2AUA9-RQZY003AC2100 Smart WiFi Router

Project No.: 2005C136 Page 2 of 8 Project No.: 2005C136 Page 3 of 8 Project No.: 2005C136 Page 4 of 8 Project No.: 2005C136 Page 5 of 8

-0.3mm AC19V1.0-ROC01铜板贴 10044461 AC19V1.0-ROC01 133.7mm 17.7mm Power : 12V 2A MAC SSID Serial No. Pin No. FCC ID: 2AUA9-RQZY003 IP Address：192.168.0.1 Model:RSD0614 Made in China This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 供应商来料 AC2100 Smart WiFi Router

Project No.: 2005C136 Page 6 of 8 2.4G Ant. 1+5G Ant. 1 5G Ant. 2 2.4G Ant. 2+5G Ant. 3 5G Ant. 4 Project No.: 2005C136 Page 7 of 8 Project No.: 2005C136 Page 8 of 8

Report No.: BTL-FCCP-3-2005C136 Page 1 of 6 FCC RF EXPOSURE REPORT FCC ID: 2AUA9-RQZY003 Project No. : 2005C136 Equipment : AC2100 Smart WiFi Router Brand Name : ROCK, rock space Test Model : RSD0614 Series Model : N/A Applicant : Shenzhen Renqing Excellent Technology Co., Ltd. Address : 104, No.15, Longfu Industrial Zone, Tongsheng Community, Dalang Street, Longhua District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Renqing Excellent Technology Co., Ltd. Address : 104, No.15, Longfu Industrial Zone, Tongsheng Community, Dalang Street, Longhua District, Shenzhen, Guangdong, China Date of Receipt : May 21, 2020 Date of Test : May 22, 2020 ~ Jun. 10, 2020 Issued Date : Jul. 02, 2020 Report Version : R02 Test Sample : Engineering Sample No.: DG202005224 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & FCC Part 2.1091 FCC Title 47 Part 2.1091, OET Bulletin 65 Supplement C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chay Cai Approved by : Ethan Ma Add: No.3, Jinshagang 1 st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Te l : +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-3-2005C136 Page 2 of 6 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue Jun. 17, 2020 R01 Updated the address of applicant and manufacturer. Jun. 28, 2020 R02 Added the test factory information. Jul. 02, 2020 Report No.: BTL-FCCP-3-2005C136 Page 3 of 6 1. TEST FACILITY The test facilities used to collect the test data in this report is at the location of No.3,Jinshagang 1st Road, Shixia, Dalang Town, Dongguan, Guangdong, China. BTL's Test Firm Registration Number for FCC: 357015 BTL's Designation Number for FCC: CN1240 2. MPE CALCULATION METHOD Calculation Method of RF Safety Distance: where: S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Table for Filed Antenna For WLAN 2.4GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) 1 N/A N/A Dipole N/A 3.5 2 N/ A N/A Dipole N/A 3.5 Note: This EUT supports CDD, and all antennas have the same gain, then, 1) Non Beamforming function, Directional gain = G ANT +Array Gain, For power measurements, Array Gain = 0 dB (N ANT ≤ 4), so the Directional gain=3.5. For power spectral density measurements, N ANT = 2, N SS = 1. So Directional gain = G ANT + Array Gain = G ANT +10log (N ANT / N SS ) dB =3.5+10log(2/1)dBi=6.51. Then, the power spectral density limit is 8-(6.51-6)=7.49. 2) Beamforming function, Beamforming Gain: 3dB. So the Directional gain=3+3.5=6.5. Then, the power limit is 30-(6.5-6)=29.5. Table for Antenna Configuration: For Non Beamforming: Operating Mode TX Mode 1TX 2TX 802.11b V (Ant. 1) - 802.11g V (Ant. 1) - IEEE 802.11n (HT20) - V (Ant. 1 + Ant. 2) IEEE 802.11n (HT40) - V (Ant. 1 + Ant. 2) For Beamforming: Operating Mode TX Mode 2TX IEEE 802.11n (HT20) V (Ant. 1 + Ant. 2) IEEE 802.11n (HT40) V (Ant. 1 + Ant. 2) Report No.: BTL-FCCP-3-2005C136 Page 4 of 6 For WLAN 5GHz: Ant. Brand Model Name Antenna Type Connector Gain (dBi) Note 1 N/A N/A Dipole N/A 4 UNII-1 2 N/A N/A Dipole N/A 4 UNII-1 3 N/A N/A Dipole N/A 4 UNII-1 4 N/A N/A Dipole N/A 4 UNII-1 1 N/A N/A Dipole N/A 5.5 UNII-3 2 N/A N/A Dipole N/A 5.5 UNII-3 3 N/A N/A Dipole N/A 5.5 UNII-3 4 N/A N/A Dipole N/A 5.5 UNII-3 Note: This EUT supports CDD, and all antennas have the same gain, then, 1) Non Beamforming function, Directional gain = G ANT +Array Gain, a) For UNII-1: For power measurements, Array Gain = 0 dB (N ANT ≤ 4), so the Directional gain=4. For power spectral density measurements, N ANT = 4, N SS = 1. So Directional gain=G ANT +Array Gain = G ANT +10log (N ANT / N SS ) dB =4+10log(4/1)dBi=10.02. Then, the power spectral density limit is 17-(10.02-6)=12.98. b) For UNII-3: For power measurements, Array Gain = 0 dB (N ANT ≤ 4), so the Directional gain=5.5. For power spectral density measurements, N ANT = 4, N SS = 1. So Directional gain = G ANT + Array Gain = G ANT +10log (N ANT / N SS ) dB =5.5+10log(4/1)dBi=11.52. Then, the power spectral density Limit is 30-(11.52-6)=24.48. 2) Beamforming function, Beamforming Gain: 6dB. So, a) For UNII-1: The Directional gain=6+4=10. Then, the average output power limit is 30-(10-6)=26. b) For UNII-3: The Directional gain=6+5.5=11.5. Then, the average output power limit is 30-(11.5-6)=24.5. Table for Antenna Configuration: For Non Beamforming: Operating Mode TX Mode 1TX 4TX IEEE 802.11a V (Ant. 1) - IEEE 802.11n (HT20) - V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11n (HT40) - V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac (VHT20) - V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac (VHT40) - V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac (VHT80) - V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) Report No.: BTL-FCCP-3-2005C136 Page 5 of 6 For Beamforming: Operating Mode TX Mode 4TX IEEE 802.11n (HT20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11n (HT40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac (VHT20) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac (VHT40) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) IEEE 802.11ac (VHT80) V (Ant. 1 + Ant. 2 + Ant. 3 + Ant. 4) Report No.: BTL-FCCP-3-2005C136 Page 6 of 6 3. TEST RESULTS For 2.4GHz Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 3.5 2.2387 24.73 297.1666 0.13242 1 Complies For 2.4GHz Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Average Output Power (dBm) Max. Average Output Power (mW) Power Density (S) (mW/cm 2 ) Limit of Power Density (S) (mW/cm 2 ) Test Result 6.5 4.4668 18.14 65.1628 0.05794 1 Complies For 5GHz UNII-1 Non Beamforming: Directional Gain (dBi) Directional Gain (numeric) Max. Output Power (dBm) Max. Output …

Text truncated - open the document above for the full version.

Report No.: BTL-FCCP-1-2005C136 Page 1 of 118 FCC Radio Test Report FCC ID: 2AUA9-RQZY003 This report concerns: Original Grant Project No. : 2005C136 Equipment : AC2100 Smart WiFi Router Brand Name : ROCK, rock space Test Model : RSD0614 Series Model : N/A Applicant : Shenzhen Renqing Excellent Technology Co., Ltd. Address : 104, No.15, Longfu Industrial Zone, Tongsheng Community, Dalang Street, Longhua District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Renqing Excellent Technology Co., Ltd. Address : 104, No.15, Longfu Industrial Zone, Tongsheng Community, Dalang Street, Longhua District, Shenzhen, Guangdong, China Date of Receipt : May 21, 2020 Date of Test : May 22, 2020 ~ Jun. 10, 2020 Issued Date : Jun. 28, 2020 Report Version : R01 Test Sample : Engineering Sample No.: DG202005224 for conducted, DG202005225 for radiated. Standard(s) : FCC Part15, Subpart C (15.247) ANSI C63.10-2013 FCC KDB 558074 D01 15.247 Meas Guidance v05r02 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. Prepared by : Chay Cai Approved by : Ethan Ma Add: No.3, Jinshagang 1st Road, Shixia, Dalang Town,Dongguan, Guangdong, China. Tel: +86-769-8318-3000 Web: www.newbtl.com Report No.: BTL-FCCP-1-2005C136 Page 2 of 118 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL shall have no liability for any declarations, inferences or generalizations drawn by the client or others from BTL issued reports. The report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST, A2LA, or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.: BTL-FCCP-1-2005C136 Page 3 of 118 Table of Contents Page REPORT ISSUED HISTORY 6 1 . SUMMARY OF TEST RESULTS 7 1.1 TEST FACILITY 8 1.2 MEASUREMENT UNCERTAINTY 8 1.3 TEST ENVIRONMENT CONDITIONS 9 2 . GENERAL INFORMATION 10 2.1 GENERAL DESCRIPTION OF EUT 10 2.2 DESCRIPTION OF TEST MODES 12 2.3 PARAMETERS OF TEST SOFTWARE 14 2.4 DUTY CYCLE 15 2.5 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 16 2.6 SUPPORT UNITS 16 3 . AC POWER LINE CONDUCTED EMISSIONS TEST 17 3.1 LIMIT 17 3.2 TEST PROCEDURE 17 3.3 DEVIATION FROM TEST STANDARD 17 3.4 TEST SETUP 18 3.5 EUT OPERATION CONDITIONS 18 3.6 TEST RESULTS 18 4 . RADIATED EMISSIONS TEST 19 4.1 LIMIT 19 4.2 TEST PROCEDURE 20 4.3 DEVIATION FROM TEST STANDARD 20 4.4 TEST SETUP 21 4.5 EUT OPERATION CONDITIONS 22 4.6 TEST RESULTS - 9 KHZ TO 30 MHZ 22 4.7 TEST RESULTS - 30 MHZ TO 1000 MHZ 22 4.8 TEST RESULTS - ABOVE 1000 MHZ 22 5 . BANDWIDTH TEST 23 5.1 LIMIT 23 5.2 TEST PROCEDURE 23 5.3 DEVIATION FROM STANDARD 23 5.4 TEST SETUP 23 Report No.: BTL-FCCP-1-2005C136 Page 4 of 118 Table of Contents Page 5.5 EUT OPERATION CONDITIONS 23 5.6 TEST RESULTS 23 6 . MAXIMUM OUTPUT POWER TEST 24 6.1 LIMIT 24 6.2 TEST PROCEDURE 24 6.3 DEVIATION FROM STANDARD 24 6.4 TEST SETUP 24 6.5 EUT OPERATION CONDITIONS 24 6.6 TEST RESULTS 24 7 . CONDUCTED SPURIOUS EMISSIONS 25 7.1 LIMIT 25 7.2 TEST PROCEDURE 25 7.3 DEVIATION FROM STANDARD 25 7.4 TEST SETUP 25 7.5 EUT OPERATION CONDITIONS 25 7.6 TEST RESULTS 25 8 . POWER SPECTRAL DENSITY TEST 26 8.1 LIMIT 26 8.2 TEST PROCEDURE 26 8.3 DEVIATION FROM STANDARD 26 8.4 TEST SETUP 26 8.5 EUT OPERATION CONDITIONS 26 8.6 TEST RESULTS 26 9 . MEASUREMENT INSTRUMENTS LIST 27 10 . EUT TEST PHOTO 29 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 33 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 38 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 43 APPENDIX D - RADIATED EMISSION- ABOVE 1000 MHZ 46 APPENDIX E - BANDWIDTH 97 APPENDIX F - MAXIMUM OUTPUT POWER 102 APPENDIX G - CONDUCTED SPURIOUS EMISSIONS 108 Report No.: BTL-FCCP-1-2005C136 Page 5 of 118 Table of Contents Page APPENDIX H - POWER SPECTRAL DENSITY 115 Report No.: BTL-FCCP-1-2005C136 Page 6 of 118 REPORT ISSUED HISTORY Report Version Description Issued Date R00 Original Issue. Jun. 17, 2020 R01 Updated the address of applicant and manufacturer. Jun. 28, 2020 Report No.: B TL-FCCP-1-2005C136 Page 7 of 118 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standard(s): FCC Part15, Subpart C (15.247) Standard(s) Se ction Te st Ite m Te st Re su l t Judgment Remark 15.207 AC Power Line Conducted Emissions APPENDIX A PASS ------ 15.247(d) 15.205(a) 15.209(a) Radiated Emissions APPENDIX B APPENDIX C APPENDIX D PASS ------ 15.247(a)(2) Bandwidth APPENDIX E PASS ------ 15.247(b)(3) …

Text truncated - open the document above for the full version.

Report No.: B TL-FCCP-1-2005C136 Page 110 of 118 Test Mode TX G Mode Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-2005C136 Page 111 of 118 Test Mode TX N-20M Mode_Ant. 1 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-2005C136 Page 112 of 118 Test Mode TX N-20M Mode_Ant. 2 Bandedge-CH01 Bandedge-CH11 CH01 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH11 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-2005C136 Page 113 of 118 Test Mode TX N-40M Mode_Ant. 1 Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-2005C136 Page 114 of 118 Test Mode TX N-40M Mode_Ant. 2 Bandedge-CH03 Bandedge-CH09 CH03 – 10th Harmonic of the fundamental frequency CH06 – 10th Harmonic of the fundamental frequency CH09 – 10th Harmonic of the fundamental frequency Report No.: B TL-FCCP-1-2005C136 Page 115 of 118 APPENDIX H - POWER SPECTRAL DENSITY Report No.: B TL-FCCP-1-2005C136 Page 116 of 118 Test Mode TX B Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -9.60 8 Complies 06 2437 -6.37 8 Complies 11 2462 -9.03 8 Complies CH01 CH06 CH11 Test Mode TX G Mode Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -10.59 8 Complies 06 2437 -5.39 8 Complies 11 2462 -10.11 8 Complies CH01 CH06 CH11 Report No.: B TL-FCCP-1-2005C136 Page 117 of 118 Test Mode TX N-20M Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -11.90 8 Complies 06 2437 -11.94 8 Complies 11 2462 -11.48 8 Complies CH01 CH06 CH11 Test Mode TX N-20M Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -12.58 8 Complies 06 2437 -12.28 8 Complies 11 2462 -11.61 8 Complies CH01 CH06 CH11 Test Mode TX N-20M Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 01 2412 -9.22 7.49 Complies 06 2437 -9.10 7.49 Complies 11 2462 -8.53 7.49 Complies Report No.: B TL-FCCP-1-2005C136 Page 118 of 118 Test Mode TX N-40M Mode_Ant. 1 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -15.10 8 Complies 06 2437 -12.62 8 Complies 09 2452 -15.02 8 Complies CH03 CH06 CH09 Test Mode TX N-40M Mode_Ant. 2 Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -14.49 8 Complies 06 2437 -13.27 8 Complies 09 2452 -14.47 8 Complies CH03 CH06 CH09 Te s t Mode TX N-40M Mode_Total Channel Frequency (MHz) Power Spectral Density (dBm/3kHz) Max. Limit (dBm/3kHz) Result 03 2422 -11.77 7.49 Complies 06 2437 -9.92 7.49 Complies 09 2452 -11.73 7.49 Complies End of Test Report

Report No.: B TL-FCCP-1-2005C136 Page 29 of 118 10. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.: B TL-FCCP-1-2005C136 Page 30 of 118 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.: B TL-FCCP-1-2005C136 Page 31 of 118 Radiated Emissions Test Photos 30 MHz to 1 GHz Report No.: B TL-FCCP-1-2005C136 Page 32 of 118 Radiated Emissions Test Photos Above 1 GHz
