2AUTE-2TS25L1) Portable Photo Printer, 2) Mini Photo Printer, 3) Dye-Sublimation Photo Printer, 4) Photo Printer

Take out a consumable, put it into the compartment according to the direction shown below, place your finger in the "Push" position and press it into place until it makes a "click" sound; 1. The photo paper is susceptible to moisture, please use it as soon as possible after opening. 2. This device only supports official photo paper that comes with the ribbon, please do not replace it by yourself. 3. Avoid excessive direct sunlight and low temperature. 4. If the consumable is damaged or deformed by external force, please do not insert it into the device by force. Product Introduction Accessories LED Indicator Paper Outlet USB Type-C Port Lanyard Hole consumable compartment Power Button USB Type-C Cable LED Indicator Status Consumable Installation InstructionsPrinting Instructions 01 02 03 PIX22 Ouick Start GuideConsumable If there is a paper jam or ribbon jam and cannot be solved, please contact the after-sales service and do not remove it violently. * Note: The items in the package are actually based on the order . Open the consumable compartment. Insert the consumable. Close the consumable compartment. HeyPhoto APP Scan the QR code to download the "HeyPhoto" APP. Long press the power button until the indicator light tums on, then release. The device will power on. Open APP, click "Add Device" , Search for "PIX22-XXXX" and click to connect. In the app, select the photos you want to print. You can also edit the photos as needed before printing. 1. After the first connection, you just need to click the print icon for subsequent use, the printer will be automatically connected and print. 2. Do not exit the APP during the printing process, this may cause printing failure. 3 1 1 2 Solid orange Flashing orange (slow) Solid red Flashing red (slow) Flashing red (fast) Status Indicator Light Status Indicator Light Status Status Indicator Light Status Status No Photo Paper/Color Ribbon is depleted/No Photo Paper Cartridge inserted Photo Paper/Color Ribbon is jammed Low battery Temperature/device abnormality Color Ribbon error/ Photo Paper Cartridge not recognized Error Status Printer Status Solid blue Bluetooth is connected, ready to use Printing/receiving data via Bluetooth Device powering on Flashing blue (slow) Flashing blue (fast) Flashing blue (fast) Bluetooth pairing mode Flashing green (slow) Charging in progress Fully charged (powered on) Fully charged (powered off) Solid green Solid green (until the USB-C cable is unplugged) Charging status Flashing red (slow) indicator indicates the temperature is outside the safe range for charging. Recommended charging temperature: 0°C to 45°C. Product Parameters Product Name Portable Photo Printer Printer Model HCP-2TS25L Dimensions 125x85x33.5mm Weight Bare Printer 286g Print Method Thermal Dye Sublimation Print Size 54x72mm Print Resolution 300dpi Battery Capacity 860mAh Charging Interface 5V / 2A，Type-C Interface Operating Temperature 5°C~35°C This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec�on against harmful interference in a residen�al installa�on. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruc�ons, may cause harmful interference to radio communica�ons. However, there is no guarantee that interference will not occur in a par�cular installa�on. If this equipment does cause harmful interference to radio or television recep�on, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —Reorient or relocate the receiving antenna. —Increase the separa�on between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. This device complies with Part 15 of the FCC Rules. Opera�on is subject to the following two condi�ons: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired opera�on. This device complies with FCC radia�on exposure limits set forth for an uncontrolled environment and it also complies with Part 15 of the FCC RF Rules. This equipment must not be co-located or opera�ng in conjunc�on with any other antenna or transmi�er. End-users and installers must be provided with antenna installa�on instruc�ons and consider removing the no-colloca�on statement. Cau�on! Any changes or modifica�ons not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Warning: Opera�on of this equipment in a residen�al environment could cause radio interference. FCC ID: 2AUTE-2TS25L iPhone 16 Pro Max, iPhone 16 Pro, iPhone 16 Plus, iPhone 16, iPhone 15 Pro Max, iPhone 15 Pro, iPhone 15 Plus, iPhone 15, iPhone 14 Pro Max, iPhone 14 Pro, iPhone 14 Plus, iPhone 14, iPhone SE (3rd genera�on), iPhone 13 Pro Max, iPhone 13 Pro, iPhone 13, iPhone 13 mini, iPhone 12 Pro Max, iPhone 12 Pro, iPhone 12, iPhone 12 mini, iPhone SE (2nd genera�on), iPhone 11 Pro Max, iPhone 11 Pro, iPhone 11, iPhone XS Max, iPhone XS, iPhone XR, iPhone X, iPhone 8 Plus, iPhone 8 Use of the Made for Apple badge means that an accessory has been designed to connect specifically to the Apple product(s) iden�fied in the badge and has been cer�fied by the developer to meet Apple performance standards. Apple is not responsible for the opera�on of this device or its compliance with safety and regulatory standards. Apple, iPad, iPad Air, iPad Pro, iPhone are trademarks of Apple Inc., registered in the U.S. and other countries and regions. Apple, iPad, iPad Air, iPad Pro, iPhone are trademarks of Apple Inc., registered in the U.S. and other countries and regions. The trademark…

Text truncated - open the document above for the full version.

Project No.: 2510C254 Page 1 of 20 ATTACHMENT PHOTOGRAPHS OF EUT Project No.: 2510C254 Page 2 of 20 Project No.: 2510C254 Page 3 of 20 Project No.: 2510C254 Page 4 of 20 Project No.: 2510C254 Page 5 of 20

Label location

Project No.: 2510C254 Page 6 of 20 Project No.: 2510C254 Page 7 of 20 Project No.: 2510C254 Page 8 of 20 Project No.: 2510C254 Page 9 of 20 Project No.: 2510C254 Page 10 of 20 Project No.: 2510C254 Page 11 of 20

Project No.: 2510C254 Page 12 of 20 BT ANT. Project No.: 2510C254 Page 13 of 20 Project No.: 2510C254 Page 14 of 20 Project No.: 2510C254 Page 15 of 20 Project No.: 2510C254 Page 16 of 20 Project No.: 2510C254 Page 17 of 20

Project No.: 2510C254 Page 18 of 20 Project No.: 2510C254 Page 19 of 20 Project No.: 2510C254 Page 20 of 20 NFC.ANT

Report No.: BTL-FCCP-3-2510C254 Report Version: R00 Page 1 of 4 FCC RF EXPOSURE REPORT FCC ID: 2AUTE-2TS25L Project No. : 2510C254 Equipment : 1) Portable Photo Printer 2) Mini Photo Printer 3) Dye-Sublimation Photo Printer 4) Photo Printer Brand Name : Hanin or , HPRT or , iDPRT, PRT Test Model : HCP-2TS25L Model Name : HCP-2TS25L, CP2200, CP2201, CP2200 Pro, CP2200-L, D2200, DD20, PIX2200, PIX22, PIX22L, PIX22 Pro, Zeva 2200, W2200, W22 Hardware Version : Z5S-MBC Software Version : CP2200_V1.01.05 Applicant : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Manufacturer : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Factory : Xiamen Hanin Co., Ltd. Address : No.96, RongYuan Road, Tong'an District, Xiamen City, Fujian Province, P.R. China Date of Receipt : Oct. 28, 2025 Date of Test : Nov. 01, 2025 ~ Nov. 22, 2025 Issued Date : Dec. 26, 2025 Test Sample : Engineering Sample No.: DG92025102818 Standard(s) : FCC Guidelines for Human Exposure IEEE C95.1 & KDB447498 D01 v06 The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. (Dongguan) Prepared by : Chella Zheng Approved by : Chay Cai No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong People’s Republic of China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.: BTL-FCCP-3-2510C254 Report Version: R00 Page 2 of 4 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-3-2510C254 R00 Original Report. Dec. 26, 2025 Valid Report No.: BTL-FCCP-3-2510C254 Report Version: R00 Page 3 of 4 1. GENERAL CONCULUSION According to FCC KDB447498 D01, Appendix A, SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm, the 1-g and 10-g SAR test exclusion thresholds are determined by the following: [(max. power of channel, including tune-up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR, and ≤ 7.5 for 10-g extremity SAR, where  f(GHz) is the RF channel transmit frequency in GHz  Power and distance are rounded to the nearest mW and mm before calculation  The result is rounded to one decimal place for comparison Appendix A - SAR Test Exclusion Thresholds for 100 MHz - 6 GHz and < 50 mm MHz 5 10 15 20 25 30 35 40 45 50 mm 150 39 77 116 155 194 232 271 310 349 387 SAR Test Exclusion Thresholds (mW) 300 27 55 82 110 137 164 192 219 246 274 450 22 45 67 89 112 134 157 179 201 224 835 16 33 49 66 82 98 115 131 148 164 900 16 32 47 63 79 95 111 126 142 158 1500 12 24 37 49 61 73 86 98 110 122 1900 11 22 33 44 54 65 76 87 98 109 2450 10 19 29 38 48 57 67 77 86 96 3600 8 16 24 32 40 47 55 63 71 79 5200 7 13 20 26 33 39 46 53 59 66 5400 6 13 19 26 32 39 45 52 58 65 5800 6 12 19 25 31 37 44 50 56 62 Report No.: BTL-FCCP-3-2510C254 Report Version: R00 Page 4 of 4 2. TABLE FOR FILED ANTENNA Ant. Manufacturer Model Name Antenna Type Connector Gain (dBi) 1 Xiamen Hanin Co.,Ltd. HCP-2TS25F PCB N/A -5.89 Note: The antenna gain is provided by the manufacturer. 3. TEST RESULTS SAR Test Exclusion 3SAR Test Exclusion BLE 2402 5.305.303.38841.05033 Exclusion Thresholds LimitResult BT 2440 5.375.373.44351.0758 Function Frequency (MHz) Max. Output Power (dBm) Max. Tune-up Power (dBm) Max. Tune-up Power (mW) Note: No SAR evaluation required since transmitter power is below FCC threshold. End of Test Report

Report No.:BTL-FCCP-2-2510C254 Report Version: R00 Page 1 of 61 FCC Radio Test Report FCC ID: 2AUTE-2TS25L This report concerns: Original Grant Project No. : 2510C254 Equipment : 1) Portable Photo Printer 2) Mini Photo Printer 3) Dye-Sublimation Photo Printer 4) Photo Printer Brand Name : Hanin or , HPRT or , iDPRT, PRT Model Name : HCP-2TS25L, CP2200, CP2201, CP2200 Pro, CP2200-L, D2200, DD20, PIX2200, PIX22, PIX22L, PIX22 Pro, Zeva 2200, W2200, W22 Applicant : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Manufacturer : Xiamen Hanin Co., Ltd. Address : Room 305A, Angye Building, Pioneering Park,Torch High-tech Zone,Xiamen,China Factory : Xiamen Hanin Co., Ltd. Address : No.96, RongYuan Road, Tong'an District, Xiamen City, Fujian Province, P.R. China Date of Receipt : Oct. 28, 2025 Date of Test : Oct. 29, 2025 ~ Nov. 26, 2025 Issued Date : Dec. 26, 2025 Test Sample : Engineering Sample No.: DG92025102817 for radiated & ac power line conducted emissions, DG92025102818 for others. Standard(s) : FCC CFR Title 47, Part 15, Subpart C The above equipment has been tested and found compliance with the requirement of the relative standards by BTL Inc. (Dongguan) Prepared by : Chella Zheng Approved by : Chay Cai No.3, Jinshagang 1st Road, Dalang, Dongguan, Guangdong People’s Republic of China. Te l : + 8 6-769-8318-3000 Web: www.newbtl.com Service mail: [email protected] Report No.:BTL-FCCP-2-2510C254 Report Version: R00 Page 2 of 61 Declaration BTL represents to the client that testing is done in accordance with standard procedures as applicable and that test instruments used has been calibrated with standards traceable to international standard(s) and/or national standard(s). BTL's reports apply only to the specific samples tested under conditions. It is manufacture’s responsibility to ensure that additional production units of this model are manufactured with the identical electrical and mechanical components. BTL assumes no responsibility for the data provided by the customer, any statements, inferences or generalizations drawn by the customer or others from the reports issued by BTL. The report must not be used by the client to claim product certification, approval, or endorsement by A2LA or any agency of the U.S. Government. This report is the confidential property of the client. As a mutual protection to the clients, the public and ourselves, the test report shall not be reproduced, except in full, without our written approval. BTL’s laboratory quality assurance procedures are in compliance with the ISO/IEC 17025: 2017 requirements, and accredited by the conformity assessment authorities listed in this test report. BTL is not responsible for the sampling stage, so the results only apply to the sample as received. The information, data and test plan are provided by manufacturer which may affect the validity of results, so it is manufacturer’s responsibility to ensure that the apparatus meets the essential requirements of applied standards and in all the possible configurations as representative of its intended use. Limitation For the use of the authority's logo is limited unless the Test Standard(s)/Scope(s)/Item(s) mentioned in this test report is (are) included in the conformity assessment authorities acceptance respective. Please note that the measurement uncertainty is provided for informational purpose only and are not use in determining the Pass/Fail results. Report No.:BTL-FCCP-2-2510C254 Report Version: R00 Page 3 of 61 Table of Contents Page REVISION HISTORY 6 1 . APPLICABLE STANDARDS 7 2 . SUMMARY OF TEST RESULTS 7 2.1 TEST FACILITY 8 2.2 MEASUREMENT UNCERTAINTY 8 2.3 TEST ENVIRONMENT CONDITIONS 9 3 . GENERAL INFORMATION 10 3.1 GENERAL DESCRIPTION OF EUT 10 3.2 DESCRIPTION OF TEST MODES 12 3.3 PARAMETERS OF TEST SOFTWARE 13 3.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 3.5 SUPPORT UNITS 13 3.6 CUSTOMER INFORMATION DESCRIPTION 13 4 . AC POWER LINE CONDUCTED EMISSIONS 14 4.1 LIMIT 14 4.2 TEST PROCEDURE 14 4.3 DEVIATION FROM TEST STANDARD 14 4.4 TEST SETUP 15 4.5 EUT OPERATING CONDITIONS 15 4.6 TEST RESULTS 15 5 . RADIATED EMISSIONS 16 5.1 LIMIT 16 5.2 TEST PROCEDURE 17 5.3 DEVIATION FROM TEST STANDARD 18 5.4 TEST SETUP 18 5.5 EUT OPERATING CONDITIONS 20 5.6 TEST RESULT - 9 KHZ TO 30 MHZ 20 5.7 TEST RESULT - 30 MHZ TO 1000 MHZ 20 5.8 TEST RESULT - ABOVE 1000 MHZ 20 6 . BANDWIDTH 21 6.1 LIMIT 21 Report No.:BTL-FCCP-2-2510C254 Report Version: R00 Page 4 of 61 Table of Contents Page 6.2 TEST PROCEDURE 21 6.3 DEVIATION FROM STANDARD 21 6.4 TEST SETUP 21 6.5 EUT OPERATION CONDITIONS 21 6.6 TEST RESULTS 21 7 . MAXIMUM OUTPUT POWER 22 7.1 LIMIT 22 7.2 TEST PROCEDURE 22 7.3 DEVIATION FROM STANDARD 22 7.4 TEST SETUP 22 7.5 EUT OPERATION CONDITIONS 22 7.6 TEST RESULTS 22 8 . CONDUCTED SPURIOUS EMISSION 23 8.1 LIMIT 23 8.2 TEST PROCEDURE 23 8.3 DEVIATION FROM STANDARD 24 8.4 TEST SETUP 24 8.5 EUT OPERATION CONDITIONS 24 8.6 TEST RESULTS 24 9 . POWER SPECTRAL DENSITY 25 9.1 LIMIT 25 9.2 TEST PROCEDURE 25 9.3 DEVIATION FROM STANDARD 25 9.4 TEST SETUP 25 9.5 EUT OPERATION CONDITIONS 25 9.6 TEST RESULTS 25 10 . POWER SPECTRAL DENSITY 26 10.1 LIMIT 26 10.2 TEST PROCEDURE 26 10.3 DEVIATION FROM STANDARD 26 10.4 TEST SETUP 26 10.5 EUT OPERATION CONDITIONS 26 10.6 TEST RESULTS 26 Report No.:BTL-FCCP-2-2510C254 Report Version: R00 Page 5 of 61 Table of Contents Page 11 . MEASUREMENT INSTRUMENTS LIST 27 APPENDIX A - AC POWER LINE CONDUCTED EMISSIONS 35 APPENDIX B - RADIATED EMISSION - 9 KHZ TO 30 MHZ 38 APPENDIX C - RADIATED EMISSION - 30 MHZ TO 1000 MHZ 43 APPENDIX D - RADIATED EMISSION - ABOVE 1000 MHZ 46 APPENDIX E - BANDWIDTH 54 APPENDIX F - MAXIMUM OUTPUT POWER 56 APPENDIX G - CONDUCTED SPURIOUS EMISSION 58 APPENDIX H - POWER SPECTRAL DENSITY 60 Report No.:BTL-FCCP-2-2510C254 Report Version: R00 Page 6 of 61 REVISION HISTORY Report No. Version Description Issued Date Note BTL-FCCP-2-2510C254 R00 Original Report. Dec. 2…

Text truncated - open the document above for the full version.

Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 1 of 13 TEST REPORT Reference No. .................... : WTX25X05125353W Applicant ........................... : Xiamen Hanin Co.,Ltd. Address ............................. : Room 305A, Angye Building, Pioneer Park, Torch High-tech Zone, Xiamen city, Fujian Province, P.R. China Manufacturer ..................... : The same as Applicant Address ............................. : The same as Applicant Product Name ................... : BT Antenna Model No... ......................... : HCP-2TS25F Standards .......................... : ANSI/ IEEE 149-2021 Date of Receipt sample .... : 2025-05-16 Date of Test........................ : 2025-05-16 to 2025-06-05 Date of Issue ..................... : 2025-06-05 Test Report Form No. ....... : WTX_IEEE 149 Test Result ......................... : Pass Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of approver. Prepared By: Waltek Testing Group (Shenzhen) Co., Ltd. Address: 1/F., Room 101, Building 1, Hongwei Industrial Park, Liuxian 2nd Road, Block 70 Bao'an District, Shenzhen, Guangdong, China Tel.: +86-755-33663308 Fax.: +86-755-33663309 Email: [email protected] Tested by: Approved by: Dashan Chen/Project Engineer Jason Su Reference No.: WTX25X05125353W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 2 of 13 TABLE OF CONTENTS 1.GENERAL INFORMATION .................................................................................................................................... 4 1.1 PRODUCT DESCRIPTION FOR EQUIPMENT UNDER TEST (EUT) ............................................................................... 4 2. SUMMARY OF TEST RESULTS ........................................................................................................................... 5 3. ANTENNA TEST CONFIGURATIONS ................................................................................................................ 6 3.1 TEST LOCATION ..................................................................................................................................................... 6 3.2 TEST ENVIRONMENTS............................................................................................................................................. 6 3.3 TEST EQUIPMENT LIST ........................................................................................................................................... 6 3.4 MEASUREMENT UNCERTAINTY .............................................................................................................................. 6 3.5 TEST SETUP ............................................................................................................................................................ 6 4. ANTENNA TEST RESULT ..................................................................................................................................... 7 4.1 GAIN AND EFFICIENCY ........................................................................................................................................... 7 4.2 RADIATION PATTERN 2D VIEW ............................................................................................................................... 8 4.3 RADIATION PATTERN 3D VIEW ............................................................................................................................. 10 EXHIBIT 1 - EUT PHOTOGRAPHS ........................................................................................................................ 12 EXHIBIT 2 - TEST SETUP PHOTOGRAPHS ........................................................................................................ 13 Reference No.: WTX25X05125353W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 3 of 13 Report version Version No. Date of issue Description Rev.00 2025-06-05 Original / / / Reference No.: WTX25X05125353W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 4 of 13 1.GENERAL INFORMATION 1.1 Product Description for Equipment Under Test (EUT) General Description of EUT Product Name: BT Antenna Trade Name: / Model No.: HCP-2TS25F Adding Model(s): Z5S, HPRT Z5S Note: The test data is gathered from a production sample, provided by the manufacturer. The appearance of others models listed in the report is different from main-test model HCP-2TS25F, but the circuit and the electronic construction do not change, declared by the manufacturer. Technical Characteristics of EUT Frequency Range: 2400-2500MHz Gain of Antenna: -5.69dBi (Max.) Type of Antenna: PCB Antenna Dimension: Reference No.: WTX25X05125353W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 5 of 13 2. SUMMARY OF TEST RESULTS Standards Description of Test Item Result ANSI/ IEEE 149-2021 IEEE Recommended Practice for Antenna Measurements Compliant N/A: not applicable Reference No.: WTX25X05125353W Waltek Testing Group (Shenzhen) Co., Ltd. Http://www.waltek.com.cn Page 6 of 13 3. Antenna Test Configurations 3.1 Test Location Name: Sushi TOWE Wireless Testing(Shenzhen)Co., Ltd. Address: F 401/101, Building E, Hongwei Industrial Zone, No. 6, Liuxian 3rd Road, Bao'an District, Shenzhen,518133 3.2 Test Environments Environments Parameter Temperature Voltage Humidit NTNV 25 C -- 50% 3.3 Test Equipment List Description Manufacturer Model Serial Number Cal. Date Due. Date Anechoic Chamber ETS AMS8923 Q2225 2023-06-09 2028-06-08 RF Switch ETS EMCenter 251211 / / Vector network analyzer R&S ZNB8 101413 2024-07-17 2025-07-16 3.4 Measurement Uncertainty The uncertainty is calculated using the methods suggested in the“Guide to the Expression of Uncertainty in Measurement" (GUM) published b…

Text truncated - open the document above for the full version.

Report No.:BTL-FCCP-1-2510C254 Report Version: R00 Page 30 of 75 12.1. EUT TEST PHOTO AC Power Line Conducted Emissions Test Photos Report No.:BTL-FCCP-1-2510C254 Report Version: R00 Page 31 of 75 Radiated Emissions Test Photos 9 kHz to 30 MHz Report No.:BTL-FCCP-1-2510C254 Report Version: R00 Page 32 of 75 Radiated Emissions Test Photos 30 MHz to 1000 MHz Report No.:BTL-FCCP-1-2510C254 Report Version: R00 Page 33 of 75 Radiated Emissions Test Photos Band edge & Harmonic(1 GHz to 18 GHz) Report No.:BTL-FCCP-1-2510C254 Report Version: R00 Page 34 of 75 Radiated Emissions Test Photos Harmonic(18 GHz to 26.5 GHz) Report No.:BTL-FCCP-1-2510C254 Report Version: R00 Page 35 of 75 Conducted Test Photos
