2AR5EID151Fitness Tracker

ID151 Fitness Tracker User Manual Thank you for purchasing our products. This manual addresses the safety guidelines, warranty, and operating instructions. Please review this manual thoroughly before operating your device. Contents English Version Getting Started .................................................................1 What’s in the Box ............................................................1 What’s in this Document ..................................................1 Setting Up Your Tracker ..................................................2 Charging Your Tracker .....................................................2 Assembling/Dissembling Your Tracker.............................3 Wearing Your Tracker......................................................3 All-day Wear and Exercise..............................................3 Using Your Tracker...........................................................5 App Installation................................................................5 App Interfaces.................................................................6 Pairing the Tracker with Your Phone...............................8 Getting to Know Your Tracker.........................................9 Touch Key.......................................................................9 Waking a Dimmed Screen............................................10 Tracker Interfaces.........................................................10 Function Introduction....................................................11 1. Changing the Clock Face..........................................11 2. Tracking Daily Activity Data ......................................12 3. Monitoring Heart Rate...............................................12 4. Stopwatch.................................................................13 5. Setting Alarms..........................................................13 6. Tracking Sports: Walk...............................................14 7. Tracking Sports: Run................................................15 8. Tracking Sports: Bike...............................................16 8.1 Abnormal Situations During Exercise ..................17 8.2 Abnormal Operation Situation During Exercise...18 9. Tracking Sleep........................................................18 10. More Functions.......................................................19 10.1 Call Notification................................................19 10.2 Message Notification........................................19 10.3 Sedentary Reminder.........................................20 10.4 Remote Camera Control...................................20 10.5 Device Error Notification...................................21 Basic Specifications.....................................................21 Electronic Information Products/Poisonous and Harmful Statement........................................................21 FAQs..............................................................................22 Warranty and Safety Instructions................................24 Warranty .........................................................................24 Important Safety Instructions.........................................24 What’s in the box - 1 - Getting Started Note: This tracker is designed with a built-in USB plug, no charging cable is required for charging, and no charging cable or wall charger is included in the package. ID151 Fitness Tracker User Manual Thank you for purchasing our products. This manual addresses the safety guidelines, warranty, and operating instructions. Please review this manual thoroughly before operating your device. Fitness tracker (ID151 with bands) User manual What’s in this Document This manual gets you started quickly by setting up your tracker. Setup ensures that your tracker can synchronize its data with the VeryFitPro app, where you can get detailed information on your stats, view historical trends, log sleep, and more. As soon as setup is complete, you’re ready to start moving. The remainder of the manual walks you through every function on your ID151. Please charge your tracker for at least 10 minutes to have it activated before initial use. - 2 - Setting up Your Tracker 1. Charging your tracker Insert the built-in USB plug of the tracker into the USB port for charging. Please ensure that the metal strips align with the USB strips. When the tracker shows a low battery indication, connect the tracker to a USB charging adaptor or a port with 5V-500mA. If the tracker is installed correctly, the tracker will vibrate. If the tracker does not vibrate, remove the tracker, flip it upside-down and reinsert it into the charging port. Remove the tracker from the power supply once fully charged. USB charger requirement: DC USB port (5V-500mA) Charging time: 1-2hr(s) - 3 - Assemble Push the bands in following the direction of the arrow. Disassemble Gently pull the bands off the tracker body following the direction of the arrow. Wearing Your Tracker All-day wear and exercise For all-day wear when you’re not exercising, wear the device on your wrist horizontally, a finger’s width below your wrist bone and lay flat, the same way you would put on a watch. 2. Assembling/Dissembling Your Tracker For optimized heart rate tracking, keep these tips in mind: 1. Experiment with wearing the tracker higher on your wrist during exercise. Because blood flow in your arm increases the farther up you go, moving the tracker up a couple of inches can improve the heart rate signal. Also, many exercises such as bike riding or weight lifting cause you to bend your wrist frequently, which is more likely to interfere with the heart rate signal if the tracker is lower on your wrist. - 4 - 2. Do not wear your tracker too tight; a tight band restricts blood flow, potentially affecting the heart rate signal. That being said, the tracker should also be slightly tighter (snug but not constricting) during exercise than dur…

Text truncated - open the document above for the full version.

FCC ID Label Information 1. Label location: 2. FCC ID Label: FCC ID:2AR5EID151 FCCID Label Location

BT Antenna

SHENZHEN MIFANG NETWORK TECHNOLOGY CO., LTD. 305, No.8 BLDG., SUOLING INDUSTRIAL ZONE XIKENG, GUANLAN, LONGHUA, SHENZHEN, GUANGDONG, CHINA Tel:+86-13715282097 Fax: N/A Declaration concerning Antenna Specification It is hereby declared that the product Model No.: ID151 FCC ID: 2AR5EID151 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: 2.4G ANT Type of antenna: FPC ANT Gain of the antenna: -2.03dBi Frequency range: 2402~2480 MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: SHENZHEN MIFANG NETWORK TECHNOLOGY CO., LTD. Address: 305, No.8 BLDG., SUOLING INDUSTRIAL ZONE XIKENG, GUANLAN, LONGHUA, SHENZHEN, GUANGDONG, CHINA City: Shenzhen ZIP / Postal code: Country: China Place: Shenzhen Date: 2019-01-02 Signature: version01

RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v05 The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune‐up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison pt=‐2.27dBm =0.593mW at 2480MHz So (0.593mW/5mm)x √2.480GHz =0.187<3 Then SAR evaluation is not required

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15.247 Report Reference No. ................ : CTL1911261011-WF Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Nice Nong (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name ............................ : Fitness Tracker Model/Type reference ................ : ID151 List Model(s) ............................... : N/A Trade Mark .................................. : LETSCOM, Letsfit, ANBES FCC ID ......................................... : 2AR5EID151 Applicant’s name ....................... : SHENZHEN MIFANG NETWORK TECHNOLOGY CO., LTD. Address of applicant ................. : 305, No.8 BLDG., SUOLING INDUSTRIAL ZONE XIKENG, GUANLAN, LONGHUA, SHENZHEN, GUANGDONG, CHINA Test Firm ..................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm ................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ....................... : Standard ...................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. TRF Originator ............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF .................................. : Dated 2011-01 Date of receipt of test item ........ : Nov. 29, 2019 Date of sampling ........................ : Nov. 29, 2019 Date of Test Date ........................ : Nov. 29, 2019–Dec. 18, 2019 Data of Issue............................... : Dec. 19, 2019 Result .......................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 35 Report No.: CTL1911261011-WF TEST REPORT Test Report No. : CTL1911261011-WF Dec. 19, 2019 Date of issue Equipment under Test : Fitness Tracker Model /Type : ID151 Listed Models : N/A Applicant : SHENZHEN MIFANG NETWORK TECHNOLOGY CO., LTD. Address : 305, No.8 BLDG., SUOLING INDUSTRIAL ZONE XIKENG, GUANLAN, LONGHUA, SHENZHEN, GUANGDONG, CHINA Manufacturer : SHENZHEN MIFANG NETWORK TECHNOLOGY CO., LTD. Address : 305, No.8 BLDG., SUOLING INDUSTRIAL ZONE XIKENG, GUANLAN, LONGHUA, SHENZHEN, GUANGDONG, CHINA Test result Pass * * In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. V1.0 Page 3 of 35 Report No.: CTL1911261011-WF ** Modified History ** Revisions Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2019-12-19 CTL1911261011-WF Tracy Qi V1.0 Page 4 of 35 Report No.: CTL1911261011-WF Table of Contents Page 1. SUMMARY ............................................................................................................................................................... 5 1.1. TEST STANDARDS ..................................................................................................................................................... 5 1.2. TEST DESCRIPTION ........................................................................................................................................................ 5 1.3. TEST FACILITY .............................................................................................................................................................. 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. GENERAL INFORMATION .......................................................................................................................................... 8 2.1. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 8 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY .......................................................................................................... 8 2.4. EQUIPMENTS USED DURING THE TEST .............................................................................................................................. 9 2.5. RELATED SUBMITTAL(S) / GRANT (S) ................................................................................................................................ 9 2.6. MODIFICATIONS ........................................................................................................................................................... 9 3. TEST CONDITIONS AND RESULTS ............................................................................................................................ 10 3.1. CONDUCTED EMISSIONS TEST ....................................................................................................................................... 10 3.2. RADIATED EMISSIONS AND BAND EDGE .......................................................................................................................... 13 3.3. MAXIMUM CONDUCTED OUTPUT POWER ...................................................................................…

Text truncated - open the document above for the full version.
