2ARRB-PIP15BUAudio Baby Monitor

nursery AUDIO BABY MONITOR User Guide Important Notes: • Charge PIP15-2 MULTI-ROOM for 16 hours before use. PIP15 MULTI-ROOM PIP15-2 MULTI-ROOM PIP15-3 MULTI-ROOM PIP15-4 MULTI-ROOM For : Safety instructions WARNING Strangulation Hazard. Children have STRANGLED in cords. Keep this cord out of the reach of children (more than 1 metre away). Never use extension cords with AC Adapters. Only use the AC Adapters provided. Baby monitor setup and use: •Determine a location for the baby unit that will allow you to hear your baby in his/her cot. •Place the baby unit on a flat surface, such as a dresser, bureau, or shelf. •NEVER place the baby unit or cords within the cot. WARNING This digital audio baby monitor is compliant with all relevant standards regarding electromagnetic fields and is, when handled as described in the User Guide, safe to use. Therefore, always read the instructions in this User Guide carefully before using the device. •Adult assembly is required. Keep small parts away from children when assembling. •This product is not a toy. Do not allow children to play with it. •This digital audio baby monitor is not a substitute for responsible adult supervision. •Keep this User Guide for future reference. •Keep the cords out of reach of children. •Do not cover the digital audio baby monitor with a towel or blanket. •Test this monitor and all its functions so that you are familiar with it prior to actual use. •Do not use the digital audio baby monitor in damp areas or close to water. •Do not install the digital audio baby monitor in extreme cold or heat, direct sunlight, or close to a heat source. •Do not touch the plug contacts with sharp or metal objects. •Connect the power adapters to easily accessible power outlet. CAUTION There is a risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. Welcome... to your new Motorola PIP15-2 MULTI-ROOM Baby Monitor! •Secure, interference free reception and high-quality sound. •Magnetically attached baby and parent units. • Long range up to 1000 feet outdoors (line of sight). •Two-way talk back between baby and parent units. •Battery powered portable baby and parent units. •Parent unit with mute function and sound alert LED indicator. •Out of range and low battery alert LED indicator. Need help? If you have any problems setting up or using your PIP15-2 MULTI- ROOM, please contact Customer Services at motorolanursery.com/ support or +1-800-763-2207 (United States and Canada). Alternatively, you may find the answer in the ‘Help’ section at the back of this guide. This User Guide provides you with all the information you need to get the most from your digital audio baby monitor. Read the instructions carefully, and be aware that this digital audio baby monitor is only intended as an aid. It is not a substitute for responsible and proper adult supervision. Before you use the digital audio baby monitor, set up the parent and baby units. Follow the simple instructions in ‘Getting started’, on the next few pages. Important Only use the power adapters supplied. Got everything? USB Type C cable x 3 USB-C power socket x 3 Baby unit x 2 Ni-MH Ni-MH Rechargeable Ni-MH AAA battery cell x 6 Quick Start Guide Quick Start Guide Parent unit 6 1. At a glance ...........................................................................7 2. Connect and charge ........................................................ 9 3. Before use ............................................................................11 4.Using the digital audio baby monitor .......................12 5. Help ....................................................................................... 1 6 6. Technical Specifications .................................................17 7. General information ........................................................ 1 8 7 1. At a glance At a glance Baby unit A Microphone B Power button Press and hold to turn the baby unit on or off. C Power jack D Power / Battery charging/ Linking LED indicator •When powered on, it lights up in red first and becomes green. •It lights up in red when the batteries are charging. It becomes dim when the batteries are fully charged. •It flashes red when the batteries are not installed or when the battery level is low. E Speaker F Temperature sensor G Battery compartment A B D Front view C E F Back view G 8 At a glance Parent unit B A D F E C G H I Front view J Back view K A Display B Microphone C Scroll up / Volume up Press to increase the speaker volume or scroll up in screen. D Menu / OK / Scroll left •Enter the main menu and confirm menu options. •Press to scroll left during editing. E Power jack F Scroll down / Volume down / Mute •Press to decrease the speaker volume or scroll down in screen. •Press and hold to mute the speaker. G Power / battery charging / Linking LED indicator •It lights up in green when powered on. •It flashes green when the parent and baby units are being linked or not linked with each other. •It lights up in green when the batteries are charging. It flashes green when the batteries are not installed or when the battery level is low. H Power button / Talk back •Press and hold to turn the parent unit on or off. •Press and hold to speak to your baby. I Back / Scroll right •Press to go back to the previous level. •Press to scroll right during editing. J Speaker K Battery compartment 9 Connect and charge 2.Connect and charge WARNING •Use only the approved rechargeable Ni-MH battery cells (AAA Ni-MH rechargeable batteries) supplied with your PIP15-2 MULTI-ROOM. •Strangulation Hazard. Children have STRANGLED in cords. Keep adapter cords out of the reach of children (more than 1 metre away). Never use extension cords with AC adapters. Only use the AC adapters provided. Note: When charging the batteries for the first time, charge for at least 16 hours continuously. After charging for the first time, subsequent charging time is about 8 to 10 hours…

Text truncated - open the document above for the full version.

Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: +86-0755-2573 6666 Email: [email protected] CFR 47 §2.911(d)(5)(i) Attestation Letter Attestation Letter Date: 2024-03-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(i) Filing FCC ID: 2ARRB-PIP15BU Meizhou Guo Wei Electronics Co., Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely Yours, Signature Raymond Leung Engineering Manager Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China.

Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: +86-0755-2573 6666 Email: [email protected] CFR 47 §2.911 (d)(5)(ii) Attestation Letter Attestation Letter Date: 2024-03-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d)(5)(ii) Filing FCC ID: 2ARRB-PIP15BU Meizhou Guo Wei Electronics Co., Ltd certifies that as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely Yours, Signature Raymond Leung Engineering Manager Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China.

U.S. AGENT LETTER OF ATTESTATION Date: 2023-04-20 FEDERAL COMMUNICATIONS COMMISSION Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements CFR 47 §2.911(d) (7) Filing Meizhou Guo Wei Electronics Co., Ltd certifies that, as of the date of the filing of the application, Meizhou Guo Wei Electronics Co.,LLC is our designated U.S. agent for service of process for FCC ID. Meizhou Guo Wei Electronics Co.,Ltd accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Meizhou Guo Wei Electronics Co.,LLC accepts, as of the date of the filing of the application, the obligation of the designated U.S. agent for service of process for FCC ID. Designated U.S. Agent Information: Company Name: Meizhou Guo Wei Electronics Co.,LLC Address: 16192 Coastal Highway,Lewes,Delaware 19958,Country of Sussex,USA FRN: 0033625732 Tel.: +44 7776 228522 Email: [email protected] Signed by (printed name): Malcolm Paton Signature: Applicant: Meizhou Guo Wei Electronics Co.,Ltd Address: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong , China. FRN: 0027997733 Tel: +86- 0755-2573 6666 Email: [email protected] Signed by (printed name): Raymond Leung Signature:

QA-FR-170-B Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: +86-0755-2573 6666 Email: [email protected] FCC Authorization Date: 2024-03-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Agent Authorization To whom it may concern: We, Meizhou Guo Wei Electronics Co., Ltd , the undersigned, Hereby authorizes Bay Area Compliance Laboratories Corp. (Shenzhen) to act on its behalf in all matters relating to application for Equipment authorization, including the signing of all documents relating to these matters. All acts carried out by Bay Area Compliance Laboratories Corp. (Shenzhen) on our behalf shall have the same effect as our own action. We, Meizhou Guo Wei Electronics Co., Ltd ,the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. This authorization is valid until further written notice from the applicant. Sincerely Yours, Signature Raymond Leung Engineering Manager

Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: +86-0755-2573 6666 Email: [email protected] FCC Confidential Authorization Date: 2024-03-14 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ARRB-PIP15BU In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Meizhou Guo Wei Electronics Co., Ltd hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Signature Raymond Leung Engineering Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 1 of 5 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 2 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 3 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 4 of 5 Adapter 1 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 5 of 5 Adapter 2

BU Label Size: 31.4x16mm MODEL: PIP15 MULTI-ROOM BU INPUT: DC5V 1A Made in China SN: FFFGGCCYYWWxxxxxx FCC ID: 2ARRB-PIP15BU IC: 20353-PIP15BU HVIN: PIP15BU MODEL: PIP15 MULTI-ROOM BUINPU T : DC5V 1A Made in China SN: FFFGGCCYYWWxxxxxx FCC ID: 2ARRB-PIP15BUIC: 20353-PIP15BUHVIN: PIP15BU

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 1 of 7 EXHIBIT C - EUT INTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 2 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 3 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 4 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 5 of 7 Antenna Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 6 of 7 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1240301-10055E-RF Page 7 of 7

Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1240301-10055E-RF TR-EM-RF022 Page 12 of 78 Version 1.0 (2023/10/07) FCC §1.1307(b) & §2.1091 – RF EXPOSURE EVALUATION Applicable Standard According to KDB 447498 D04 Interim General RF Exposure Guidance v01, clause 2.1.4 –MPE-Based Exemption: An alternative to the SAR-based exemption is provided in § 1.1307(b)(3)(i)(C), for a much wider frequency range, from 300 kHz to 100 GHz, applicable for separation distances greater or equal to λ/2π, where λ is the free-space operating wavelength in meters. The MPE-based test exemption condition is in terms of ERP, defined as the product of the maximum antenna gain and the delivered maximum time-averaged power. For this case, a RF source is an RF exempt device if its ERP (watts) is no more than a frequency-dependent value, as detailed tabular form in Appendix B. These limits have been derived based on the basic specifications on Maximum Permissible Exposure (MPE) considered for the FCC rules in § 1.1310(e)(1). Table to § 1.1307(b)(3)(i)(C) - Single RF Sources Subject to Routine Environmental Evaluation f = frequency in MHz; R = minimum separation distance from the body of a nearby person (appropriate units, e.g., m); Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1240301-10055E-RF TR-EM-RF022 Page 13 of 78 Version 1.0 (2023/10/07) Result Mode Frequency (MHz) Tune up conducted power # Antenna Gain # ERP Evaluation Distance (m) MPE-Based Exemption Threshold (mW) (dBm) (dBi) (dBd)(dBm)(mW) DECT 1920-1930 20.3 1.16 -0.99 19.31 85.31 0.2 768 Note 1: The tune-up power and antenna gain was declared by the applicant. Note 2: 0dBd=2.15dBi. Result: Compliant

1 Antenna Test Report Manufacture: Meizhou Guo Wei Electronics Co., Ltd. Product Name: PIP15 BU Antenna Antenna Type: Monopole Test Date: 2023/11/16 Tested by: Hugo Huo Approved by: Sun Zhong 2 1. General Description Manufacturer Meizhou Guo Wei Electronics Co., Ltd. Test Location No. 113, Pingkang Road, Dalang Town, Dongguan, China Product Name PIP15 BU Antenna Antenna Type Monopole Test Items Gain; Efficiency; Radiation Pattern Test Frequency 1920MHz, 1925MHz, 1930MHz Address AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. 3 2. Test Configurations Test Environment Temperature (°C) 22.9 Humidity (%RH) 62 Atmospheric Pressure (kPa) 101.7 Test Equipment Test Instrument R&S ZNB8 4 3.Test Results Gain and Efficiency Frequency (MHz) Peak Gain (dBi) Efficiency (%) 1920 0.68 52.76 1925 1.01 54.71 1930 1.16 56.36 5 4.Radiation Pattern 1920MHz 3D Theta = 90, Phi = 0 Theta = 90, Phi = 90 Theta = 0, Phi = 0 Theta = 90, Phi = 180 Theta = 90, Phi = 270 Theta = 180, Phi = 0 6 1925MHz 3D Theta = 90, Phi = 0 Theta = 90, Phi = 90 Theta = 0, Phi = 0 Theta = 90, Phi = 180 Theta = 90, Phi = 270 Theta = 180, Phi = 0 7 1930MHz 3D Theta = 90, Phi = 0 Theta = 90, Phi = 90 Theta = 0, Phi = 0 Theta = 90, Phi = 180 Theta = 90, Phi = 270 Theta = 180, Phi = 0 8 5.EUT Photo 6.Test Setup Photo Antenna
