmersive Co Address: 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 Contact Person: Sheera Goren Tel.: 818-445-2293 Email: [email protected] FRN: 0027573781 Sincerely, Sheera Goren

Request for Confidentiality Date: __06/13/24___ Subject: Confidentiality Request for: ____FCC ID: 2APZQ- ZYGO2H and IC ID: 23961- ZYGO2H___ Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 9.4, the applicant requests that a part of the subject FCC application be held confidential. T ype of Confidentiality RequestedExhibit Short Term PermanentBlock Diagrams Short Term External Photos Short Term Permanent* 1 Internal Photos Short Term PermanentOperation Description/Theory of Operation Short Term PermanentParts List & Placement/BOM Short Term PermanentTune-Up Procedure Short Term PermanentSchematics Short Term Test Setup Photos Short Term Permanent* 1 User’s Manual Swimmersive Co. has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. Short-Term Confidentiality: The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. Applicant is also aware that they are responsible to notify our TCB in the event information regarding the product or the product is made available to the public. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Our TCB will then release the documents listed above for public disclosure pursuant to FCC Public Notice DA 04-1705. 1 - The asterisked items (*) require further information to be provided to our TCB before permanent confidentiality will be extended to these exhibits. Please refer to FCC KDB 726920 and the specific Document link for D01 found at: https://apps.fcc.gov/oetcf/kdb/forms/FTSSearchResultPage.cfm?switch=P&id=41731 and review section II, 3) regarding specific information that must accompany these requests. NOTE for Industry Canada Applications: IC currently only distinguishes Permanent Confidentiality exhibits as shown above. Short Term confidentiality is not considered applicable to IC applications. Sincerely, By: __________________________ __H. Stephen Berger_______ (Signature/Title) (Print name)

May 29, 2018 Swimmersive Co. 16854 Mooncrest Dr. Encino, CA 91436 To Whom It May Concern: Please be advised that Swimmersive Co. authorizes TEM Consulting and its president, H. Stephen Berger, to act on our behalf in regulatory matters, until otherwise notified. Thank you for your attention to this matter. Sincerely, Sheera Goren CEO Swimmersive Co. Sheera Goren CEO

External Photos FCC ID: 2APZQ- ZYGO2H IC ID: 23961-ZYGO2H Description: Zygo Underwater Communication Radio Headset Model Name: Zygo2H Model Number: ZY700 (regular), ZY701 (large) Swimmersive Co. 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 By TEM Consulting, LP 140 River Rd. Georgetown, TX 78628 June 2024 Figure 1 – External photo of Zygo2H Headset Figure 2 – Bottom of Zygo2H Headset Figure 3 - Zygo2H Headset ear piece - Exterior Figure 4 – Zygo2H Headset ear piece - Interior

Label & Label Location FCC ID: 2APZQ- ZYGO2H IC: 23961-ZYGO2H Description: Zygo Underwater Communication Radio Headset Model Name: Zygo Model Number: ZY700 (regular), ZY701 (large) Swimmersive Co. 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 By TEM Consulting, LP 140 River Rd. Georgetown, TX 78628 August 2024 Figure 1 – The Zygo2 system. Note: 1.) Label to be laser etched. 26mm 8mm Model: ZY700 ZYGO IC:23961-ZYGO2H FCC ID: 2APZQ-ZYGO2H Model: ZY700 ZYGO IC:23961-ZYGO2H FCC ID: 2APZQ-ZYGO2H Standard Note: 1.) Label to be laser etched. 26mm 8mm Model: ZY701 ZYGO IC:23961-ZYGO2H FCC ID: 2APZQ-ZYGO2H Model: ZY701 ZYGO IC:23961-ZYGO2H FCC ID: 2APZQ-ZYGO2H Large

Internal Photos FCC ID: 2APZQ- ZYGO2H IC ID: 23961-ZYGO2H Description: Zygo Underwater Communication Radio Headset Model Name: Zygo2H Model Number: ZY700 (regular), ZY701 (large) Swimmersive Co. 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 By TEM Consulting, LP 140 River Rd. Georgetown, TX 78628 June 2024 Figure 1 – Internal photo of Zygo2 Headset Figure 2 – PWB Front of Zygo2 Headset Figure 3 - PWB back of Zygo2 Headset Figure 4 – Internal photo of Zygo2 Headset ear piece

RF Exposure Analysis Revision 2 FCC ID 2APZQ- ZYGO2H IC ID 23961- ZYGO2H Description: Zygo Underwater Communication Radio Model Name: Zygo2H Model Number: ZY700 (regular), ZY701 (large) Swimmersive Co. 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 By TEM Consulting, LP 140 River Rd. Georgetown, TX 78628 September 2024 TYPE CERTIFICATION Table of Contents Introduction ................................................................................................................................... 2 Product Description ...................................................................................................................... 2 Zygo Radios .................................................................................................................................. 2 FCC Requirements ........................................................................................................................ 2 ISED Canada Requirements ......................................................................................................... 3 Product Analysis ........................................................................................................................... 4 VHF Radio ................................................................................................................................ 4 Conclusion .................................................................................................................................... 4 Introduction This memo evaluates the Zygo system headset for RF exposure testing exclusion to the FCC USA and ISED Canada Requirements. Product Description The Swimmersive Zygo is a communication system for swimmers and swimming coaches. The Zygo system has 2 components. A transmitter to stream music to swimmers or for a coach to talk to his swimmers, called the Zygo Transmitter. A headset, worn by the swimmers, called the Zygo Headset. It’s primary use is to stream music to swimmers as they work out. It also allows a coach to give instructions to swimmers as they work out. When coach’s use the unit to give instructions the unit operates push-to-talk (PTT) and the Bluetooth link is not active. In this mode the unit is handheld. The Zygo transmitter operates in the 174-216 MHz VHF band and 2.4 GHz ISM bands. The Zygo headset operates in the 174-216 MHz. The unit is battery powered. Zygo Radios The Zygo system headset has a low frequency transmitter, that operates in the 174-216 MHz band. The measured powers were: Frequency (MHz) Power (dBm) 175.0 15.736 194.5 15.314 209.5 14.565 The highest measured power was with the low frequency radio channel. The low channel is at 175.0 MHz with a measured power of 37.46 mW (15.736 dBm). The low frequency radio has a duty cycle of transmission for 3.4 mS followed by a 1.0 mS off time. This calculates to a duty cycle of 5.3 dB. FCC Requirements FCC KDB 447498 D01 V06 section 4.3 gives SAR test exclusion guidance: 4.3. General SAR test exclusion guidance 4.3.1. Standalone SAR test exclusion considerations .... a) For 100 MHz to 6 GHz and test separation distances ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR,30 where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation31 • The result is rounded to one decimal place for comparison • The values 3.0 and 7.5 are referred to as numeric thresholds in step b) below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm, and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 4.1 f) is applied to determine SAR test exclusion. b) For 100 MHz to 6 GHz and test separation distances > 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following (also illustrated in Appendix B): 1) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·(f(MHz)/150)]} mW, for 100 MHz to 1500 MHz 2) {[Power allowed at numeric threshold for 50 mm in step a)] + [(test separation distance – 50 mm)·10]} mW, for > 1500 MHz and ≤ 6 GHz The formula can be used to calculate the maximum allowable power. The power of interest is the source-based time-averaged maximum conducted output power of the RF channel. The formula for the maximum allowable power, based on the guidance of section 4.3 in the KDB, is: 푃=푇∙퐷/√푓 • P is the source-based time-averaged maximum conducted output power in W • T is the numeric thresholds of 3.0 and 7.5 • D is the minimum separation distance in m • f is the RF channel transmit frequency in GHz For the highest frequency used, 216 MHz: • for a numeric threshold of 3.0 the maximum power is 32.3 mW • for a numeric threshold of 7.5 the maximum power is 80.7 mW ISED Canada Requirements Canadian regulation for RF exposure are contained in Spectrum Management and Telecommunications Radio Standards Specification RSS-102 Issue 5, March 2015, Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands). Section 2.5.1, Exemption Limits for Routine Evaluation – SAR Evaluation, provides the following exclusion limits: The values listed are for a 1 gram tissue value. If a device is worn on a limb and subject to the 10 gram value the values in the table are multiplied by 2.5: For limb-worn devices where the 10 gram value applies, the exemption limits for routine evaluation in Table 1 are multiplied by a factor of 2.5. Hence for the headset the limit is 71 mW. Product Analysis VHF Radio The low frequency radio has a 5.3 dB duty cycle It meets both the FCC and ISED test exclusion criterion. Conclusion This analysis concludes that the radio in the Zygo2H head…

Text truncated - open the document above for the full version.

Antenna FCC ID: 2APZQ- ZYGO2H IC ID: 23961-ZYGO2H Description: Zygo Underwater Communication Radio Headset Model Name: Zygo2H Model Number: ZY700 (regular), ZY701 (large) Swimmersive Co. 2447 Pacific Coast Highway, 2nd Fl. Hermosa Beach, CA 90254 By TEM Consulting, LP 140 River Rd. Georgetown, TX 78628 June 2024 The Zygo2H headset uses a “Normal Mode Conformal Helical Dipole”, with bone conductor speaker wires passing through the helix. See Figure 1. The peak gain for the Headset is – 1.39 dBi. Figure 1 – Internal photo of Zygo2 Headset antenna Table 1 – Peak gain versus frequency

Project PRJ0050267 Swimmersive Co. dba Zygo Zygo2H Wireless Certification Report Wireless Microphone (VHF) Section Prepared for: Swimmersive 16854 Mooncrest Dr Encino, CA 91436 By Nemko USA, Inc. 1601 North A.W. Grimes Blvd., Suite B Round Rock, Texas 78665 21 August 2024 Written by Veer Patel Wireless Engineer Swimmersive – ZYGO2H – VHF Section PRJ0050267 Nemko USA, Inc. Page 2 of 27 Revision History Revision Number Description Date Draft 01 Draft for review. 7/10/2024 Final 01 Release to agency 8/2/2024 Final 02 Updated Output Power and Mask data 8/21/2024 Errata: Swimmersive –ZYGO2H – VHF Section PRJ0050267 Nemko USA, Inc. Page 3 of 27 Table of C ontents Revision History ............................................................................................................................................................. 1 Compliance Certificate .................................................................................................................................................. 4 1.0 Introduction ..................................................................................................................................................... 5 1.1 Scope .......................................................................................................................................................... 5 1.2 EUT Description ........................................................................................................................................ 5 1.3 EUT Operation ........................................................................................................................................... 5 1.4 Modifications to Equipment ....................................................................................................................... 5 1.5 Test Site ...................................................................................................................................................... 5 1.6 Radiated Measurements ............................................................................................................................. 6 1.7 Applicable Documents and Clauses ........................................................................................................... 6 2.0 Fundamental Power......................................................................................................................................... 7 2.1 Test Procedure ............................................................................................................................................ 7 2.2 Test Criteria ................................................................................................................................................ 7 2.3 Test Results, Peak Power ........................................................................................................................... 7 2.3.1 RF Output Power ................................................................................................................................... 8 3.0 Frequency Stability ......................................................................................................................................... 9 3.1 Test Procedure ............................................................................................................................................ 9 3.2 Test Criteria ................................................................................................................................................ 9 3.3 Test Results ................................................................................................................................................ 9 4.0 Necessary Bandwidth Mask .......................................................................................................................... 10 4.1 Test Procedure .......................................................................................................................................... 10 4.2 Test Criteria .............................................................................................................................................. 10 4.3 Test Results .............................................................................................................................................. 10 4.3.1 Step 1: Zero Span Power, Modulated .................................................................................................. 10 4.3.2 Step 2, 3: Mask, Max Hold .................................................................................................................. 11 5.0 Radiated Spurious Emissions ........................................................................................................................ 13 5.1 Test Criteria .............................................................................................................................................. 13 5.2 Test Results .............................................................................................................................................. 13 5.3 Low Channel ............................................................................................................................................ 13 6.0 Equipment ..................................................................................................................................................... 25 6.1 Radiated Emissions .................................................................................................................................. 25 6.2 Fundamental Power, Bandwidth, Duty Cycle, Mask, Conducted Spurious ............................................. 25 7.0 Measurement Bandwidths ............................................................................................................................. 26 Appendix: Policy, Rationale, and Evaluation of EMC Measurement Uncertainty .…
