2AS3QPIVO-RC-1Pivo Remote Control

3i Inc.

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Jan 12, 2020
Application Purpose: Original Equipment
Date of Application: Jan 12, 2020
Equipment Note: Pivo Remote Control
Frequency Range: 2440.00000000 - 2440.00000000
Company: 3i Inc.
Country: South Korea

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Copyright ⓒ 2020. Lab-T, Inc. User Manual 1 Remote Quick Start Guide 2 General Information Product name : Pivo remote control. Model name : PIVO-RC-1 Material : ABS, Rubber, Plastic Controller : 2.4GHz, RF Height: 8.8 cm / 2.7 inches Width: 3.65 cm / 1.4 inches Weight: 30g / 1.0 ounces Battery 3V Coin Button Cell Made in China Company name : 3i Inc. homepage : www.getpivo.com FCC ID : 2AS3QPIVO-RC-1 3 Remote Overview For convenience, the Pivo Remote comes paired with your Pivo and is ready to use. • Up to 15 meter operating range. • Can be paired to multiple Pivo Pods. • Comes with 1 replacement 3V battery (coin type). • For video instructions visit the Pivo Youtube oficcial channel at www.youtube.com/c/pivoofficial • For downloadable version of this manual, go to help. getpivo.com 4 With your remote, you have control over various core settings of your Pivo including, rotation speed, rotation direction, shooting mode, shutter button, and more. Capture photo/start recording Increase speed Rotate clockwise Decrease speed Rotate counter-clockwise Rotate clockwise 1 round Rotate counter-clockwise 1 round Stop rotating/ Cancel shooting (may vary depending on the capture mode) Toggle between photo/video mode (may vary depending on capture mode) Remote control operation 5 If your Pivo Remote becomes disconnected or if you’ve replaced the Pivo’s remote control batteries: 2. Press and hold the “+” button on the remote control until you hear 3 quick beeps. This indicates that remote control pairing is complete. Pairing Remote Control and Pivo 1. IniciatePress the Pivo power button 3 times on quick succession. The Power Button’s LED lighting will turn white, indicating that remote control pairing is initiated. Power button “+” button RF Specification -Frequency : 2440 MHz -Modulation: GFSK Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. * This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. CAUTION : Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

External Photos

Page: 1 / 4 Copyright ⓒ 2020, Lab-T, Inc. External Photos Page: 2 / 4 Copyright ⓒ 2020, Lab-T, Inc. External Photos Front Rear Page: 3 / 4 Copyright ⓒ 2020, Lab-T, Inc. External Photos Top Bottom Page: 4 / 4 Copyright ⓒ 2020, Lab-T, Inc. External Photos Left Right

ID Label/Location Info

Internal Photos

Page: 1 / 3 Copyright ⓒ 2020. Lab-T, Inc. Internal Photos Page: 2 / 3 Copyright ⓒ 2020. Lab-T, Inc. Internal Photos Main Board_Front Main Board_Rear Antenna Page: 3 / 3 Copyright ⓒ 2020. Lab-T, Inc. Internal Photos RF Module .

Test Report

REPORT No.:TRRFCC20-0001 Total 19 pages TRF-R-022(00) Page: 2 / 19 Copyright ⓒ 2020. Lab-T, Inc. CONTENTS 1. Applicant Information .............................................................................................................................. 3 2. Laboratory Information ............................................................................................................................ 3 3. Information About Test Equipment ......................................................................................................... 4 3.1 Equipment Information ............................................................................................................................. 4 3.2 Antenna Information ................................................................................................................................. 4 3.3 Tested Companion Device Information .................................................................................................... 4 4. Test Report ................................................................................................................................................ 5 4.1 Summary .................................................................................................................................................. 5 4.2 Measurement Uncertainty ........................................................................................................................ 5 4.3 Test Report Version .................................................................................................................................. 5 4.4 Transmitter Requirements ........................................................................................................................ 6 4.4.1 Antenna Requirement ........................................................................................................................ 6 4.4.2 20 dB Bandwidth and Occupied Bandwidth ...................................................................................... 7 4.4.3 Radiated Emission, Band Edge, and Restricted bands .................................................................. 10 4.4.4 Conducted Emission ....................................................................................................................... 17 APPENDIX I .................................................................................................................................................... 18 REPORT No.:TRRFCC20-0001 Total 19 pages TRF-R-022(00) Page: 3 / 19 Copyright ⓒ 2020. Lab-T, Inc. 1. Applicant Information Applicant : 3i Inc. Address : 101-117, 29, Dongbu-ro, Dong-gu, Daegu, South Korea Telephone No. : +82-70-4756-2133 Person in charge : Gyuhyon Kim / [email protected] Manufacturer : 3i Inc. Address : 101-117, 29, Dongbu-ro, Dong-gu, Daegu, South Korea Manufacturer : ZHONGSHAN SHIHONG ELECTRONIC TECHNOLOGY CO.,LTD. Address : NO.19,3RD LONGTONG SAN ROAD, TANZHOU TOWN, ZHONGSHAN CITY, GUANGDONG PROVINCE, CHINA 2. Laboratory Information Test Laboratory : Lab-T, Inc. Address : 2182-42, Baegok-daero, Mohyeon-myeon, Cheoin-gu, Yongin-si Gyeonggi-do 17036, South Korea Telephone No. : +82 31-322-6767 Facsimile No. : +82 31-322-6768 Certificate FCC Designation No. : KR0159 FCC Registration No. : 133186 REPORT No.:TRRFCC20-0001 Total 19 pages TRF-R-022(00) Page: 4 / 19 Copyright ⓒ 2020. Lab-T, Inc. 3. Information About Test Equipment 3.1 Equipment Information Equipment type Pivo Remote Control Equipment model name PIVO-RC-1 Equipment add model name - Frequency range 2 440 MHz Modulation type GFSK Power supply DC 3.0 V H/W version remote_V02 S/W version Si24R1 V1.0 Note:The above EUT information was declared by the manufacturer. 3.2 Antenna Information Antenna type Chip Antenna gain 2.12 dBi 3.3 Tested Companion Device Information Type Manufacturer Model Note - - - - - - - - REPORT No.:TRRFCC20-0001 Total 19 pages TRF-R-022(00) Page: 5 / 19 Copyright ⓒ 2020. Lab-T, Inc. 4. Test Report 4.1 Summary FCC Part 15 Reference Parameter Clause Status Transmitter Requirements 15.203 Antenna Requirement 4.4.1 C 2.1049 20 dB Channel Bandwidth 4.4.2 C 2.1049 Occupied Bandwidth 4.4.2 C 15.249(a)(b) 15.205(a) 15.209(a) Radiated Emission, Band Edge and Restricted bands 4.4.3 C 15.207(a) Conducted Emissions 4.4.4 N/A NOTE2 NOTE 1 : NOTE 2 : C = Comply N/C = Not Comply N/T = Not Tested N/A = Not Applicable EUT operates only in Battery * The general test methods used to test this device is ANSI C63.10:2013 4.2 Measurement Uncertainty Mesurement items Expanded Uncertainty Occupied Channel Bandwidth 11.27 kHz (The confidence level is about 95 %, k=2) Radiated Spurious Emissions (1 GHz under) 4.67 dB (The confidence level is about 95 %, k=2) Radiated Spurious Emissions (Above 1 GHz) 5.85 dB (The confidence level is about 95 %, k=2) Conducted emission 2.36 dB (The confidence level is about 95 %, k=2) 4.3 Test Report Version Test Report No. Date Description TRRFCC20-0001 20-01-13 Initial issue REPORT No.:TRRFCC20-0001 Total 19 pages TRF-R-022(00) Page: 6 / 19 Copyright ⓒ 2020. Lab-T, Inc. 4.4 Transmitter Requirements 4.4.1 Antenna Requirement 4.4.1.1 Regulation Accoding to §15.203 An intentional radiator shall be designed to ensure that no antenna other than that furnished by the responsible party shall be used with the device. The use of a permanently attached antenna or of an antenna that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this section. The manufacturer may design the unit so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or electrical connector is prohibited. 4.4.1.2 Result Comply (The antenna of this EUT is Chip Antenna Type. Therefore the antenna is permanently attached. Please refer to the internal photo. Therefore this EUT Complies with the requirement of §15.203) REPORT No.:TRRFCC20-0001 Total 19 pages TRF-R-022(00)…

Text truncated - open the document above for the full version.

Test Setup Photos

Page: 1 / 3 Copyright ⓒ 2020. Lab-T, Inc. Test Setup Photos Page: 2 / 3 Copyright ⓒ 2020. Lab-T, Inc. Test Setup Photos Radiated Emission_9 kHz ~ 30 MHz Test distance : 3 m, height of table : 0.8 m Radiated Emission_30 MHz ~ 1 GHz Test distance : 3 m, height of table : 0.8 m Page: 3 / 3 Copyright ⓒ 2020. Lab-T, Inc. Test Setup Photos Radiated Emission_1 GHz ~ 18 GHz Test distance : 1 m, height of table : 1.5 m Radiated Emission_ Above 18 GHz Test distance : 1 m, height of table : 1.5 m
