2ARN3-SMARTCINEWireless Microphone System

Shenzhen Jiayz photo industrial ., Ltd Add: A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Tel: 13538005185 Fax: 0755-28435911 Date: 2020-05-07 Dear Sir/Madam, We, Shenzhen Jiayz photo industrial., Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Wireless Microphone System Model no.: SmartCine W2,SmartCine W1 Sincerely, Name/Title： michael zhao/manager Company: Shenzhen Jiayz photo industrial ., Ltd Address: A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Phone: 13538005185 Fax: 0755-28435911 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/05/07 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2ARN3-SMARTCINE SmartCine W2,SmartCine W1 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： michael zhao/manager Company: Shenzhen Jiayz photo industrial ., Ltd Address: A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Phone: 13538005185 Fax: 0755-28435911 E-Mail: [email protected]

Shenzhen Jiayz photo industrial ., Ltd A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 05/07/2020 To whom it may concern: We, Shenzhen Jiayz photo industrial., Ltd the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2ARN3-SMARTCINE including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： michael zhao/manager Company: Shenzhen Jiayz photo industrial ., Ltd Address: A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Phone: 13538005185 Fax: 0755-28435911 E-Mail: [email protected]

FCC ID: 2ARN3-SMARTCINE Fig. 1 Fig. 2 FCC ID: 2ARN3-SMARTCINE Fig. 3 Fig. 4 FCC ID: 2ARN3-SMARTCINE Fig. 5 Fig. 6 FCC ID: 2ARN3-SMARTCINE Fig. 7

LABEL AND LOCATION Label And Location Wireless Microphone System Model No.: SmartCine W2 FCC ID: 2ARN3-SMARTCINE

FCC ID: 2ARN3-SMARTCINE Fig. 1 Fig. 2 FCC ID: 2ARN3-SMARTCINE Fig. 3 Fig. 4 Antenna FCC ID: 2ARN3-SMARTCINE Fig. 5

This report shall not be reproduced except in full, without the written approval of Shenzhen HUAK Testing Technology Co., Ltd. Page 1 of 2 FCC RF Exposure Evaluation FCC ID: 2ARN3-SMARTCINE Exposure category: General population/uncontrolled environment EUT Type: Production Unit Device Type: Portable Device Refer Standard: KDB 447498 D01 General RF Exposure Guidance v06 FCC Part 2 §2.1093 Evaluation method According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. Conducted Power Results Mode Channel Frequency(MHz) Peak Conducted Output Power (dBm) GFSK 0 2402 0.163 36 2442 0.457 72 2478 -0.552 Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 36 Channel 72 Target (dBm) 0.0 0.0 0.0 Tolerance ±(dB) 1.0 1.0 1.0 This report shall not be reproduced except in full, without the written approval of Shenzhen HUAK Testing Technology Co., Ltd. Page 2 of 2 Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power SAR Test Exclusion Threshold SAR Test Exclusion dBm mW GFSK 2.450 5 1.0 1.2589 0.3941 < 3.0 Yes Remark: 1. Output power including tune up tolerance; 2. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to f) in section 4.1 is applied to determine SAR test exclusion. Conclusion The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06. ----------------THE END OF REPORT---------------

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : GTS20200429008-1-1 2ARN3-SMARTCINE Compiled by ( position+printed name+signature) .. : File administrators Peter Xiao Supervised by ( position+printed name+signature) .. : Test Engineer Moon Tan Approved by ( position+printed name+signature) .. : Manager Simon Hu Date of issue ..................................... : Apr.28, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co.,Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Jiayz photo industrial ., Ltd Address ............................................ : A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Test specification ...........................: Standard ........................................... : FCC Part 15.247 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Microphone System Trade Mark ....................................... : Manufacturer .................................... : Shenzhen Jiayz photo industrial ., Ltd Model/Type reference....................... : SmartCine W2 Listed Models .................................. : SmartCine W1 Modulation Type ............................... : GFSK Operation Frequency ........................ : From 2406MHz to 2478MHz Rating ............................................... : DC 3.0V From Battery Result................................................ : PASS Report No.: GTS20200429008-1-1 Page 2 of 35 E S T R E P O R T Test Report No. : GTS20200429008-1-1 Apr.28, 2020 ______________________________________________________________________________________________ Date of issue Equipment under Test : Wireless Microphone System Model /Type : SmartCine W2 Listed Models : SmartCine W1 Applicant : Shenzhen Jiayz photo industrial ., Ltd Address : A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Manufacturer : Shenzhen Jiayz photo industrial ., Ltd Address : A16 Builing,Intelligent Terminal Industrial Park of Sililcon Valley Power, Guanlan, Longhua District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200429008-1-1 Page 3 of 35 Contents 1. T E S T S T A N DA R D S ................................................................. 4 2. S U M M A R Y ............................................................................ 5 2.1. General Remarks 5 2.2. Product Description 5 2.3. Equipment Under Test 5 2.4. Short description of the Equipment under Test (EUT) 5 2.5. EUT operation mode 5 2.6. Block Diagram of Test Setup 6 2.7. Related Submittal(s) / Grant (s) 6 2.8. EUT configuration 7 2.9. Modifications 7 3. T E S T E N V I R O N M E N T .............................................................. 8 3.1. Address of the test laboratory 8 3.2. Test Facility 8 3.3. Environmental conditions 8 3.4. Test Description 9 3.5. Statement of the measurement uncertainty 9 3.6. Equipments Used during the Test 10 4. T E S T C O N D I T I O N S AN D R E S U L T S ........................................... 11 4.1. AC Power Conducted Emission ................................................................................... 11 4.2. Radiated Emission ........................................................................................................ 12 4.3. Maximum Peak Output Power ...................................................................................... 18 4.4. Power Spectral Density ................................................................................................ 19 4.5. 6dB Bandwidth ............................................................................................................. 21 4.6. Band Edge Compliance of RF Emission ...................................................................... 23 4.7. Spurious RF Conducted Emission ............................................................................... 26 4.8. Antenna Requirement ................................................................................................... 29 5. T E S T S E T U P P H O T O S O F T H E E U T ......................................... 30 6. E X T E R N A L A N D I N T E R N A L P H O T O S O F T H E E U T ...................... 31 Report No.: GTS20200429008-1-1 Page 4 of 35 1. T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 v05r02: Guidance for Compliance Measurements on Digital Transmission S…

Text truncated - open the document above for the full version.

FCC ID: 2ARN3-SMARTCINE
