2AUIUWVODB1BASE STATION

Wyze Cam Outdoor Base Station Base Station Power Adapter Base Station Ethernet Cable Camera Charging USB Cable Quick Start Guide Screw Assembly x1 x1 x1 x1 x1 x1 x1 IN THE BOX Power AdapterUSB Cable Ethernet Cable MicroSD Slot (MicroSD not included) 2 SYNC Button 1 LAN Port 6 Power Input 5 USB Charging port 4 Reset 3 Status Light 7 1 2 Micro SD SYNC RIGHT Power LAN 5 6 BACK RESET 3 4 LEFT 7 TOP SURFACE SETUP 3 Follow the Wyze app to set up the camera. 4 Follow the Wyze app to mount the camera. Screw Assembly Microphone 3 Removable Magnetic Mounting Base 4 Lens 2 Light Sensor 1 MicroSD Slot (SD card not included) 8 SYNC Button 7 Ceiling Mounting Hole 10 Wall Mounting Hole 9 On-O Switch USB Charging Port 5 Status Light 6 1 2 3 4 FRONT 5 6 OPEN BACK 10 9 BOTTOM Removable Magnetic Mounting Base SYNC Micro SD 7 8 Base Station Wall Mounting Ceiling Mounting Troubleshooting & FAQs support.wyze.com Community forums.wyze.com Contact Us [email protected] 1-844-WYZECAM Tutorial Videos www.youtube.com/wyzelabs NEED HELP? LIGHT INDICATIONS Solid yellow light The device is powered on and initializing Solid blue light The device is working properly Flashing yellow & blue lights The device is pairing with camera Flashing blue light The device is connecting to the network Wyze Cam Outdoor Solid yellow light The device is powered on and initializing Solid blue light The device is working properly Flashing red light The device is charging Solid red light The device is fully charged No indicator light The device is powered o or sleeping Flashing yellow & blue lights The device is pairing with base station Flashing blue light The device is connecting network (1) l'appareil ne doit pas produire de brouillage, et (2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. ISEDC Radiation Exposure Statement: This equipment complies with ISEDC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment should be installed and operated with minimum distance 20cm between the radiator& your body. 1 Follow the Wyze app to set up base station 2 Download the Wyze app and create an account. ①③ ② ①③ ② Precautions: Using the camera in the car under direct sun exposure could exceed the operating tempera- ture of the battery, resulting in irreversible damage to the battery. FCC Warning: T his device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any inte rference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be QUICK START GUIDE CAM OUTDOOR determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement To comply with FCC RF exposure compliance requirements, this grant is applicable to only mobile configurations. The antennas used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co- located or operating in conjunction with any other antenna or transmitter. Cet appareil estconforme aux limitesd'exposition de rayonnement RF ISEDC établiespour un environnement non contrôlé. Cetémetteur ne doit pas être co-implanté oufonctionner en conjonction avec toute autreantenne ou transmetteur. Industrial cellular router doit être installé et utiliséavec une distance minimale de 20cm entre leradiateur & votre corps. Front Back IS E DC RSS warning : This device complies with ISEDC licence-exempt RSS standard (s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d'ISEDC applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 <2020-11-05> TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID 2AUIUWVODB1 Model name WVODB1 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Dongsheng Song /Chief Product Officer Company: Wyze Labs, Inc. Address: 3933 Lake Washington Blvd NE Suite 350 Kirkland Washington United States 98033 Phone: 5176141124 Fax: n/a E-Mail: [email protected]

Wyze Labs, Inc. Add: 3933 Lake Washington Blvd NE Suite 350 Kirkland Washington United States 98033 Date: Nov 05, 2020 FCC ID: 2AUIUWVODB1 Model Number: WVODB1 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Wyze Labs, Inc., declare that this EUT (FCC ID: 2AUIUWVODB1) doesn’t have Ad Hoc mode function on “non-US/Canada frequencies”. In addition. The frequency selection feature is disabled by firmware for devices marked to the US/Canada. For DTS part of this device, only channels 1-11 will be used in North America, Country code selection is disabled. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name / Title: Dongsheng Song /Chief Product Officer Company: Wyze Labs, Inc. Address: 3933 Lake Washington Blvd NE Suite 350 Kirkland Washington United States 98033 Phone: 5176141124 Fax: n/a E-Mail: [email protected]

Wyze Labs, Inc. Add: 3933 Lake Washington Blvd NE Suite 350 Kirkland Washington United States 98033 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2020/11/05 To whom it may concern: We, Wyze Labs, Inc. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AUIUWVODB1 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Dongsheng Song /Chief Product Officer Company: Wyze Labs, Inc. Address: 3933 Lake Washington Blvd NE Suite 350 Kirkland Washington United States 98033 Phone: 5176141124 Fax: n/a E-Mail: [email protected]

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 5 External Photos of the EUT Fig.1 Fig.2 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 5 Fig.3 Fig.4 WIFI Antenna 1 WIFI Antenna 0 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 5 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 5 Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 5 of 5 Fig.9 Fig.10

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 _____________________________________________________________________________________________________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 1 LABEL AND LOCATION (Size: L3.0m x 2.0cm) Material: Tagboard Glue: adhesive sticker Font color: White Label color: Black Label Location BASE STATION Model No.: WVODB1 FCC ID: 2AUIUWVODB1 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 1 of 5 Internal Photos of the EUT Fig.1 Fig.2 2.4GWIFI Ant_0 2.4GWIFI Ant_1 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 2 of 5 Fig.3 Fig.4 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 3 of 5 Fig.5 Fig.6 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 4 of 5 Fig.7 Fig.8 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 ________________________________________________________________________________ _________ This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd.. Page 5 of 5 Fig.9

SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 1 of 5 Maximum Permissible Exposure Report 1. Product Information FCC ID: 2AUIUWVODB1 Product name BASE STATION Test Model WVODB1 Power supply Input: DC 12V, 1A For adapter: Input: AC 100-240V, 50/60Hz, 0.4A Max Output: DC 12 V, 1A Operation frequency 2.412-2.462GHz for 2.4G WIFI Antenna Type External antenna Antenna Gain 2.0dBi Hardware version V2.0 Software version V1.0 Channel Number 11 channels for 20MHz bandwidth (2412~2462MHz) 7 channels for 40MHz bandwidth(2422MHz~2452MHz) Channel Spacing 5MHz Exposure category General population/uncontrolled environment EUT Type Production Unit Device Type Mobile Devices 2. Evaluation Method and Limit Systems operating under the provisions of FCC 47 CFR section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. In accordance with 47 CFR FCC Part 2 Subpart J, section 2.1091 this device has been defined as mobile device whereby a distance of 0.2m normally can be maintained between the user and the device, and below RF Permissible Exposure limit shall comply with. In accordance with KDB447498D01 for Simultaneous transmission MPE test exclusion applies when the sum of the MPE ratios for all simultaneous transmitting antennas incorporated in a host device, based on the calculated/estimated, numerically modelled or measured field strengths or power density, is ≤ 1.0. The MPE ratio of each antenna is determined at the minimum test separation distance required by the operating configurations and exposure conditions of the host device, according to the ratio of field strengths or power density to MPE limit, at the test frequency. Either the maximum peak or spatially averaged results from measurements or numerical simulations may be used to determine the MPE ratios. Spatial averaging does not apply when MPE is estimated using simple calculations based on far-field plane-wave equivalent conditions. The antenna installation and operating requirements for the host device must meet the minimum test separation distances required by all antennas, in both standalone and simultaneous transmission operations, to satisfy compliance. 3. Limit 3. 1 Refer Evaluation Method ANSI C95.1–1999: IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz. FCC KDB publication 447498 D01 General 1 RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. FCC CFR 47 part1 1.1310: Radiofrequency radiation exposure limits. FCC CFR 47 part2 2.1091: Radiofrequency radiation exposure evaluation: mobile devices SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 2 of 5 3. 2 Limit Limits for Maximum Permissible Exposure (MPE)/Controlled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 1842/f 61.4 / / 1.63 4.89/f 0.163 / / (100) * (900/f 2 )* 1.0 f/300 5 6 6 6 6 6 Limits for Maximum Permissible Exposure (MPE)/Uncontrolled Exposure Frequency Range(MHz) Electric Field Strength(V/m) Magnetic Field Strength(A/m) Power Density (mW/cm²) Averaging Time (minute) Limits for Occupational/Controlled Exposure 0.3 – 3.0 3.0 – 30 30 – 300 300 – 1500 1500 – 100,000 614 824/f 27.5 / / 1.63 2.19/f 0.073 / / (100) * (180/f 2 )* 0.2 f/1500 1.0 30 30 30 30 30 F=frequency in MHz *=Plane-wave equivalent power density 4. MPE Calculation Method Predication of MPE limit at a given distance Equation from page 18 of OET Bulletin 65, Edition 97-01 S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 5. Antenna Information Artemis Antenna can only use antennas certificated as follows provided by manufacturer; Internal Identification Antenna type and antenna number Operate frequency band Maximum antenna gain Note Antenna_0 External Antenna 2412MHz-2462MHz 2.0dBi WIFI Antenna Antenna_1 External Antenna 2412MHz-2462MHz 2.0dBi WIFI Antenna SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 3 of 5 6. Conducted Power <2.4GWLAN Max Conducted Power >(Ant_0) Mode Channel Frequency(MHz) Max Conducted Power (dBm) IEEE 802.11b 1 2412 16.15 6 2437 16.27 11 2462 16.45 IEEE 802.11g 1 2412 21.72 6 2437 21.97 11 2462 22.36 IEEE 802.11n HT20 1 2412 21.71 6 2437 22.10 11 2462 22.47 IEEE 802.11n HT40 3 2422 18.82 6 2437 20.01 9 2452 21.04 <2.4GWLAN Max Conducted Power >(Ant_1) Mode Channel Frequency(MHz) Max Conducted Power (dBm) IEEE 802.11b 1 2412 18.42 6 2437 18.88 11 2462 19.53 IEEE 802.11g 1 2412 18.6 6 2437 19.57 11 2462 20.54 IEEE 802.11n HT20 1 2412 19.36 6 2437 20.07 11 2462 20.9 IEEE 802.11n HT40 3 2422 19.94 6 2437 20.35 9 2452 20.83 SHENZHEN LCS COMPLIANCE TESTING LABORATORY LTD. FCC ID: 2AUIUWVODB1 This report shall not be reproduced except in full, without the written approval of Shenzhen LCS Compliance Testing Laboratory Ltd. Page 4 of 5 7. Manufacturing Tolerance <2.4G WIFI>(Ant_0) 11B (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 16.0 16.0 16.0 Tolerance ±(dB) 1.0 1.0 1.0 11G (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 21.0 21.0 22.0 Tolerance ±(dB) 1.0 1.0 1.0 11N20SISO (Peak) Channel Channel 1 Channel 6 Channel 11 Target (dBm) 21.0 22.0 22.0 …
