2ARRB-PIP1510PUVideo baby monitor

For: PIP1510 CONNECT, PIP1510-2 CONNECT, PIP1510-3 CONNECT, PIP1510-4 CONNECT User Guide PIP1510 CONNECT 5.0" FHD Wi-Fi® Video Baby Monitor Welcome... to your new Motorola Wi-Fi ® Video Baby Monitor! Thank you for purchasing the Wi-Fi® Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their play room. Our Connected Baby Monitor let you see your baby from the hand-held viewer, or from your smartphone. Watch over and communicate with your baby from anywhere in the world. Please keep your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For questions, warranty, support or service related to the product, please contact us by visiting: motorolanursery.com This User’s Guide has all the information you need to make the most out of your product. Please read the Safety Instructions on pages 8-10 before you install the unit. Inside the Box •1 x Parent Unit • 1 x Baby Unit (Wi-Fi® Camera) • 1 x Wall Mount Bracket •1 x Power adapter for Parent Unit •1 x Power adapter for Baby Unit In multi-camera packs, you will find one or more additional Camera Units with power adapters and Wall mount bracket units. Overview of the Parent Unit 1 2 3 4 5 6 7 8 9 1.Display (LCD screen) 2. 3. Audio Level LEDs (Green, Green, Amber, Red, Red) 4. Navigation Button - Press Left/Right to pan the camera left or right. - Press Up/Down to tilt the camera upward or downward. - Press Left and Right to select parent unit volume level. - Press Up/Down/Left Right to adjust menu settings and to access menu options when menu is active. 5. Menu Button OK/Zoom Button - Press t o confirm a selection. - Press to toggle Zoom in and Zoom out. 6. 7. Talk Back Button Press and hold to talk to your baby. 8. Volune/Back Button Press to open / close the Menu options. 9. - Press for the parent unit volume selection. - Press to exit the menu or back to the previous menu. Charging LED - Red when the parent unit is ON. - Purple when electrical outlet connected. - Blue when off and connected to electrical outlet. Parent Unit ON/OFF and Screen ON/OFF Button - Press and hold to switch the parent unit ON/OFF. - Single press to switch the screen ON/OFF. Parent Unit menu icons Zoom in/out Camera selection LCD brightness Screen ON/OFF Timer Play List Split Screen for multi- camera application Alarm Message Box Temperature Unit 11 12 10 1 0. 11. 12. Speaker Fixed stand Antenna Overview of Your Baby Unit Important guidelines for installing your Video Baby Monitor •To use your Baby Unit and Parent Unit together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, a metallic door or reinforced concrete, between the Baby Unit and Parent Unit may block the radio signal. •The signal strengt h may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. •Other 2.4GHz products, such as wireless networks (Wi-Fi® routers), Bluetooth™ systems, microwave ovens or other Baby Monitors, may cause interference with this product, so keep the Baby Monitor at least 5ft (1.5m) away from these types of product, or switch them off if they appear to be causing interference. • If the signal is weak, try moving the Parent and/or the Baby Unit to differ ent positions in the rooms. 1. Photo s ensor (Night Vision Mode) 2. Camera lens 3. Infrared LEDs under the camera lens (x 8, for night vision) 4. High sens itivity microphone 5. Stand 6. Power/Link LED indicatior 7.PAIR button 8.Speaker 9.Power Socket 10. Temperature Sensor 1 2 4 5 3 10 9 8 7 6 6 Table of contents Table of contents 1.Safety Instructions ..........................................................................8 2.Getting Started ..............................................................................10 2.1 Connecting the Power Supply for the Baby Unit ......................10 2.2 Fixing magnetic mount on the wall ................................................10 2.3 Connecting the Power Supply of the Parent Unit. .....................11 2.4 Desktop Stand of the Parent Unit .....................................................11 2.5 Registration (Pairing)............................................................................12 3.Using the Baby Monitor ...............................................................13 3.1 Setting Up .................................................................................................13 3.2 Night Vision Mode ..................................................................................13 3.3 Talk Mode ...................................................................................................13 3.4 Digital Pan and Tilt .................................................................................13 3.5 Video ON/OFF ........................................................................................13 3.6 Temperature Display (HH °C / °F or LL °C / °F) ........................14 4.Parent Unit Menu Options ...........................................................14 4.1 Volume ........................................................................................................14 4.2 Zoom ...........................................................................................................14 4.3 Brightness .................................................................................................14 4.4 Audio Playlist ...........................................................................................14 4.4.1 Lullaby/Soothing Sounds Playback ....................................14 4.4.2 Audio Book (English only) Pla…

Text truncated - open the document above for the full version.

Ver. 1 15_Fbe_2011 AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: +86-755-25736666, Fax: +86-755-25732288, Website: www.sgwglobal.com ************************************************************************************************************ 11-Octoter-2021 To whom it may concern敬启者, Multiple Models Confirmation Letter型号多样性确认书 I, the undersigned, hereby confirm that the family models are listed in the following table. 我司特此确认下列表内的型号有以下相同及不同之处。 These models are identical as follows: 相同之处如下: √ Electronics/electrical designs, including firmware 电子或电机设计,包括固件 √ Construction design/Physical design/Enclosure结构设计或物理设计或外壳 √ PCB layout PCB走线布局 □ (Others, please specify其他,请说明) The only differences between these models are the follows for marketing purpose: 不同之处如下: √ Color颜色 √ software软件 The RF FW are same across different models. The Communication protocol are same so that RF parameters are no difference. □ Cosmetic details 外观细节 □ Trade name商标 √ Model Number型号 □ (Others, please specify其他,请说明) □ Suffix (“ ”) represents 子尾(“ ”)代表 □ Color code色标 √ Packing configuration包装配置 Gift box, Label, User Guide... □ (Others, please specify其他,请说明) Item No. 项目 New model 新型号 Model Number型号 Remark 注释 1 √ YES PIP1510 CONNECT PU FCC ID: 2ARRB-PIP1510PU IC: 20353-PIP1510PU 2 √ YES PIP1500 CONNECT PU 3 √ YES PIP1510 PU 4 √ YES PIP1500 PU The sample being submitted to Shenzhen Accurate Technology Co., Ltd. for conformity assessment is item no. / model number PIP1510 CONNECTPU (tested model) of the above list. Regards此致, Raymond Leung Engineering Manager

Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: 0755-2573 6666 Email: [email protected] FCC Confidential Authorization Date: 2021-10-27 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ARRB-PIP1510PU In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Meizhou Guo Wei Electronics Co., Ltd hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Raymond Leung Engineering Manager

Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF External Photos Page 1 of 6 External Photos Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF External Photos Page 2 of 6 Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF External Photos Page 3 of 6 Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF External Photos Page 4 of 6 Antenna For Adapter 1 : BQ12G-0501500-U 2.4 G FHSS Antenna Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF External Photos Page 5 of 6 For Adapter 2 : S012-1B050150VU Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF External Photos Page 6 of 6

Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF LABEL AND LOCATION Page 1 of 1 FCC ID Label Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Internal Photos Page 1 of 4 Internal photos Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Internal Photos Page 2 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Internal Photos Page 3 of 4 Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Internal Photos Page 4 of 4

Note: This report may contain data that are not covered by the A2LA accreditati ★ on and are marked with an asterisk “ ”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503396 Web: www.atc-lab.com Version 821: 2021-11-09 Page 1 of 65 SAR TEST REPORT Applicant Name : Meizhou Guo Wei Electronics Co., Ltd. Address : AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Report Number : SZ1210926-54083E-SA FCC ID 2ARRB-PIP1510PU IC 20353-PIP1510PU Test Standard (s) FCC 47 CFR part 2.1093 RSS-102 Issue 5 Amendment 1 (February 2, 2021) Sample Description Product Type: Video baby monitor Model No.: PIP1510 CONNECT PU Multiple Model(s) No.: PIP1500 CONNECT PU, PIP1510 PU, PIP1500 PU Trade Mark: Motorola Date Received: 2021/09/28 Date of Test: 2021/12/02 Report Date: 2021/12/03 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Lancd Li Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: SZ1210926-54083E-SA Version 821: 2021-11-09 Page 2 of 65 SAR Attestation of Test Results MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) 2.4 GHz SRD 10g Limb SAR 0.18 4.0 Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices RSS-102 Issue 5 Amendment 1 (February 2, 2021) Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands). Safety Code 6 Health Canada’s Radiofrequency Exposure Guidelines Limits of Human Exposure to Radiofrequency Electromagnetic Energy in the Frequency Range from 3 kHz to 300 GHz RF Exposure Procedures: TCB Workshop April 2019 IEC/IEEE 62209-1528:2020 Measurement procedure for the assessment of specific absorption rate of human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices – Part 1: Devices used next to the ear (Frequency range of 300 MHz to 6 GHz) KDB procedures KDB 447498 D01 General RF Exposure Guidance v06. KDB 648474 D04 Handset SAR v01r03. KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in Safety Code 6 Health Canada’s Radiofrequency Exposure Guidelines and has been tested in accordance with the measurement procedures specified in IEC/IEEE 62209-1528:2020 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Shenzhen Accurate Technology Co., Ltd. Report No.: SZ1210926-54083E-SA Version 821: 2021-11-09 Page 3 of 65 SAR TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 EUT DESCRIPTION ................................................................................................................................................... 5 TECHNICAL SPECIFICATION ............................................................................................................................................. 5 REFERENCE, STANDARDS, AND GUIDELINES ................................................................................................. 6 SAR LIMITS ..................................................................................................................................................................... 7 FACILITIES ................................................................................................................................................................. 8 DESCRIPTION OF TEST SYSTEM .......................................................................................................................... 9 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 16 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 16 EQUIPMENTS LIST & CALIBRATION INFORMATION ........................................................................................................ 16 SAR MEASUREMENT SYSTEM VERIFICATION ............................................................................................. 17 LIQUID VERIFICATION ................................................................................................................................................... 17 SYSTEM ACCURACY VERIFICATION ............................................................................................................................... 18 SAR SYSTEM VALIDATION DATA ......................................................................................................................... 19 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 20 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS ...............................................................…

Text truncated - open the document above for the full version.

★ Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “ ”. Shenzhen Accurate Technology Co., Ltd. is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. Shenzhen Accurate Technology Co., Ltd. 1/F., Building A, Changyuan New Material Port, Science & Industry Park, Nanshan District, Shenzhen, Guangdong, P.R. China Tel: +86 755-26503290 Fax: +86 755-26503396 Web: www.atc-lab.com Version 30: 2021-11-09 Page 1 of 44 FCC&RSS-FHSS TEST REPORT Applicant Name : Meizhou Guo Wei Electronics Co., Ltd Address : AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Report Number : SZ1210926-54083E-RF-00A FCC ID: 2ARRB-PIP1510PU IC 20353-PIP1510PU Test Standard (s) FCC PART 15.247; RSS-GEN ISSUE 5, FEBRUARY 2021 AMENDMENT 2; RSS-247, ISSUE 2, FEBRUARY 2017 Sample Description Product Type: Video baby monitor Model No.: PIP1510 CONNECT PU Multiple Model(s) No.: PIP1500 CONNECT PU, PIP1510 PU, PIP1500 PU( Please refer to DOS for Model difference） Trade Mark: Motorola Date Received: 2021/09/26 Date of Test: 2021/09/29~2021/11/18 Report Date: 2021/11/24 Test Result: Pass* * In the configuration tested, the EUT complied with the standards above. Prepared and Checked By: Approved By: Black Ding Candy Li EMC Engineer EMC Engineer Shenzhen Accurate Technology Co., Ltd. Report No.: SZ1210926-54083E-RF-00A Version 30: 2021-11-09 Page 2 of 44 FCC&RSS-FHSS TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 SPECIAL ACCESSORIES ................................................................................................................................................. 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 7 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 7 EXTERNAL I/O CABLE .................................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 FOR CONDUCTED EMISSION .................................................................................................................................... 7 FOR RADIATED EMISSION BELOW 1G ................................................................................................................... 8 SUMMARY OF TEST RESULTS ............................................................................................................................... 9 TEST EQUIPMENT LIST ......................................................................................................................................... 10 FCC§15.247 (I), §1.1307 (B) (1) & §2.1093 – RF EXPOSURE .................................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 RSS-102 – RF EXPOSURE ........................................................................................................................................ 12 APPLICABLE STANDARD ............................................................................................................................................ 12 FCC §15.203 & RSS-GEN §6.8– ANTENNA REQUIREMENT ............................................................................ 13 APPLICABLE STANDARD ............................................................................................................................................ 13 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 13 FCC §15.207 (A) & RSS-GEN §8.8…

Text truncated - open the document above for the full version.

Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Test Photos Page 1 of 3 Photo of Conducted Emission Measurement Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Test Photos Page 2 of 3 Photo of Radiated Emission Measurement (Below 1G) Photo of Radiated Emission Measurement (Above 1G) Shenzhen Accurate Technology Co., Ltd. Project No.: SZ1210926-54083E-RF Test Photos Page 3 of 3
