2AU8HSPH420-BQIndustrial smart handheld terminal

Basic OperationsSafety Warning Part Name How to Set Up/Use Radio Properly Scan Mode Settings PLTE Status PLTE Settings & Status Power on/off 1D/2D scanner operating instructions Adjust the volume Preventing water from ingress Airplane mode Restore factory settings Install Micro-SIM/T card Precautions SPH420-bq Enter the PLTE APK, set PLTE module configurations in 4G interface: Set scan mode Check PLTE module status in PLTE Status interface: ① 1D/2D scanner ② P ower on/off button ③ V olume+ ④ V olume- ⑤ C us tomiz able button ⑥ F ront c amer a ⑦ Br and logo ⑧ Distanc e/Light sensor ⑨ F ront speak er ⑩ Menu return button ⑪ F ront fingerprint rec ognition ⑫ R eturn button ⑬ Headphone jack ⑭ T ype -C ⑮ P eripheral int erf ac e ⑯ POC dedicated inter com button ⑰ SOS ⑱ R ear c amer a ⑲ P eripheral int erf ac e ⑳ SIM/TF car d slo t ㉑ NFC ㉒ Br and logo ㉓ Cr adle charging port ㉔ Flash LED Water ingress caused by improper operation and willful damage to LCD are not covered by warranty! To avoid unnecessary damage or conflict, read below information before using. 1.Do not use the device while you are driving. 2.During a call, please keep the phone at least 15mm away from your ear or body. 3.Please turn off the device if it is forbidden for using near some medical instrument. 4.Please turn off the device when you are on a plane, because wireless device may interfere with the radio communication system. 5.Do not use the device near gas station or in the hazardous environment. 6.Avoid using in extremely high or extremely low temperature environments. Press and hold the Power key button for 3 seconds to turn on the device. To turn off your device, press and hold the Power key for 3 seconds, and then select Power off. Sound From the Settings menu, select sound to change the sound settings for the device: sound, phone ring tone, and system sound. Display From the Settings menu, select Display to change the display of the device, such as brightness, wallpaper, sleep time, and font size. Storage In the Settings menu, select Storage to view the storage status and available space of the system. Battery In the Settings menu, select Battery to view battery information. Security & location In the Settings menu, select Security &location to change how screen is locked. Language In the Settings menu, select System->Languages to change the system language. Backup & reset In the Settings menu., select System->Backup and reset options to back up the data in the device or restore the factory settings. Date and time From the Settings menu, select System->Date &Time to change the time and date of system. Developer options In the Settings menu, open the developer options to connect the device to the computer and transfer data. About equipment In the Settings menu, select System->About Phone to view various information: Android version, kernel version, ect. Install the appropriate scanning tool APK in the handheld, open the APK, click to open the corresponding scanning function item, the 1D/2D scanner will emit a red scanning light, aim at the QR code or barcode, and the scanning tool APK will display the corresponding information Use the volume up and down buttons on the left side of the phone to adjust the volume. Cover the SIM card, USB interface and other covers properly to achieve IP68 waterproof. Setting->Network & Internet->Airplane mode Setting->Reset->Restore factory settings Open the SIM cover, you will see the TFF SIM card & Micro SD card slot. Please be aware of the right slot & direction as illustration. Function use Click the Settings app in the application interface to enter the settings. Figure 1 SIM card slot Figure 3 Lock the sim card Figure 4 Close the back cover of the SIM card Figure 7 Application interface Figure 8 4G PLTE off state Figure 9 4G PLTE on state Figure 10 Scan mode page Figure 11 state page Figure 2 Put the SIM card into the card slot Figure 5 1D/2D scannerFigure 6 1D/2D scanner working status 1. The USB port/antenna port needs to be plugged tightly before the waterproof test. 2. The phone may affect the waterproof effect after a destructive drop 3. Obvious changes in atmospheric pressure will cause the handset, speaker, and microphone to be silent or noisy. After soaking in water, the speaker, sending voice, and answering sound will be affected. You need to drain off the water. After a period of time, it will return to normal. 4. After soaking in sea water, please use clean water to desalt. 5. When using the PLTE network, the USB interface cannot use the file transfer function. When using the USB file transfer function, the PLTE switch must be turned off. Quick Start Guide FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Radiation Exposure Statement This device complies with FCC radiation exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must be installed and operated in accordance with provi…
