2ASJR-CM275-1113120GEN 2.75 Asset Tracker

08/15/2022, 15.21 Carrier – NaturaLINE, PrimeLINE, ThinLINE, EliteLINE 08/15/2022, 15.21 ! 1.Electrical Ratings and Requirements Product Supply Ratings Power Supply: 12-30 VAC 50-60 Hz or 6-15 VDC, 3A WARNING These procedures should only be performed by trained installation technicians. High voltage/current lines are present and caution should be used to prevent injuries. Installer must conform to local standards and ordinances as required. IMPORTANT Make sure that power is off, unit is disconnected and that no damages have occurred during drilling. 08/15/2022, 15.21 2.Required Tool Kit 13mm (1/2 “) Drill Bit Center Punch Cutting compound for the drill Drill for removing burrs Degreasing rags 18mm open face wrench Side cutting pliers Magnet Cable Ties 08/15/2022, 15.21 3.GT Sense Reefer Kit A complete GT Sense Reefer Kit includes: 1.GT Sense Device 2.Antenna (80 mm diameter round black version with 3M VHB tape and threaded mount on the back cables and connectors 3.RMM Cable . 08/15/2022, 15.21 4.RMM Bracket 08/15/2022, 15.21 5.Installation Before beginning the antenna installation, please print and cut out the template to use for locating the antenna mounting hole. Step 1 Use the antenna installation template to locate the antenna placement on the access cover. Place the template towards the edge of the access cover and mark the center point. Check that there is nothing on the inside surface of the access cover that could be damaged when a hole is drilled in the centre-punched location. NOTE: Avoid blocking the information labels. NOTE: If an antenna by another company is already mounted, DO NOT remove it. 08/15/2022, 15.21 Step 2 Drill a 13 mm (1/2′′) hole at the centre-punched mark. Remove all burrs after drilling. Step 3 Degrease/clean the surface where the antenna will be mounted with a metal cleaner or similar before fitting the antenna. 08/15/2022, 15.21 Step 4 Remove the nut, lock washer, and plastic washer from the threaded mount on the backside of the antenna by slipping them off the antenna cable via the slots. Step 5 Insert the connector end of the antenna cable through the drilled hole in the access cover. Remove the 3M VHB table liner from the backside of the antenna. Push the thread mount through the drilled hole and secure the antenna cables. Note: Specific orientation/rotation of the antenna is not required. Step 6 Replace the plastic washer, lock washer and nut on the antenna threaded mount on the inside of the access cover. Tighten the nut firmly with the 18mm open face wrench, torque to 1.5 N-m (11.5 in-lbs). 08/15/2022, 15.21 Step 7 Remove the access plug from side of control box. Cut a hole in the plug and run cables trough. Seal with silicone. Step 8 If a modem is already present in the RMM slot, remove it maintaining the Mounting screws and unplug all the connections 08/15/2022, 15.21 Step 9 Route the antenna cables across the door hinge through existing cable channel (if present) to the RMM slot using the cable ties to secure the cables. Do not be concerned with the extra length of cable at this time. Step 10 Fit the GT Sense Device into the RMM slot and secure with the screws from the removed modem. If no modem was removed, use the M5 screws and mylar washers provide in the RMM bracket kit. InsertGT Senseand slide down and lock in place 08/15/2022, 15.21 Step 11 Connect and secure the antenna cables to appropriate Farkas connectors on the GT Sense Device before connecting the RMM cable to the The antenna cables are identified by labels near the connector ends. The corresponding Fakra connectors on the GT Sense Device are identified with the names “GPS” and “CELL”. After connecting the antenna cables, attach the RMM cable to the mating connector on the GT Sense Device and secure with the screws provided on the connector. Step 12 Plug the 3 and 7 position connector into the orange 10 position connector on the end of the GT RMM Cable as indicated by the 3/7 label on the 10 position connector. 08/15/2022, 15.21 If the RMM Cable you are installing has an inline fuse, the fuse is intended to be 08/15/2022, 15.21 on the Ground Line for A/C reverse polarity protection for the GT Sense Device. Orange Connector on CBL0037 GT RMM Cable The 3 and 7 position connector plugged into the orange 10 position connector. Step 13 Secure any extra length of antenna cable or RMM cable with cable ties making sure not cables are in tension. Step 14 Secure the control box door. Step 15 Use the Installation app to verify GPS and communications are working (future). Installation complete. FCC/CE/ISED Compliance FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to…

Text truncated - open the document above for the full version.

Letter of Authorization and Anti- Drug Statement Applicant Name: Globe Tracker ApS Address: Strandgade 91, 4th Floor DK-1401 Copenhagen K Denmark Product Name: CM2.75-1113120 Model Number: CM2.75-1113120 FCC ID: 2ASJR-CM275-1113120 We authorize: CETECOM Inc., to act on our behalf on all matters concerning the above named equipment. We declare that CETECOM Inc. is allowed to forward all information related to the approval project to the Federal Communications Commission and discuss any issues concerning the approval application. The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti- Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes. Does the applicant or authorized agent so certify? ☒ Yes I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements. Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application. If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time. Signature of Authorized Person Filing: Title: Director Of Engineering Date: 9/6/2022

Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21048 Date: 09/06/2022 Subject: Request for Permanent Confidentiality FCC ID: 2ASJR-CM275-1113120 To Whom It May Concern: In accordance with §0.457(d) and §0.459 of CFR 47, and KDB 726920, Globe Tracker ApS hereby requests permanent confidentiality for documents filed under the following exhibit types: 1. Block Diagram 2. Schematic Diagram 3. Part List 4. Operational Description These items contain detailed system and equipment description and related information about the product which Globe Tracker ApS considers to be proprietary, confidential and a custom design which otherwise would not be released to the general public. Since this design is a basis from which future technological products will evolve, Globe Tracker ApS also feels that this information would be of benefit to its competitors, and that the disclosure of the information in these exhibits would give our competitors an unfair advantage in the market. We are aware that exhibit types cover letters, attestations, label document, test reports, RF exposure information (SAR and MPE reports), cannot be requested to be classified confidential and are thus subject to publication, as will be documents of all other exhibits types for which we have not requested a confidentiality classification. Best Regards, _______________________________ Signature Name: Mark Oudshoorn Title: Director of Engineering Company Name: Globe Tracker ApS Address: Strandgade 91, 4 th Floor DK-1401 Copenhagen K Denmark

70.00 2.76 42.00 1.65 R6.50 0.26 R2.00 0.08 NOTES: 1. TEXT AND IMAGES SHOWN ARE FOR REFERENCE ONLY LABEL WILL BE PRINTED FROM PRINTER FILE ON MANUFACTURING LINE 2. LABEL TO BE WHITE BACKGROUND, WATER-PROOF POLYESTER, WITH PERMANENT ADHESIVE 3. THE FOLLOW LABEL INFORMATION IS PRINTED AFTER A SUCCESSFUL PCB TEST: - SERIAL NUMBER - BUILD DATE - CCID - CELL ID - DEV EUI MANUFACTURER & MANUFACTURER ADDRESS BUILD DATE PRODUCT MODEL NUMBER SERIAL NUMBER 70.00 2.76 42.00 1.65 R6.50 0.26 R2.00 0.08 D C B A A B C D 1 2 3 4 5 6 7 8 7 6 5 4 3 2 COPYRIGHT © 2022 GLOBE TRACKER ALL RIGHTS RESERVED 0: 1.0 mm 0.0 0.5 mm 0.00: 0.25 mm 0.000: 0.125 mm ANGULAR: 0.5 DEG UNITS OF MEASURE: FINISH: TITLE B 23AUG2022 SEE NOTES LAB-0014 SHEET 1 OF 1 TOLERANCES EXCEPT WHERE NOTED MATERIAL: REVPART NO. SIZE CONFIDENTIAL DRAWN: QA: APPROVED: MFG: CHECKED: GLOBE TRACKER, ApS CVR#33579004 DK-1401 Copenhagen K, DENMARK CONFIDENTIAL JJT GEN 2.75 RMM, CM275-113120 INFORMATION & SN LABEL METRIC, mm SEE NOTES DP ES MA DP SCALE 1:1 A

Globetracker Version 2.75 Globetracker Version 2.75 Views

Radio Frequency Exposure Evaluation Report FOR: Globe Tracker ApS Model Number: CM2.75-1113120 Product Description: Asset Tracking Device / Data Modem FCC ID: 2ASJR-CM275-1113120 IC: 25752-CM275111312 Per: CFR Part Part1 (1.1307 &1.1310), Part 2 (2.1091), FCC KDB 447498 D01 General RF Exposure Guidance v06 ISED RSS-102 Issue 5 Report number: EMC_GLOBE_004-22001_FCC_ISED_MPE_Rev1 DATE: 2022-10-31 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V5.0 2015-10-27 © Copyright by CETECOM Test Report #: EMC_GLOBE_004-22001_FCC_ISED_MPE_Rev1 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-10-31 Page 2 of 7 IC: 25752-CM275111312 Page 2 of 7 1 Assessment This RF Exposure evaluation report provides evidence for compliance of the below identified device with the RF Exposure limits for mobile devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091) and IC standard RSS-102 issue 5 under worst case conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated respectively, where relevant. The device meets the limits as stipulated by the above given FCC and IC rule parts based on available specifications for worst case conditions at 20cm distance to the body. Company Description Model # Globe Tracker ApS Asset Tracking Device / Data Modem CM2.75-1113120 Report reviewed by: TCB Evaluator 2022-10-31 Compliance Arndt Stoecker (Director of Regulatory Services) Date Section Name Signature Responsible for the Report: 2022-10-31 Compliance Cheng Song (EMC Engineer) Date Section Name Signature Test Report #: EMC_GLOBE_004-22001_FCC_ISED_MPE_Rev1 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-10-31 Page 3 of 7 IC: 25752-CM275111312 Page 3 of 7 2 Administrative Data 2.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Street Address: 411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Lab Manager: Arndt Stoecker Responsible Project Leader: Akanksha Baskaran 2.2 Identification of the Client / Manufacturer Client’s Name: Globe Tracker ApS Street Address: Strandgade 91, 4th floor City/Zip Code DK-1401 Copenhagen K Country Denmark Identification of the Manufacturer Manufacturer’s Name: Same as Client Manufacturers Address: City/Zip Code Country Test Report #: EMC_GLOBE_004-22001_FCC_ISED_MPE_Rev1 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-10-31 Page 4 of 7 IC: 25752-CM275111312 Page 4 of 7 3 Equipment under Assessment Model No: CM2.75-1113120 HW Version : Rev 5 SW Version : 10.10 FCC-ID : 2ASJR-CM275-1113120 IC: 25752-CM275111312 PMN: GEN 2.75 Asset Tracker Product Description: Asset Tracking Device / Data Modem Radio Information: Cellular & GPS:  Quectel EG25-G(D)  FCC ID: XMR201903EG25G; IC ID: 10224A-201903EG25G LoRa:  Semtech SX1262  Frequency of Operation: 433 MHz, 863-870 MHz (EU), 902-928 MHz (NA) Antenna Information as declared: Cellular:  Model: JCB046L  Manufacturer: JIAXING JINCHANG ELECTRONIC TECHNOLOGY CO.;TD  Peak Gain: 0.5 dBi LoRa:  Type: Chip w/ PCB Trace  Manufacturer: Johanson Technology  Peak Gain: -0.5 dBi Power Supply/ Rated Operating Voltage Range: AC Input: Voltage Range: 12-36 VAC, Frequency: 50/60 Hz DC Input: Voltage Range: 9-18 VDC Lithium Ion Battery Operating Temperature Range Tmin: -25 ºC / Tmax: +70 ºC, Tnom: +25 ºC Sample Revision Prototype Unit; Production Unit; Pre-Production Test Report #: EMC_GLOBE_004-22001_FCC_ISED_MPE_Rev1 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-10-31 Page 5 of 7 IC: 25752-CM275111312 Page 5 of 7 4 RF Exposure Limits and FCC and IC Basic Rules For the specific described radio apparatus the following basic limits and rules apply for both, FCC and IC where not indicated differently. 4.1 Power Density Limits acc. to FCC 1.1310(e) / RSS-102 i5, cl. 4: FCC Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 1500 – 100000 1.0 30 IC Frequency Range (MHz) Power density (W/m 2 ) Averaging time (minutes) 300 – 6000 0.02619 x f (MHz) 0.6834 6 4.2 Routine Environmental Evaluation Categorical Exclusion Limits acc. to FCC 2.1091(c) / RSS-102, cl. 2.5 (rounded to 1 decimal point): FCC operating frequency < 1.5GHz: excluded if ERP < 1.5W / 31.8dBm (EIRP: 33.9 dBm); operating frequency > 1.5GHz: excluded if ERP < 3.0W / 34.8dBm (EIRP: 36.9 dBm); IC 300MHz < = operating frequency < 6 GHz: excluded if EIRP < 0.0131 x f (MHz) 0.6834 W 4.3 RF Exposure Estimation (MPE Estimation) Having available the source based average output power and peak antenna gain or the ERP/EIRP of the specified device and for a known minimum distance of its radiating structures from the body of persons according to its use cases (at least 20cm) the power density at that distance can be estimated by the following formula for plane-wave equivalent conditions (far-field conditions), when ground reflection is neglected. 2 4R PG S   where: S = power density (mW/cm 2 or W/m 2 ) P = power input to the antenna (mW or W) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm or m) Test Report #: EMC_GLOBE_004-22001_FCC_ISED_MPE_Rev1 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-10-31 Page 6 of 7 IC: 25752-CM275111312 Page 6 of 7 5 Evaluations 5.1 Analysis of RF Exposure for simultaneous transmission  Evaluations are based on worst case power density limits for US and Canada.  Calculations are made for 20cm.  Evaluations are based on ERP/EIRP measured or calculated from known gain and conducted output power. FCC: Operating…

Text truncated - open the document above for the full version.

A2LA Accredited IC recognized # 3462B-1 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 © Copyright by CETECOM FCC / ISED Test Report For: Globe Tracker ApS Model: CM2.75-1113120 Product Description: Asset Tracking Device / Data Modem FCC ID: 2ASJR-CM275-1113120 IC ID: 25752-CM275111312 Applied Rules and Standards: 47 CFR Part 15.247 (DTS) RSS-247 Issue 2 (DTSs) & RSS-Gen Issue 5 REPORT #: EMC_GLOBE_004-22001_FCC_15.247 DATE: 2022-09-30 Test Report #: EMC_GLOBE_004-22001_FCC_15.247 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-09-30 Page 2 of 39 IC ID: 25752-CM275111312 TABLE OF CONTENTS 1 ASSESSMENT .............................................................................................................................................................. 3 2 ADMINISTRATIVE DATA ............................................................................................................................................... 4 2.1 IDENTIFICATION OF THE TESTING LABORATORY ISSUING THE EMC TEST REPORT ........................................................................... 4 2.2 IDENTIFICATION OF THE CLIENT ............................................................................................................................................. 4 2.3 IDENTIFICATION OF THE MANUFACTURER ................................................................................................................................. 4 3 EQUIPMENT UNDER TEST (EUT) ................................................................................................................................... 5 3.1 EUT SPECIFICATIONS ......................................................................................................................................................... 5 3.2 EUT SAMPLE DETAILS ......................................................................................................................................................... 6 3.3 ACCESSORY EQUIPMENT (AE) DETAILS ................................................................................................................................... 6 3.4 TEST SAMPLE CONFIGURATION ............................................................................................................................................. 6 3.5 MODE OF OPERATION.......................................................................................................................................................... 6 4 SUBJECT OF INVESTIGATION ...................................................................................................................................... 7 5 MEASUREMENT RESULTS SUMMARY .......................................................................................................................... 7 6 MEASUREMENT UNCERTAINTY.................................................................................................................................... 8 6.1 ENVIRONMENTAL CONDITIONS DURING TESTING: ...................................................................................................................... 8 6.2 DATES OF TESTING: ............................................................................................................................................................ 8 7 MEASUREMENT PROCEDURES .................................................................................................................................... 9 7.1 RADIATED MEASUREMENT .................................................................................................................................................... 9 7.2 POWER LINE CONDUCTED MEASUREMENT PROCEDURE .......................................................................................................... 11 7.3 RF CONDUCTED MEASUREMENT PROCEDURE ....................................................................................................................... 11 8 TEST RESULT DATA .................................................................................................................................................. 12 8.1 MAXIMUM PEAK CONDUCTED OUTPUT POWER ....................................................................................................................... 12 8.2 POWER SPECTRAL DENSITY ............................................................................................................................................... 14 8.3 DUTY CYCLE .................................................................................................................................................................... 16 8.4 BAND EDGE COMPLIANCE .................................................................................................................................................. 17 8.5 EMISSION BANDWIDTH 6DB AND 99% OCCUPIED BANDWIDTH ................................................................................................... 21 8.6 RADIATED TRANSMITTER SPURIOUS EMISSIONS AND RESTRICTED BANDS ................................................................................... 25 9 TEST SETUP PHOTOS ................................................................................................................................................ 38 10 TEST EQUIPMENT AND ANCILLARIES USED FOR TESTING ......................................................................................... 38 11 HISTORY ................................................................................................................................................................... 39 Test Report #: EMC_GLOBE_004-22001_FCC_15.247 FCC ID: 2ASJR-CM275-1113120 Date of Report 2022-09-30 Page 3 of 39 IC ID: 25752-CM275111312 1 Assessment The following device was e…

Text truncated - open the document above for the full version.

868 and 915MHz dual (wideband) ISM band SMD chip antennaP/N 0900AT43A0070 Detail Specification: Page 1 of 11 *Efficiency based on evaluation board 0900AT43A0070-EB2SMA, Layout# 2, page 6 L ±± W ±± T a ±± https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 2.0 2021 Johanson Technology, Inc. All Rights Reserved Peak Gain (dBi) -0.5 typ. (XZ-Total) Average Gain (dBi) -2.5 typ. (XZ-Total) Layout Recommendation #1 - 0900AT43A0070-EB1SMA, see page 2 Suffix = S Part Number Explanation Packing Style Terminal Configuration Function RF Feeding Point To trace element No. 1 2 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Frequency (MHz) 858 - 928 Reel Quantity (pcs/reel) 1,000 Operating Temperature -40 to +85°C Impedance ( Ω) Input Power (W) Recommended Storage Conditions and Period for unused T&R Product +5 to +35°C Humidity 45 - 75% RH 50 2 max. (CW) 18 months max. Return Loss (dB) 4 min. High Frequency Ceramic Solutions Part Number 1/29/2021 Let us help you with the antenna design, optimization, and tuning! 0900AT43A0070 General Specifications https://www.johansontechnology.com/ask-a-question 100% Tin e.g. 0900AT43A0070S e.g. 0900AT43A0070E e.g. 0900AT43A0070(E or S) Mechanical Dimensions Suffix = E Suffix = None T & R Bulk (loose pcs) 0.012 Radiated Efficiency* 48% ave. Layout Recommendation #2 - 0900AT43A0070-EB2SMA, see page 6 Evaluation Board P/N Suffix 0.008 0.008 0.276 0.079 In 7.00 2.00 +.004 / -.0080.031 0.020 0.20 0.20 +0.10 / -0.20 0.30 mm 0.80 0.50 Top View Side View
 a T L W Top Bottom 868 and 915MHz dual (wideband) ISM band SMD chip antennaP/N 0900AT43A0070 Detail Specification: Page 2 of 11 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 2.0 2021 Johanson Technology, Inc. All Rights Reserved • Need help laying out the antenna, want us to review your antenna design (free!), require the Gerber files for this EVB, or would like us to validate the new tuning values of your PCB (fee may apply) go to: https://www.johansontechnology.com/ask-a- question Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. High Frequency Ceramic Solutions 1/29/2021 Layout Recommendation #1: Evaluation Board p/n: 0900AT43A0070-EB1SMA • Orderable EVB for evaluation, it comes with a female SMA connector. Go to: https://www.johansontechnology.com/request- a-sample and ask for p/n 0900AT43A0070-EB1SMA • The total antenna area usage for this EVB is approx. 25x10mm (due to trace element), but the trace can be re- shaped to reduce effective area and conform to the designer's PCB. • Attention: Matching circuits and component values will be different on the client's design, depending on PCB layout, geometry, etc. It is recommended that the designer leave available slots for a "pi" (or shunt-series-shunt) network. The antenna matching network values you see here are used when antenna is mounted on Johanson's evaluation board. 35mm 10mm No GND 19mm (can be any length) 50Ω CPWG Feed Line 30mm GND Plane GND GND 1.8 6 8.4 1.5 22.5 6.5 0.5 0 Ohm 2.2 pF 0.5 0.5 * *Line width should be designed to match 50ohm characteristic impedance, depending on your PCB material and thickness(distance to GND) All units in: mm 1.01.4 868 and 915MHz dual (wideband) ISM band SMD chip antennaP/N 0900AT43A0070 Detail Specification: Page 3 of 11 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 2.0 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/29/2021 Typical Electrical Performance (T=25°C) on Layout Recommendation #1 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Return Loss (with matching) 0.70.91.11.30.51.5 -25 -20 -15 -10 -5 -30 0 freq, GHz dB(S(1,1)) m15 m25 m18 m15 freq= dB(S(1,1))=-6.031 858.0MHz m25 freq= dB(S(1,1))=-22.032 893.0MHz m18 freq= dB(S(1,1))=-7.694 928.0MHz This antenna has about 20MHz of guard-band on each side. 868 and 915MHz dual (wideband) ISM band SMD chip antennaP/N 0900AT43A0070 Detail Specification: Page 4 of 11 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 2.0 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/29/2021 Typical Radiation Patterns (T=25°C) of Layout Recommendation #1 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Y :Φ(Phi)=90 o X :Φ(Phi)=0 o Z :θ(Theta)=0 o XY-plane @868MHz Total XZ-Plane @868MHz Total YZ-Plane @868MHz Total 868 and 915MHz dual (wideband) ISM band SMD chip antennaP/N 0900AT43A0070 Detail Specification: Page 5 of 11 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 2.0 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/29/2021 Typical Radiation Patterns (T=25°C) of Layout Recommendation #1 Johanson Technology, Inc. reserves the right to make design changes without notice. All sales are subject to Johanson Technology, Inc. terms and conditions. Y :Φ(Phi)=90 o X :Φ(Phi)=0 o Z :θ(Theta)=0 o XY-plane @915MHz Total XZ-Plane @915MHz Total YZ-Plane @915MHz Total 868 and 915MHz dual (wideband) ISM band SMD chip antennaP/N 0900AT43A0070 Detail Specification: Page 6 of 11 https://www.johansontechnology.com 4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821 Ver. 2.0 2021 Johanson Technology, Inc. All Rights Reserved High Frequency Ceramic Solutions 1/29/2021 Layout Recommendation #2: Evaluation Board p/n: 090…

Text truncated - open the document above for the full version.

CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 FCC/ISED Test Setup Photos For: Globe Tracker ApS Model: CM2.75-1113120 Product Description: Asset Tracking Device / Data Modem FCC ID: 2ASJR-CM275-1113120 IC ID: 25752-CM275111312 Addition to Report #: EMC_GLOBE_004-22001_FCC_15B EMC_GLOBE_004-22001_FCC_15.247 DATE: 2022-09-30 Page 2 of 5 FCC 15B 30MHz – 1GHz 1GHz – 3GHz 3GHz – 18GHz Page 3 of 5 FCC 15.247 9kHz – 30MHz 30MHz – 1GHz 1GHz – 3GHz 3GHz – 18GHz Page 4 of 5 EUT Photos Page 5 of 5 Date Report Name Changes to report Prepared by 2022-09-30 EMC_GLOBE_004-22001_FCC_Setup_Photos Initial Version Cheng Song <<< The End >>>
