2ARRB-MBH40MOTOROLA true wireless headphones

Product Parameters Project Parameters EARBUDS 3.7V 2.4 - 2.480GHz 10m 20Hz-20KHz 320mAh 100mm 75mm Power On Method 1: Open the charging case lid，white LED on for 1 sec. Method 2: When the left and right Earbuds are turned off，Press and Hold MFB for 2 sec，white LED on for 1 sec. Power Off Method 1: Put the TWS on the charging case and close lid. Method 2: Earbuds is ON,press and hold MFB for 6 sec,orange LED ON for 2 sec,Left & Right earbuds power off. Pairing Mode Step1： Fully open the charging case top lid,Master flashes white and orange, Slave flashes white one time every 5 sec. Step2： Call in progress Activate Voice Assistant Left & Right earbuds operation Pick Call ：Incoming call,press MFB once Reject Call：Incoming call,press and hold MFB for 2 sec End Call ：Call in progress,press MFB once Activation:Earbuds is in Standby mode,Press and hold Left or Right earbuds MFB for 2 sec. Play music mode Left & Right earbuds operation ① ② ③ Previous song：Triple press MFB Next song：Double press MFB Stop/Play: Press MFB once ① ② ③ Touch area position Charging BOX LED Indicator -38dB±1dB ≈34g FunctionOperation Intelligent Voice Activation stop music play music Set volume to 8 level increase volume turn down volume play previous song play next song Function Hello_Moto stop music play music increase volume moderate volume play previous song turn down volume play next song Command words answer the phone reject the call Voice recognition on and off operations Enable speech recognition: Earbuds is in Standby mode，six press MFB ，and there is an enabled voice prompt. Turn off speech recognition: Earbuds is in Standby mode，six press MFB ，and there is a voice prompt to turn it off. Factory Reset 1234 7891011112 Searching mobile device“MOTO BUDS H40”for pairing ， after finish Paring，Master and Slave flashes white one time every 5 sec. CHARGING CASE Rated input Rated output Charging CASE Battery Capacity Charging CASE Weight Bluetooth Frequency Bluetooth Distance Frequency R Working Voltage MIC Sensitivity Bluetooth Version Earphone Battery Capacity Earphone Weight 32mAh ≈4g V5.3 Pick Call Reject Call User Manual MOTOROLA True Wireless Bluetooth Headphones MOTO BUDS H40 Earbud is in OFF mode without charging case, press and hold pairing button for 10 sec,white and orange LED flashing 3 times Type-C Charging Socket Charging Case LED Indicator Functional Touch Area Charging Case Product Description Product Composition LR User Manual Charging Cable Bluetooth Bluetooth set up My device MOTO BUDS H40 5V 320mA 5V 180mA (Incoming call：The white light flashes three times quickly, stop for 2s) Left & Right earbuds operation Earbuds Charging complete：White LED always on Open or close the charging case（>20%）：White light will turn off after 10 seconds Charging to the case：Orange LED flashing Open or close the charging case（<20%）：Orange light flashes for 10 seconds and then goes out Note: This function is turned off by default at the factory and needs to be manually turned on for the first time. Note: To prevent accidental contact, please adjust to avoid the touch area when wearing. To avoid hearing damage, keep the volume at a moderate level. Avoid listening to music at loud volume levels for prolonged periods of time as this may cause permanent hearing damage or hearing loss.Don't use this product when it is unsafe to do so. For example,while operating a vehicle, cycling, crossing a road, or any activity which requires your attention and ability to hear. Please visit: motorolasound.com/support 1. Safety Instructions 2. Help & More Consumer Products and Accessories Limited Warranty(“Warranty") Thank you for purchasing this Motorola branded product manufactured under license by Meizhou GuoWei Electronics Co. LTD("MZGW") What Does this Warranty Cover? Subject to the exclusions contained below. MZGW warrants that this Motorola branded product(“Product”)or certified accessory(“Accessory”)sold for use with this product that it manufactured to be free from defects in materials and workmanship under normal consumer usage for the period outlined below.This Warranty is your exclusive warranty and is not transferable. Who is covered? This Warranty extends only to the first consumer purchaser, and is not transferable. What will MZGW do? MZGW or its authorized distributor at its option and within a commercially reasonable time, will at no charge repair or replace any Products or Accessories that does not conform to this Warranty. We may use functionally equivalent reconditioned/refurbished /pre-owned or new Products,Accessories or parts. 3.General Information ANY IMPLIED WARRANTIES, INCLUDING WITHOUTLIMITATION THE IMPLIED WARRANTIES OFMERCHANTABILITY AND FITNESS FOR A PARTICULARPURPOSE, SHALL BE LIMITED TO THE DURATION OFTHIS LIMITED WARRANTY, OTHERWISE THE REPAIROR REPLACEMENT PROVIDED UNDER THIS EXPRESSLIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THECONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHERWARRANTIES.EXPRESS OR IMPLIED,IN NO EVENTSHALL MOTOROLA OR MZGW BE LIABLE, WHETHER INCONTRACT OR TORT (INCLUDING NEGLIGENCE) FORDAMAGES IN EXCESS OF THE PURCHASE PRICE OFTHE PRODUCT OR ACCESSORY, OR FOR ANY INDIRECTINCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGESOF ANY KIND. OR LOSS OF REVENUE OR PROFITS.LOSS OF BUSINESS, LOSS OF INFORMATION OR OTHERFINANCIAL LOSS ARISING OUT OF OR IN CONNECTIONWITH THE ABILITY OR INABILITY TO USE THE PRODUCTSOR ACCESSORIES TO THE FULL EXTENT THESEDAMAGES MAY BE DISCLAIMED BY LAW. Some jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or exclusions may not apply to you.This Warranty gives you specific legal rights, and you may also have other rights that vary from one jurisdiction to another. What Other Limitations Are There? Consumer Products One (1)year from the date of the products original purchase by the first consumer purchaser of the product Consumer Accessories Ninety(90) days from t…

Text truncated - open the document above for the full version.

1RWH,IWKHHTXLSPHQWIRUZKLFKWKHDSSOLFDQWVHHNVDXWKRUL]DWLRQLVSURGXFHGE\ DQ\RIWKHHQWLWLHVLGHQWLILHGRQWKHFXUUHQW&RYHUHG/LVW MĞinjŚŽƵ'ƵŽ WĞi lĞĐtƌŽŶiĐs Ž͕͘>td &RYHUHG (TXLSPHQW &HUWLILFDWLRQ $WWHVWDWLRQ /HWWHU '$7(： )HGHUDO &RPPXQLFDWLRQV &RPPLVVLRQ $XWKRUL]DWLRQ DQG (YDOXDWLRQ 'LYLVLRQ  2DNODQG 0LOOV 5RDG &ROXPELD 0'  86$ $771 5HYLHZLQJ (QJLQHHU )&& ,'$55B0BH 0HL]KRX *XR WHL (OHFWURQLFV &R/WG ³WKH DSSOLFDQW ́ FHUWLILHV WKDW WKH HTXLSPHQW IRU ZKLFK DXWKRUL]DWLRQ LV VRXJKW LV QRW ³FRYHUHG ́ HTXLSPHQW SURKLELWHG IURP UHFHLYLQJ DQ HTXLSPHQW DXWKRUL]DWLRQ SXUVXDQW WR VHFWLRQ  RI WKH )&& UXOHV WKHDSSOLFDQWVKRXOG LQFOXGH DQ H[SODQDWLRQ RQ ZK\ WKH HTXLSPHQW LV QRW ³FRYHUHG ́ HTXLSPHQW 6LJQHG 3ULQWHG QDPH$S WDQJ 7LWOH(QJLQHHULQJ 'LUHFWRU &RPSDQ\ 1DPH0HL]KRX *XR WHL (OHFWURQLFV &R /WG 'DWH Meizhou Guo Wei Electronics Co., Ltd ³WKH DSSOLFDQW ́ FHUWLILHV WKDW DV RI WKH GDWHRI WKH ILOLQJ RI WKHDSSOLFDWLRQ WKH DSSOLFDQWLV QRWLGHQWLILHG RQ WKH &RYHUHG /LVW DV DQHQWLW\ SURGXFLQJ ³FRYHUHG ́ HTXLSPHQW

&B;B(G  86$*(17/(77(52)$77(67$7,21 86$JHQW 72 2IILFH RI (QJLQHHULQJ 7HFKQRORJ\ )HGHUDO &RPPXQLFDWLRQV &RPPLVVLRQ  2DNODQG 0LOOV 5RDG 86$JHQW &RPSDQ\ 1DPHBDLKHWLDQ ,QQRYDWLYH 6ROXWLRQV)51 &RQWDFW1DPHKHQQHWK <RXQJ 6WUHHW $GGUHVV &KDVH5G &LW\3URYLQFHZLS'HDUERUQ0, 7HOHSKRQH1R (PDLOkHQ\RXQJ@EDLKHWLDQVROXWLRQVFRP &ROXPELD 0'  7KLV OHWWHU LV WR FRQILUP WKDW ZH KDYH DFFHSWHG WKH UHVSRQVLELOLW\ WR DFW DV 86 DJHQW UHSUHVHQWDWLYH RQ EHKDOI RI WKH 0HL]KRX *XR WHL (OHFWURQLFV &R /WG QRWHG EHORZ IRU DOO IXWXUH )&& FHUWLILFDWLRQUHJLVWUDWLRQV REWDLQHG GXULQJ WKH SHULRG RI WKLV DJUHHPHQW ZKLFK HQGV DW WKH VSHFLILHG GDWH EHORZ $V SHU 86 DJHQW ZH DUH DZDUH RI WKH UHTXLUHPHQWV LQYROYHG DV RXWOLQHG LQ )&& (TXLSPHQW $XWKRUL]DWLRQ 3URJUDP LQ WKHLU 5HSRUW DQG 2UGHU )&&  DQG WKH FODXVH †  $SSOLFDWLRQ UHTXLUHPHQWV $SSOLFDQW &RPSDQ\ QDPH0HL]KRX *XR WHL (OHFWURQLFV &R /WG  6LJQDWXU  'DWH   7KH$SSOLFDQWDFNQRZOHGJHWKHDFFHSWDQFHRILWVREOLJDWLRQWRPDLQWDLQDQDJHQWIRU VHUYLFHRISURFHVVLQWKH8QLWHG6WDWHVIRUQROHVVWKDQRQH\HDUDIWHUHLWKHUWKH JUDQWHHKDVSHUPDQHQWO\WHUPLQDWHGDOOPDUNHWLQJDQGLPSRUWDWLRQRIWKHDSSOLFDEOH HTXLSPHQWZLWKLQWKH86RUWKHFRQFOXVLRQRIDQ\&RPPLVVLRQUHODWHG DGPLQLVWUDWLYHRUMXGLFLDOSURFHHGLQJLQYROYLQJWKHHTXLSPHQWZKLFKHYHULVODWHU  $SSOLFDQW¶V 1DPH $S W DQJ 7LWOH 0$1$*(5  7LWOH 86 $JHQW¶V 1DPH .HQQHWK<RXQJ PDQDJHU 6LJQDWXUHH *UDQWHH FRGH )&& ,' &RQWDFW 1DPH $S W $55B $55B0BH DQJ $GGUHVV AD1 Section,Economic Development Area,Dongsheng Industrial District, Meizhou,Guangdong 7HOHSKRQH 1R  )D[ 1R  (PDLO [email protected] FRN: Jul 2024

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¶VUHJXODWLRQVZLOOKDYHDIIL[HGWRLWD ODEHOLGHQWLFDOWRWKDWVXEPLWWHGIRUDSSURYDOZLWKWKLVDSSOLFDWLRQ &ŽƌŝŶƐƚĂŶĐĞƐǁŚĞƌĞŽƵƌĂƵƚŚŽƌŝnjĞĚĂŐĞŶƚƐŝŐŶƐƚŚĞĂƉƉůŝĐĂƚŝŽŶĨŽƌĐĞƌƚŝĨŝĐĂƚŝŽŶŽŶŽƵƌďĞŚĂůĨ͕/ ĂĐŬŶŽǁůĞĚŐĞƚŚĂƚĂůůƌĞƐƉŽŶƐŝďŝůŝƚLJĨŽƌĐŽŵƉůLJŝŶŐǁŝƚŚƚŚĞƚĞƌŵƐĂŶĚĐŽŶĚŝƚŝŽŶƐĨŽƌĐĞƌƚŝĨŝĐĂƚŝŽŶ͕  ƐƚŝůůƌĞƐŝĚĞƐǁŝƚŚMĞŝnjŚŽƵ GƵŽ WĞŝ EůĞĐƚƌŽŶŝĐƐŽ͕͘>ƚĚŶĚAD1 Section, Economic Development <^ŝŐŶĂƚƵƌĞ> EĂŵĞ ˖ ƉWĂŶŐ dŝƚůĞ ˖ EŶŐŝŶĞĞƌŝŶŐDŝƌĞĐƚŽƌ ŽŵƉĂŶLJ ˖ MĞŝnjŚŽƵ GƵŽWĞŝ EůĞĐƚƌŽŶŝĐƐ Ž͕͘>ƚĚ Area,DŽŶŐƐŚĞŶŐ/ŶĚƵƐƚƌŝĂůDŝƐƚƌŝĐƚ͕MĞŝnjŚŽƵ͕GƵĂŶŐĚŽŶg China ;ƉƉůŝĐĂŶƚEĂŵĞĂŶĚĂĚĚƌĞƐƐͿ

x 6FKHPDWLFV x %ORFNGLDJUDP x2SHUDWLRQGHVFULSWLRQ 7KHVHPDWHULDOVFRQWDLQWUDGHVHFUHWVDQGSURSULHWDU\LQIRUPDWLRQDQGDUHQRW FXVWRPDULO\UHOHDVHGWRWKHSXEOLF7KHSXEOLFGLVFORVXUHRIWKLVLQIRUPDWLRQPLJKWEH KDUPIXOWRWKHFRPSDQ\DQGSURYLGHXQMXVWLILHGEHQHILWVWRRXUFRPSHWLWRUV '$7(：8 (TXLSPHQW $XWRULVDWLRQ 'LYLVLRQ )HGHUDO &RPPXQLFDWLRQV &RPPLVVLRQ  2DNODQG 0LOOV 5RDG &ROXPELD 0'  )&& ,'$55%0%H 3URGXFW 1DPH 027252/$ WUXH ZLUHOHVV KHDGSKRQHV 5HTXHVW IRU &RQILGHQWLDOLW\ 3XUVXDQW WR 6HFWLRQV  DQG  RI WKH FRPPLVVLRQ¶V UXOHV ZH KHUHE\ UHTXHVW WKDW WKH IROORZLQJ GRFXPHQWV EH KHOG FRQILGHQWLDO /LVW KHUH WKH GRFXPHQWV IRU ZKLFK \RX DUH VHHNLQJ FRQILGHQWLDOLW\ ± IRU H[DPSOH «  6LJQDWXUH! 1DPH˖$S :DQJ 7LWOH ˖ (QJLQHHULQJ 'LUHFWRU &RPSDQ\˖0HLzKRX *XR :HL (OHFWURQLFV &R /WG

ModelNo.: AT2301

Meizhou Guo Wei Electronics Co.,Ltd AD1 Section, Economic Development Area , Dongsheng Industrial District,Meizhou, Product: MOTOROLA true wireless headphones ModelMOTO BUDS H40 FCC ID:2ARRB-MBH40 Guangdong,China 5V 320mA

MOTO BUDS H40_CN V1 产品名称：摩托罗拉真无线蓝牙耳机 产品型号：MOTO BUDS H40 蓝牙版本：V5.3 频响范围：20Hz -20KHz 耳机电池容量：32mAh 充电仓电池容量：320mAh 耳机额定输入：5V 90mA 充电仓额定输入：5V 320mA 无线传输距离：10米 制造商：梅州国威电子有限公司 地址： 中国广东省梅州市经济开发区 AD1区 服务热线：400-105-4098 执行标准：GB 4943.1-2022 中国制造 Pr oduct Name：Motor ola true wireless headphones Pr oduct Model：MOTO BUDS H40 Bluetooth Version：V5.3 Fr equency Response：20Hz-20KHz Batt ery of Earphone：32mAh Batt ery of Charging case：320mAh Rated Input(Earphone)：5V 90mA Rated Input(Charging case)：5V 320mA Transmission Distance：10m Manufacture：Meizhou Guo Wei Electronics Co.,L td. Addres s：AD1 Section, Economic Development Area, Meizhou, Guangdong,China Service Hotline：400-105-4098 Exec utive Standard：GB 4943.1-2022 Made in China MOTOROLA and the Stylized M Logo are trademarks or register ed trademarks of Motor ola Trademark Holdings, LL C. and are used under license. All other trademarks are the property of their respective owners. 2024 Motor ola Mobility LLC. All rights reserved. MOTO BUDS H40 MOTO BUDS H40 FCC ID:2ARRB-MBH40MO TO BUDS H40 Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 6 974106 820609 MO TO BUDS H40 White 0 0 0 0 0 0 0 0 0 0 0 0 0 0 6 974106 820616 MO TO BUDS H40 Pink 0 0 0 0 0 0 0 0 0 0 0 0 0 0 6 974106 820630 MO TO BUDS H40 Black chrome 0 0 0 0 0 0 0 0 0 0 0 0 0 0 6 974106 820623 FCC ID:2ARRB-MBH40 FCC ID:2ARRB-MBH40 FCC ID:2ARRB-MBH40 FCC ID:2ARRB-MBH40MO TO BUDS H40 Black 0 0 0 0 0 0 0 0 0 0 0 0 0 0 6 974106 820609

ThetestreportiseffectiveonlywithbothsignatureandspecializedstampandTheresult(s)showninthisreportreferonlytothesample(s)tested.Without writtenapprovalofBlueAsia,thisreportcan ’ tbereproducedexceptinfull.Theresultsdescribedinthisreportdonotrepresentthequalityorcharacteristicsofthe sampledbatch,nordotheyrepresentanysimilaroridenticalproductsthatarenotexplicitlystated. ModelNo.: AT2301

RFExposureevaluation ProductName:MOTOBUDSH40 FCCID:2ARRB-MBH40 TestStandard: KDB447498D04GeneralRFExposure Guidancev01 Accordingto447498D04InterimGeneralRFExposureGuidancev01 Antgain=1.71dBi MaxOutputpower=0.645dBm@EDR@2480MHz ERP=0.645dBm+1.71dBi-2.15=0.205dBm So ComplywithRFexposureexemptionlimit. worse case：10^0.0645=1.16mW < 2.72 mW

Website:www.cblueasia.com Tel:+86-755-23059481 Email:[email protected] ThetestreportiseffectiveonlywithbothsignatureandspecializedstampandTheresult(s)showninthisreportreferonlytothesample(s)tested.Without writtenapprovalofBlueAsia,thisreportcan ’ tbereproducedexceptinfull.Theresultsdescribedinthisreportdonotrepresentthequalityorcharacteristicsofthe sampledbatch,nordotheyrepresentanysimilaroridenticalproductsthatarenotexplicitlystated. TestReport Applicant:MeizhouGuoWeiElectronicsCo.,Ltd Address: AD1Section,EconomicDevelopment Area,DongshengIndustrialDistrict,Meizhou, Guangdong ProductName:MOTOROLAtruewirelessheadphones BrandMark:N/A Model:MOTOBUDSH40 Seriesmodel:N/A ReportNumber:BLA-EMC-202407-A2902 FCCID:2ARRB-MBH40 DateofReceipt:2024.07.05 DateofTest:2024.07.09to2024.07.17 TestStandard:47CFRPart15,SubpartC15.247 TestResult:Pass Compiledby:Reviewby:Approvedby: IssuedDate:2024.07.18 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Address: BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China ReportNo.:BLA-EMC-202407-A2902 Page 2 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] TableofContents 1Generalinformation......................................................................................................................................................5 1.1Generalinformation.................................................................................................................................................5 1.2GeneraldescriptionofEUT.....................................................................................................................................5 2Testsummary................................................................................................................................................................6 3TestConfiguration........................................................................................................................................................7 3.1Testmode................................................................................................................................................................7 3.2OperationFrequencyeachofchannel....................................................................................................................7 3.3Testchannel.............................................................................................................................................................8 3.4Auxiliaryequipment.................................................................................................................................................9 3.5Testenvironment.....................................................................................................................................................9 4Laboratoryinformation..............................................................................................................................................10 4.1Laboratoryandaccreditations...............................................................................................................................10 4.2Measurementuncertainty......................................................................................................................................10 5Testequipment............................................................................................................................................................11 6Testresult....................................................................................................................................................................12 6.1Antennarequirement.............................................................................................................................................12 6.2ConductedemissionsatACpowerline(150kHz-30MHz)..................................................................................13 6.3ConductedpeakoutputPower..............................................................................................................................17 6.420dBBandwidth....................................................................................................................................................18 6.5ConductedBandEdgesMeasurement.................................................................................................................19 6.6Conductedspuriousemissions.............................................................................................................................20 6.7CarrierFrequenciesSeparation............................................................................................................................21 6.8HoppingChannelNumber.....................................................................................................................................22 6.9DwellTime.............................................................................................................................................................23 6.10Radiatedspuriousemissions..............................................................................................................................24 6.11Radiatedemissionswhichfallintherestrictedbands.........................................................................................35 7AppendixA..................................................................................................................................................................42 7.1MaximumConductedOutputPower.....................................................................................................................42 7.2-20dBBandwidth...................................................................................................................................................46 7.3OccupiedChannelBandwidth..................…

Text truncated - open the document above for the full version.

ReportNo.:BLA-EMC-202407-A2902 Page 57 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdgeNVNT2-DH12480MHzAnt1No-HoppingRef BandEdgeNVNT2-DH12480MHzAnt1No-HoppingEmission ReportNo.:BLA-EMC-202407-A2902 Page 58 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] ReportNo.:BLA-EMC-202407-A2902 Page 59 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.5BandEdge(Hopping) ConditionModeFrequency(MHz)AntennaHoppingModeMaxValue(dBc)Limit(dBc)Verdict NVNT1-DH12402Ant1Hopping-50.06-20Pass NVNT1-DH12480Ant1Hopping-52.75-20Pass NVNT2-DH12402Ant1Hopping-49.96-20Pass NVNT2-DH12480Ant1Hopping-52.1-20Pass BandEdge(Hopping)NVNT1-DH12402MHzAnt1HoppingRef BandEdge(Hopping)NVNT1-DH12402MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202407-A2902 Page 60 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdge(Hopping)NVNT1-DH12480MHzAnt1HoppingRef BandEdge(Hopping)NVNT1-DH12480MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202407-A2902 Page 61 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdge(Hopping)NVNT2-DH12402MHzAnt1HoppingRef BandEdge(Hopping)NVNT2-DH12402MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202407-A2902 Page 62 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] BandEdge(Hopping)NVNT2-DH12480MHzAnt1HoppingRef BandEdge(Hopping)NVNT2-DH12480MHzAnt1HoppingEmission ReportNo.:BLA-EMC-202407-A2902 Page 63 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] ReportNo.:BLA-EMC-202407-A2902 Page 64 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.6ConductedRFSpuriousEmission ConditionModeFrequency(MHz)AntennaMaxValue(dBc)Limit(dBc)Verdict NVNT1-DH12402Ant1-35.15-20Pass NVNT1-DH12441Ant1-36.86-20Pass NVNT1-DH12480Ant1-36.32-20Pass NVNT2-DH12402Ant1-36.71-20Pass NVNT2-DH12441Ant1-36.54-20Pass NVNT2-DH12480Ant1-36.45-20Pass Tx.SpuriousNVNT1-DH12402MHzAnt1Ref Tx.SpuriousNVNT1-DH12402MHzAnt1Emission ReportNo.:BLA-EMC-202407-A2902 Page 65 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] Tx.SpuriousNVNT1-DH12441MHzAnt1Ref Tx.SpuriousNVNT1-DH12441MHzAnt1Emission ReportNo.:BLA-EMC-202407-A2902 Page 66 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] Tx.SpuriousNVNT1-DH12480MHzAnt1Ref Tx.SpuriousNVNT1-DH12480MHzAnt1Emission ReportNo.:BLA-EMC-202407-A2902 Page 67 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] Tx.SpuriousNVNT2-DH12402MHzAnt1Ref Tx.SpuriousNVNT2-DH12402MHzAnt1Emission ReportNo.:BLA-EMC-202407-A2902 Page 68 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] Tx.SpuriousNVNT2-DH12441MHzAnt1Ref Tx.SpuriousNVNT2-DH12441MHzAnt1Emission ReportNo.:BLA-EMC-202407-A2902 Page 69 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] Tx.SpuriousNVNT2-DH12480MHzAnt1Ref Tx.SpuriousNVNT2-DH12480MHzAnt1Emission ReportNo.:BLA-EMC-202407-A2902 Page 70 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] ReportNo.:BLA-EMC-202407-A2902 Page 71 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.7CarrierFrequenciesSeparation ConditionModeAntennaHoppingFreq1(MHz)HoppingFreq2(MHz)HFS(MHz)Limit(MHz)Verdict NVNT1-DH1Ant12440.96452442.0191.05450.871Pass NVNT2-DH1Ant12440.9572442.00551.04850.841Pass CFSNVNT1-DH12441MHzAnt1 CFSNVNT2-DH12441MHzAnt1 ReportNo.:BLA-EMC-202407-A2902 Page 72 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] ReportNo.:BLA-EMC-202407-A2902 Page 73 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.8NumberofHoppingChannel ConditionModeAntennaHoppingNumberLimitVerdict NVNT1-DH1Ant17915Pass NVNT2-DH1Ant17915Pass HoppingNo.NVNT1-DH12441MHzAnt1 HoppingNo.NVNT2-DH12441MHzAnt1 ReportNo.:BLA-EMC-202407-A2902 Page 74 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] ReportNo.:BLA-EMC-202407-A2902 Page 75 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] 7.9DwellTime ConditionModeFrequency (MHz) AntennaPulseTime (ms) TotalDwellTime (ms) Burst Count PeriodTime (ms) Limit (ms) Verdict NVNT1-DH12441Ant10.403127.34831631600400Pass NVNT1-DH32441Ant11.66257.315531600400Pass NVNT1-DH52441Ant12.907302.32810431600400Pass NVNT2-DH12441Ant10.413130.50831631600400Pass NVNT2-DH52441Ant12.91331.7411431600400Pass DwellNVNT1-DH12441MHzAnt1OneBurst DwellNVNT1-DH12441MHzAnt1Accumulated ReportNo.:BLA-EMC-202407-A2902 Page 76 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] DwellNVNT1-DH32441MHzAnt1OneBurst DwellNVNT1-DH32441MHzAnt1Accumulated ReportNo.:BLA-EMC-202407-A2902 Page 77 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] DwellNVNT1-DH52441MHzAnt1OneBurst DwellNVNT1-DH52441MHzAnt1Accumulated ReportNo.:BLA-EMC-202407-A2902 Page 78 of 83 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Tel:+86-755-23059481 Email:[email protected] DwellNVNT2-DH12441MHzAnt1OneBurst D…

Text truncated - open the document above for the full version.

承 認 書 SPECIFICATION FOR APPROVAL 客戶名稱 CUSTOMER ： 客戶料號 CUSTOMER’S P/N ： 料號 PART NUMBER ： KBAN3216E245H0201 規格 DESCRIPTION ： Chip Antenna 3216 L Ant 2.45G Type H02 版本 VERSION ： V1.2 日期 ISSUE DATE ： 2020/08/25 客 戶 承 認 CUSTOMER APPROVED 工 程 部 R&D CENTER 承 認 APPROVAL 確 認 CHECKED 製 作 DRAWN Ziv Alex Jerry 萬誠科技股份有限公司 OneWave Electronic Co., Ltd. 112台北市北投區立功街151號1樓 1F, No. 151, Li Gong Street, Beitou District, Taipei City 112, Taiwan 電話: (02) 2898-2220 TEL: +886 2 2898-2220 傳真: (02) 2898-5055 FAX: +886 2 2898-5055 2/11 ONEWAVE TECHNOLOGY CO., LTD. 3216 Chip antenna For Bluetooth / WLAN Applications Dimension (mm) L 3.23 ± 0.20 W 1.66 ± 0.20 T 0.45 ± 0.20 P/N: KBAN3216E245H0201 3/11 ONEWAVE TECHNOLOGY CO., LTD. Part Number Information KBAN 3216 E 245 H 02 01 A B C D E F G A Product Series Antenna B Dimension L x W 3.2 x 1.6mm (±0.2mm) C Material High K material D Working Frequency 2.4 ~ 2.5GHz E Feeding mode PIFA & Single Feeding F Antenna type Type = 02 G Mark type Type = 01 1. Electrical Specification Remark : Bandwidth & Peak Gain was measured under evaluation board of next page Specification Part Number KBAN3216E245H0201 Central Frequency 2450 MHz Bandwidth 120 (Min.) MHz Return Loss -6.5 (Max) dB Peak Gain 1.71 dBi Impedance 50 Ohm Operating Temperature -40～+110 °C Maximum Power 4 W Resistance to Soldering Heats 10 ( @ 260°C) sec. Polarization Linear Azimuth Beamwidth Omni-directional Termination Ni / Au (Leadless) 4/11 ONEWAVE TECHNOLOGY CO., LTD. 2. Recommended PCB Pattern Evaluation Board Dimension 2 nd Evaluation Board Dimension Suggested Matching Circuit 重要資訊 : 匹配元件建議使用精準度高的電感±0.1~0.3nH、電容±0.1pF 5/11 ONEWAVE TECHNOLOGY CO., LTD. Layout Dimensions in Clearance area( Size=5.9*5.0mm) FootPrint (Unit : mm) ◆ 2 nd Layout Dimensions in Clearance area( Size=8.0*3.0mm) Matching Circuit 50 ohm transmission Line 6/11 ONEWAVE TECHNOLOGY CO., LTD. 3. Measurement Results Return Loss 7/11 ONEWAVE TECHNOLOGY CO., LTD. Radiation Pattern Efficiency Peak Gain Directivity 2400MHz 77.26 % 1.63 dBi 2.75 dBi 2450MHz 79.88 % 1.71 dBi 2.68 dBi 2500MHz 77.98 % 1.67 dBi 2.75 dBi Chamber Coordinate System Z Y X 8/11 ONEWAVE TECHNOLOGY CO., LTD. 4.Reliability and Test Condictions ITEM REQUIREMENTS TEST CONDITION Solderability 1. Wetting shall exceed 90% coverage 2. No visible mechanical damage Pre-heating temperature:150°C/60sec. Solder temperature:230±5°C Duration:4±1sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Solder heat Resistance 1. No visible mechanical damage 2. Central Freq. change :within ± 6% 10 ± 0.5 sec. 60 sec . . T E M P ( °C ) 150 °C 2 6 0 °C Pre-heating temperature:150°C/60sec. Solder temperature:260±5°C Duration:10±0.5sec. Solder:Sn-Ag3.0-Cu0.5 Flux for lead free: rosin Component Adhesion (Push test) 1. No visible mechanical damage The device should be reflow soldered(230±5°C for 10sec.) to a tinned copper substrate A dynometer force gauge should be applied the side of the component. The device must with-ST-F 0.5 Kg without failure of the termination attached to component. Component Adhesion (Pull test) 1. No visible mechanical damage Insert 10cm wire into the remaining open eye bend ,the ends of even wire lengths upward and wind together. Terminal shall not be remarkably damaged. Thermal shock 1. No visible mechanical damage 2. Central Freq. change :within ±6% Phase Temperature(°C) Time(min) 1 +110±5°C 30±3 2 Room Temperature Within 3sec 3 -40±2°C 30±3 4 Room Temperature Within 3sec +110°C=>30±3min -40°C=>30±3min Test cycle:10 cycles The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to High Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: +110±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Resistance to Low Temperature 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature:-40±5°C Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. Humidity 1. No visible mechanical damage 2. Central Freq. change :within ±6% 3. No disconnection or short circuit. Temperature: 40±2°C Humidity: 90% to 95% RH Duration: 1000±12hrs The chip shall be stabilized at normal condition for 2~3 hours before measuring. 4±1 sec. 60sec TEMP (°C) 150°C 230°C 9/11 ONEWAVE TECHNOLOGY CO., LTD. 5.Soldering and Mounting Mildly activated rosin fluxes are preferred. The minimum amount of solder can lead to damage from the stresses caused by the difference in coefficients of expansion between solder, chip and substrate. The terminations are suitable for all wave and re-flow soldering systems. If hand soldering cannot be avoided, the preferred technique is the utilization of hot air soldering tools. Recommended temperature profiles for re-flow soldering in Figure 1. P…
