M otorola VM36XL Digital Video Baby Monitor User Guide For: VM36XL, V M36XL-2, VM36XL-3 and VM36XL-4 Welcome... • 1 x Parent Unit • 1 x Baby Unit (Camera) • 1 x Power adapter for the Parent Unit • 1 x Power adapter for the Baby Unit In multi-camera packs, you will find one or more additional camera, Star Grip and power adapter units. to your new Motorola Digital Video Baby Monitor! Thank you for purchasing your new Motorola Digital Video Baby Monitor. Now you can see and hear your baby sleeping in another room or you can monitor your older children in their playroom. Please retain your original dated sales receipt for your records. For warranty service of your Motorola product, you will need to provide a copy of your dated sales receipt to confirm warranty status. Registration is not required for warranty coverage. For product related questions, please visit at: This User's Guide provides you with all the information you need to get the most fr om your product. Before you use the Baby Monitor, we recommend you fully charge the batteries in the Baby Unit and Parent Unit, so that they continue to work if you disconnect them from the power supplies to carry to other locations. Please read the Safety Instructions on pages 7-9 before you install the units. Got everything? motorolanursery.com Overview of the Parent Unit 1.Display (LCD screen) 2.VIDEO ON/OFF button V Press to turn the LCD screen ON/ OFF (Note: audio is maintained.) 3.TA L K b u t t o n T Press and hold to speak to your baby 4.RESET button (recessed - use small pin) 5.UP button + Normal Mode: Tilt camera Up Menu Mode: Move Up menu options 6.DOWN button - Normal Mode: Tilt camera Down Menu Mode: Move Down menu options 7.MENU button M Press to open / close the Menu options 8.OK button O 9. Small plug power adapter outlet 10.LEFT button < Normal Mode: Pan camera Left Menu Mode: Move Left along menu options 11.RIGHT button > Normal Mode: Pan camera Right Menu Mode: Move Right along menu options 12.Charging LED: BLUE when mains power connected. 13.Parent Unit ON/OFF LED (Green) 14.Audio Level LEDs (Green, Amber, Red, Red) 15.Volume buttons Press -/+ to decrease/increase Volume level on Parent Unit 16.Power button 0 Press and Hold to turn the Parent Unit ON/OFF 17.Microphone 18.Stand 19.Speaker 7 10 8 9 11 12 13 14 15 16171 2 5 3 6 4 18 19 Parent Unit menu icons Signal Level Indication (5 Levels) Night Vision Mode (Video also changes to Black/White) Ta l k M o d e O n Battery Level Indication (4 Levels) Panning Camera Left Panning Camera Right Ti l t i n g C a m e r a U p Tilting Camera Down Zoom Level Control (1X, 2X) Brightness Level Control (8 Levels) Lullaby Control (5 Sound Selections) Alarm Setting (6h, 4h, 2h, Off) On status bar, indicates alarm set, and when flashing, that alarm time has been reached or missed. Temperature scale select ( o C / o F) Readings display in BLUE, but turn RED > 29ºC / 84ºF, or < 14ºC / 57ºF Displays HH o C / o F if >36 o C / 97 o F. Displays LL o C / o F if < 1 o C / 34 o F. Camera Control (scan, view , add , delete ) V Set Screen Off Timer (Off , 5 min, 30 min, 60 min) Indicates the screen off timer is set Volume Level Control (8 Levels + Off ) No Baby Unit detected View multiple cameras on screen. Available when you have more than 1 Baby Unit (Camera). Important guidelines for installing your Baby Monitor • To use your Video Monitor Baby and Parent Units together, you must be able to establish a radio link between them, and the range will be affected by environmental conditions. • Any large metal object, like a refrigerator, a mirror, a filing cabinet, metallic doors or reinforced concrete between the Baby and Parent Unit may block the radio signal. • The signal strength may also be reduced by other solid structures, like walls, or by radio or electrical equipment, such as TVs, computers, cordless or mobile phones, fluorescent lights or dimmer switches. • Use of other 2.4 GHz products, such as wireless networks (Wi-Fi ® routers), Bluetooth™ systems, or microwave ovens, may cause interference with this product, so keep the Baby Monitor away at least 3 feet from these types of products, or turn them off if they appear to be causing interference. • If the signal is weak, try moving the Parent and/or the Baby Unit to different positions in the room(s). 1. Photo Sensor (Night Vision Mode) 2. Camera Lens 3. Infrared LEDs (x 8, for night vision) 4. Power LED • On when linked to Parent Unit • Flashes when searching for Parent Unit 5. Microphone 6. Camera Battery LED • Flashes when AC power is connected to the camera. 7. POWER ON/OFF switch 8. Te mperature Sensor 9. P ower Adapter Socket 10. PAIR button 11. Speaker 12. Star Grip or Tripod mount screw hole Overview of Your Baby Unit 6 7 1 2 3 4 5 9 10 12 8 11 6Table of contents Table of contents 1.Safety Instructions ..................................................................................... 7 2.Getting Started........................................................................................ 10 2.1Baby Unit Power Supply............................................................................ 10 2.2Parent Unit Power Supply ......................................................................... 11 2.3Registration (Pairing) ................................................................................ 13 3.Using the Baby Monitor ........................................................................... 14 3.1Setting up .................................................................................................. 14 3.2Pan and Tilt ................................................................................................ 14 3.3Night Vision Mode .................................................................................... 14 3.4Talk Mode.................................................................................................. 14 3.5Video ON/OFF ......................................................................…

Text truncated - open the document above for the full version.

Ver. 1 15_Fbe_2011 AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: +86-755-25736666, Fax: +86-755-25732288, Website: www.sgwglobal.com ************************************************************************************************************ 30-April-2021 To whom it may concern敬启者, Multiple Models Confirmation Letter型号多样性号确认书 I, the undersigned, hereby confirm that the family models are listed in the following table. 我司特此确认下列表内的型号有以下相同及不同之处。 These models are identical as follows: 相同之处如下:Parent Unit √ Electronics/electrical designs, including firmware 电子或电机设计,包括固件 √ Construction design/Physical design/Enclosure结构设计或物理设计或外壳 √ PCB layout PCB走线布局 □ (Others, please specify其他,请说明) The only differences between these models are the follows for marketing purpose: 不同之处如下: √ Color颜色 √ Software 软件 √ Cosmetic details 外观细节 □ Trade name商标 √ Model Number型号 □ (Others, please specify其他,请说明) □ Suffix (“ ”) represents 子尾(“ ”)代表 □ Color code色标 √ Packing configuration包装配置 Item No. 项目 New model 新型号 Model Number型号 Remark 注释 1 √ YES VM36XLPU FCC ID: 2ARRB-VM36XLPU IC: 20353-VM36XLPU 2 √ YES VM50APU 3 √ YES VM50GPU 4 √ YES VM55PU 5 √ YES VM855 CONNECTPU The sample being submitted to Bay Area Compliance Laboratories Corp. (Shenzhen) for conformity assessment is item no. / model number VM36XLPU (tested model) of the above list. Regards此致, Raymond Leung Engineering Manager

Meizhou Guo Wei Electronics Co., Ltd ADD: AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. Tel: 0755-2573 6666 Email: [email protected] FCC Confidential Authorization Date: 2021-04-27 FEDERAL COMMUNICATIONS COMMISSIONS Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request regarding application for certification of FCC ID: 2ARRB-VM36XLPU In accordance with Sections 0.457 and 0.459 of the Commission’s Rules, Meizhou Guo Wei Electronics Co., Ltd hereby requests long-term confidential treatment of information accompanying this application as outlined below:  Block Diagram  Schematics  Operation Description The above materials contain proprietary and confidential information not customarily released to the public. The public disclosure of these materials provides unjustified benefits to its competitors in the market. Sincerely Yours, Raymond Leung Engineering Manager

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 1 of 6 EXHIBIT B - EUT EXTERNAL PHOTOGRAPHS Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 2 of 6 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 3 of 6 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 4 of 6 Adapter1-Model: BQ05A-0501000-U Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 5 of 6 Adapter2-Model: YWK-AD050100-U Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 6 of 6

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF EXHIBIT A - FCC ID LABEL AND LOCATION FCC ID Label FCC ID Label Location Information The label shown shall be permanently affixed at a conspicuous location on the device and be readily visible to the user at the time purchase (Labeling requirements per 2.925)

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 1 of 5 EXHIBIT C - EUT INTERNAL PHOTOGRAPH Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 2 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 3 of 5 Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 4 of 5 Battery Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 5 of 5 Ant

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. SAR TEST REPORT For Meizhou Guo Wei Electronics Co., Ltd. AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. FCC ID: 2ARRB-VM36XLPU IC: 20353-VM36XLPU Report Type: Original Report Product Type: Video baby monitor Report Number: SZ1210401-09458E-SA Report Date: 2021-04-21 Reviewed By: Seven Liang SAR En gineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) ,6F,7F,the 3rd Phase of Wan Li Industrial Building D,Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1210401-09458E-SA SAR Test Report 2 of 65 Attestation of Test Results EUT Information EUT Description Video baby monitor Tested Model VM36XLPU Multiple Model VM50APU, VM50GPU, VM855 CONNECTPU, VM55PU FCC ID 2ARRB-VM36XLPU IC 20353-VM36XLPU Serial Number SZ1210401-09458E-SA-S_21I Test Date 2021/04/02 MODE Max. SAR Level(s) Reported(W/kg) Limit (W/kg) 2.4 GHz SRD 1g Body SAR 0.68 1. 6 Applicable Standards FCC 47 CFR part 2.1093 Radiofrequency radiation exposure evaluation: portable devices IEEE1528:2013 IEEE Recommended Practice for Determining the Peak Spatial-Average Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement Techniques RSS-102 Issue 5 March 2015 Radio Frequency (RF) Exposure Compliance of Radio communication Apparatus (All Frequency Bands). IEC 62209-2:2010 Human exposure to radio frequency fields from hand-held and body-mounted wireless communication devices-Human models, instrumentation, and procedures-Part 2: Procedure to determine the specific absorption rate (SAR) for wireless communication devices used in close proximity to the human body (frequency range of 30 MHz to 6 GHz) KDB procedures KDB 447498 D01 General RF Exposure Guidance v06. KDB 648474 D04 Handset SAR v01r03. KDB 865664 D01 SAR measurement 100 MHz to 6 GHz v01r04 KDB 865664 D02 RF Exposure Reporting v01r02 Note: This wireless device has been shown to be capable of compliance for localized specific absorption rate (SAR) for General Population/Uncontrolled Exposure limits specified in FCC 47 CFR part 2.1093 and has been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and RF exposure KDB procedures. The results and statements contained in this report pertain only to the device(s) evaluated. Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1210401-09458E-SA SAR Test Report 3 of 65 TABLE OF CONTENTS DOCUMENT REVISION HISTORY ......................................................................................................................... 4 EUT DESCRIPTION ................................................................................................................................................... 5 TECHNICAL SPECIFICATION ......................................................................................................................................... 5 REFERENCE, STANDARDS, AND GUIDELINES ................................................................................................. 6 SAR LIMITS ................................................................................................................................................................ 7 FACILITIES ................................................................................................................................................................. 8 DESCRIPTION OF TEST SYSTEM .......................................................................................................................... 9 EQUIPMENT LIST AND CALIBRATION ............................................................................................................. 15 EQUIPMENTS LIST & CALIBRATION INFORMATION ................................................................................................... 15 SAR MEASUREMENT SYSTEM VERIFICATION ............................................................................................. 16 LIQUID VERIFICATION ............................................................................................................................................... 16 SYSTEM ACCURACY VERIFICATION .......................................................................................................................... 17 EUT TEST STRATEGY AND METHODOLOGY ................................................................................................. 19 TEST POSITIONS FOR BODY-WORN AND OTHER CONFIGURATIONS ............................................................................. 19 TEST DISTANCE FOR SAR EVALUATION ................................................................................................................... 19 SAR EVALUATION PROCEDURE ................................................................................................................................ 20 PEAK TRAVSMIT POWER MEASUREMENT .................................................................................................... 21 PROVISION APPLICABLE ....................................................................................................................…

Text truncated - open the document above for the full version.

Note: This report may contain data that are not covered by the A2LA accreditation and are marked with an asterisk “★”. BACL is not responsible for the authenticity of any test data provided by the applicant. Data included from the applicant that may affect test results are marked with an asterisk ’*’. Customer model name, addresses, names, trademarks etc. are not considered data. This report cannot be reproduced except in full, without prior written approval of the Company. Unless otherwise stated the results shown in this test report refer only to the sample(s) tested. This report is valid only with a valid digital signature. The digital signature may be available only under the Adobe software above version 7.0. FCC PART 15.247 RSS-GEN ISSUE 5, MARCH 2019 AMENDMENT 1 RSS-247, ISSUE 2, FEBRUARY 2017 TEST REPORT For Meizhou Guo Wei Electronics Co., Ltd. AD1 Section, Economic Development Area, Dongsheng Industrial District, Meizhou, Guangdong, China. FCC ID: 2ARRB-VM36XLPU IC: 20353-VM36XLPU Report Type: Original Report Product Type: Video baby monitor Re port Number: SZ1210401-09458EB Re port Date: 2021-04-29 Reviewed B y: Jacob Kong RF Engineer Prepared By: Bay Area Compliance Laboratories Corp. (Shenzhen) 5F(B-West) ,6F,7F,the 3rd Phase of Wan Li Industrial Building D,Shihua Rd, FuTian Free Trade Zone, Shenzhen, China Tel: +86-755-33320018 Fax: +86-755-33320008 www.baclcorp.com.cn Bay Area Compliance Laboratories Corp. (Shenzhen) Report No.: SZ1210401-09458EB FCC Part 15.247 RSS-GEN ISSUE 5, MARCH 2019 AMENDMENT 1, RSS-247, ISSUE 2, FEBRUARY 2017 Page 2 of 42 TABLE OF CONTENTS GENERAL INFORMATION ....................................................................................................................................... 4 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ..................................................................................... 4 OBJECTIVE ................................................................................................................................................................... 4 TEST METHODOLOGY .................................................................................................................................................. 4 MEASUREMENT UNCERTAINTY .................................................................................................................................... 5 TEST FACILITY ............................................................................................................................................................. 5 SYSTEM TEST CONFIGURATION .......................................................................................................................... 6 DESCRIPTION OF TEST CONFIGURATION ...................................................................................................................... 6 EUT EXERCISE SOFTWARE .......................................................................................................................................... 6 SPECIAL ACCESSORIES ................................................................................................................................................. 6 EQUIPMENT MODIFICATIONS ....................................................................................................................................... 6 SUPPORT EQUIPMENT LIST AND DETAILS .................................................................................................................... 6 EXTERNAL I/O CABLE .................................................................................................................................................. 7 BLOCK DIAGRAM OF TEST SETUP ................................................................................................................................ 7 SUMMARY OF TEST RESULTS ............................................................................................................................... 8 TEST EQUIPMENT LIST ........................................................................................................................................... 9 FCC §1.1307(b) & §2.1093 - RF EXPOSURE INFORMATION ............................................................................ 10 APPLICABLE STANDARD ............................................................................................................................................ 10 TEST RESULT ............................................................................................................................................................. 10 RSS-102 – RF EXPOSURE ......................................................................................................................................... 11 APPLICABLE STANDARD ............................................................................................................................................ 11 FCC §15.203 & RSS-Gen §6.8– ANTENNA REQUIREMENT .............................................................................. 12 APPLICABLE STANDARD ............................................................................................................................................ 12 ANTENNA CONNECTOR CONSTRUCTION .................................................................................................................... 12 FCC §15.207 (a) & RSS-Gen §8.8– AC LINE CONDUCTED EMISSIONS ......................................................... 13 APPLICABLE STANDARD ............................................................................................................................................ 13 EUT SETUP ................................................................................................................................................................ 14 EMI TEST RECEIVER SETUP ........................................................................................................…

Text truncated - open the document above for the full version.

Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 1 of 2 EXHIBIT D - TEST SETUP PHOTOGRAPHS Conducted Emissions - Front View Conducted Emissions - Side View Bay Area Compliance Laboratories Corp. (Shenzhen) Project No.: SZ1210401-09458E-RF Page 2 of 2 Radiated Emissions View (Below 1 GHz) Radiated Emissions View (Above 1 GHz)
