2AVD2-MH11906Monster Bluetooth Headphones

MONSTER ISPORT SOLITAIRE LITE Model No.: MH11906 Quick Start Guide Please read this Quick Start Guide carefully and keep it for future use. Product Overview • Headphone • Eartips x 3 Pairs (M size is installed on the headset) • SportClip™ x 3 Pairs (M size is installed on the headset) • Charging Cable • Quick Start Guide & Warranty letter 1. Volume Down Button, Track Forward 2. Multi Function Button (MFB) (Power On/Play/Pause...) 3. Volume Up Button, Track Back 4. Indicator Light 5. USB-C Charging Port 6. MIC Power On/Off In power off mode, press and hold the MFB for about 2 seconds to power on the headphones, the white indicator on for 1 second and you will hear “Power on”. In power on mode, press and hold the MFB for about 5 seconds to power off the headphones, the white indicator on for 1 second and you will hear “Power off”. Pairing In power off mode, press and hold the MFB for about 5 seconds until indicator light flashes white, you hear “Power on”...”Pairing”. Now headphones are in pairing mode. Activate Bluetooth ® on your equipment and set it to search for new devices (new Monster device). When the headphones are paired successfully, “connected” will be heard. Note: When you unbox the headphones and power it on for the first time, it will enter to pairing mode automatically. Music Play/Pause: In the music playback mode, press the MFB to play/pause music. Previous song: In the music playback mode, press and hold the Volume Down Button for 2 seconds for previous song. Next song: In the music playback mode, press and hold the Volume Up Button for 2 seconds for next song. Sound characteristics: Press and hold the volume plus and minus 3 seconds, switch from “Normal” to “Turbo” will have two “di di” beeps, and switch from Turbo to Normal will have “di” beep. Volume Control Short press the Volume Up or Down Button to turn volume up or down, you hear tone once you reach the maximum volume or minimum volume. Call Answer/End Call: short press the MFB. Reject Call: long press the MFB about 2 seconds. Voice Control After connecting to the phone, quickly double press the MFB to activate the voice assistant. LED Guide to Indicator Lights Mode Description Voice prompts Power On White LED indicator lights for about 1 second “Power On” Power Off White LED indicator lights for about 1 second “Power Off” Pairing White LED flashes quickly “Pairing” Connected No function operation, the indicator light is off “connected” Charging The white LED indicator lights up when charging, and turns off when fully charged - Note: * Please put the earphones in the correct position to charge. * It is not recommended to replace the battery privately. * The battery (battery pack or combination battery) must not be exposed to excessive heat such as sunlight or fire. FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. • This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction.

DATE:2020.11.05 EquipmentAutorisationDivision FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 FCCID:2AVD2-MH11906 ProductName:MonsterBluetoothHeadphones RequestforConfidentiality PursuanttoSections0.457and0.459ofthecommissionsrules,weherebyrequestthat thefollowingdocumentsbeheldconfidential: (Listherethedocumentsforwhichyouareseekingconfidentiality–forexample...) Schematics Blockdiagram  Operationdescription Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoourcompetitors. <Signature> Name:QingyunHe Title:R&DManager Company:ShenzhenMonsterCreativeTechnologyCo.,Ltd.

External Photos M/N: MH11906 External Photos M/N: MH11906 External Photos M/N: MH11906

Earphone Design Roadmap 2020 深圳市魔声创新技术有限公司 产品型号版本日期 制图审核批准滕斌斌 单位尺寸 备注 A0 mm 202009-29 L下盖R下盖 Made in China Model No.: MH11906 FCC ID: 2AVD2-MH11906 Input: DC 5V 500mA CMIIT ID:XXXXXXXXXXX

Internal Photos M/N: MH11906 Internal Photos M/N: MH11906 Internal Photos M/N: MH11906

FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011009 Page 1 of 3 FCC RF EXPOSURE REPORT Shenzhen Monster Creative Technology Co., Ltd. Monster Bluetooth Headphones Model Number: MH11906 FCC ID: 2AVD2-MH11906 Prepared for: Shenzhen Monster Creative Technology Co., Ltd. Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2011009 Date of Test: Sep. 29~Oct. 30, 2020 Date of Report: Nov. 05, 2020 FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011009 Page 2 of 3 1. Applicable Standards FCC Part 2(Section 2.1093) FCC KD B447498 D01 General RF Exposure Guidance v06 2. Exposure Evaluation of Portable or Mobile Devices Human exposure to RF emissions from portable devices (47 CFR §2.1093), as defined by the FCC, must be evaluated with respect to the FCC-adopted limits for SAR. Evaluation of mobile devices, as defined by the FCC, may also be performed with respect to SAR limits, but in such cases it is usually simpler and more cost-effective to evaluate compliance with respect to field strength or power density limits. For certain devices that are designed to be used in both mobile and portable configurations similar to those described in 47 CFR §2.1091(d)(4), such as certain desktop phones and wireless modem modules, compliance for mobile configurations is also satisfied when the same device is evaluated for SAR compliance in portable configurations. SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR where • f(GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011009 Page 3 of 3 3. Evaluation Results Mode Frequency (MHz) Peak output Power (dBm) Peak output Power (mW) Target power (dBm) Results GFSK 2402 -3.25 0.473 -3±1 0.196 2441 -4.85 0.327 -4±1 0.157 2480 -6.14 0.243 -6±1 0.100 8-DPSK 2402 -0.23 0.948 0±1 0.390 2441 -1.87 0.650 -1±1 0.312 2480 -3.26 0.472 -3±1 0.199 BLE 2402 -2.25 0.596 -2±1 0.246 2440 -3.52 0.445 -3±1 0.197 2480 -4.66 0.342 -4±1 0.158 Note: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required. End of Test Report

FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011008 Page 1 of 56 FCC PART 15C TEST REPORT FOR CERTIFICATION On Behalf of Shenzhen Monster Creative Technology Co., Ltd. Monster Bluetooth Headphones Model Number: MH11906 FCC ID: 2AVD2-MH11906 Prepared for: Shenzhen Monster Creative Technology Co., Ltd. Flat G, 3/F, Building D, The Central Avenue, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2011008 Date of Test: Sep. 29~Oct. 30, 2020 Date of Report: Nov. 05, 2020 FCC ID: 2AVD2-MH11906 EST Technology Co., Ltd Report No. ESTE-R2011008 Page 2 of 56 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION......................................................................................................................... 3 1. GENERAL INFORMATION ................................................................................................................. 5 1.1. Description of Device (EUT) ........................................................................................................... 5 1.2. Antenna Information ........................................................................................................................ 5 2. SUMMARY OF TEST ......................................................................................................................... 6 2.1. Summary of test result ...................................................................................................................... 6 2.2. Test Facilities ................................................................................................................................... 7 2.3. Measurement uncertainty ................................................................................................................. 8 2.4. Assistant equipment used for test ..................................................................................................... 8 2.5. Block Diagram ................................................................................................................................. 8 2.6. Test Mode ......................................................................................................................................... 9 2.7. Power Setting of Test Software ........................................................................................................ 9 2.8. Duty Cycle ...................................................................................................................................... 10 2.9. Channel List ................................................................................................................................... 11 2.10. Test Equipment List ....................................................................................................................... 12 3. 6DB BANDWIDTH .......................................................................................................................... 13 3.1. Limit ............................................................................................................................................... 13 3.2. Test Setup ....................................................................................................................................... 13 3.3. Spectrum Analyzer Setting ............................................................................................................. 13 3.4. Test Procedure ................................................................................................................................ 13 3.5. Test Result ...................................................................................................................................... 14 4. MAXIMUM PEAK OUTPUT POWER ................................................................................................. 16 4.1. Limit ............................................................................................................................................... 16 4.2. Test Setup ....................................................................................................................................... 16 4.3. Spectrum Analyzer Setting ............................................................................................................. 16 4.4. Test Procedure ................................................................................................................................ 16 4.5. Test Result ...................................................................................................................................... 17 5. POWER SPECTRAL DENSITY .......................................................................................................... 19 5.1. Limit ............................................................................................................................................... 19 5.2. Test Setup ....................................................................................................................................... 19 5.3. Spectrum Analyzer Setting ............................................................................................................. 19 5.4. Test Procedure ................................................................................................................................ 19 5.5. Test Result ...................................................................................................................................... 20 6. CONDUCTED BAND EDGE ............................................................................................................. 22 6.1. Limit ............................................................................................................................................... 22 6.2. Test Setup …

Text truncated - open the document above for the full version.

Conducted Test Radiated Test (Below 1GHz) Radiated Test (Above 1GHz)
